Momax smart Ultra-Air Mist AP9S User manual

MAX
1.0L
0.8L
0.6L
0.4L
0.2L
Ultra-Air Mist
IoT UV-C Purifying Fan with Humidifier
AP9S
INSTRUCTION MANUAL
IoT 智能紫外光空氣淨化加濕風扇
使用說明 / 使用說明
IoT 智能紫外光空氣淨化加濕風扇

MAX
1.0L
0.8L
0.6L
0.4L
0.2L
Product Information p.2 - 22
產品資料 p.23 - 43
產品資料 p.44 - 64
1

How does bladeless plus humidifier work?
1. Air is sucked in through small vents in the base by an electric motor.
2. The air is propelled through the H14 HEPA and the UV-C chamber,
then to the slit in the frame.
3. Air passes over the ramp which channels its direction.
4. As it is pushed out of the fan, surrounding air is drawn into the airflow,
making the volume higher and smoother because of no rotor blades.
5. Humidifying mist can decrease 1-2 degrees in the surrounding when
cold distilled water or pure water is filled in the water tank.
Before Using
1. Please make sure the electric power supply of your region meets the
product’s requirement.
2. Make sure there are no broken parts of the power cord and the
product.
3. This product cannot replace daily air ventilation, dust collection, or use
as a fume cupboard.
4. Do not use this appliance when you have used indoor smoke-type
insect repellents or in places with oily residues, burning incense, or
chemical fumes.
5. Leave at least 30cm of space around the product when using.
6. Do not insert your fingers or objects into the air outlet or the air inlet to
prevent physical injury or malfunctioning of the appliance.
7. This product is not waterproof.
Introduction Quick Start Guide
1. Download ‘MOMAX Smart’ APP
Download “MOMAX Smart” from iOS App Store, Android Google
Play Store or other platforms.
2. Register
Register an account and log in using your mobile number or email
address.
3. Device turn on Wi-Fi
The app is ready to add a device, press & hold the power button for 5
secs (you will hear “beep” 3 times).
When “ ” appears and blinks, tap “confirm indicator rapidly blink” on
MOMAX Smart app to continue.
4. Connect to the Internet Wi-Fi
Choose your Wi-Fi network and enter the password. The smart device
will start connecting to your device via Wi-Fi network.
Tips:
 •StableWi-Finetworkisrequired
•LinktotheWi-Finetworkagainwhenthedeviceisdisconnected
5. Successfully connected
Once the connection is completed. You will see the “Wi-Fi” symbol
appear on the LED screen of Ultra-Air Mist.
Tap “+” or “add device” at the upper right corner and choose the fan
on the Momax Smart app.
The app will automatically match the device. After the match is found,
you can edit the name of the device.
Tips: The device name should be identifiable and easy to pronounce (voice control).
2 3

6. Connect to a new Wi-Fi network
Press & hold the power button for 5 secs and follow steps 1-5.
Remote Control Page
You can control the ON/OFF, cool fan speed, humidity, UV-C, auto-off
timer function and 3 shortcut modes using the app. Moreover, this
device can execute automatically according to conditions such as
specific time, weather, etc. (allow access to your location is required).
Find “AP9S” in MOMAX’s channel
helpdesk.momaxsmart.com
Get step-by-step setup and support.
Watch the latest video tutorial to learn to setup and operate your AP9S.
Keep up to date with the latest updates.
Boost mode
Highest possible wind speed running
at a maximum.
Sleep mode
Lowest possible wind speed to reduce
operational noises to a minimum.
Natural mode
Simulates a natural wind flow by
adjusting the wind speed randomly.
3 shortcut modes
3 shortcut modes are applicable to MOMAX Smart app and remote
control.
4 5

Smart Home Ecology System
Adding multiple devices in interactive smart mode.
Voice Control
This smart device supports voice control with Amazon Alexa, Google
Assistant and other China platforms, etc. To connect with these platforms,
please refer to the App>More Services>Voice Service. Voice commands
of each platform may vary, please refer to the relevant user manual.
Set fan to Sleep.
Set fan to level 1-9.
Turn on/off the fan.
6 7

MAX
1.0L
0.8L
0.6L
0.4L
0.2L
90°
Product Overview
Air Outlet
Air Inlet
LED Screen
Power Button (Main Unit)
Power Button (Humidifier)
LED Indicator
Humidifier Unit
Air Inlet
Built-in Power Port
8 9

AUTO
MODE
UV
AUTO
MODE
UV
ON/OFF UV-C Sterilization
3 Modes
(Natural / Boost / Sleep) Humidifier
•ON/OFF
•3Levels
•AutoMode
Timer
(1-8 Hours Auto-off Timer
Function)
Auto Mode (Air Purifier)
Fan Speed (1-9)
Oscillation
Wi-Fi PM2.5 Data
Mode Wind Speed
Timer Humidity Rate
(Auto measurement)
UV-C Light Humidification Level
LED Display Remote Control
10 11

Operating Instructions Of Remote Control
1. Battery
1st use: Simply remove the clear contact-prevention strip coming out
of the closed battery compartment.
Battery replacement: As shown in the picture. Please note the battery
direction.
- Please do not install the positive and negative poles of the battery in
the wrong position.
- Please use the specified battery. Do not recharge the non-
rechargeable batteries.
- Please take out the battery when not in use for more than 2 months.
2. The remote control should be pointed at the remote control signal
receiver on the LED screen to maximize the remote control signal.
Operating Instructions Of Power Button
1. Power ON/OFF
Tap for 1 sec to Power on.
Tap & hold for 2 secs to Power off.
2. Fan speed
When the fan is operating, tap repeatedly the button to adjust the fan
speed (up to 9-speed settings).
3. Oscillation
When the fan is operating, tap the button for 1 sec, the fan will start
oscillate.
Tap the button for 1 sec again to stop oscillation.
2
4
3
CR2025
+
CR2025
+
1
MAX
1.0L
0.8L
0.6L
0.4L
0.2L
80°
30°
12 13

Operating Instructions Of Humidifier Unit
Add water before using the humidifier. Do not operate without water.
Tap the power button repeatedly to do the followings:
Power ON > Humidification level 1-2-3 > Auto mode* > Power OFF
* Humidifier turns ON when the humidity rate of the environment at or
below 45% and OFF at or above 55%.
This icon indicates the humidifier unit is not installed properly. Please re-
install according to the video tutorial.
When LED is flashing in Red, it indicates the water level of the humidifier is
below 0.2L, please fill in water from 0.2-1.2L.
Do not exceed the water level (max.)
* Recommend to replace water in the water tank with distilled water or
pure water on a daily basis to avoid growth of mold or bacteria.
Ensure the machine is unplugged before maintenance.
Maintenance
Surface
Use a lightly moistened soft cloth with neutral cleanser to clean the
remote control and the surface of the unit.
Humidifier Unit
Use a small amount of easy cleaning agent for the water tank and pour
40°C warm water over it.
Pour out the water and clean the tank with a small brush.
Filter
1. Use a vacuum cleaner or soft brush to clean the dust or debris of the air
inlet/outlet.
MAX
1.0L
0.8L
0.6L
0.4L
0.2L
2. Use a vacuum cleaner or soft brush to remove
the dust on the H14 HEPA every 3 months. This
will help extend the life of the filter and maintain
its performance.
Note: Do not wash the filter directly.
14 15

MAX
1.0L
0.8L
0.6L
0.4L
0.2L
MAX
1.0L
0.8L
0.6L
0.4L
0.2L
Filter Replacement
This device has a memory function. After a total of 720 hours of
operation, will appear on the LED display and you will hear indicator
sound for 3 times. After filter maintenance or replacement, press & hold
the power button of remote control for 5 secs to restart a new memory.
About H14 HEPA Filters and UV-C
H14 HEPA filter UV-C
Structures
White mesh filter with
fine glass threadswith a
diameter of less than 1
micron ( 0 . 0 0 1mm).
UV-C Light
Common
Uses
•Haveanefficiencyof
99.995% to eliminate
bacteria, viruses
•Airborneparticlesof0.3
micron
•PM2.5(fineparticulate
matter with size less than
2.5 micron)
•Filter0.005%of0.1
micron particles per liter
of air.
•Allergens(e.g.Dust
mites, pollen, mold spore,
etc.)
Kills or inactivates
the airborne
infectious particles
(e.g. germs,
mold spore, etc.)
that circulate
throughout the
space.
Filtration :
Coverage about 37.5m2(2.3m ceilling height)
Fan Air Circulation :
Delivery up to 4.5 - 4.6m/s (max.)
Effective Range
1. Simply remove the humidifier unit & filter.
2. Put in the new filter.
3. Assemble the humidifier unit and finished the
filter replacement.
4. Press & hold the power button of the remote
control for 5 secs to restart a new memory.
16 17

Model No. : AP9S
Operating Voltage / Frequency : 100-240V ~50/60Hz
Adapter Power : 60W, DC24V, 2.5A
CADR : 86.3m3/hr
Effective Area : Up to 37.5m2(Ceilling Height : 2.3m)
Filter Type : H14 HEPA
UV-C Lifecycle : 10000 hrs
Horizontal Oscillation : 80° ± 5°
Vertical Manual Adjustment : 30°
Wind Speed : 4.5 - 4.6m/s
Auto-off Timer : 1-8 hrs
Water Tank Capacity : 1.2L
Wireless Frequency : 2.402GHz - 2.480GHz (Wi-Fi + Bluetooth)
Wireless Distance : 10m (Wi-Fi)
Size : 815 x 225 x 225mm
Weight : 4.1kg ± 0.3kg
Contains
1.Ultra-Air IoT UV-C Purifying Fan
2.H14 HEPA Filter (1pc)
3.Remote Control (Button Cell Lithium Battery CR2025 (1pc) included)
4.Power Adapter (Cable Length : 1.8m)
5.Instruction Manual And Warranty Card
Specification
Points for attention
Before using, please read this user manual carefully and keep it for future
reference.
1. To avoid electric shock and fire, do not allow water, liquid or any
flammable detergent to get into or to clean the product.
2. Do not spray insecticide, perfume or other flammable sprays around
the product.
3. Before connecting the power supply, please check whether the
voltage of the product is consistent with the local power supply
voltage.
4. This product cannot replace daily air ventilation, dust collection, or
use as a fume cupboard.
5. Ensure the product is used and kept in a well-ventilated area.
6. Leave at least 30cm of space on the back and sides of the product
when using.
7. Ensure both the filter and its cover are properly installed before using.
8. Do not insert a finger or other things into the air outlet / inlet to
prevent physical damage or trouble.
9. Do not place the machine near a heating device such as a stove or
heater.
10. Do not attempt to repair, disassemble or modify this machine.
11. Please only use the correct local AC power outlet of the power
supply. Before connecting the product to the power supply, first,
verify that the voltage marked on the back or bottom of the product
matches the local voltage.
12. Remove the dust from the power plug and insert it all the way. If the
power cord or plug is damaged or found defective, to avoid danger,
it must be replaced by a professional from the manufacturer or
maintenance department.
Warnings
18 19

13. When an abnormality occurs (such as a burning smell, overheat,
etc.), turn off the machine and unplug the power cord.
14. Do not cover the air inlet with clothing, cloth strips, curtains, etc. Do
not block the inlet and air outlet, for example, do not place objects on
or in front of the air outlet.
15. Do not use the machine in the bathroom or other places where it
may come into contact with water, or wash the machine with water.
16. Do not use this unit in a location where it may be exposed to direct
sunlight or wind and rain.
17. Do not place in places where chemicals are used or where oil or
flammable gas may leak such as hospitals, factories, or laboratories.
18. When using for a long time without supervision, please check it every
2 weeks.
19. Do not allow the machine to tip over, and do not drop the machine
horizontally to carry it.
20. Make sure to leave a certain amount of space around the machine.
Insufficient ventilation may cause overheating or fire hazards.
21. Hold the plug when pulling out the power plug.
22. This product is only for domestic use.
Please reference Mobile Apps content: Before accepting the Agreement,
you are supposed to thoroughly read all the contents of the Agreement,
and fully understand its terms, especially restrictive clauses or exceptions
and Privacy Notice. Restrictive clauses or exceptions are bold or
highlighted in other forms to catch your attention. In case of any doubt
about the terms of the Agreement, please contact the relevant business
department of Tuya. You are not allowed to use the service before
you have read and accepted all the terms of the Agreement, relevant
agreements, and rules, etc. Once you select “agree and submit the
Agreement” (see registration page for detailed wordings) and complete
the registration procedure, or you use the service in any form, it will be
deemed that you have read and agreed with the restriction of the
Agreement and rules above. In case of any breach of the Agreement,
Tuya has the right to unilaterally restrict, suspend or terminate the service
for you, and has the right to investigate your relevant responsibilities.
1. Do not place the product as household waste;
2. Please dispose of discarded electronic products properly according to
local regulations;
3. MOMAX encourages you to participate in the electronic recycling
program.
Service Agreement of
Smart Mobile Application Platform
Disposal of Electronic Products
20 21

1. For any defect, in the judgment of our technician, caused under
normal use, we are responsible for repairing free of charge 12 months
commencing from the date of purchase at the discretion of our
company;
2. A valid warranty card and original purchase invoice must be presented
upon request of warranty service;
3. This warranty card shall not apply to the product if:
(a) It is consumable part(s), such as Filter, or;
(b) it has explicitly modified or repaired in any way by persons other
than technicians of this company, or;
(c) it has been damaged through misuse, malicious acts, negligence,
the inflow of any liquid, or;
(d) losses or damages are caused by force majeure or natural
disasters.
4. No alteration to this warranty card will be allowed;
5. The warranty terms and conditions are subject to change without prior
notice;
6. Please retain your proof of purchase for warranty service;
7. Please consult the dealer about the product compatibility with your
cell phone/ PDA before purchase. Product specifications are subject
to change without prior notice;
8. Please visit www.momax.net for the latest product information.
Warranty Conditions 簡介
無葉風扇加濕器如何工作？
1. 空氣通過底座入風口上的小孔吸入。
2. 空氣通過H14 HEPA和UV-C位置過濾並推動氣流，然後到達無葉風扇框
架中的縫隙。
3. 空氣通過坡道引導氣流方向
4. 空氣從風扇中推出時，周圍的空氣會被吸入氣流中。由於是無葉風扇，
沒有任何葉面阻礙轉動，因此可製造更大氣流，使空間更涼快。
5. 於水箱中注入冷蒸餾水或純淨水，加濕霧氣可降低周圍溫度1-2℃。
使用之前
1. 請確保您所在地區的電源供應符合產品要求。
2. 確保電源線和產品沒有破損。
3. 本產品不能代替日常通風，日常除塵或用作抽風櫥。
4. 當您使用室內煙霧型驅蟲劑或在有油性殘留物，燃燒的香火或化學煙霧
的地方時，請勿使用本產品。
5. 使用時，產品四周至少預留30厘米的空間。
6. 請勿將手指或其他物體插入出風口或入氣口，以免造成人身傷害或設備
故障。
7. 本產品不防水。
22 23

快速入門指南
1. 下載“MOMAX Smart”應用程式
在iOS或Android或任何平台上下載“MOMAXSmart”應用程式。
2. 註冊
註冊一個帳戶，然後使用您的手機號碼或電子郵件地址登錄。
3. 開啟Wi-Fi
帳戶註冊後，應用程式可以添加裝置。按住輕觸式屏幕5秒(你會聽“
嗶”聲3下)。
當輕觸式屏幕出現“ ”並閃爍時，請在MOMAXSmart應用程式上點
擊“確認指示燈快速閃爍”以繼續。
4. 連接到互聯網Wi-Fi
選擇您的Wi-Fi網絡，然後輸入密碼。智能設備將開始通過Wi-Fi網絡連接
到您的設備。
提示：
•需要穩定的Wi-Fi網絡。
•當設備兩端連接時，再次鏈接到Wi-Fi網絡。
5. 成功連接
連接完成後。您可以在Ultra-AirMist的輕觸式屏幕上看到“Wi-Fi”符號。
點擊右上角的“+”或“添加設備”，然後在MOMAX Smart應用程式上，
選擇風扇符號。
應用程序將自動與設備配對。配對後，您可以編輯設備的名稱。
提示：設備名稱應易於識別且易於發音（語音控制）。
6. 重新連接Wi-Fi網絡
按住機身上的輕觸式屏幕5秒鐘，再進行步驟1-5。
控制設備版面
您可以使用應用程式控制開/關、風扇速度、加濕度、紫外光、自動關機
功能及3種快捷模式。此外，亦可以根據特定時間，天氣等條件自動執行
你的預設模式（須允許所在地區存取權，以獲取地區天氣數據）。
搜尋 “AP9S” in helpdesk.momaxsmart.com
獲取有關設定和支援。
觀看最新的視頻教學，學習設置和操作您的 AP9S。
隨時了解最新資訊。
24 25

強勁模式
最高風速運行。
睡眠模式
最低風速運行，將運行噪音降至最低。
自然模式
通過隨機調整風速來模擬自然風流。
三種快捷模式
三種快捷模式只能由MOMAXSmart應用程式控制。
智能家居生態系統
添加多個設備的互動智能模式。
26 27

把風扇的模式設置為睡眠模式。
將風扇風速調到1-9。
打開/關閉風扇。
語音控制
此智能設備支持使用AmazonAlexa、GoogleAssistant及中國內地等平台進
行語音控制。要連接這些平台，請參閱App>更多服務>語音服務。
每個平台的語音指令可能略有所差異，請參閱相關的用戶手冊。
產品總覽
MAX
1.0L
0.8L
0.6L
0.4L
0.2L
出風口
入風口
LED屏幕
電源按鈕（主機）
電源按鈕（加濕器）
LED指示燈
加濕器
28 29

90°
入風口
電源輸入插口
AUTO
MODE
UV
Wi-Fi PM2.5數據
模式 風速
定時 濕度
UV-C紫外光 加濕度
LED顯示屏
30 31

AUTO
MODE
UV
電源鍵 UV-C紫外光功能
快捷鍵(3種模式) 加濕器
•開啟/關閉
•3段加濕
•自動模式
定時(1-8小時自動關機功能)
自動模式(空氣淨化功能)
風速(可設9段風速)
擺動
遙控器
2
4
3
CR2025
+
CR2025
+
1
1. 電池
 第一次使用：只需從電池蓋邊取出透明防觸膠帶即可。
 電池更換：如圖所示。請注意電池方向。
 •請勿將電池的正極和負極安裝在錯誤的位置。
 •請使用指定的電池。請勿給非充電電池充電。
 •如果不使用電池超過2個月，請取出電池。
2. 遙控器應對準輕觸式屏幕上的遙控器信號接收器，以加強遙控器訊號。
遙控器操作說明
32 33

MAX
1.0L
0.8L
0.6L
0.4L
0.2L
80°
30°
1. 電源開/關
•輕按1秒開啟電源。
•按住2秒關閉電源。
2.風速
 冷風運行時，重覆輕按電源按鍵可調整風速(多達9段風速)。
3. 擺動
 風扇運行時，輕按電源按鍵1秒可啟動擺動模式。
 再輕按1秒可停止擺動。
電源按鍵 (機身)作說明 加濕器操作說明
使用加濕器前請先加水，切勿於缺水情況下使用產品。
重覆輕按電源按鍵操作以下：
開啟電源>加濕度1-2-3>自動模式*>關閉電源
*加濕器在環境濕度等於或低於45%時開啟，在55%或以上時關閉。
此圖標表示加濕器安裝不正確。請按照視頻教學重新安裝。
當LED燈呈紅色閃爍，表示加濕器的水位低於0.2L，請注入水0.2-1.2L。
請勿超越最高水位(max.)
*建議每天用乾淨的蒸餾水或純水替換水箱中的水以避免滋生霉菌及細菌。
34 35

MAX
1.0L
0.8L
0.6L
0.4L
0.2L
保養
保養前，請確保拔除電源插頭。
表面
使用蘸有中性清潔劑的微濕布輕擦遙控制和產品表面。
加濕器
使用少量易清潔劑清洗水箱，然後倒入40℃的溫水。倒出水並用刷子清潔
水箱。
濾網
1. 使用吸塵機或軟毛刷清潔入氣口及出風口的灰塵或碎屑。
2. 每3個月，建議使用吸塵器或軟刷清除H14 HEPA濾網上的灰塵和放在陽
光下。這將有助延長過濾網的使用壽命及性能。
 注意：請勿使用水直接清洗濾網。
MAX
1.0L
0.8L
0.6L
0.4L
0.2L
MAX
1.0L
0.8L
0.6L
0.4L
0.2L
濾網更換
設備具有記憶功能。經過720小時的操作，LED顯示屏顯示，你將聽到3次
提示音。保養或更換濾網後，按住遙控器電源按鍵5秒鐘以重新啟動記憶功
能。
1.移取加濕器並取出舊濾網。
2.將新的濾網放入。
3.重新裝回加濕器後，完成安裝。
4.按住遙控器電源開/關5秒鐘以重新啟動記憶功能。
36 37
