MODUNFUL M9898 User manual

Specifications
You are advised to record the following information to ensure a quick customer service response.
Date of purchase :
Name of seller(shop or retailer)
Date : year month day
Tel :
© Wenzhou Mojia Trade Co. LTDAll rights reserved. 2020
Hand Dryer
M908098
■Thank you for your recent purchase of Modunful product. Please read the enclosed information to ensure the safe use of your prod. uct
Safety Precautions
Installation Diagram
Maintenance
Important Tips
Troubleshooting
Specifications
English
Instruction Manual
Introduction
How to use Important Tips
Troubleshooting
Item
Description
Model name
Hand Dryer (type with high speed top blower)
Model number
M9898
Power Rating
AC110 120V50Hz/60Hz
Directly connect to power supply
Motor power
550W
Sensing distance
120-150mm
Dry time
5-10s
Decibel
83db
Heater
Nickel chromium heater
Safety device
Excess current fuse/Temperature fuse (Motor, heater, and power terminal block)
Dimensions (mm)
Width 295,depth 175, height 325
Mass
3.4kg
Arir speed
100m/s
Available set temperature range
Between 0 and 50 °C *Set a temperature that prevents condensation

Wenzhou Mojia
10/2020
9 .4 inch
8mm
9 .4 inch
WARNING
CAUTION
May result in death or serious injury.
May result in injury or property damage.
SafetyPrecautions
These precautions are important for safe usage.Be sure to follow them and use
the product correctly.
InstallaStaiofenty Precautions
A. Installation Steps
1. Choose a suitable installation location.
Symbols and meanings
The following symbols are used to indicate important safety instructions for the
use of the product.
Symbol
Definition
This symbol indicates a prohibited use the product.
This symbol is used to indicate a requirement in the use of this product.
Fig.1
2. Drill four holes, dia 8mm insert plastic dowels. (Fig.1)
Fig.2
3.Loose screws at the hand dryer sides. Remove the shell.(Fig.2)
4.Insert screws into dowels and tighten them.(Fig.3)
4.Connect ACpower cable.
2 3
66.9inch
63in ch
31 . 9 in ch
35.8in ch
40.1in ch
44.1i n ch
Fig.3
10.1inch
10.1inch
WARNING
Always use the specified power supply.
Otherwise, a fire could result.
Do not damage the power line.
Continued use of a unit with a damaged line could cause fire,
electric shock, or product problems.
Never disassemble, repair or modify the product.
Doing so could cause fire or electric shock.
Do not stub out cigarettes on this product.
Doing so could result in burns on the surface or cause a fire.
Do not cover Air nozzles with a hand or insert any object into
Air nozzles.
Doing so could result an electric shock or burn injury.
Do not squirt water on the product when cleaning it.
Doing so could result an electric shock.
Stop using the product immediately in case of abnormality or
product problems.
Continued use of the product could cause fire, electric shock, or injury.
When cleaning, turn off the power switch.
Failure to do so could result in sudden activation of the unit or
electrical shock.
CAUTION
Do not hang on the product.
Doing so could drop the product and result in injury.
REQUESTS
Use water-resistant material for nearby walls or floor as small water drops
may spread about if a user moves hands violently when drying hands.

Installation
Installation
B. Installation Check
1. Check AC power cable connection.
2. Check if AC power on.
3. Put outer cover back.
4.Insertsecurityscrewsandtightenthem.
C. Test Running
Steps
Results
Note
1. Shake
the
device
slightly.
The device is firmly
fixed.
There may be
abnormal sounds or
vibrations if the
device is not firmly
fixed.
2. Check
power
voltage.
Use rated voltage.
The device may be
burnt or cause
personal injury if not
running under rated
voltage.
3. Plug in.
Switch off external
power.
Check the power if
the display light is
not on.
4. Put
hands
below the
device for
drying.
Air goes out at a
high speed.
Check if hands are
too far away from
the sensor if there is
no air going out.
D. Operation Instructions
1. The machine starts operating automatically when user's
hands are put approximately 20cm (7.78") below the
sensor located next to air louver. Whenever the hands are
moved out of sensing range, the machine will stop after
approx. 0.5 sec.
2. The 0.2 sec time delay helps avoid false triggers by
unexpected movements.
3. For safety reasons, the machine will immediately stop
operatingwhenitisusedcontinuouslyover 60 seconds.
The machine resumes to standard function when hands
are moved away.
STANDARD INSTALLATION
POWER DIAGRAM
4 5

Maintenance
Troubleshooting
Important Tips
1. Turn off power supply prior to removing outer case.
2. Turn off power supply before maintenance or cleaning. If
Casing is covered with dust, do not splash water onto it.
Use only damp sponge or cloth to wipe dirt off.
3. Do not use eradicator, abrasive powder or oil, acid or alkali
liquid detergent to clean casing.
4. Never try to put a small screw-driver or any other object
into the holes of air Louver from outside. This might cause
damage to the interior parts, and electric shock may occur.
5. Keep sensor case clean, never use any abrasive cleaning
agent, rough surface articles, steel brush or sandpaper to
rub the sensor case. This will make the sensor case dull
and decrease the sensitivity of sensor.
6. Do not dry other objects except hands to ensure the safety.
7. To avoid damage to the machine or cause physical harm to
the person, please keep the live parts away from water.
8. Do not bump the casing.
9. For indoor installation and use only.
Please read this section to troubleshoot any problem before requesting repair services.
Trouble
Solutions
No dry air blown when hands put in.
●Power Switch might be set to OFF.
→If so, set Power Switch to ON.
●Has the Circuit Breaker ON been tripped?
→If it is OFF, please reset it.
●Is the sensor dirty?
→If the sensor is not clean, wipe it with a soft damp cloth.
Dryer not stopped when hands removed
●Is the sensor dirty?
→If the sensor is not clean, wipe it with a soft damp cloth.
No warm air blows
●Heater Power Switch might be set to OFF.
→If so, set Heater Power Switch to ON.
The air volume is weak
●Has Filter accumulated dust or debris?
→Clean Filter if there is an accumulation of dust or debris
If the problem still persists after performing suggested actions, turn off the power switch and set the breaker to "Off."
Misuse prevention timer
6
The misuse prevention timer stops operation automatically after approximately 60 seconds of
continuous operation.
In order to continue to use the product, remove hands then start again.
7
WARNING
Do not squirt water on the product when cleaning it.
Doing so could result an electric shock.
When cleaning, turn off the power switch.
Failure to do so could result in sudden activation of the product or electrical shock.
REQUESTS
Do not use acid or alkali chemicals, benzine, or thinners.
Doing so could cause cracks.
Do not use cleansers, nylon sponges or dry cloth.
Doing so could make scratches.
