Moen Legend 2200P Setup guide

Illustrated Parts
■ Order by Part Name and
Part Number (Bold Face Type)
CRITICAL DIMENSIONS
(DO NOT SCALE)
H
C
Retainer Clip
883
512 - IPS to IPS
Stop-
Chec Valve
Replacement Cartridge
1200 or 1225
Knob Kit
13094 Clear
15508 Charcoal
Knob Insert Kit
15613
Stop Tube
10089
99497 Polished Brass
Hardware Pac age
96806
Stop-Chec
Valve Kit
12318
Escutcheon
221 Chrome
221P Polished Brass
Escutcheon Screws
15528 Chrome
99498 Polished Brass
T RDER PARTS CALL: 1-800-BUY-M EN
Rev. 11/03
Showerhead
3900 Chrome
3906P Polished Brass
Tub Spout (IPS)
3911 Chrome
3911A Antique Brass
Tub Spout (cc)
3960 Chrome
3960A Antique Brass
3801P Polished Brass
Shower Arm & Flange
A704 Chrome
A704P Polished Brass
Valve nly
M DEL
2200
2220
2200P
2220P
Shower nly
M DEL
2205
2225
2225A
Tub & Shower
M DEL
2215
2215A
2235
2235P
DISC NTINUED SKUS
LEGEND®
Single-Handle Tub/Shower alve Only
