Modern-Mill ACRE THE FERNWOOD User manual
Assembly Instructions
THE FERNWOOD
3
3
A) (8) 3/4” Screws
B) (8) 1-1/4” Screws
C) (12) 1-1/2“ Screws
D) (14) 2-1/2“ Screws
CHAIR BACK
SEAT
ASSEMBLY
A-FRAME
LEFT LEG ASSEMBLYRIGHT LEG ASSEMBLY
Unpack all the parts from the
shipping box
1.
(1) Chair Back
(1) Chair Arms (1) A-Frame
(1) Seat Assembly
(1) Left & Right Leg
(1) Seat Support
A
B
C
D
2. Painting or staining
IF YOU PLAN TO FINISH YOUR FERNWOOD CHAIR, BE SURE TO
PAINT OR STAIN EACH PIECE BEFORE ASSEMBLY.
USE A WATER-BASED STAIN OR PAINT TO FINISH YOUR
FERNWOOD CHAIR. LET DRY COMPLETELY BEFORE ASSEMBLY.
5
5
3. Insert cross support
into corresponding pegs
CROSS SUPPORT
(2) 2-1/2 SCREWS (4) 1-1/2 SCREWS
SEAT
SUPPORT
7
7
4. Attach both legs to A-Frame with
pegs on legs to slots on A-Frame
Secure A-Frame
with 1-1/2” screws
(4) ON TOP (4) ON BOTTOM
(8) 1-1/2“
SCREWS
A-FRAME
9
9
(6) FLAT HEAD 1-1/4” SCREWS INTO THE SIDES AND
(2) 1-3/4” SCREWS INTO THE CROSS SUPPORT
METAL SUPPORT
(8) 3/4 SCREWS
5. Attach seat bottom to legs
11
11
6. 7.
Insert the back rest into
slot on seat
Place arm around back and insert
into top notches on both legs
SECURE WITH (8) 2-1/2” SCREWS SECURE WITH (8) 1-1/4” FLAT HEAD SCREWS IN
PRE- MARKED HOLES ALONG THE BACK,
AND (2) 1-1/2” SCREW ON THE INSIDE OF EACH
FRONT LEG SUPPORT
SCREW LOCATION
(8) 2-1/2 SCREWS
(8) 1-1/4 SCREWS
* Don‘t over tighten
SCREW LOCATION
(2) 2-1/2 SCREWS
