Moen POSI-TEMP 82241 User manual

Specifications
MOEN SPECIFIER SERVICES 1-800-321-8809 Ext. 2158
CRITICAL DIMENSIONS
(DO NOT SCALE)
®
DESCRIPTION
•Metal construction with a chrome plated, LifeShine®
polished brass, Platinum™, or Satine™finish
•Includes valve, handle insert, adjustable showerhead
arm and flange
•1/2” IPS connections
OPERATION
•Handle operates counterclockwise through a 270°
arc with off at 6 o’clock and maximum hot at the 9
o’clock position. Shut off in clockwise direction
•Adjustable temperature limit stop to control
maximum hot water temperature
•Pressure balancing mechanism maintains selected
discharge temperature to ± 2°
FLOW
•Showerhead is limited to 2.5 gpm (9.5 L/min)
CARTRIDGE
•1222 cartridge design
•Nonmetallic/nonferrous and stainless steel materials
•Accommodates back to back installations
STANDARDS
•Third party certified by CSA to meet CSA B-125,
ASME A112.18.1M and all applicable requirements
referenced therein and complies with the applicable
requirements of ANSI A117.1
WARRANTY
•Lifetime limited warranty against leaks, drips and
finish defects to the original consumer purchaser
•5 year warranty if used in commercial installations
POSI-TEMP®
Single-Handle Tub/Shower
Models: 82241, 82241PM, 82247, 82251PM
82251ST, 82252ST
(Packed 1 per carton)
NOTE: See reverse side for illustrated
parts and optional handle inserts
ADA symbol applies to shower
valve control only.
ADA
THIN WALL APPLICATION
THICK WALL APPLICATION
7" (178mm)
ESCUTCHEON
DIAMETER
2" CC (51mm)
1 7/8" IPS (48mm)
MAX WALL
HOT
INLET
COLD
INLET
FINISHED WALL LINE
FACE OF STUD
4-1/2" (114mm)
WALL OPENING
FLOOR
45" (1143mm)/
48" (1219mm)-SHOWER
32" (813mm)-TUB OR
TUB SHOWER
7-1/2"
(191mm)
MIN.
TUB RIM
6'-6"
(1981mm)
1 3/8" (35mm)
2 1/2" MAX. (63mm)
1/2" MIN. CC (13mm)
5/8" MIN. IPS (16mm)
FLOOR LINE
1 3/8"
(35mm)
1 1/2"
(38mm)
PLASTER GROUND
3/16" (typ) (5mm)
PLASTIC
TUB/SHOWER
SURROUND
3-1/2" (89mm) MAX.
2-1/4" (57mm) MIN.
DIAMETER
WALL
OPENING
L
C
L
C
Rev. 4/01
