modway MOD-6264 User manual

Thank you for purchasing the MODWAY BED!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step instructions.
2. Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 35 minutes.
3. Please do not use any tools other than those provided or recommended in these instructions.
4. Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save tools that have been provided.
6. Please keep all fitting out of reach of children.
Hardware:
1JCBB BOLT M8 x 20mm 16 PCS
2M8 SPRING WASHER 16 PCS
3M8 FLAT WASHER 16 PCS
4
5
6
Component:
A. HEADBOARD
C. SIDE RAIL (L/R)
D.
E. BED SLAT
BED LEG
01 of 04
MOD - 6264
x 1
x 2
x 1
x 4
B. FOOTBOARD x 1
ALLEN KEY (BALL SHAPE) M5
7
1 PC
5005 L-BRKT 4 PCS
A
B
C
C
E
WOOD SCREW M4 x 20mm (Black) 8 PCS
D
WOOD SCREW M4 x 32mm 6 PCS

STEP 1
02 of 04
1.1 Secure the Bed Leg (E) & L Bracket (5) to the Headboard (A) and Footboard (B) using
hardware parts BOLT (1),SPRING WASHER(2), FLAT WASHER (3), ALLEN KEY (4)
& WOOD SCREW (6).
1. JCBB BOLT M8 x 20mm x 8pcs 2. M8 SPRING WASHER x 8pcs
STEP 1.1
STEP 1.2
6
A
B
4
1
2
3
3. M8 FLAT WASHER x 8pcs 4. ALLEN KEY (BALL SHAPE) M5
5. 5005 L-BRKT x 4pcs
E
E
E
E
5
6. SCREW M4 x 20mm x 4pcs Screw Driver
MOD - 6264

STEP 3
03 of 04
STEP 4
3.1 Attach the Side Rails (C) to the Headboard (A) & Footboard (B) using hardware parts
BOLT (1),SPRING WASHER(2), FLAT WASHER (3), ALLEN KEY (4) & WOOD SCREW (6).
4.1 Secure the Slats (D) into the Side Rail (C) using hardware parts WOOD SCREW (7).
1. JCBB BOLT M8 x 20mm x 8pcs 2. M8 SPRING WASHER x 8pcs 3. M8 FLAT WASHER x 8pcs 4. ALLEN KEY (BALL SHAPE) M5
6. SCREW M4 x 20mm x 4pcs Screw Driver
1
2
3
4
6
C
C
STEP 3.1
STEP 3.2
7
D
D
7. WOOD SCREW M4 x 32mm x 6pcs Screw Driver
C
A
B
MOD - 6264

STEP 5
04 of 04
5.1 Carefully position the assembled bed to the desired location by four adults.
Assembly is complete. The bed is ready to use now!
NOTE: Hardware may loosen over time. Periodically check that all connections are tight.
