Moen POSI-TEMP L82691 Setup guide


MODEL TYPE FINISH
L82694 Tub/Shower Chrome
L82691 Shower Only Chrome
L82839 Tub/Shower Chrome
L82694CBN Tub/Shower Classic Brushed
Nickel
L82691CBN Shower Only Classic Brushed
Nickel
POSI-TEMP®
Single-Handle Tub/Shower Valve
Cartridge Repair Kit
(Contains grommets
grease pack, and all
necessary O-Rings)
96988
Escutcheon
100998 Chrome
100998CBN Classic Brushed Nickel
Retainer Clip
96914
Shower Arm& Flange
A704 Chrome
A704CBN Classic Brushed Nickel
Diverter Tub Spout
3926 - IPS (for L82694)
3929 - CC (for L82839)
3806CBN - IPS (for L82694CBN)
Escutcheon Screws
15528 Chrome
163ST Used for Classic Brushed Nickel
Handle Kit
117948 Chrome
117948CBN Classic
Brushed Nickel
Knob Handle Kit
115000
(not included in
L82694CBN/L82691CBN)
Replacement Cartridge
1222 Stop Tube Kit
96987 Chrome
96987BN Used for Classic Brushed Nickel
Temperature
Limit Stop Kit
106479
Handle Adapter & Screw
116653
Set Screw
94770
Illustrated Parts
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
Order by Part Number
Showerhead
100997 Chrome
100997CBN Classic Brushed Nickel
