Moen Chrome T3405 User manual

DATA CABLE ( 30' ) ( 9.2 m )
7-5/16"
( 70 mm )
2-3/4"
( 186 mm )
1-13/16"
( 46 mm )
4-3/8"
( 111 mm )
15/16"
( 24 mm )
1-1/2"
( 38 mm )
(
5 mm to 89mm
)
3
/16
"
TO 3-1/2
"
THICK
WALL
FINISHED WALL LINE
7"
( 177 mm )
ioDIGITAL™
Shower Trim Only
Models: T3405, T3415 series
Optional Remote: A340 series
(Sold separately)
CRITICAL DIMENSIONS
(DO NOT SCALE)
Specifications
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
Valve: 3381 (Sold separately)
Rev. 2/09
DESCRIPTION
• Metal construction with various finishes identified by suffix
• Includes 7" rainshower showerhead, arm and flange
• Includes digital controller for temperature & flow
OPERATION
• Digital Thermostatic control
• Digital control dial controls temperature with LED indicators
• Digital control dial controls the flow rate with LED indicators
• Digital on/off button
• Digital pause button
• Temperature range adjustment from 60 degrees F to 120 degrees F (16
degrees C to 49 degrees C). Factory maximum setting is 115 degrees
(46 degrees C)
• 4 digital presets for temperature and flow rate
• Remote (optional) uses RF technology and has a 30’ (9.2m) range
depending on intermediary structures
FLOW
• Showerhead limited to 2.5 gpm (9.5 L/min)
STANDARDS
• Third party certified to meet ASME A112.18.1/CSA B-125.1 and
all applicable requirements referenced therein including ASSE 1016
• Digital controller third party certified to meet UL1951
• Digital controller and Remote control third party certified to meet FCC
part 15
WARRANTY
• Lifetime limited warranty against finish defects to the original consumer
purchaser
• 5 year warranty against leaks, drips and operation defects
to the original consumer purchaser
• 5 year warranty against finish defects if used in commercial installations
• 1 year warranty against leaks, drips and operation defects if used in
commercial installations
