modway MOD-5818 User manual

MOD-5818 QUEEN BED
Customer Service 908-368-1025︱www.modway.com Page 1 of 4
Thank you for purchasing Modway Queen Bed!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components
and hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
and environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten
the components from time to time, so please save the tools that have been provided.
6.Please keep all fitting out of reach of children.
Hardware:
Components:
1. Middle Headboard x1 2.Bed Rail x2 3. Footboard x1 4. Center Rail x1 5.Center Support Leg x3
6. Center Plastic Cover x13 7. Side Plastic Cover x26 8. Slat x26 9. Leg x4
10. Column Support LegWith Adjust Foot Glide x2 11. Left Column x1 12. Right Column x1
9
10
10
11
12
Bolt M8x80mm x6
Bolt M8x50mm x12
Bolt M8x25mm x8
Lock Washer
x42
Allen Wrench x1
Open Wrench x1
Nut x6
A.
I.
B.
C.
F.
G.
H.
Bolt M8x20mm x10
Flat Washer x42
D.
E.

MOD-5818 QUEEN BED
Customer Service 908-368-1025︱www.modway.com Page 2 of 4
STEP 1:
1. Attach the Column Support LegWith Adjustable Foot Glide(10)to the bottom of Left Column(11) &
Right Column(12) by using 4 pieces of Bolts(B), 4 pieces of Lock Washers(F) and 4 pieces of Flat
Washers(E). Tighten Bolts(B) by using Allen Wrench(G) fully as shown.
2. Please note the bottom of the Column Support Leg(10) has the adjustable foot glide which you can
adjust the height if necessary.
STEP 2:
1. Attach each Leg(9) to the bottom of Middle Headboard(1) & Footboard(3) by using 2 pieces of Bolts(B),
2 pieces of Lock Washers(F) and 2 pieces of Flat washers(E). Tighten Bolts (B) by using Allen
Wrench(G) fully as shown.
B
x 4
x 4
E
x 4
F
G
x 1
B
x 8
x 8
E
x 8
F
G
x 1
G
B
E
11
12
10
10
3
9
99
9
9

MOD-5818 QUEEN BED
Customer Service 908-368-1025︱www.modway.com Page 3 of 4
STEP 3:
1. Attach the Left Column (11) & Right Column(12) to Middle Headboard(1) by using 6 pieces of Bolts(A),
12 pieces of Lock washers(F), 12 pieces of Flat washers(E), 6 pieces of Nuts(H). Tighten Bolts(A) and
Nuts(H) by using Allen Wrench(G) and Wrench(I) as shown.
STEP 4:
Attach one end of Bed Rail (2) to the assembled Headboard (1) by using 2 pieces of Bolts (C), 2 pieces of Lock
Washers (F) and 2 pieces of Flat Washers(E). Do not fully tighten Bolts(C) at this step.
Repeat the same steps for the other end of Bed Rail to the Footboard (3).
Repeat the same steps for the other Bed Rail to Headboard (1) and Footboard (3).
Finally tighten all the Bolts (C) fully.
A
x6
x 12
E
x
F
G
x1
x 6
H
12 x 1
I
1
3
2
2
C
x 8
x 8
E
x 8
F
G
x 1
12
11

MOD-5818 QUEEN BED
Customer Service 908-368-1025︱www.modway.com
Page 4 of 4
STEP 5:
1. Attach each Center Support Leg (5) to Center Rail (4) by using 2 pieces of Bolt(D),2 pieces of Lock
Washers(F) and 2 pieces of Flat Washers(E). Tighten Bolts (D) by using Allen Wrench(G) fully as
shown in Figure 1.
2. Attach the Center Rail (4) to the assembled Headboard &Footboard by using 4 pieces of Bolts (D), 4
pieces of Lock Washers(F) and 4 pieces of Flat Washers(E). Tighten Bolts (D) by using Allen wrench
(G) fully as shown in Figure 2.
3. Please note the bottom of each Center Support Leg (5) has the adjustable foot glide which you can
adjust the height if necessary.
STEP 6:
Insert 2 pieces of Side Plastic Covers (7) into each end of 2 pieces of Slats (8) as shown.
Insert the other end of the Slats (8) into 1 piece of Center Plastic Cover (6) as shown.
Insert the assembled Side Plastic Covers (7) into the corresponding holes on the Slat support of the Bed Rail
(2), and the assembled Center Plastic Cover (6) into the corresponding holes on Center Rail (4) as shown.
Repeat the same steps for the remaining 24 pieces of Slats(8).
Assembly is completed. The Bed is ready to enjoy now!
1
2
3
D
x 10
x 10
E
x 10
F
G
x 1
8
7
6
7
1
2
4
3
