Modern 003-7445 User manual

Rock - Landscape Rake - 1
Operator’s Manual
YOU'RE ALWAYS AHEAD...WITH A MODERN BEHIND.
ROCK & LANDSCAPE RAKE


www.modernusa.com
Go Galvanized!
SUMMER 2008
003-7445
003-7450
003-7460
003-7440
003-7445
003-7450


PRE-DELIVERY CHECKLIST
Inspect the blade thoroughly after assembly to be
certain it is set up properly before delivering it to
the customer. The following checklist is a reminder
of points to inspect. Check off each item as it is
found satisfactory or after proper adjustment is
made.
DELIVERY CHECKLIST
     
that is bolted in an upside down shipping posi-
tion.
___Show customer how to make adjustments.
___Point out safety features.
___Give Operator’s Manual to the customer and ask
him to familiarize himself with all sections of it.
DAILY CHECKLIST
___Check that unit is properly and securely at-
tached to tractor.
-
cure and cotter pins are in place.
___Check that cutting edge of blade is in good
condition.


Date Dealer’s Rep Signature
The above equipment and Operator’s Manual have been received by me and I have been thoroughly

Date Owner’s Signature
CHECK LIST


The SAFETY ALERT SYMBOL indicates
that there is a potential hazard to personal safe-
ty involved and extra safety precautions must be
taken. When you see this symbol on your ma-
        
read the message that follows it.
DANGER    
       
death or serious injury. This signal word is lim-
ited to the most extreme situations.
WARNING    
       
death or serious injury.
CAUTION-

or moderate injury. It may also be used to alert
against unsafe practices.
Know your controls and how to stop tractor
and engine quickly in an emergency. READ THIS
MANUAL AND THE ONE PROVIDED WITH YOUR
TRACTOR.

to operate this equipment without proper in-
structions. Any person who operates this equip-
ment must be instructed in and be capable of
       
and all controls.
Always wear relatively tight and belted clothing
to avoid entanglement in moving parts. Wear

       
sneakers.
Do not let anyone operate the machine and
scraper without proper instruction.
Always lower the unit to the ground and stop
engine before getting off the tractor.
Always be sure the unit is in the fully raised posi-
tion when in transport.
Never permit any person other than the opera-
tor to ride or board the tractor at any time.
Keep alert and watch ahead as well as behind
the tractor when working with the rake.
Do not allow rides on frame at any time.
Avoid excessive speed during operation.
!
OPERATION
SAFETY SECTION
WARNING
WARNING
CAUTION
DANGER


When turning close to buildings or passing

clearance for the rake.
Avoid catching the rake on stumps or other im-
movable objects.
Make adjustments only when the rake is at-
tached to the tractor and lowered to a position
to allow safe adjustments.
      
feet are never under the tines.
Jeep all people and pets at a safe distance away
when operating the unit.
Always comply with all state and local lighting
and marking requirements when operating on
highways.
Sand areas where paint is chipped and repaint
to prevent rust.
Never work on unit without safety blocks.
       

Travel slowly over rough terrain.
Periodically tighten all hardware to ensure unit is
in a safe condition.
Store unit where it cannot fall or tip and injure
someone.
REPLACING TINES
    
Remove the tine from frame and reinstall. Re-
place it when tines are worn or broken.
BOLTS
Keep all the bolts tight at all times by checking
them periodically. Replace the bolts only with
those having the same marks on the heads as
an original bolt.
PREVENT RUST
Sand areas where paint is chipped and repaint
to prevent rust.
This unit is designed for a wide range of appli-
-

and many other uses.
The safe operation of this unit is the respon-

-
-
tices before starting operation.
TRACTOR SIZE
The rock rake may be mounted on any wheeled
Cat 1 tractor.
ROCK RAKE ANGLING


grading without unhooking from the tractor.
     
ground by operating the lift control lever of the
tractor .
MAINTENANCE
SAFETY SECTION continued
OPERATING SECTION
MAINTENANCE SECTION
WARNING
CAUTION
DANGER


5’ • 6’ landscape RaKe MaIn asseMBlY
1
2
23
11
12
3
20
9
4
8
4
3
10
18 17
21
19
15
16
14
13
24

ITEM PART NO. QUANTITY DESCRIPTION
1. . . . . . . . . . . . . . . . . . . . . 406-8601 . . . . . . . . . . . . . . . . .30 . . . . . . . . . . . Tine
1. . . . . . . . . . . . . . . . . . . . . 406-8601 . . . . . . . . . . . . . . . . .36 . . . . . . . . . . . Tine
2. . . . . . . . . . . . . . . . . . . . . 103-33071 . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . 5’ Tine Bar Weldment
2. . . . . . . . . . . . . . . . . . . . . 103-33081 . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . 5’ Tine Bar Weldment
3. . . . . . . . . . . . . . . . . . . . . 105-10 . . . . . . . . . . . . . . . . . . .2 . . . . . . . . . . . . Hitch Pin
4. . . . . . . . . . . . . . . . . . . . . 103-42751 . . . . . . . . . . . . . . . .2 . . . . . . . . . . . . A-Frame
8. . . . . . . . . . . . . . . . . . . . . 103-42752 . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . A-Frame Brace
9. . . . . . . . . . . . . . . . . . . . . 660-3101 . . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Bolt, 10x100 MM
10. . . . . . . . . . . . . . . . . . . . 665-101 . . . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Nut
11. . . . . . . . . . . . . . . . . . . . 660-4961 . . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Bolt
12. . . . . . . . . . . . . . . . . . . . 669-1211 . . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Lock Nut
13. . . . . . . . . . . . . . . . . . . . 103-42777 . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Mount Frame Weldment
14. . . . . . . . . . . . . . . . . . . . 412-0657 . . . . . . . . . . . . . . . . .30 . . . . . . . . . . . Lock Nut
14. . . . . . . . . . . . . . . . . . . . 412-0657 . . . . . . . . . . . . . . . . .36 . . . . . . . . . . . Lock Nut
15. . . . . . . . . . . . . . . . . . . . 412-00751 . . . . . . . . . . . . . . . .30 . . . . . . . . . . . Flat Washer
15. . . . . . . . . . . . . . . . . . . . 412-00751 . . . . . . . . . . . . . . . .36 . . . . . . . . . . . Flat Washer
16. . . . . . . . . . . . . . . . . . . . 412-20401 . . . . . . . . . . . . . . . .30 . . . . . . . . . . . Bolt
16. . . . . . . . . . . . . . . . . . . . 412-20401 . . . . . . . . . . . . . . . .36 . . . . . . . . . . . Bolt
17. . . . . . . . . . . . . . . . . . . . 667-101 . . . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Spring Water
18. . . . . . . . . . . . . . . . . . . . 668-101 . . . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Flat Washer
19. . . . . . . . . . . . . . . . . . . . 406-86005 . . . . . . . . . . . . . . . .5 . . . . . . . . . . . . 5’ Tooth support
19. . . . . . . . . . . . . . . . . . . . 406-86006 . . . . . . . . . . . . . . . .6 . . . . . . . . . . . . 6’ Tooth support
20. . . . . . . . . . . . . . . . . . . . 105-7149 . . . . . . . . . . . . . . . . .2 . . . . . . . . . . . . Spacer
21. . . . . . . . . . . . . . . . . . . . 121-12050 . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Pin w/hair pin
23. . . . . . . . . . . . . . . . . . . . 151-12050 . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Lock pin
24. . . . . . . . . . . . . . . . . . . . 401-7263 . . . . . . . . . . . . . . . . .1 . . . . . . . . . . . . Slotted nut
 - 7
5’ • 6’ landscape RaKe MaIn asseMBlY


MODEL____________________________________ SERIAL #____________________________________
DEALER____________________________________ DATE DELIVERED_____________________
DEALER’S STAMP


-


altered or repaired.
1. Parts may not be returned without authorization by ModernAg Products.


defective.




LIMITED WARRANTY POLICY & REGISTRATION
DEALER: I hereby certify that:
1. The machine has been correctly assembled in accordance with
manufacturers instructions.


operators manual.

correct usage of machine and on limitation of warranty.

PURCHASER: I hereby certify that:
1. The machine is correctly assembled.

understood.


the machine

in operators manual.

am aware of its limitations.
