EEI -1215 BOOKSHELF
Hardware:
Component:
1 Left Frame x1 2 Middle Frame x1
Thank you for purchasing the HEADWAY BOOKSHELF！
！！
！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the table, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 45 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of small children.
9 Ladder x1
A Bolt x56
D Allen Wrench x1
C Screw x48
B Nut x44
1
2
3
4
4
5
6
5
7
7
7
7
8
8
8
8
8
8
7
7
9
3 Right Frame x1 4 Back Rail x10
5 Front Rail x2 6 Central Rail x1
7 Top/Bottom Shelf x6 8 Central Shelf x6

Customer Service 908-368-1025︱
︱︱
︱www.modwayfurniture.com Page 2 of 4
EEI -1215 BOOKSHELF
Ax20 Bx20 Dx1
STEP 1:
Hardware & Tool required
STEP 2:
Please put the Left Frame (1) and the Middle Frame (2) on a carpeted or padded surface as shown below.
Note: The back of each shelving unit is the end with five sets of pre-drilled holes. These holes were drilled to affix the 5pcs
Back Rails (4).
Insert 2pcs Bolts (A) into the pre-drilled holes on the back of the Left Frame (1) and Middle Frame (2) through the pre-drilled
holes on the Back Rail (4) as shown.
Use 2pcs Nuts (B) with the 2pcs Bolts (A) to attach the Left Frame (1) and Middle Frame (2) as shown.
Tighten the Bolts (A) and Nut (B) by hand at first, then use Allen Wrench (D) to tighten the Bolts (A) clockwise until secure.
Repeat the above steps for affixing the Right Frame (3) to Middle Frame (2) and the remaining 4pcs Back Rails(4).
Ax24 Cx24 Dx1 Hardware & Tool required
Insert 8pcs Bolts (A) into the pre-drilled holes on the front of Left Frame (1), Right Frame (3) and Middle Frame (2) through
the pre-drilled holes on the Front Rail (5) as shown.
Use 8pcs Nuts (B) with the 2pcs Bolts (A) to attach the Left Frame (1) and Middle Frame (2) as shown.
Tighten the Bolts (A) and Nut (B) by hand at first, then use Allen Wrench (D) to tighten the Bolts (A) clockwise until secure.
Repeat the same steps for affixing the Central Rail (6) and the other Front Rail (5).
Front
Back

Customer Service 908-368-1025︱
︱︱
︱www.modwayfurniture.com Page 3 of 4
EEI -1215 BOOKSHELF
STEP 3:
STEP 4:
Place 1pc Central Shelf (8) to the Right Frame (3) and Middle Frame (2) as shown.
Attach the Central Shelf (8) into the Right Frame (3) and Middle Frame (2) by using 4pcs Screws (C) from the pre-drilled
holes on the bottom frame rails as shown.
Use Phillips Head Screwdriver (not included) to tighten Screws (C) clockwise until secure.
Repeat the same steps for affixing the remaining 5pcs Central Shelves (8).
Ax12 Cx24 Dx1 Phillips Head Screwdriver (not included) Hardware & Tool required
Cx24 Phillips Head Screwdriver (not included) Hardware & Tool required
Place 1pc Top/Bottom Shelf (7) to the Right Frame (3) and Middle Frame (2) as shown.
Note: Pre-drilled holes on the Top/Bottom Shelf (7) should face front.
Insert 2pcs Bolts (A) into the pre-drilled holes on the Top/Bottom Shelf (7) through the pre-drilled holes on the Front Rail (5).
Use Allen Wrench (D) to tighten the Bolts (A) clockwise until secure.
Attach the Top/Bottom Shelf (7) into the Left Frame (1) and Middle Frame (2) by using 4pcs Screws (C) from the pre-drilled
holes on the bottom frame rails as shown.
Use Phillips Head Screwdriver (not included) to tighten Screws (C) clockwise until secure.
Repeat the same steps for affixing the remaining 5pcs Top/Bottom Shelf (7).
Front

Customer Service 908-368-1025︱
︱︱
︱www.modwayfurniture.com Page 4 of 4
EEI -1215 BOOKSHELF
STEP 5:
Assembly is completed. The bookshelf is ready to enjoy now!
Attach the Ladder (9) to the Central Rail (6) as shown.
The Ladder (9) is designed for adjusting. It can be moved to left or right for use.
9
6
6
9
