modway MOD 6095 User manual

Customer Service 908-368-1025 www.modwayfurniture.com
MOD 6095, MOD 6096
Thank you for purchasing the MODWAY BED！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approx assembly time: 20 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.
Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all small pieces out of reach of children.
2
1
2
Hardware for Metal Bed Frame
Ax4
Bx4
FLAT WASHER
Cx1
JCBB M8 x 45MM
M5 ALLEN KEY
Dx4
E
x8
FLAT WASHER
G
x4
JCBB M8 x 45MM
HEX NUT 5/16"
12.8
H
x1
SPANNER
F
x4
SPRING WASHER
Hardware for Headboard
I
JCBB M8 x 60MM x4
3
Page 1/2
2- LEG
1- HEADBOARD
3- BED FRAME
COMPONENT

Page 2/2
Ax4 Bx4 Cx1
Hardware & Tool required
STEP 1:
Place Headboard (1) and Leg (2) on a carpeted or padded area as shown. Attach Legs (2) into Headboard (1) by inserting Flat Washer (B)
and JCBB 45mm Bolt (A) into the holes on the back of Leg (2) and Headboard (1). Tighten with Allen Wrench (C).
STEP 2:
1. Line up the bed frame board's pre-drilled holes to match those of the headboard.
2. Secure the headboard to the bed frame by using JCBB bolt 60mm (E) for the thicker bed
frame, and JCBB bolt 45mm (D) for the thinner bed frame. Before inserting each bolt, place Spring washer (G) and Flat washer (F) on each
bolt. Then fit a Flat washer (F) on the screw as it protrudes through the other side of the bed frame.
3. Place a Hex nut (H) after the Flat washer (F) at the end of each screw. Then tighten by using the M5 Allen key (C) and hold the Hex nut
(H)
by using Spanner (I).
4) Repeat the same procedure for each screw and each side of the bed frame.
Assembly is completed. The bed is ready to enjoy now!
Hx4 Ix1 Cx1
12.8
Fx8
Dx4 / Ex4 Gx4
Hardware & Tool required
Hx4 Ix1 Cx1
12.8
Fx8
