Moffat Curlflow Slicer HCS021114 Instruction Manual

Overall Construction
Fitted with wheels for ease of cleaning•
Front and rear cleaning access•
Main body of machine finished in two-pack•
for durability
Rear of unit clad with colorbond•
Exit table and rear chute fully stainless steel•
construction
Suppled with electrical cable wand to ensure•
operator safety
Operation
Gravity feed rear chute with automatic•
pushers fitted
Adjustable weights fitted to pusher arms•
Button operation (front mounted)•
Emergency stop buttons front mounted•
Technical data sheet for
MOFFAT CURLFLOW SLICER 11 & 14MM
Model Number HCS021114
Twin frame unit fitted with two•
independent motors
Twin variable weighted pusher•
design to suit soft and crusty breads
Loaf guides incorporated into•
rear chute
Fitted with emergency stop buttons•
Standard with green start and red•
stop buttons
V type stainless steel bagging spade•
fitted as standard
Exit table fitted with adjustable lexan•
loaf guides
6244 MOF Curlflow FA.indd 1 21/4/08 9:46:59 AM

Technical data sheet for
MOFFAT CURLFLOW SLICER 11 & 14MM
Model Number HCS021114
Machine Range / Output
Sandwich slice thickness 11mm•
Toast slice thickness 14mm•
Maximum loaf length 330mm•
Maximum loaf height 140mm•
Output approx 300 loaves per frame per hour•
Note: Maximum output will depend vary depending
crustiness of breads being sliced and condition of slicing
blades. 300 loaves per hour is an average per frame only
Specifications
W 1100mm x D 950mm x H 1780mm•
(with pushers disengaged)
400 – 415V, 3P+N+E, 50Hz, 1.0kW•
4 pin 10A plug supplied•
Weight 300kg•
Additional Technical Information
Power outlet to be located a minimum 1.5m off floor•
Options
Front exit table bread bagging unit•
(manual load air blowing design)
HCS1418 machines also available on request –•
14mm & 18mm
