Modena MD Series User manual

05/17
www.modena.co.id
MD Series
BUKU PETUNJUK PENGGUNAAN
FRIZER RUMAHAN
DAN KARTU GARANSI
FREEZER MANUAL
AND
WARRANTY CARD

Bahasa Indonesia 1
Dengan cara pemakaian yang benar, Anda akan mendapatkan manfaat yang maksimal
selama bertahun-tahun.
Bacalah buku petunjuk pengoperasian ini dengan seksama, agar seluruh manfaat dan
kelebihan yang dimiliki frizer rumahan ( freezer ) MODENA bisa Anda peroleh. Simpanlah
buku petunjuk pengoperasian ini dekat dengan frizer rumahan ( freezer ) Anda, agar
sewaktu-waktu jika diperlukan mudah untuk mendapatkannya.
Sertakan buku petunjuk pengoperasian ini jika frizer rumahan ( freezer ) ini dialihkan kepada
pihak lain, dengan demikian pemakai yang baru dapat segera memahami cara penggunaan
frizer rumahan ( freezer ) ini.
Terima kasih atas kepercayaan Anda untuk memilih produk MODENA.
SELAMAT ATAS PILIHAN ANDA MENGGUNAKAN FRIZER RUMAHAN (FREEZER) MODENA

Bahasa Indonesia 2
DAFTAR ISI HLM.
• Kata Pengantar 2
• Bagian 1 : Nama-nama Bagian 4
• Bagian 2 : Instalasi 4
• Bagian 3 : Cara Penggunaan 5
• Bagian 4 : Pemeliharaan 6
•Bagian 5 : Tindakan Pencegahan 7
• Bagian 6 : Hal-hal yang perlu diperhatikan 8
• Bagian 7 : Masalah & Solusinya 9
• Bagian 8 : Spesifikasi 9
NOMOR : P.8.INDO3.00101.0212

Bahasa Indonesia 3
Letakkan freezer di permukaan yang kuat
dan rata. Permukaan yang tidak rata dapat
mengakibatkan benda yang ada di
dalamnya dapat berjatuhan.
Berikan cukup ruang untuk aliran udara antara
freezer dan dinding untuk meminimaliskan
biaya pengoperasian dan memaksimalkan
umur kompresor.
Bagian 2: Instalasi
Bagian 1: Nama-nama bagian

Bahasa Indonesia 4
Jangan meletakkan freezer di dekat sumber
panas seperti kompor, hot plates, dll dan
hindari freezer dari sinar matahari karena
akan mengakibatkan pendinginan
berkurang.
Letakkan freezer di mana freezer tersebut
tidak terkena air hujan. Menggunakan freezer
yang telah tekena air hujan akan
mengakibatkan kebocoran pada listrik.
Pastikan voltase yang digunakan adalah
220 Volt dan frekwensi 50 Hz. Jangan
menggunakan perpanjangan kabel atau
stop kontak bercabang karena akan
mengakibatkan korsleting, panas yang
berlebihan dan kebakaran.
Jika instalasi di tempat lembab tidak dapat
dihindari, maka instalasi sakelar pemutus
harus dilakukan untuk menghindari terjadinya
korsleting.
P
PE
ER
RS
SI
IA
AP
PA
AN
N
S
SE
EB
BE
EL
LU
UM
M
D
DI
IG
GU
UN
NA
AK
KA
AN
N
-Bukalah kardus penutup, keluarkan dan letakkan freezer pada permukaan yang rata.
-Bersihkan bagian dalam freezer dengan air hangat dan keringkan dengan kain lap yang bersih.
-Bukalah pintu beberapa saat supaya mendapatkan ventilasi lalu tutup dan masukkan kabel listrik
ke steker dan freezer akan bekerja.
-Biarkan unit bekerja untuk waktu kurang lebih 2 jam untuk mendinginkan bagian dalam sebelum
menaruh benda-benda di dalamnya.
M
ME
EM
MA
AH
HA
AM
MI
I
P
PE
EN
NG
GA
AT
TU
UR
R
S
SU
UH
HU
U
-Untuk menyesuaikan suhu di dalam freezer, sesuaikan tombol yang terdapat pada bagian depan
bawah dari frizer rumahan ( freezer ).Biasanya untuk pemakaian normal, suhu untuk frizer rumahan
( freezer ) menggunakan posisi antara FREEZING –MIN dan FREEZING –MAX.
-Suhu tidak dapat diatur pada posisi FREEZING –MAX untuk jangka waktu yang lama. Posisi ini
hanya digunakan untuk membekukan makanan yang perlu dibekukan dalam waktu yang cepat.
Setelah makanan beku, posisi thermostat harus dikembalikan ke posisi antara angka FREEZING -
MIN dan FREEZING –MAX.
-Pengaturan suhu antara COOLING-MIN dan COOLING-MAX digunakan untuk mendinginkan
minuman dalam kemasan, serta bahan-bahan makanan lain yang tidak diharapkan untuk beku.
-Jika tidak digunakan untuk jangka waktu tertentu, putarlah tombol thermostat ke posisi COOLING –
MIN.
Bagian 3: Cara Penggunaan

Bahasa Indonesia 5
P
PR
RO
OS
SE
ES
S
D
DE
EF
FR
RO
OS
ST
TI
IN
NG
G
(
(p
pe
en
nc
ca
ai
ir
ra
an
n
b
bu
un
ng
ga
a
e
es
s)
)
-Jika terdapat bunga es dengan ketebalan mencapai 5 mm di dalam freezer, buang/kikis
bunga es dengan menggunakan sendok plastic (scraper). Jangan menggunakan pisau atau
sejenisnya karena akan merusak kabinet bagian dalam.
-Bilamana suatu waktu freezer perlu dibersihkan secara tuntas, pilihlah waktu di mana stok
makanan di dalam freezer sedikit dan jalankan proses defrosting sebagai berikut :
a.Keluarkan semua makanan dari freezer. Untuk menjaga agar makanan tetap segar,
sebaiknya ditempatkan pada freezer lain.
b.Setelah itu putuskan freezer dari hubungan listrik dan buka penutup freezer.
c.Jika bunga es mulai mencair, bersihkan bunga es dengan sendok plastic (scraper). Untuk
mempercepat pencairan sisa bunga es, tempatkan semangkuk air panas ke dalam kabinet
freezer.
d.Bilamana proses pencairan sudah selesai, bersihkan kabinet bagian dalam dengan
menggunakan bicarbonate (soda) dan air. Setelah itu dikeringkan.
e.Bilamana kabinet sudah benar-benar bersih dan kering, tutup kembali pintu freezer dan
sambungkan ke sumber listrik. Lalu putar knob ke posisi FREEZER (MAX), jika sudah cukup
dingin putar knob ke posisi antara MIN –MAX, sesuai kebutuhan.
-Bersihkan freezer dengan mengunakan kain yang lembut dan kering. Jika sangat kotor,
gunakan kain yang telah dibasahi dengan sedikit sabun kemudian bilas dengan menggunakan
kain yang telah dicelup di dalam air.
-Bersihkan freezer secara regular supaya bersih setiap saat.
-Jangan menggunakan bubuk pengkilap, bubuk deterjen, bensin, acid, thinner, minyak atau
air panas untuk membersihkan seluruh bagian pada unit.
Posisi Tombol
Perkiraan Suhu *
COOLING :
- MIN
- MAX
8°C ~ 10°C
-1°C ~ 1°C
FREEZING :
- MIN
- MAX
0°C ~ -2 °C
~ s/d -25 °C
Bagian 4: Pemeliharaan
*) CATATAN :
Perkiraan suhu tersebut di atas diukur berdasarkan unit kosong (tanpa makanan di dalam freezer).
Suhu tersebut dapat berubah berdasarkan penempatan jumlah makanan di dalam freezer, suhu di
dalam ruangan tempat freezer diletakkan, banyaknya pintu freezer dibuka, dan faktor lain-lainnya.

Bahasa Indonesia 6
Jangan menyiram freezer secara langsung
dengan air atau mencuci dengan air karena
dapat mengakibatkan korsleting dan
kebocoran pada listrik.
Unit ini hanya digunakan untuk menyimpan
makanan beku dan es krim. Menyimpan
benda-benda lain akan mempengaruhi
makanan yang disimpan di dalam freezer.
Jangan meletakkan benda-benda yang berat
atau benda yang mengandung air di atas
freezer karena bila benda jatuh atau air
tumpah akan mengakibatkan insulasi
komponen listrik menjadi rusak.
Jika terdapat kebocoran gas, jangan
menyentuh freezer. Bukalah pintu rumah dan
jendela untuk ventilasi. Kebocoran gas dapat
mengakibatkan ledakan dan kebakaran.
Jangan pernah untuk bergantungan di bagian
pintu atau memanjat freezer.
Setiap perbaikan, pembongkaran atau
modifikasi harus dilakukan oleh tenaga ahli.
Memperbaiki, membongkar atau modifikasi
sendiri dapat merusak freezer.
Jangan menaruh benda-benda yang mudah
meledak/terbakar ke dalam freezer.
Selalu cabutlah stop kontak sebelum
membersihkan freezer.
Bagian 5: Tindakan Pencegahan

Bahasa Indonesia 7
Jangan gunakan kabel listrik atau steker yang
telah rusak, atau steker tidak dapat menancap
pada stop kontak.
Jika ada kerusakan pada kabel listrik maka
segera hubungi ke Service Center MODENA
untuk dilakukan pergantian . Pergantian
kabel listrik haruslah dilakukan oleh
tenaga yang berpengalaman dan sangat
mengerti akan kelistrikan. Jangan pernah
mengganti sendiri kabel listrik dikarenakan
akan bisa menyebabkan bahaya yang bisa
merugikan diri sendiri dan orang lain.
Jangan menyentuh kabel listrik atau benda
listrik lainnya dan mengoperasikannya dengan
tangan yang basah.
JIKA LISTRIK PADAM
- Cabutlah kabel listrik dari tempatnya.
- Jangan membuka dan menutup pintu terlalu sering karena akan mengurangi tingkat
kedinginan.
-Jika listrik padam lama, taruhkan biang es (dry ice) di dalam freezer.
- Hindari untuk menaruh benda-benda baru di dalam cooler karena akan menaikkan suhu di
dalam kompartmen.
- Pasang kembali kabel listrik +/- 10 ~ 15 menit setelah aliran listrik menyala normal.
TIDAK DIGUNAKAN UNTUK WAKTU YANG LAMA
- Cabutlah kabel listrik dari tempatnya.
- Keluarkan semua benda-benda di dalam kompartmen.
- Bersihkan bagian dalam kompartmen.
- Biarkan pintu dalam keadaan terbuka untuk mengeringkan kompartmen secara keseluruhan
untuk mencegah adanya jamur dan bau yang tidak sedap.
PEMINDAHAN
- Cabutlah kabel listrik dari tempatnya.
- Pada saat pemindahan, pastikan roda/kaki freezer tidak merusak kabel listrik.
- Pastikan freezer tidak terbentur tangga, ambang pintu, dll.
Perhatian!
Produk ini tidak boleh dibuang bersama sampah rumah tangga lainnya. Untuk
mencegah kemungkinan bahaya terhadap lingkungan atau kesehatan manusia akibat
pembuangan sampah yang
tidak terkontrol.
Unit mengandung insulasi gas dan refrigan yang harus dibuang dengan benar. Ketika Anda
ingin membuang produk, Kami menyarankan Anda untuk berkonsultasi dengan penyedia jasa
resmi sehingga dapat mempelajari informasi yang dibutuhkan dan bentuk yang resmi.
Pastikan pipa-pipa dan saluran kerja refrigran pada unit tidak rusak sebelum dibawa oleh
bagian penanganan barang bekas.
Konsultasikan dengan penyedia jasa resmi untuk menanyakan semua hal dan masalah yang
berhubungan dengan unit. Jangan melakukan hal-hal atau membiarkan orang lain melakukan
hal-hal kepada unit sebelum menanyakan kepada penyedia jasa resmi.
Bagian 6: Hal-hal yang perlu diperhatikan

Bahasa Indonesia 8
Lakukan pengecekan terhadap hal-hal di bawah ini sebelum menghubungi Service Center kami bila
terjadi gangguan pengoperasian :
Tidak bekerja
-Apakah kabel listrik tercabut dari tempatnya?
-Apakah ada sumber listrik/sekring yang terputus?
-Apakah sakelar pemutus aktif?
Tidak dingin
-Apakah pengaturan suhu sudah benar?
-Apakah terlalu banyak makanan yang disimpan di dalam freezer?
-Apakah pintu freezer terlalu sering dibuka?
-Apakah freezer diletakkan di dekat tempat yang panas?
-Apakah tempat instalasi freezer tidak baik ventilasinya?
-Apakah terdapat banyak bunga es di dalam freezer?
Suara bising
Apakah freezer diletakkan di permukaan yang rata?
Apakah bagian belakang freezer menempel dinding?
Apakah cooler menempel dengan benda lain?
Kompresor akan mengeluarkan suara bising pada saat permulaan
pengoperasian. Suara akan hilang pada saat pendinginan.
Pengembunan pada
bagian luar freezer
Permukaan luar dapat berembun bilamana udara terlalu
panas/lembab. Hal ini terjadi pada saat kelembaban udara tinggi
dan partikel air di udara menyentuk permukaan yang dingin. Hal ini
normal. Bersihkan dengan lap kering.
Dinding luar freezer
menjadi panas
Pada musim panas atau pada saat unit pertama kali bekerja, dinding
luar freezer akan menjadi panas. Panas tersebut tidak akan
mempengaruhi makanan yang ditaruh di dalam freezer.
W= Putih S = Stainless V = Silver G = Abu-abu L = Hitam U = Biru
Desain dan spesifikasi dapat berubah setiap saat tanpa pemberitahuan terlebih dahulu.
MODEL
MD 95
MD 75
MD 60
MD 45
Kapasitas (liter)
950
750
560
430
Fungsi Pendingin
Ya
Ya
Ya
Ya
Suhu (celcius)
- 25
- 25
- 25
- 25
Warna
Stainless/ Abu-abu
(S/G)
Stainless/ Abu-abu
(S/G)
Stainless/ Abu-abu
(S/G)
Stainless/ Abu-abu
(S/G)
Jumlah Pintu
2
2
2
2
Pintu dengan kunci
Ya
Ya
Ya
Ya
Lampu penerang
Ya
Ya
Ya
Ya
Roda
Ya
Ya
Ya
Ya
Thermostat
Ya
Ya
Ya
Ya
Keranjang
5
5
4
4
Ketebalan insulasi (mm)
75
75
75
75
Kapasitas beku (kg/24 jam)
68
45
38
26
Lama defrosting (jam)
41
36
34
31
Jumlah Kompresor
2
1
1
1
Daya listrik (watt)
600
360
310
220
Tegangan listrik (Volt)
220
220
220
220
Frekuensi listrik (Hz)
50
50
50
50
Dimensi Produk (PxLxT) mm
1980 x 1050 x 930
1950 x 840 x 830
1680 x 750 x 830
1360 x 750 x 830
Berat (Kg)
160
90
77
67
Bagian 8: Spesifikasi
Bagian 7 : Masalah & Solusinya

Bahasa Indonesia 9
W= Putih S = Stainless V = Silver G = Abu-abu L = Hitam U = Biru
Desain dan spesifikasi dapat berubah setiap saat tanpa pemberitahuan terlebih dahulu.
MODEL
MD 130 W
MD 65 W
MD 37 W
Kapasitas (liter)
1300
650
370
Fungsi Pendingin
Ya
Ya
Ya
Suhu (celcius)
- 25
- 25
- 25
Warna
Putih (W)
Putih (W)
Putih (W)
Jumlah Pintu
3
2
2
Pintu dengan kunci
Ya
Ya
Ya
Lampu penerang
Tidak
Tidak
Tidak
Roda
Ya
Ya
Ya
Thermostat
Ya
Ya
Ya
Keranjang
2
1
1
Ketebalan insulasi (mm)
75
75
75
Kapasitas beku (kg/24 jam)
72
36
21
Lama defrosting (jam)
-
-
-
Jumlah Kompresor
2
1
1
Daya listrik (watt)
536
268
183
Tegangan listrik (Volt)
220
220
220
Frekuensi listrik (Hz)
50
50
50
Dimensi Produk (PxLxT) mm
2650 x 960 x 908
1930 x 670 x 825
1256 x 670 x 825
Berat (Kg)
150
81
62


English 11
Thank you for your trust and decision to buy MODENA product and make it a part of your
modern family's needs and lifestyle. The stylish and advanced design in each product is an
elegant combination for your daily household activities.
This book contains various matters regarding Freezer, from its method of usage,
maintenance, various professional features of the product down to its trouble-shooting. As a
manufacturer of user friendly home appliances, we thrive to simplify the description in this
manual to facilitate the users.
In order for this Freezer to perform normally for an extended period of time, we highly
recommend not only the buyer to hold onto this manual, but also those who wish to operate
the product optimally to maintain its service period and quality. This manual is recommended
for use by anyone who operates this unit.
Enjoy your daily activities, We hope that our products may provide the best services to your
family.
INSTRUCTION AND GUIDE TO USING FREEZER

English 12
CONTENTS PAGE.
• Introduction 11
• Part 1 : Name of Parts 13
•Part 2 : Installation 13
• Part 3 : How to Use 14
• Part 4 : Maintenance 15
• Part 5 : Precaution Action 16
• Part 6 : Points of Attention 17
• Part 7 : Problem & Solution 18
• Part 8 : Specification 18

English 13
* The features and product specifications depend on the product
type.
Install the freezer on even and sturdy surface.
Uneven surface may cause objects in it to fall.
Provide adequate space for air circulation
between the freezer and the wall to minimize
the operational costs and to maximize the
compressor’s age.
Part 2: Installation
Part 1: Name of Parts

English 14
Do not put the freezer near the heat source
such as stove, hot plates etc. and avoid
placing freezer under direct sunlight which
may hamper with the cooling process.
Do not expose the freezer to rain water. Using
freezer which has been exposed to rainwater
will result in electricity leakage.
Make sure the voltage is set to 220 volt and
the frequency to 50 Hz. Do not use cord
extension or branched outlet since it poses
risks of shortage, overheating and fire.
If the unit must be installed in a humid
environment, make sure to install a circuit
breaker to avoid shortage.
PREPARATION BEFORE USE
-Open the carton box, lift and put the freezer on an even surface.
-Clean the inside of the freezer with warm water and dry it with clean cloth.
-Open the door for some time for ventilation purpose, close it and plug the power cord to
the outlet to start
the freezer.
-Leave the unit operational for around 2 hours to cool the inner chamber before putting objects inside
it.
UNDERSTANDING THE THERMOSTAT
-To adjust the temperature inside the freezer, use the buttons on the lower front part of the
household freezer. For
normal usage, household freezer is set to between FREEZING –MIN and FREEZING –MAX.
-Temperature cannot be set to FREEZING –MAX for long periods of time. This setup should only
be used to freeze
food in short period of time. After the food is frozen, the thermostat must be set back to between
FREEZING –MIN
and FREEZING –MAX.
-Temperature is set between COOLING-MIN and COOLING-MAX to cool packaged drinks and other
food/drink items
which do not necessarily have to be frozen.
-When left unused for long period of time, turn the thermostat to COOLING –MIN.
Part 3: How to Use

English 15
D
DE
EF
FR
RO
OS
ST
TI
IN
NG
G
P
PR
RO
OC
CE
ES
SS
S
-If the frost inside the freezer reaches more than 5 mm of thickness, scrape it using a plastic
scraper. Do not use
knife or other sharp objects to avoid damage to the inside of the cabinet.
-If the freezer must be thoroughly cleaned at one time, make sure there’s not a lot of food in the
freezer and perform
the following defrosting process:
1. Remove all food from the freezer. To maintain freshness, store the food in another freezer.
2. Disconnect the freezer from power source and open the cover.
3. When the frost starts melting, clean it using plastic scraper. To accelerate the
defrosting,place a bowl of hot
water inside the freezer cabinet.
4. When the defrosting is complete, clean the inside of the cabinet using bicarbonate (soda) and
water, then dry.
5. When the cabinet is completely clean and dry, close the freezer and connect it to a power
source, then rotate
the knob to FREEZER (MAX) position. If it’s cold enough, turn the knob to MIN-MAX
accordingly. “When
defrosting, refrain from using sharp objects such as hammer, knife or bottle to avoid
damaging the inside of
the evaporator and hamper the chest freezer’s operations.
-Clean the freezer using soft and dry cloth. If it’s very dirty, use cloth that is lightly soaked with soap
water and rinse using wet cloth.
-Clean the freezer on a regular basis.
-Do not use shining powder, detergent, gasoline, acid, thinner, oil or hot water to clean the inside of
the unit.
Position knob
temperature *
COOLING :
-MIN
-MAX
8°C ~ 10°C
-1°C ~ 1°C
FREEZING :
-MIN
-MAX
0°C ~ -2 °C
~ s/d -25 °C
*)Note:
The aforementioned temperature is measured with the unit empty (without any food in the freezer).
The temperature may change according to the amount of food stored in the freezer, the ambient
temperature, the amount of freezer doors being opened and other factors.
Part 4: Maintenance

English 16
Do not pour water onto the freezer to avoid
shortage and electricity leakage.
This unit may only be used to store frozen food
and ice cream. Storage of other types of objects
will affect the condition of food stored inside the
freezer.
Do not put heavy or watery objects on top of
the freezer to avoid spill which may damage
the electrical components’ insulation.
Refrain from touching the freezer during gas
leakage. Open the windows and doors to vent
out the gas. Gas leakage may cause explosion
and fire.
Do not hang on to the door nor climb the
freezer.
All repairs, disassembly or modification must be
performed by expert technicians. Self attempt at
repairs, disassembly or modification may cause
damage to the freezer.
Do not store combustible / flammable objects
inside the freezer.
Always unplug the power cord before cleaning
the freezer.
Part 5: Precaution Action

English 17
Do not use damaged power cord or plug,
especially if the plug cannot fit the outlet. If the
cable is damaged or broken it must only be
replaced by an approved service technician to
protect the user from danger.
If there is damage the power cord
immediately contact to the Service Center
MODENA to do the replacement.
Replacement power cord must be done by
experienced personnel and understand
about electricity. Never replace the power
cord itself, due to the dangers that could
lead to harm themselves and others.
Do not touch power cord or other electrical
components or operate the unit with wet hands.
DURING A POWER OUT
-Unplug the power cord.
-Do not open or close the door too frequently to preserve coolness.
-If the power is out for a long period of time, store dry ice inside the freezer.
-Avoid storing new objects inside the cooler to maintain the compartment’s temperature.
-Replug the power cord 10-15 minutes after the power is back on.
IF LEFT UNUSED FOR A LONG PERIOD OF TIME
-Unplug the power cord.
-Remove all objects in the compartment
-Clean the inside of the compartment
-Leave the door open to completely dry the compartment and prevent fungi or bad smell.
RELOCATION
-Unplug the power cord.
-When moving the freezer, make sure the wheels are not damaging the power cord.
-Avoid hitting the stairs, doorways, etc.
Attention!
This product must not be disposed of with other household waste. To prevent possible harm
to the environment or human health from uncontrolled waste disposal.
The unit contains a gas insulation and refrigerant that must be disposed of properly. When you want
to dispose of the product, We advise you to consult with authorized service providers so that they can
learn information required and official forms.
Make sure the pipes and duct work of refrigerant the unit is not damaged before it was taken by a
part handling goods former.
Consult with authorized service providers to ask all the things and issues that relate to units. Do not
do things or allow others to do things to the unit before asking the official service provider
Part 6 : Points of Attention

English 18
Check the following before contacting our Service Center in the event of dysfunction:
Unit is not working
-Is the power cord unplugged?
-Is there a problem with the power source / fusebox?
-Is the circuit breaker activated?
Unit is not cold
-Is the temperature properly regulated?
-Is there too much food being stored inside the freezer?
-Is the freezer door opened too frequently?
-Is the freezer installed in a hot environment?
-Does the freezer have poor ventilation?
-Is there too much frost inside the freezer?
Noise
-Is the freezer put on even surface?
-Is the back of the freezer against the wall?
-Is the cooler put against other objects?
- The compressor will emit loud noise at the beginning of operations.
The noise will disappear when the freezing starts.
Condensation on the
outer surface of the
freezer
-Dew may form on the outer surface of the freezer when the ambient air is too
hot / humid. Condensation occurs during high humidity and when the water
particles in the air come into contact with cold surface. This is perfectly
normal. Simply wipe the surface using dry cloth.
Outer Surface of the
Freezer Is Hot to the
Touch
-During summer or when the unit is operating for the first time, the
outer surface of the freezer may become hot to the touch. The heat
will not affect the food being stored inside freezer
W= White S = Stainless V = Silver G = Grey L = Black U = Blue
* Specifications of this appliance may change without notice to improve the quality of the product.
MODEL
MD 95
MD 75
MD 60
MD 45
Capacity(liter)
950
750
560
430
Freezing function
Yes
Yes
Yes
Yes
Temperature (celcius)
- 25
- 25
- 25
- 25
Color
Stainless/ Grey(S/G)
Stainless/ Grey(S/G)
Stainless/ Grey(S/G)
Stainless/ Grey(S/G)
Number of doors
2
2
2
2
Door with locks
Yes
Yes
Yes
Yes
Light
Yes
Yes
Yes
Yes
Wheels
Yes
Yes
Yes
Yes
Thermostat
Yes
Yes
Yes
Yes
Basket
5
5
4
4
Insulation thickness (mm)
75
75
75
75
Freezing capacity (kg/24hours)
68
45
38
26
Duration of defrosting (hours)
41
36
34
31
Number of Compressors
2
1
1
1
Power (watt)
600
360
310
220
Voltage (Volt)
220
220
220
220
Frequency (Hz)
50
50
50
50
Product dimension(LxWxH) mm
1980 x 1050 x 930
1950 x 840 x 830
1680 x 750 x 830
1360 x 750 x 830
Weight(Kg)
160
90
77
67
Part 7: Problem & Solutions
Part 8 : Specification

English 19
W= White S = Stainless V = Silver G = Grey L = Black U = Blue
* Specifications of this appliance may change without notice to improve the quality of the product.
MODEL
MD 130 W
MD 65 W
MD 37 W
Capacity(liter)
130
650
370
Freezing function
Yes
Yes
Yes
Temperature (celcius)
- 25
- 25
- 25
Color
White (W)
White (W)
White (W)
Number of doors
3
2
2
Door with locks
Yes
Yes
Yes
Light
No
No
No
Wheels
Yes
Yes
Yes
Thermostat
Yes
Yes
Yes
Basket
2
1
1
Insulation thickness (mm)
75
75
75
Freezing capacity (kg/24hours)
72
36
21
Duration of defrosting (hours)
-
-
-
Number of Compressors
2
1
1
Power (watt)
536
268
183
Voltage (Volt)
220
220
220
Frequency (Hz)
50
50
50
Product dimension(LxWxH) mm
2650 x 960 x 908
1930 x 670 x 825
1256 x 670 x 825
Weight(Kg)
150
81
62
Other manuals for MD Series
1
This manual suits for next models
7
Table of contents
Languages:
Other Modena Freezer manuals

Modena
Modena MD 0110 MLWH Owner's manual

Modena
Modena SC Series User manual

Modena
Modena MD WH Series User manual

Modena
Modena VM Series User manual

Modena
Modena MC Series User manual

Modena
Modena MX 0310 Owner's manual

Modena
Modena Preserva MD 0318 WD Owner's manual

Modena
Modena SC 1303 Owner's manual

Modena
Modena MD Series User manual

Modena
Modena Conserva Series Owner's manual
