Moen Extensa 7560C User manual

FAUCET DESCRIPTION
•Hydrolock® quick connect installation
•Flush button with raised stream and spray indicators
•Metal construction with 10 finishes
•Pullout spray with 59" fiber hose
•1/2" IPS connections will accept standard ball nose
connection for 3/8" tubing
OPERATION
•Lever style handle
•Temperature controlled by 180˚ arc of handle travel
•Spout receptor rotation is 145˚
•Operates with less than 5 lbs. of force
•Operates in stream or spray mode in the pullout or
retracted position
FLOW
•Flow is limited to 2.2 gpm (8.3 L/min) at 60 psi
CARTRIDGE
•1225 cartridge design
•Engineered polymers, non-ferrous and stainless
steel materials
STANDARDS
•Designed and manufactured to comply with the
requirements of: CSA B-125, ASME A112.18.1M, IAPMO PS
49-92, NSF 61 Section 9, California Proposition 65, ANSI
A117.1, ADA
•The backflow protection system in this device consists of
two independently operating check valves, a primary and
a secondary which prevent backflow
WARRANTY
•Lifetime limited warranty against leaks, drips and
finish defects to the original consumer purchaser
•5 year warranty if used in commercial installations
For 8"(203mm)
Mounting
2-1/2"(64mm)
Max. Deck Thickness
Single Mount Esc.
2-1/8"(54mm)
Max. Deck Thickness
Deck Esc.
1-1/4"(32mm) Dia.
Minimum
Mounting Hole
3/8" (10mm)
Supply Tubes
1/2" IPS
Connection
16"
(406mm)
8"
(203mm)
10"
(254mm)
Cold
Hot
Flexible
Metal Hose
Counter Weight
Deck Escutcheon
10-7/16" x 2-7/16" wide
(265mm x 62mm)
3 Hole, 4" o.c. Installation Single Hole Installation
1/4" (6mm)
Threaded Dia.
18 NPSM
11-1/8"
(284mm)
10-3/8"
(264mm)
2-3/8" (60mm)
Escutcheon Dia.
ADA
Rev. 12/06
NOTE: DESIGNED TO INSTALL
THRU 1 OR 3 HOLES 1-1/4” (32mm) MIN. DIA.
Specifications
CRITICAL DIMENSIONS
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
Extensa™
Single Control Kitchen Faucet
w/Pullout Spray
Models: 7560C, 7560S, 7560W, 7560V, 7560BL,
7560SL, 7560SLBL
87560W, 87560SL
DISCONTINUED MODELS: 7560, 7560CS,
7560CBL, 87560C, 87560S, 87560SLBL, 87560CS,
87560CBL, 87560
