Moduline DB1.72424S User manual

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 24” WIDE FOR SMALL PARTS –P/N DB1.72424S
BILL OF MATERIALS
A. 3x3 Bin Qty = 11
B. 3x6 Bin Qty = 8
C. 6x6 Bin Qty = 2
D. 3x4 Bin Qty = 1
E. 4x6 Bin Qty = 3

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 24” WIDE FOR MEDIUM PARTS –P/N DB1.72424M
BILL OF MATERIALS
A. 3x3 Bin Qty = 1
B. 3x6 Bin Qty = 7
C. 6x6 Bin Qty = 5
D. 3x4 Bin Qty = 1
E. 4x6 Bin Qty = 3

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24”DEEP x 24” WIDE FOR LARGE PARTS –P/N DB1.72424L
BILL OF MATERIALS
B. 3x6 Bin Qty = 2
D. 3x4 Bin Qty = 1
E. 4x6 Bin Qty = 3
F. 3x12 Bin Qty = 3
G. 6x12 Bin Qty = 2
H. 3x8 Bin Qty = 1

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 30” WIDE FOR SMALL PARTS –P/N DB1.72430S
BILL OF MATERIALS
A. 3x3 Bin Qty= 11
B. 3x6 Bin Qty = 13
C. 6x6 Bin Qty = 3
D. 3x4 Bin Qty = 1
E. 4x6 Bin Qty = 3

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 30” WIDE FOR MEDIUM PARTS –P/N DB1.72430M
BILL OF MATERIALS
A. 3x3 Bin Qty = 1
B. 3x6 Bin Qty = 6
C. 6x6 Bin Qty = 9
D. 3x4 Bin Qty = 1
E. 4x6 Bin Qty = 3

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 30” WIDE FOR LARGE PARTS –P/N DB1.72430L
BILL OF MATERIALS
F. 3x12 Bin Qty = 2
G. 6x12 Bin Qty = 6

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 32” WIDE FOR SMALL PARTS –P/N DB1.72432S
BILL OF MATERIALS
A. 3x3 Bin Qty = 15
B. 3x6 Bin Qty = 16
C. 6x6 Bin Qty = 4

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 32” WIDE FOR MEDIUM PARTS –P/N DB1.72432M
BILL OF MATERIALS
A. 3x3 Bin Qty = 1
B. 3x6 Bin Qty = 7
C. 6x6 Bin Qty = 12

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 32” WIDE FOR LARGE PARTS –P/N DB1.72432L
BILL OF MATERIALS
B. 3x6 Bin Qty = 2
F. 3x12 Bin Qty = 2
G. 6x12 Bin Qty = 6
H. 3x8 Bin Qty = 1

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 36” WIDE FOR SMALL PARTS - P/N DB1.72436S
BILL OF MATERIALS
A. 3x3 Bin Qty = 15
B. 3x6 Bin Qty = 16
C. 6x6 Bin Qty = 4
D. 3x4 Bin Qty = 1
E. 4x6 Bin Qty = 3

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 36” WIDE FOR MEDIUM PARTS –P/N DB1.72436M
BILL OF MATERIALS
A. 3x3 Bin Qty = 1
B. 3x6 Bin Qty = 7
C. 6x6 Bin Qty = 12
D. 3x4 Bin Qty = 1
E. 4x6 Bin Qty = 3

Moduline Aluminum Cabinets
P: 888-343-4463 | F: 508-580-5199
ModulineCabinets.com
PLASTIC DRAWER BIN INSTALLATION GUIDE
24” DEEP x 36” WIDE FOR LARGE PARTS –P/N DB1.72436L
BILL OF MATERIALS
B. 3x6 Bin Qty = 2
D. 3x4 Bin Qty = 1
E. 4x6 Bin Qty = 3
F. 3x12 Bin Qty = 2
G. 6x12 Bin Qty = 6
H. 3x8 Bin Qty = 1
