Moen Single-Handle Shower Trim Only T2605BN User manual

FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
CRITICAL DIMENSIONS
(DO NOT SCALE)
Specifications
ADA
VESTIGE™MOENTROL®
Single-Handle Shower Trim Only
Models: T2605,T2605BN,
T2605ORB, T2605PW
FINISHED
WALL LINE
C
5-1/2"
(140mm)
WALL OPENING
32" (813mm) - TUB OR
TUB SHOWER
45" (1143mm)/
48" (1219mm) - SHOWER
2-1/16" (52mm) MAX.
1-7/16" (37mm) MIN.
1-3/4" (44mm)
L
7" (178mm)
ESCUTCHEON
DIAMETER
FLOOR
TUB RIM
7" (178mm)
MIN.
6’-6"
(1981mm)
FAUCET DESCRIPTION
• Metal construction with chrome plated, pewter,
oil rubbed bronze, or brushed nickel finishes
• Includes showerhead, arm and flange
OPERATION
• Lever style handle with temperature indicator on the
escutcheon, pull-on/push-off operation
• Temperature operates through an 180° arc of handle
travel (full cold to full hot)
• Adjustable temperature limit stop to control maximum
hot water temperature
• Pressure balancing mechanism maintains selected
discharge temperature to ± 2°
FLOW
• Showerhead limited to 2.5 gpm (9.5 L/min)
CARTRIDGE
• 1225® cartridge design
• Nonmetallic/nonferrous and stainless steel materials
• Accommodates back to back installations
STANDARDS
• Third party certified to meet: CSA B-125, ASME A112.18.1M,
ANSI A117.1 and all applicable requirements referenced therein
WARRANTY
• Lifetime limited warranty against leaks, drips and finish
defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
