MODA MINI GRAZE®INT COLOR 0-10V
INSTALLATION
955 White Drive Las Vegas, NV 89119 | T: 702 407 7775
F: 702 407 7773 | www.modalight.com | © 2019
1 / 9
Due to continuous improvements and innovations, specifications may change without notice.
Please refer to our website for current technical data. These figures are provided as a guideline
only and may vary with differing power supplies and installations. All rights reserved. E&OE.
VDC 01/2/2019
Max Continuous Run: See section 13
Continuidad Máxima: Vea sección 13
Run continue Max: Voir la section 13
!
Verify electrical plan and ensure all hardware is present
Verificar plan electrico y verifique que todo el equipo esté presente
Vérifier le plan électrique et assurer que tout le matériel est présent
2
1
DRY/DAMP LOCATION INSTALL
INSTALACIÓN DE LUGARES SECOS/HÚMEDOS
INSTALLATION EMPLACEMENT SEC/HUMIDE
Must be installed by a qualified electrician in accordance with all national and local electrical and construction codes and
regulations by a person familiar with the construction and operation of the product and the hazards involved. Failure to comply
with the following installation instructions will void the warranty and may result in serious injury or possible death. Ensure power
is off before installation, verify electrical plan first and read all installation instructions prior to installation.
Debe ser instalado por un electricista calificado de acuerdo con todos los códigos y reglamentos eléctricos y de construcción nacionales y locales, por una
persona familiarizada con la construcción y el funcionamiento del producto y los riesgos involucrados. El incumplimiento de las siguientes instrucciones de
instalación anulará la garantía y puede provocar lesiones graves o la muerte. Asegúrese de que la energía esté apagada antes de la instalación, verifique
primero el plan eléctrico y lea todas las instrucciones de instalación antes de instalar.
Doit être installé par un électricien qualifié conformément à tous les codes et réglementations électriques et de construction nationaux et locaux par une
personne connaissant bien la construction et le fonctionnement du produit et les risques encourus. Le non-respect des instructions d’installation suivantes
annulera la garantie et pourrait entraîner des blessures graves ou la mort éventuelle. Assurez-vous que l’alimentation est coupée avant l’installation, vérifiez
d’abord le plan électrique et lisez toutes les instructions d’installation avant l’installation.
Dimmer
(Optional) Leader Cable Jumper
Cable
Fixture to
Fixture
Connection
Terminator
100-277V AC
Mounting Bracket can be moved to the left or right of the fixture
El soporte se puede mover hacia la izquierda o hacia la derecha del accesorio
Le support de montage peut être déplacé vers la gauche ou la droite de l’appareil
!
Overall fixture length
with connectors:
1ft - 1’ 13/32” (315.26mm)
4ft - 4’ 7/16” (1.23m)
2 11/16” (68.25mm)
7/32” (5.25mm)
3 5/32” (80mm)
1 1/2” (38 MM)
Mounting Bracket
(Bottom View)
1/8”
(3.5mm)
1 7/32”
(31mm) 1 1/2” (38mm)

MODA MINI GRAZE®INT COLOR 0-10V
INSTALLATION
955 White Drive Las Vegas, NV 89119 | T: 702 407 7775
F: 702 407 7773 | www.modalight.com | © 2019
2 / 9
Due to continuous improvements and innovations, specifications may change without notice.
Please refer to our website for current technical data. These figures are provided as a guideline
only and may vary with differing power supplies and installations. All rights reserved. E&OE.
VDC 01/2/2019
4
5For a straight run of fixtures, use Moda Mini Graze Mounting Track
Para un tramo recto de los accesorios , utilice la canal de montaje Moda Mini Graze
Pour une course rectiligne de luminaires , utiliser Moda Mini Graze piste de montage
3Mount to surface using the 4 screw holes on the bracket
Monte a superficie utilizando los 4 agujeros para tornillos en el soporte
Mont à la surface en utilisant les 4 trous de vis sur le support
Push down on bracket to rotate to desired angle, then release
Empuje hacia debajo sobre el soporte para rotar al ángulo deseado, y luego suelte
Appuyez sur le support pour le faire pivoter à l’angle souhaité, puis relâchez-le
Bracket is self locking, do not rotate like a conventional bracket. Place on a flat surface and push down
on bracket to release locking mechanism then release once desired position has been reached.
El soporte se autobloquea, no rote como un soporte convencional. Coloque en superficie plana y empuje hacia debajo sobre el soporte para
liberar el mechanismo de bloqueo, luego suelte cuando aya alcanzado la posición deseada.
Support est auto-bloquante , ne tournent pas comme un support classique. Placer sur une surface plane et pousser vers le bas sur le support
pour libérer le mécanisme de verrouillage puis relâcher une fois la position désirée est atteinte.
!
170º Rotation

MODA MINI GRAZE®INT COLOR 0-10V
INSTALLATION
955 White Drive Las Vegas, NV 89119 | T: 702 407 7775
F: 702 407 7773 | www.modalight.com | © 2019
3 / 9
Due to continuous improvements and innovations, specifications may change without notice.
Please refer to our website for current technical data. These figures are provided as a guideline
only and may vary with differing power supplies and installations. All rights reserved. E&OE.
VDC 01/2/2019
6
7
8Wiring
Cablería
Cables
100-
277v AC
0-10V DIMMER
100-
277v AC
5 PIN
LEADER
CABLE
0-10V DIMMER
100-
277v AC
UL/cUL
CE/CCC
UL / cUL
100-277V AC Leader Cable
0-10V Dimmer
Screw Moda Mini Graze into the mounting track
Atornille Moda Mini Graze al canal de montaje
Vissez Moda Mini Graze dans la voie de montage
Snap Moda Mini Graze into mounting track then slide to connect fixtures
Encaje Moda Mini Graze en el canal de montaje y luego deslice para conectar accesorios
Accrochez Moda Mini Graze dans la piste puis faites glisser pour connecter les appareils
!
Ceiling mounted
Instalación en techos
Plafond monté
Use appropriate mounting screws suitable for each surface
Use tornillos de montaje adecuados para cada superficie
Utilisez des vis de montage appropriées pour chaque surface
High torque may damage bracket
Alto torsión puede dañar el soporte
Un couple élevé peut endommager le support
!
Minimum end to end spacing is 5/16” (3.66mm)
Espacio minimo de extremo a extremo es 5/16” (3.66mm)
L’espacement minimal entre les extrémités est 5/16” (3.66mm)
UL/cUL CE/CCC*
Live 100-277V Black Brown
Neutral White Blue
Ground Green Green/Yellow
0-10V / Data + Purple Black
0-10V / Data - Grey Grey
*Not illustrated

MODA MINI GRAZE®INT COLOR 0-10V
INSTALLATION
955 White Drive Las Vegas, NV 89119 | T: 702 407 7775
F: 702 407 7773 | www.modalight.com | © 2019
4 / 9
Due to continuous improvements and innovations, specifications may change without notice.
Please refer to our website for current technical data. These figures are provided as a guideline
only and may vary with differing power supplies and installations. All rights reserved. E&OE.
VDC 01/2/2019
9
10
Connect leader cable and connect terminator
Connectar el cable leader y conectar Terminador
Branchez le câble leader et connectez Terminateur
CLICK!
Connect
Terminator
To release,
press down
on thumb
latch and
pull.
Terminator MUST be placed on final fixture!
Terminator DEBE ser colocado en el accesorio final!
Terminator DOIT être placé sur l’appareil final!
Do NOT mix SO with HO fixtures
NO combine accesorios SO con HO
Ne pas mélanger SO avec les luminaires HO
!
!
Ensure a positive click to avoid arcing
Asegúrese un clic positivo para evitar arco eléctrico
Assurez un clic positif pour éviter de cambrer
!
CLICK!
Connection types
Tipos de connexiones
Types de connexion
Sizes can be mixed, Do Not Exceed Max Run Lengths (see section 13)
Se pueden combinar tamaños, No Exeder Longitud Maxima (vea sección 13)
Vous pouvez combiner tailles, Dépasser Aucune Longueur Maximale (voir la section 13)
Jumper Cable
Terminator
Jumper Cable
Leader Cable
!
Fixture to Fixture
CLICK!
Maximum bend radius of
fixture to fixture connection is
45°

MODA MINI GRAZE®INT COLOR 0-10V
INSTALLATION
955 White Drive Las Vegas, NV 89119 | T: 702 407 7775
F: 702 407 7773 | www.modalight.com | © 2019
5 / 9
Due to continuous improvements and innovations, specifications may change without notice.
Please refer to our website for current technical data. These figures are provided as a guideline
only and may vary with differing power supplies and installations. All rights reserved. E&OE.
VDC 01/2/2019
11
13 Maximum lengths
Longitudes máximas
Longueurs maximales
PRODUCT 120V AC 240V AC 277V AC
Moda Mini Graze Int Color 0-10V SO 1ft 120ft 240ft 240ft
Moda Mini Graze Int Color 0-10V SO 4ft 120ft 240ft 240ft
Moda Mini Graze Int Color 0-10V HO 1ft 50ft 100ft 100ft
Moda Mini Graze Int Color 0-10V HO 4ft 50ft 100ft 100ft
Maximum run is dependent upon the dimmer / dimming system used. Each connection uses 1mA.
A dimmer rated at 50mA will allow 50 connections.
La longitud máxima depende del sistema de atenuación / atenuación utilizado. Cada conexión usa 1mA. Un
atenuador con una clasificación de 50 mA permitirá 50 conexiones.
Le longueurs maximum dépend du système gradateur / gradateur utilisé. Chaque connexion utilise 1mA. Un
gradateur évalué à 50 mA permettra 50 connexions.
!
Power on!
Encender!
Allumer!
12
Setback chart
Gráfica de retroceso
Chart Abaissement
!
1 feet
10 Feet Wall
Recommended setback from the wall is 1/10 of the wall height
Retroceso de la pared recomendada es 1/10 de la altura del muro
Revers recommandée de la paroi est de 1/10 de la hauteur du mur

MODA MINI GRAZE®INT COLOR 0-10V
INSTALLATION
955 White Drive Las Vegas, NV 89119 | T: 702 407 7775
F: 702 407 7773 | www.modalight.com | © 2019
6 / 9
Due to continuous improvements and innovations, specifications may change without notice.
Please refer to our website for current technical data. These figures are provided as a guideline
only and may vary with differing power supplies and installations. All rights reserved. E&OE.
VDC 01/2/2019
14
INPUT VOLTAGE: 120V AC, 60Hz
OUTPUT VOLTAGE: 41.5V (at non-dimming)
OUTPUT CURRENT: 95mA (at non-dimming)
Dimmer
Model Position
Output
Voltage
(V)
Output
Current
(mA)
LED
Power
(W)
Current
Ratio
(%)
LED Power
Ratio
(%)
Mini
Load
Request Flicker
None 42.18 96.00 4.05
Compatible dimmers
Atenuadores de luz compatibles
Gradateurs compatibles
INPUT VOLTAGE: 120V AC, 60Hz
OUTPUT VOLTAGE: 41.5V (at non-dimming)
OUTPUT CURRENT: 95mA (at non-dimming)
Dimmer
Model Position
Output
Voltage
(V)
Output
Current
(mA)
LED
Power
(W)
Current
Ratio
(%)
LED Power
Ratio
(%)
Mini
Load Request Flicker
Grafik Eye QS
with Grafik Eye
GRX-TVI
10V 41.02 95.00 3.90 98.95% 96.24% No No
5V 38.90 42.25 1.64 44.00% 40.59% No No
0V 35.39 0.74 0.03 0.77% 0.65% No No
Legrand
CD4FBLW
10V 40.05 94.25 3.77 98.18% 93.22% No No
5V 38.87 41.75 1.57 43.49% 38.83% No No
0V 34.93 0.49 0.02 0.51% 0.42% No No
Legrand
LMRC-111
10V 41.00 94.50 3.87 98.44% 95.68% No No
5V 38.87 41.50 1.61 43.23% 39.84% No No
0V 35.26 0.49 0.02 0.51% 0.43% No No
Leviton
IP710-DL
10V 40.70 92.25 3.75 96.09% 92.72 No No
5V 38.77 42.00 1.63 43.75% 40.21% No No
0V 35.37 0.72 0.03 0.75% 0.63% No No
Lutron
Skylark
SLV-600P
10V 41.04 94.75 3.89 98.70% 96.03% No No
5V 38.88 41.75 1.62 43.49% 40.09% No No
0V 35.36 0.72 0.03 0.75% 0.63% No No

MODA MINI GRAZE®INT COLOR 0-10V
INSTALLATION
955 White Drive Las Vegas, NV 89119 | T: 702 407 7775
F: 702 407 7773 | www.modalight.com | © 2019
7 / 9
Due to continuous improvements and innovations, specifications may change without notice.
Please refer to our website for current technical data. These figures are provided as a guideline
only and may vary with differing power supplies and installations. All rights reserved. E&OE.
VDC 01/2/2019
FIXTURE SKU
0-10V
SO
1FT
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Red 1FT 30X100 136-1000
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Green 1FT 30X100 136-1001
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Blue 1FT 30X100 136-1002
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Amber 1FT 30X100 136-1003
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Yellow 1FT 30X100 136-1004
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Golden Yellow 1FT 30X100 136-1005
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Ice Blue 1FT 30X100 136-1006
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Cyan 1FT 30X100 136-1007
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Light Green 1FT 30X100 136-1008
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Pink 1FT 30X100 136-1009
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Violet 1FT 30X100 136-1010
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Turquoise 1FT 30X100 136-1011
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Dark Blue 1FT 30X100 136-1012
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Dark Orange 1FT 30X100 136-1013
0-10V
HO
1FT
Moda Mini Graze Interior High Output Silver 0-10V Dimming Red 1FT 30X100 136-1200
Moda Mini Graze Interior High Output Silver 0-10V Dimming Green 1FT 30X100 136-1201
Moda Mini Graze Interior High Output Silver 0-10V Dimming Blue 1FT 30X100 136-1202
Moda Mini Graze Interior High Output Silver 0-10V Dimming Amber 1FT 30X100 136-1203
Moda Mini Graze Interior High Output Silver 0-10V Dimming Yellow 1FT 30X100 136-1204
Moda Mini Graze Interior High Output Silver 0-10V Dimming Golden Yellow 1FT 30X100 136-1205
Moda Mini Graze Interior High Output Silver 0-10V Dimming Ice Blue 1FT 30X100 136-1206
Moda Mini Graze Interior High Output Silver 0-10V Dimming Cyan 1FT 30X100 136-1207
Moda Mini Graze Interior High Output Silver 0-10V Dimming Light Green 1FT 30X100 136-1208
Moda Mini Graze Interior High Output Silver 0-10V Dimming Pink 1FT 30X100 136-1209
Moda Mini Graze Interior High Output Silver 0-10V Dimming Violet 1FT 30X100 136-1210
Moda Mini Graze Interior High Output Silver 0-10V Dimming Turquoise 1FT 30X100 136-1211
Moda Mini Graze Interior High Output Silver 0-10V Dimming Dark Blue 1FT 30X100 136-1212
Moda Mini Graze Interior High Output Silver 0-10V Dimming Dark Orange 1FT 30X100 136-1213
0-10V
SO
4FT
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Red 4FT 30X100 136-3000
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Green 4FT 30X100 136-3001
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Blue 4FT 30X100 136-3002
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Amber 4FT 30X100 136-3003
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Yellow 4FT 30X100 136-3004
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Golden Yellow 4FT 30X100 136-3005
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Ice Blue 4FT 30X100 136-3006
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Cyan 4FT 30X100 136-3007
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Light Green 4FT 30X100 136-3008
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Pink 4FT 30X100 136-3009
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Violet 4FT 30X100 136-3010
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Turquoise 4FT 30X100 136-3011
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Dark Blue 4FT 30X100 136-3012
Moda Mini Graze Interior Standard Output Silver 0-10V Dimming Dark Orange 4FT 30X100 136-3013

MODA MINI GRAZE®INT COLOR 0-10V
INSTALLATION
955 White Drive Las Vegas, NV 89119 | T: 702 407 7775
F: 702 407 7773 | www.modalight.com | © 2019
8 / 9
Due to continuous improvements and innovations, specifications may change without notice.
Please refer to our website for current technical data. These figures are provided as a guideline
only and may vary with differing power supplies and installations. All rights reserved. E&OE.
VDC 01/2/2019
FIXTURE SKU
0-10V
HO
4FT
Moda Mini Graze Interior High Output Silver 0-10V Dimming Red 4FT 30X100 136-3200
Moda Mini Graze Interior High Output Silver 0-10V Dimming Green 4FT 30X100 136-3201
Moda Mini Graze Interior High Output Silver 0-10V Dimming Blue 4FT 30X100 136-3202
Moda Mini Graze Interior High Output Silver 0-10V Dimming Amber 4FT 30X100 136-3203
Moda Mini Graze Interior High Output Silver 0-10V Dimming Yellow 4FT 30X100 136-3204
Moda Mini Graze Interior High Output Silver 0-10V Dimming Golden Yellow 4FT 30X100 136-3205
Moda Mini Graze Interior High Output Silver 0-10V Dimming Ice Blue 4FT 30X100 136-3206
Moda Mini Graze Interior High Output Silver 0-10V Dimming Cyan 4FT 30X100 136-3207
Moda Mini Graze Interior High Output Silver 0-10V Dimming Light Green 4FT 30X100 136-3208
Moda Mini Graze Interior High Output Silver 0-10V Dimming Pink 4FT 30X100 136-3209
Moda Mini Graze Interior High Output Silver 0-10V Dimming Violet 4FT 30X100 136-3210
Moda Mini Graze Interior High Output Silver 0-10V Dimming Turquoise 4FT 30X100 136-3211
Moda Mini Graze Interior High Output Silver 0-10V Dimming Dark Blue 4FT 30X100 136-3212
Moda Mini Graze Interior High Output Silver 0-10V Dimming Dark Orange 4FT 30X100 136-3213
ACCESSORIES DESCRIPTION SKU
Leader Cable US 5 Pin 10ft Power to first fixture of run 299-0100
Leader Cable US 5 Pin 25ft Power to first fixture of run 299-0102
Jumper Cable US 5 Pin 1ft Connection between fixtures 299-1100
Jumper Cable US 5 Pin 4ft Connection between fixtures 299-1102
Leader Cable EU 5 Pin 3m Power to first fixture of run 299-0101
Leader Cable EU 5 Pin 7.62m Power to first fixture of run 299-0103
Jumper Cable EU 5 Pin 300mm Connection between fixtures 299-1101
Jumper Cable EU 5 Pin 1m Connection between fixtures 299-1103
Terminator 5 Pin Must be fixed to last fixture for safety 299-2100
Mounting Track Allows user to install fixtures in a continuous linear position.
Packaged in 5 4ft sections in total of 20ft. 299-3200

MODA MINI GRAZE®INT COLOR 0-10V
INSTALLATION
955 White Drive Las Vegas, NV 89119 | T: 702 407 7775
F: 702 407 7773 | www.modalight.com | © 2019
9 / 9
Due to continuous improvements and innovations, specifications may change without notice.
Please refer to our website for current technical data. These figures are provided as a guideline
only and may vary with differing power supplies and installations. All rights reserved. E&OE.
VDC 01/2/2019
!Do not attempt to install or use the product
until installation is fully read and understood!
¡No intente instalar o utilizar el producto sin antes leer y comprender las
instrucciones!
Ne tentez pas d’installer ou d’utiliser le produit jusqu’à ce que l’installa-
tion est entièrement lu et compris!
!Do not use the product if lens or power
cables are damaged!
¡No utilize el producto si el lente o cables de energía están defectuosos!
Ne pas utiliser le produit si l’objectif ou les câbles d’alimentation sont
endommagés!
!Do not use currents or voltages of any kind
that do not fit under the product’s requirements!
¡Por favor no utilice corrientes o voltajes que no sean los que se especifi-
can para los productos!
S’il vous plaît ne pas utiliser des courants ou des tensions autres que
celles spécifiées pour la lampe!
!Not compatible with voltage step down
devices/voltage converters/buck converter.
No es compatible con dispositivos de reducción de voltaje /
convertidores de voltaje / convertidor de buck.
Non compatible avec les dispositifs abaisseurs de tension / convertisseurs
de tension / convertisseur abaisseur.
!Make sure that power or cable is completely
off or disconnected before connecting or
disconnecting the product!
¡Por favor asegurese que el suministro de electricidad este apagado y ca-
bles estén desconectados antes de conectar o desconectar los productos!
Faire S’il vous plaît assurer que l’alimentation et les câbles d’électricité
sont hors tension et débranché avant de brancher ou de débrancher
lampes!
!Must be wired on its own dedicated lighting
circuit. Do not share the same lighting circuit
with motors, fans or computers as this may cause
flickering of the fixture.
Debe conectarse en su propio circuito de iluminación dedicada. No
comparta en el mismo circuito de iluminación con motores, ventiladores
o computadoras ya que puede causar parpadeo en el equipo.
Doit être câblé sur son propre circuit d’éclairage dédié. Ne partagent
pas le même circuit d’éclairage avec moteurs, des ventilateurs ou des
ordinateurs, car cela risquerait de scintillement de l’appareil.
!Data and Power must be run in separate
conduit!
De datos y de alimentación se deben ejecutar en un conducto separado!
Les données et la puissance doivent être exécutées dans un conduit séparé!
!Only use compatible dimmers.
Solo utilizar atenuadores de luz compatibles.
Utilisez uniquement des gradateurs compatibles.
!Never put power and data in the same
conduit or raceway!
¡Nunca se pudo alimentar ni datos en los mismos cables o conductos!
Ne mettez jamais la puissance et les données dans le même conduit ou
caniveau!
!Max total run using 18 gauge wire is 300ft
for 0-10V cables.
¡La continuidad máxima con un cable de calibre 18 es de 300 pies para
los cables de 0-10V!
La course totale maximum utilisant le fil de calibre 18 est 300ft pour les
câbles 0-10V.
!Do not mix SO fixtures with HO fixtures.
No mezcle los accesorios SO con los accesorios HO.
Ne pas mélanger les appareils SO avec les appareils HO.
!If a fixture is not working, please remove from
service.
Si un accesorio no está funcionando, por favor poner fuera de servicio.
Si un appareil ne fonctionne pas, s’il vous plaît retirer du service.
!Do not coat the product in paint! This will ruin
the product and void warranty!
No cubra el producto en pintura! Esto va a arruinar el producto y anular la
garantía!
Ne pas enduire le produit dans la peinture! Cela va ruiner le produit et
annuler la garantie!
!Please make sure to install in accordance with
the local code!
Por favor asegúrese de instalar de acuerdo con el código local!
Faire S’il vous plaît veillez à installer en conformité avec le code local!
!No serviceable parts - Do not disassemble.
No hay piezas reparables - No desamblar.
Aucune pièce - Ne pas démonter.
!Do not hot swap fixtures!
No remplaze el producto mientras estén calientes!
Feds ne cherchez pas produit tout chaud!
!Do not open fixtures as they are line voltage
and could cause a shock.
No intente abrir el producto ya que contienen lineas de voltaje y podría
causar un corto circuito.
Ne pas essayer d’ouvrir le produit car ils contiennent des lignes de tension
pordría et provoquer un court-circuit.
!Must use terminator.
Se tiene que utilizar terminadores.
Doit utiliser terminateur.
!Do not stare into beam.
No mire fijamente la luz.
Ne pas regarder le faisceau.
!Do not connect line voltage to data.
No conecte el voltaje de línea a los datos.
Ne pas connecter la tension de ligne aux données.
