Mode Machines MAP-01 User manual

MAP-01 USER MANUAL
GENERAL SETTINGS
1. ENCODER
The encoder underneath the display is used to scroll through the menu. By turning left or right
you can change the settings. After powering on the unit, you are automatically in the selection
mode. Here you can now scroll through the menu and search for the desired parameters. First,
the Version Number will occur for x seconds and nally the Mode Machines Logo. After that
you have to turn the encoder to enable all functions.
2. CHANGING THE PARAMETERS
By pressing the encoder you will reach the next level and by turning the encoder you will be
able to edit the selected parameter. By pressing the encoder again you can jump back to the
highter menu level. The right switch activates the arpeggio to ON and OFF. Please refer to
explanation in thr setting MIDI OUTPUT.
The switch in the middle allowes a quick change of the BPM setting. Press it and the BPM value
will pop up which you can change by turning the encoder. By pressing thr knob again will
show the previous display setting again.The knob on the left has various functions depending
on the settings in parameters SPECIAL. Please refer to the explanation of this parameter later.
ARPEGGIATOR STYLES
3. ARPEGGIATOR STYLES
There are three basic arpeggiator styles on boars ( also RANDOM, but this can be found at a
later stage with separate explanation!)
3.1 ARPEGGIO STYLE (UPWARD)
- the arpeggio is played upwards
3.2 ARPEGGIO STYLE (DOWNWARD)
- the arpeggio is played downwards

MAP-01 USER MANUAL
3.3 ARPEGGIO STYLE (UPWARD/ DOWNWARD)
- the arpeggio is rst played upwards and then downwards
3.4 ARPEGGIO STYLE (DOWNWARD / UPWARD)
- the arpeggio is rst played downwards and then upwards
3.5 ARPEGGIO STYLE (Sequencer)
- the arpeggio is playing the notes continiousely until the run button will pushed off
ASSORTMENT
4. ASSORTMENT
Also there are variations possible:
4.1 ASSORTMENT (ON)
- the played notes are are repeated within a certain value and sorted
4.2 ASSORTMENT (OFF)
- the played notes are repeated as played

MAP-01 USER MANUAL
OCTAVE
5. OCTAVE
The generated arpeggio will be transposed into various ictave regions after the rst run
5.1 OCTAVE (OFF)
- no octave transposing
Example: c – e – g
5.2 OCTAVE (OCTAVE +1 FWD)
- transposed up by one octave
Example: c – e – g / c1 – e1 – g1
5.3 OCTAVE (OCTAVE +2 FWD)
- transposed rst by one octave, then by two octaves higher
Example: c – e – g / c1 – e1 – g1 / c2 – e2 – g2
5.4 OCTAVE (OCTAVE +3 FWD)
- transposed rst by one octave, thrn by two and thrn three octaves higher
Example: c – e – g / c1 – e1 – g1 / c2 – e2 – g2 / c3 – e3 – g3
5.5 OCTAVE (OCTAVE +3 BWD)
- transposed rst by one octave, thrn by two and thrn three octaves higher
Example: c – e – g / c3 – e3 – g3 / c2 – e2 – g2 / c1 – e1 – g1
5.6 OCTAVE (OCTAVE +2 BWD)
- transposed rst by one octave, thrn by two and thrn three octaves higher
Example: c – e – g / c2 – e2 – g2 / c1 – e1 – g1

MAP-01 USER MANUAL
5.7 OCTAVE (OCTAVE -1 BWD)
- transposed down by one octave
Example: c – e – g / c-1 – e-1 – g-1
5.8 OCTAVE (OCTAVE -2 BWD)
- transposed down rst by one octave, then by two octaves
Example: c – e – g / c-1 – e-1 – g-1 / c-2 – e-2 – g-2 /
5.9 OCTAVE (OCTAVE -3 BWD)
- transposed down rst by one octavr, then two, them three octaves
Example: c – e – g / c-1 – e-1 – g-1 / c-2 – e-2 – g-2 / c-3 – e-3 – g-3
5.10 OCTAVE (OCTAVE -2 FWD)
- transposed up by two octaves and then by one octave
Example: c – e – g / c-2 – e-2 – g-2 / c-1 – e-1 – g-1
5.11 OCTAVE (OCTAVE -3 FWD)
- transposed up by three octaves, then by two, then by one octave
Example: c – e – g / c-3 – e-3 – g-3 / c-2 – e-2 – g-2 / c-1 – e-1 – g-1
RANDOM
- ON / OFF

MAP-01 USER MANUAL
ARPEGGIO SIDE/ SPLIT POINT
8. ARPEGGIO SIDE
- selects the side of the keyboard which is occupied with the arpeggio. This setting refers to the
selected split point.
8.1 ARPEGGIO SIDE (BOTH)
- there is no seperation and all notes are used for thr arpeggio
8.2 ARPEGGIO SIDE (LOWER)
- the notes of the lefthand side of the keyboard are used for the arpeggio. The notes on the
righthand side stay ignored.
8.3 ARPEGGIO SIDE (RIGHT)
- the notes on the righthand side of the keyboard are used for the arpeggio. The notes on thr
lefthand side stay ignored.
9. SPLIT POINT
9.1 SPLIT POINT (NONE - e.g. C4)
Selection of the split point for the arpeggio. The value can be selected through the encoder or
directly via MIDI. You can move the pitch wheel to each direction and then play a note on the
keyboard to set the note value to NONE.
RUN NOTE/ STOP NOTE/ VELOCITY
10. RUN NOTE
10.1 RUN NOTE (NONE -e.g. C4)
- selection of the run note of the arpeggio. Same as switching on the RUN MODE. The value can
be set via the encoder or directly via MIDI. By moving the pitchwheel and pressing a note on
the keyboard the note value is set to NONE.

MAP-01 USER MANUAL
11. STOP NOTE
11.1 STOP NOTE (NONE -e.g. C4)
- setting the stop note for thr arpeggio. Same as switching offthe RUN MODE.
The value can be selected via the encoder or via MIDI directly by moving the pitchwheel and
pressing a note on your keyboard to set a note value NONE.
12. VELOCITY
12.1 VELOCITY (DYNAMIC)
- here you can decide between dynamic and static velocity. Dynamic means that all notes are
played with the actual pressed velocity.
12.2 VELOCITY (FIX)
- by setting this to FIX, all notes are played only in the velocity which was selected in the
velocity value, not depending on the played value.
VELOCITY VALUE/ LEGATO/ SUSTAIN
13. VELOCITY VALUE
13.1 VELOCITY VALUE (0-127)
- here you can select the velocity value. NOTE: by changing this value, the menu parameter
VELOCITY will automatically changed to FIX!
14. LEGATO
14.1 LEGATO (ON)
- the notes will be stopped just before the next notes are started
14.2 LEGATO (OFF)
- the legato function is deactivated

MAP-01 USER MANUAL
15. SUSTAIN
15.1 SUSTAIN (ON)
- the sustain command is actived and therefore permanently used on the arpeggio. This is
recommended only for certain sounds. Sounds using sustain are not suitable for this function,
for example organ sounds, as all notes stay on permanently.
15.2 SUSTAIN (OFF)
- the sustain offcommand is activated and therefore permanently used on the arpeggio.
MULTIPLE/ GROOVE/ SPECIAL
16. MULTIPLE (1-16)
- this sets the repeat rate in which the arpeggio notes are played. For example: playing the keys
"c - e - g" means that the arpeggio will play "c - e - g". Is the multiple value selected to "3" then
the arpeggio will play "c - c - c - e - e - e - g - g - g".
17. GROOVE
- you can choose between various groove styles. Also different lenghts of the notes within the
arpeggio. These options are currently selectable:
17.1 GROOVE
- 1/4 - 1/8 - 1/16 - 1/1
The notes are played equally in 1/4, 1/8, 1/16, 1/1 notes. Then there are styles where for
example the rst note is played in 1/4, the second in 1/8, the third in 1/4 and the fourth in 1/16.
The selection on these blocks are displayed in the unit.
18. PITCH ARPEGGIO
- the pitch of the arpeggio can be adjusted by this value
19. SPLIT ARPEGGIO
- the pitch of the split part of the keyboard can be adjusted by this value

MAP-01 USER MANUAL
20 Arpeggio Tune
- Adjustment of the clock tuning ( müssen wir uns einen vernünftigen text ausdenken)
21 GLOBALASSIGN
- congured which Global settings are used by this arpeggio setting
22 MODE
22.1 Arpeggio
22.2 Arpeggio Latch1
22.3 Arpeggio Latch 2
22.4 Sequence
- SEQUENCER: here you can store all notes in the order played and played back sequentially.
The difference between the arpeggio and the sequence is that the sequence plays as long as
the knob SEQUENCE is pressed again. This means you have the option of a "mini-sequencer".
GLOBAL SETTINGS
23. GLOBAL SETTINGS
- Global settings are in general only done once and are loaded automatically after powering on
23.1 MIDI IN CHANNEL (1-16)
- selecting of the MIDI in channel. You can choose from 1-16.
- if the USB Channel is selected the Midi In Channel automatically will be switched off
23.2 MIDI OUT CHANNEL (1-16)
- selecting of the MIDI out channel. You can choose from 1-16.
If the RUN MODE of the arpeggiator is switched off, then you can also use as MIDI channel
converter.
23.3 USB IN CHANNEL (1-16)
- selecting of the input USB channel. You can choose from 1-16.
- if the USB Channel is selected the Midi In Channel automatically will be switched off

MAP-01 USER MANUAL
23.4 USB OUT CHANNEL (1-16)
- selecting of thr output USB channel. You can choose from 1-16.
If the RUN MODE of the arpeggiator is switched off, then you can also use as MIDI
channel converter.
24 SPLIT MIDI CHANNEL
- Selects the Midi Channel where the split section will be transmit
25 SPLIT USB CHANNEL
- Selects the USB Channel where the split section will be transmit
26.5 PROGRAM (1-64)
- you can store up to 64 user programs
26.6 PRESET (1-64)
- selection of the pre-stored arpeggio congurations. Via program change commands you can
select also the presets.
CLOCK/ PROGRAM CHANGE
27. CLOCK
27.1 ARPEGGIO CLOCK (INTERN)
- the arpeggiator runs independantly on its internal clock
27.2 ARPEGGIO CLOCK (INTERN CLOCK OUT)
- as midi clock intern, but also send the commands MIDI CLOCK and START/ STOP/ PAUSE
additionally.
27.3 ARPEGGIO CLOCK (EXTERN)
- the arpeggiator reacts to external MIDI CLOCK commands.

MAP-01 USER MANUAL
27.4 ARPEGGIO CLOCK (EXTERN CLOCK OUT)
- the external MIDI CLOCK commands are additionally routed to the output.
28 PRESET SAVE
- Number were the preset is save
29 PRESET LOAD
- Number were the preset is load
30 GLOBAL SAVE
- Number were the global is save
31 GLOBAL LOAD
- Number were the global is load
32 SYSEX SEND
- send a sysex dump
33. PROGRAM CHANGE
33.1 PROGRAM CHANGE (ON)
- program changes are possible via MIDI
- currently not active
33.2 PROGRAM CHANGE (OFF)
- program changes are not possible via MIDI
- currently not active

MAP-01 USER MANUAL
33 PROGRAM CHANGE (OFF)
- program changes are not possible via MIDI
- currently not active
34. CONTROL CHANGE
- control changes are not possible via MIDI
- currently not active
34. SYSEX CHANGE
- sysex changes are not possible via MIDI
- currently not active
.BYTE "ARPEGGIO STYLE: ", 0FFh
.BYTE "ASSORTMENT: ", 0FFh
.BYTE "OCTAVE: ", 0FFh
.BYTE "RANDOM: ", 0FFh
.BYTE "ARPEGGIO SIDE: ", 0FFh
.BYTE "SPLIT POINT: ", 0FFh
.BYTE "RUN NOTE: ", 0FFh
.BYTE "STOP NOTE: ", 0FFh
.BYTE "VELOCITY VALUE: ", 0FFh
.BYTE "LEGATO: ", 0FFh
.BYTE "SUSTAIN: ", 0FFh
.BYTE "MULTIPLE: ", 0FFh
.BYTE "GROOVE: ", 0FFh
.BYTE "PITCH ARPEGGIO: ", 0FFh
.BYTE "PITCH SPLIT: ", 0FFh
.BYTE "ARPEGGIO TUNE: ", 0FFh
.BYTE "GLOBAL ASSIGN: ", 0FFh
.BYTE "MODE: ", 0FFh
