Monessen Hearth VWF18NA User manual

®
This gas log set is to be installed
only in a solid-fuel burning replace
with a working ue constructed of
noncombustible material.
READ AND SAVE THESE INSTRUCTIONS
MODELS
VWF18NA VWF24NA VWF30NA VWF36NA
VENTED GAS LOG SET
INSTALLATION AND OPERATING INSTRUCTIONS
WARNINGS
If the information in this manual is not followed exactly,
a re or explosion may result causing property damage,
personal injury or loss of life.
– Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
re department.
– Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.

2 27D7300
CONTENTS
Important Safety Information ......................... 3
Product Specications .................................... 4
Minimum Hearth Dimensions ........................ 4
Getting Started ................................................. 5
Burner - Grate Assembly 18", 24", 30", 36" ... 5
18", 24", 30", 36" Ceramic Fiber or
Refractory Logs ............................................. 5
Items for Installation ...................................... 5
Minimum Free Opening Area of
Chimney Damper for Venting ........................ 5
Minimum chimney Height and Flue Opening 5
Placement in a Fireplace with a Restrictive
Barrier ......................................................... 6
Installation ........................................................ 7
Installation for Gas Valve Kits ........................ 8
Supplemental Instructions for
SPL-NGA/SPL-LPA ....................................... 8
Supplemental Instructions for MANVK ........ 10
Supplemental Instructions for MVVKLPA .... 10
Supplemental Instructions for MVVKNA...... 10
Supplemental Instructions for CVTHL-NG .. 11
Supplemental Instructions for CVTHL-LP ... 11
Wiring (Millivolt) .............................................. 12
Connecting the Gas ....................................... 13
Log Placement ............................................... 14
Filling Front Buner Pan ............................... 14
Placement of Glowing Embers (Rock Wool)14
Placement of Decorative Volcanic Rock ..... 14
VWF18MO Log Placement ......................... 14
VWF24MO Log Placement ......................... 16
VWF30MO Log Placement ......................... 17
VWF36MO Log Placement ......................... 19
VWF18AOLog Placement ........................... 21
VWF24AO/Log Placement .......................... 22
VWF30AO Log Placement .......................... 23
VWF24B Log Placement ............................. 25
VWF24/18SRO ........................................... 26
VWF30/24SRO ........................................... 28
VWF36/30SRO ........................................... 30
VWF18SPA Log Placement ....................... 32
VWF24SPA Log Placement ....................... 34
VWF30SPA Log Placement ........................ 35
VWF24/18WP Log Placement .................... 38
VWF30/24WP Log Placement .................... 40
VWF36/30WP Log Placement .................... 42
Operating Instructions for
SPK and CVTHL kits ................................. 44
For Your Safety Read Before Lighting......... 44
Manual Control (SPK) and Hi/Lo control
(CVTHL) Lighting Instructions .................... 44
Millivolt Control Lighting Instructions ......... 45
Operating Instructions for MANVK Kits ....... 46
For Your Safety Read Before Lighting......... 46
Manual Control Lighting Instructions ........... 46
To Turn Off Gas to Heater ........................... 46
Flame Appearance .......................................... 47
Checking Burner Flames............................. 47
Pilot Flame Appearance .............................. 47
Fireplace Draft Test ....................................... 48
Remote Control Receiver Replacement ...... 49
Cleaning and Servicing ................................. 49
Replacement Parts ......................................... 50
Assembly..................................................... 50
Massive Oak Logs....................................... 51
American Oak Logs..................................... 52
Birch Logs ................................................... 52
Split River Oak Logs ................................... 52
Split Pine Logs ............................................ 53
Weathered Pine Logs .................................. 54
Massachusetts Requirements ....................... 55
Warranty .......................................... Back Cover

27D7300 3
IMPORTANT SAFETY INFORMATION
1. The installation, combustion and ventilation air must con-
form with local codes or, in the absence of local codes,
with the National Fuel Gas Code, ANSI Z223.1.
2. Installation and repair should be done by a qualied
service person. MHS Vented Gas Logs must be installed
onlyinamasonryoraUL127solid-fuelreplacewith
minimum venting requirements, see installation sec-
tion.
3. Topreventmalfunction,gaslogsetandueshouldbe
cleaned at least annually by a professional service person.
More frequent cleaning may be required due to exces-
sive lint from carpeting, etc. It is imperative that control
compartments, burners and circulating air passageways
be kept clean.
4. A damper clamp must be installed to provide the
minimum permanent vent opening to vent ue prod-
ucts, Refer to installation instructions.
5. Neverburnsolidfuelsinareplacewhereagaslogset
is installed.
6. This appliance must NOT be used with glass
doors in the closed position. A replace screen
must be in place when the log set is burning. Provisions
for adequate combustion air must be provided.Adequate
combustionairusuallyresultsinallamescurlinginto
thereplaceawayfromscreenanduptheue.
8. Keep room area clear and free from combustible materi-
als,gasolineandotherammablevaporsandliquids.
9. Children and adults should be alerted to the hazard of
high surface temperature and should stay away to avoid
burns or clothing ignition.
10. Young children should be carefully supervised when they
are in the same room with the gas log set in operation.
11. Donotplaceclothingorotherammablematerialnear
thereplacewhenthegaslogsareinuse.
12. Do not use this gas log set if any part has been under-
water.Immediatelycallaqualiedservicetechnicianto
inspect the gas logs and replace any part of the control
system and any gas control which has been under wa-
ter.
13. The gas log set must be isolated from the gas supply
piping system by closing its individual manual shutoff
valve during any pressure testing of the gas supply
piping system at test pressures equal to or less than 1/2
psig (3.5kPa).
14. Securegaslogsettoreplace.
15. This log set will burn off the paint on the front grate bar.
Note: See cleaning section for refurbishing.
16. LP sets mu s t b e install e d w i th SPK-LP or
MVVKLP kits.
17. FOR MASSACHUSETTS RESIDENTS ONLY:
Continued on page 4
IMPORTANT
Read these instructions carefully before installing or trying to operate this vent-free gas heater.
WARNING
• Any change to this heater or its controls can be dangerous.
• Improper installation or use of the heater can cause serious injury or death from re,
burns, explosion or carbon monoxide poisoning.
• Do not allow fans to blow directly into the stove. Avoid any drafts that alter burner
ame patterns.
• Do not use a blower insert, heat exchanger insert or other accessory, not approved
for use with this heater where applicable.
INSTALLER
Please leave these instructions with the appliance.
OWNER
Please retain these instructions for future reference.
WARNING
This appliance is for installation
only in a solid fuel burning replace
(masonry replace or manufactured
replace)
WARNING
This product must be installed by a
licensed plumber of gas tter when
installed within the Commonwealth
of Massachusetts.
Installation of this vented gas log in the Commonwealth
of Massachusetts requires the damper be permanently
removed or welded in the full open position. In addition, a
naturally vented gas log may not be installed in a bedroom
or bathroom in the Commonwealth of Massachusetts.
Flex line installation must not exceed 36".

4 27D7300
D
C
A
B
Figure 2 - Minimum Hearth Dimensions
Model A B C
VWF18NA 17" 13" 20"
VWF24NA 23" 13" 26"
VWF30NA 24" 13" 32"
VWF36NA 36" 13" 34"
For SPK and CVTHL Kits, add 4" to C and A Dimensions.
For MVVK Kit, add 8" to C and A Dimensions.
For SRO and WP logs, add 8" to C and A dimensions
with or without any control valve.
The minimum inlet gas supply pressure is 4" for natural and 10" for
LP.
The maximum inlet gas supply pressure for this log set is 10" for natural
and 13" for LP.
Nominal Rates (BTU/Hr)
VWF18NA 80,000 VWF30NA 90,000
VWF24NA 90,000 VWF36NA 90,000
Note: Actual performance, ame height, BTU/Hr will vary with specic installation, gas pressure,
shutoff valve position (fully open), valve type, and rebox draft conditions.
MINIMUM HEARTH DIMENSIONS
Model A B C D
VWF18NA 18" 12" 121/2" 161/2"
VWF24NA 24" 12" 14" 20"
VWF30NA 30" 11" 18" 26"
VWF36NA 36" 12" 20" 28"
PRODUCT SPECIFICATIONS
www.ncertied.org
We suggest that our gas hearth
products be installed and
serviced by professionals who
are certied in the U.S. by the
National Fireplace Institute®
(NFI) as Gas Specialists.
SAFETY INFORMATION
WARNING
Never connect unit to private (non-
utility) gas wells. This gas is commonly
known as wellhead gas.

27D7300 5
Chimney Height Flue Opening
6' 64 sq in
8' 64 sq in
10' 64 sq in
15' 51 sq in
20' 51 sq in
30' 51 sq in
GETTING STARTED
MAKE SURE YOU HAVE RECEIVED ALL PARTS
Check your packing list to verify that all listed parts have been received. You should have the following:
BURNER - GRATE ASSEMBLY 18", 24", 30", 36"
• Burner and Grate Weldment Assembly • Lava Rocks (x2) • Reducer
• Glowing Embers (Rock Wool) • Damper Clamp • Injector
• Installation /Operating Instructions • Vermiculite • 3/8" Aluminum Tube with 3/8"
• Shield Plate 90° Elbow, 1/2" to 3/8"tubetting
18", 24", 30" OR 36" CERAMIC FIBER OR REFRACTORY LOGS
• Individual Logs • Installation Instructions
Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately inform the dealer
from whom you purchased the appliance. Do not attempt to install any part of the appliance unless you have all parts
in good condition.
ITEMS REQUIRED FOR INSTALLATION
Ensure that the following items are available before proceeding with installation:
• External regulator (for propane/L.P.G. only) • Shutoff valve • Pipe wrench
 • Pipingwhichcomplieswithlocalcodes • Drillwithmasonrybit(formountingtotheoor)
• Pipe sealant approved for use with propane/L.P.G. (Resistant to sulfur compounds)
MINIMUM FREE OPENING AREA OF CHIMNEY DAMPER FOR VENTING
MINIMUM CHIMNEY HEIGHT AND FLUE OPENING
WARNING
• Handle the gas log burner assembly by the grate only. Do not pick the unit up by the
burner.
• Gloves are recommended when handling ceramic ber logs to prevent skin irritation
from loose bers. Logs are fragile — handle with care.
WARNING
The replace and gas logs function as a system. If the replace is not drafting properly
and spilling into the room (check with a match or a smoke stick), reposition the damper
clamp until the positive draft is obtained by opening the damper. If negative pressure
in home prevents having a positive draft, contact your dealer for assistance.

6 27D7300
PLACEMENT IN A FIREPLACE WITH A RESTRICTIVE BARRIER
IMPORTANT INFORMATION FOR THE INSTALLATION OF THIS GAS LOG SET
ThefollowingareguidelinesforplacingaVWFlogsetwithSPK,MVVK,orCVTHLkitinareplacethathasarestric-
tivebarrieralongthebottomfrontopeningofthereplace.Someexamplesofbarriersareglass/screendoorframesand
sunken/recessedreplaces.
Glass door frames
with adjustable
louvers should have
the lovers fully open
while the unit is in
operation.
Height of restrictive barrier
caused by glass door frames,
recessed replaces, etc. from
the base or bottom surface of the
unit. (See Table).
The log set should be
placed against or as near
as possible to the rear wall
of the replace/rebox.
Depth of replace/rebox.
(See Table).
Figure 3
NOTE: Non combustible material such as
refractory brick may be used to line the oor
of the replace in order to raise the height
of the gas log set in relation to a restrictive
barrier.
X
Height of Restriction (X) Minimum Depth of Fireplace/Firebox
No restriction 13" - SPK Manual Control)
131/2" - MVVK (Millivolt Control) and MXVK (Hi/Lo Control)
0 to 1.5" 15"
Greater than 11/2" to 3" 15"
Greater than 3: Any barrier greater than three inches (3") placed in front of the gas log
set is not recommended by the manufacturer.
WARNING
Barriers such as the bottom of a glass door frame placed in front of a gas log set can
change the air ow characteristics of the replace which in turn can cause the unit to
overheat and malfunction. Any deviation from the installation guidelines on this sheet
will potentially void the warranty.
CAUTION
If the replace has a restrictive barrier and
is equipped with a remote receiver, it must
be placed outside. See Remote Control
Receiver Replacement page 49.

27D7300 7
Damper Stop
Damper
In compliance with ANSI Z21.60•CGA2.26 and National Fuel Gas Code, Section 6.
BEFORE INSTALLING THE APPLIANCE
 • Turnoffgassupplytoreplaceorrebox.
 • Cleanreplaceoorandchimneybeforeinstallinglogset.Sealanyash.Cleanoutdoorstoprotecttheunitfromdown
drafts.
ASSEMBLY PROCEDURE
1. Placegrate/burnerassemblyintoreboxwiththefrontpanfacingforward.
2. Drill two (2) 5/32" diameter holes approximately 11/2" deep.
 3. Anchorthefrontpantotheoorusingthescrewsprovided.
Proper installation of the grate is essential to prevent any movement of the gas logs and controls
during operation.
INSTALLATION
Figure 5 - Securing Grate/Burner Assembly into Firebox
Screws
INSTALL AND OPERATE THE APPLIANCE AS DIRECTED IN THIS MANUAL.
DAMPER STOP INSTALLATION
A damper stop must be provided with the unit. The damper stop must be installed as shown in Figure 4 to prevent full closure
ofthereplacedamperbladeandprovideaminimumueopening,per table on page 5.
Shouldtheclampnott,orprovidetherequiredpermanentopeningfromthetable,havethedampercuttoprovideaminimum
permanent opening or install a permanent stop.
Figure 4 - Damper Stop Installation
Injector
(Natural Gas
Only)
FOR MASSACHUSETTS RESIDENTS ONLY: Instal-
lation of this vented gas log in the Commonwealth of Mas-
sachusetts requires the damper be permanently removed
or welded in the full open position. In addition, a naturally
vented gas log may not be installed in a bedroom or bath-
room in the Commonwealth of Massachusetts.

8 27D7300
The Safety Pilot Kit attaches to the burner pan as shown above.
Usesoapywaterwhencheckingallttingsforleaks.
SUPPLEMENTAL INSTRUCTIONS FOR SPK-NGA/SPK-LPA
Adjust pilot ame to
cover thermocouple
INSTALLATION FOR GAS VALVE KITS
Figure 6 - Connecting Valve to Unit (Natural Gas only)
Natural Gas Injector
Reducer
Gas Control
Valve
Pipe Nipple
Burner Fitting
Figure 7 - Connecting Valve to Unit (LP only)
Gas Control
Valve
LP Air-Mixing
Injector
Brass Nut
Burner Fitting
SPK-NGA Kit Includes
Valve
Pilot (Congured for NG)
Pipe Nipple
Heat Shield
Knob Extenders
SPK-LPA Kit Includes
Valve
Pilot (Congured for LP)
Air Mixing Nut
Brass Nut
Heat Shield
Knob Extenders
WARNING
LP sets must be installed with a SPK
or MVVKLP Kit which includes the air
mixing nut and vermiculite. The natural
gas orice must be removed.

27D7300 9
INSTALLATION FOR GAS VALVE KITS
Figure 8 - Installing Pilot
Screw
Figure 9 - Installing Heat Shield
Gas Control
Valve
Heat Shield
Control
Knob
Knob Extensions

10 27D7300
INSTALLATION FOR GAS VALVE KITS
SUPPLEMENTAL INSTRUCTIONS
FOR MANVK
MANVK Kit Includes
Valve
Knob Extenders
Control Knob
Reducer
Valve
Knob Extenders
Control Knob
Injector
Figure 10 - MANVK
SUPPLEMENTAL INSTRUCTIONS
FOR MVVKLPA
Figure 11 - MVVKLPA
MVVKLPA Kit Includes
Valve Assembly
Pilot
Heat Shield
Air Mixing Injector
Vermiculite
Brass Nut
LP Air-
Mixing
Injector
Brass Nut
Flex
Hose
90° Cast Iron
Elbow
Burner Fitting
Gas Control
Valve
Flex
Hose
Reducer
Pipe
Nipple
Gas Control
Valve
Burner Fitting Injector
Figure 12 - MVVKNA
Heat Shield
SUPPLEMENTAL INSTRUCTIONS
FOR MVVKNA
MVVKNA Kit Includes
Valve Assembly
Pilot
Heat Shield
Pipe Nipple
Heat Shield
90° Cast Iron
Elbow
WARNING
TheMANVKkitis
for Natural Gas
Only

27D7300 11
INSTALLATION FOR GAS VALVE KITS
SUPPLEMENTAL INSTRUCTIONS
FOR CVTHL-NG
CVTHL-NG Kit Includes
Valve
Pilot for NG
Pipe Nipple
Knob Extender
Heat Shield
Self Tapping Screws
Pilot Bracket
Natural Gas Injector
Reducer
Gas Control
Valve
Pipe Nipple
Burner Fitting
Figure 13 - CVTHL-NG Connecting Valve to Unit (Natural Gas only)
Figure 14 - CVTHL-LP Connecting Valve to Unit (LP only)
CVTHL-LP Kit Includes
Valve
Pilot for LP
Brass Nut
Vermiculite
LP Air-Mixing Injector
Knob Extender
Heat Shield
Self Tapping Screws
Pilot Bracket Gas Control
Valve
Heat Shield
Control
Knob
LP Air-Mixing Injector
Brass Nut
Heat Shield
Control
Knob

12 27D7300
THTP
TP TH
Millivolt
Valve
Pilot
WIRING (MILLIVOLT)
Figure 15 - Wiring Diagram
The Millivolt (thermopile) is a self powered combination gas control that does
not require 110VAC to operate. See Figure 15 and installation instructions
provided with optional wall switch or remote control for wiring instructions. A
maximum length of 15 feet of 18 awg two conductor wire is to be used for wall
switch. Note switches must be suitable for Millivolt operation. The optional
wallswitchandremotereceivermustbemountedoutsidetherebox.
CHECKING SYSTEM OPERATION
The Millivolt system and individual components may be
checked with a Millivolt meter having a 0-1000MV range.
Conduct each check shown in chart below by connection
meter test leads to terminals as indicated.
A. COMPLETE MILLIVOLT SYSTEM CHECK
("A" READING - CONTACTS CLOSED - CONTROL KNOB "ON" - MAIN BURNER SHOULD BE COME
ON)
a. If the reading is more than 100 Millivolts and the automatic valve still does not come on — replace the control.
b. If the closed circuit reading (“A” reading) is less than 100 Millivolts, determine cause for low reading — proceed as
follows:
B. THERMOPILE OUTPUT READING CHECK
(“B” READING - CONTACTS OPEN - MAIN BURNER OFF)
a. 325 Millivolts minimum. If the minimum Millivolt reading is not obtainable, readjust pilot for maximum Millivolt
output.IfMillivoltreadingisstillbelowminimumspecied,replacethermopile.
Optional Wall Switch or Remote Reciever
WARNING
Label all wires prior to disconnection when servicing
controls. Wiring errors can cause improper and dangerous
operation. Verify proper operation after servicing
WARNING
Do not
connect to 110
volt supply
WARNING
Keep wiring away
from heat source and
hot surfaces.
CHECK
TEST TO TEST
CONNECT
METER
LEADS TO
TERMINALS
METER
READING
SHOULD BE
ACOMPLETE
SYSTEM
TH & THTP MIN 100 MV
BTHERMOPILE
OUTPUT
TP & THTP MIN 325 MV

27D7300 13
CONNECTING THE GAS
Pipe Coupling
To Gas Log
Set or to Gas
Valve Shutoff
Valve
Gas Supply Inlet
Figure 16 - Gas Connection
Pipe
IMPORTANT: Holdappliancermlywithawrenchtopreventmovementwhenconnectingtoinletpiping.
Always use an external regulator for all propane/LPG gas logs only, to reduce the supply tank pressure to a maximum of
13" w.c.
Locations that the Pressure Tapping
Point May be Installed
WARNING
Connecting directly
to an un regu lated
propane/LPG tank can
cause an explosion.
CAUTION
Use new black iron pipe, steel pipe, copper tubing, or internally tinned copper tubing.
Copper or internally tinned copper tubing can only according to the National Fuel Gas
Code, section 2.6.3, providing gas meets sulde limits, and where permitted by local
codes. Gas piping system must be sized to provide minimum inlet pressure at the
maximum ow rate (BTU/Hr). Undue pressure loss will occur if the pipe is too small.
A manual shutoff valve must be installed upstream of the appliance. Union tee and
plugged 1/8" NPT pressure tapping point should be installed upstream of the appliance.
See Figure 16.
NOTICE
NOTICE: A qualied gas appliance installer must connect the appliance to the gas
supply. Consult all local codes before installation.

14 27D7300
LOG PLACEMENT
FILLING THE BURNER PAN
Fill the burner pan with vermiculite to the bottom of the rear log and sloped to the front edge of the burner pan. Excess ver-
miculitecanspillforwardortothesideoftheburnerpan.Donotoverllthepropanemodel.Donotcoverthepilot(ifSPK
or MVVK is installed) with vermiculite or rock wool (embers).
PLACEMENT OF GLOWING EMBERS (ROCK WOOL)
TheWildreameappearancecanvaryduetodifferencesindraftandreplacecongurationsandemberplacement.After
installing rear (#1) and front logs (#2 and #3), cover the entire top surface of the vermiculite in the burner pan with the rock
wool supplied with unit. Tear the rock wool into pieces approximately 1/2" in size (roughly the size of a nickel) and cover
the burner evenly. Do no use more rock wool than the amount supplied with the unit. To enhance the appearance of the
Wildreame,itisrecommendedtoformamoundofrockwoolinthecenteroftheburner,2"to3"high,visiblethrough
the two front logs.
PLACEMENT OF DECORATIVE VOLCANIC ROCK
Sprinkle volcanic rock in front of front glowing embers and to both sides.
DO NOT SPRINKLE ON BURNERS, EMBER BED, PILOT OR LOGS.
IMPORTANT: Do not handle logs with your bare hands! Always wear gloves to prevent skin irritation
from ceramic bers. After handling logs, wash your hands gently with soap and water to remove any
traces of bers.
VWF18 MASSIVE OAK LOGS
1.Slide shield plate down back of burner pan. See Figure 17.
2.Centerrearlog#1ongratebarsandushwithrearofthegrate.See Figure 18.
Continued
Figure 17 - Sliding Shield Plate Down Back of
Burner Pan
Figure 18 - Centering Rear Log (#1) on Grate Bars
Burner
Pan
Shield
Plate
Rear Log (#1)

27D7300 15
3. Place front left log #2 on the front of the grate and to the left.
See Figure 19.
4. Place front right log #3 on the front of the grate and to the
right. See Figure 20.
NOTE: Allow 2" between the back log and the two
front logs.
5. Install left side middle log #4 as shown. See Figure 21.
6. Install right side middle log (#5). See Figure 22.
7. Install right top log #5 as shown. See Figure 23.
Front Left Log (#2)
Figure 19 - Placing Front Left Log (#2) on Grate
Figure 20 - Placing Front Right Log (#3) Figure 21 - Placing Left Middle Log (#4)
Figure 22 - Installing Right Side Middle Log (#5)
and Left Top Log (#7)
Front Right Log (#3)
Left Side Middle Log (#4)
Right Side Middle Log (#5) Right Top Log (#6)
Figure 23 - Installing Right Top Log (#6)
LOG PLACEMENT

16 27D7300
LOG PLACEMENT
VWF24 MASSIVE OAK LOGS
1. Slide shield plate down back of burner pan. See Figure 24.
2. Centerrearlog#1ongratebarsandushwithrearofthe
grate. See Figure 25.
3. Place front left log #2 on the front of the grate and to the left.
See Figure 26.
4. Place front right log #3 on the front of the grate and to the
right. See Figure 27.
NOTE: Allow 2" between the back log and the
two front logs.
5. Install left side middle log #4 as shown. See Figure 28.
Burner
Pan
Shield
Plate
Rear Log (#1)
Front Left Log (#2)
Figure 26 - Placing Front Left Log (#2) on Grate
Figure 27 - Placing Front Right Log (#3) Figure 28 - Placing Left Middle Log (#4)
Front Right Log (#3)
Left Side Middle Log (#4)
Figure 24 - Sliding Shield Plate Down Back of
Burner Pan
Figure 25 - Centering Rear Log (#1) on Grate Bars
Continued

27D7300 17
Figure 29 - Installing Right Side Middle Log (#5)
and Left Top Log (#29) Figure 30 - Installing Right Top Log (#30)
Right Side Middle Log (#5)
Left Top Log (#7) Right Top Log (#6)
6. Install right side middle log #5 as shown. See Figure 29.
7. Install left top log #7 as shown. See Figure 29.
8. Install right top log #6 as shown. See Figure 30.
LOG PLACEMENT
Continued
VWF30 MASSIVE OAK LOGS
1.Slide shield plate down back of burner pan. See Figure 31.
2.Centerrearlog#1ongratebarsandushwithrearofthegrate.See Figure 32.
Figure 31 - Sliding Shield Plate Down Back of
Burner Pan
Figure 32 - Centering Rear Log (#1) on Grate Bars
Burner
Pan
Shield
Plate Rear Log (#1)

18 27D7300
LOG PLACEMENT
VWF30 MASSIVE OAK LOGS (continued)
3. Place front left log #2 on the front of the grate and to the
left. See Figure 33.
4. Place front right log #3 on the front of the grate and to the
right. See Figure 34.
NOTE: Allow 2" between the back log and the two
front logs.
5. Install left middle log #4 as shown. See Figure 35.
6. Install right middle log #5 as shown. See Figure 36.
7. Install right top log #6 as shown. See Figure 37.
8. Install left top log #7 as shown. See Figure 38.
9. Install top crossover log #8 as shown. See Figure 39.
Front Left Log (#2)
Figure 33 - Placing Front Left Log (#2) on Grate
Figure 34 - Placing Front Right Log (#3) Figure 35 - Placing Left Middle Log (#4)
Figure 36 - Installing Right Middle Log (#5) Figure 37 - Installing Right Top Log (#6)
Figure 38 - Installing Left Top Log (#7) Figure 39 - Installing Top Crossover Log (#8)
Front Right
Log (#3)
Left Middle Log (#4)
Right Middle Log (#5) Right Top Log (#6)
Left Top Log (#7) Top Crossover Log (#8)

27D7300 19
LOG PLACEMENT
VWF36 MASSIVE OAK LOGS
1. Slide shield plate down back of burner pan. See Figure 40.
2. Centerrearlog#1ongratebarsandushwithrearofthegrate.
See Figure 41.
3. Place front left log #2 in front of the plate and to the left. See
Figure 42.
NOTE: Allow 2" between the back log and the front
left log.
4. Place center front log #3 on middle grate prong. See
Figure 43.
5. Place front right log #4 in front of the plate and to the right.
See Figure 44.
NOTE: Allow 2" between the back log and the right
front log.
Shield
Plate
Burner Pan
Figure 40 - Sliding Shield Plate Down
Back of Burner Pan
Rear Log (#1)
Figure 41 - Centering Rear Log (#1)
Front Left Log
(#2)
Figure 42 - Placing Front Left Log (#2)
Center Front Log (#3)
Figure 43 - Placing Center Front Log (#3) Figure 44 - Placing Right Front Log (#4)
Front Right Log (#4)
Continued

20 27D7300
LOG PLACEMENT
Left Side Log (#6)
Figure 45 - Installing Left Side Log (#6)
Right Side Middle Log (#7)
Figure 46 - Installing Right Side Middle Log (#7)
Right Side Log (#10)
Figure 47 - Installing Right Side Log (#10)
VWF36 MASSIVE OAK LOGS (continued)
6. Install left side log #6. See Figure 45.
7. Install right side middle log #7. See Figure 46.
8. Install right side log #10. See Figure 47.
9. Install top left middle log #8. See Figure 48.
10. Install top left log #9. See Figure 49.
11. Install top right log #11. See Figure 50.
12. Install top middle log #5. See Figure 51.
Top Left Middle Log (#8)
Figure 48 - Installing Top Left Middle Log (#8) Figure 49 - Installing Top Left Log (#9)
Top Left Log (#9)
Figure 50 - Installing Top Right Log (#11) Figure 51 - Installing Top Middle Log (#5)
Top Right Log (#11) Top Middle Log (#5)
