Moen 3869 Series User manual

CRITICAL DIMENSIONS
(DO NOT SCALE)
FINISHED
WALL LINE
Max thickness:
2” if mounting into a stud
1-1/4” if mounting
w/toggle bolts
30-5/8"
(778mm)
Vacuum
Breaker
#A714
Hole Size
5/8" (17mm)
1-1/2" (39mm)
Specifications
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
Rev. 11/09
Single Function Handshower
with Slidebar
Models: 3869 series
DESCRIPTION
•Various finishes identified by suffix
•Handheld shower
•69" double interlock spiral hose (metal)
•Vacuum breaker
•30" slide bar with push button height selection
OPERATION
•Single function
•Handshower holder rotates to adjust angle of handshower
FLOW
• Designed to deliver 2.5 gpm (9.5 L/min) at 80 psi
STANDARDS
• Designed and manufactured to comply with the applicable
requirements of CSA B-125.1, ASME A112.18.1 and ASSE 1014
and all applicable specifications referenced therein
WARRANTY
•Lifetime limited warranty against material or
manufacturing defects
