OPERATING AND MAINTENANCE MANUAL
ELECTRONIC DOUGHNUT JAMMER
ONLY FOR USE WITH SEEDLESS FILLINGS
MANUAL No.Y-DN-06E

FG053 -JAMMER 22-08-14 Rev A14
2

FG053 -JAMMER 22-08-14 Rev A14
3
Failure to adhere to the cleaning and maintenance
instructions detailed in this booklet could affect the
warranty of this machine
ONLY FOR USE WITH
SEEDLESS FILLINGS

FG053 -JAMMER 22-08-14 Rev A14
4
INDEX
1.0 INTRODUCTION
2.0 DIMENSIONS
3.0 SPECIFICATIONS
4.0 SAFETY
5.0 INSTALLATION
6.0 ISOLATION
7.0 CLEANING INSTRUCTIONS
8.0 OPERATING CONDITIONS
9.0 OPERATING INSTRUCTIONS
10.0 SETTING
11.0 MAINTENANCE
12.0 PROBLEM SOLVING
13.0 SPARES AND SERVICE
14.0 ELECTRICS

FG053 -JAMMER 22-08-14 Rev A14
5
1.0 INTRODUCTION
Mono’s electronic filler can fill doughnuts and pastries two at a time without mess or
waste. Fillings are precisely dispensed through dual nozzles in variable, preset
amounts.
To change fillings halfway through a run – just lift the filler unit from the console and
replace it with another unit containing the new filling.
Mono’s doughnut and pastry filler is simple to operate and programme – and really easy
to keep clean.
2.0 DIMENSIONS
Height (with hopper) 460mm (18”)
Height (without hopper) 205mm (8”)
Depth (including tray) 360mm (14”)
Wi th 390mm (15 ½”)

FG053 -JAMMER 22-08-14 Rev A14
6
3.0 SPECIFICATIONS
Weight (without filling) 10.5kg (23lbs)
Hopper capacity 9.1kg (20lbs)
Single elivery capacity 9.5gms to 907gms
(1/3oz to 2lbs)
These figures can vary depending on the filling used.
WARNING.
Only to be used with seedless jams and fillings
ELECTRICAL REQUIREMENTS
See serial plate for machine version.
240volt 1 phase 50Hz total power 60Watts 0.3amps
or
120volt 1 phase 50Hz total power 60Watts 1.5amps
NOISE LEVEL
Less than 85dB

FG053 -JAMMER 22-08-14 Rev A14
7
4.0 SAFETY
1.0 Always use the nearest available socket to the machine avoiding cables trailing across
the floor.
2.0 Plugs on flexible cables must be correctly connected and the cable secured by the
cord grip.
3.0 Flexible cables should be positioned and protected so that heavy equipment or
materials cannot damage them.
4.0 Cables should be checked regularly for damage (checks should be made with the
cable disconnected from the mains).
5.0 Damaged cables should be taken out of service straight away.
6.0 Do not carry out makeshift repairs to cables
7.0 Loose or damaged plugs must be replaced immediately.

FG053 -JAMMER 22-08-14 Rev A14
8
5.0 INSTALLATION
1The Mono electronic doughnut jammer should be plugged into a 13-amp wall socket.
2For best results the Electronic jammer should be used on a flat surface.
6.0 ISOLATION
TO STOP THE ELECTRONIC JAMMER IN AN
EMERGENCY SWITCH OFF
AT THE WALL SOCKET.

FG053 -JAMMER 22-08-14 Rev A14
9
7.0 CLEANING INSTRUCTIONS
ISOLATE FROM MAINS SUPPLY BEFORE CLEANING
1.0 The machine should be cleaned every day.
2.0 Empty filler hopper into a container and cover over for future use.
DO NOT TOP UP A HALF FULL CONTAINER.
3.0 Wash outside of filler unit and the entire lid with a mild detergent/sanitiser and hot
water.
4.0 Dismantle the pump unit at the base of the filler by removing the thumb screws (1)
that hold the pump to the chamber (2) .
5.0 Dismantle the pump chamber components as shown above and wash thoroughly.
6.0 Dry the components and reassemble the impellers (3) on the correct spindles with
the recessed side facing down.
DO NOT USE FORCE
7.0 Replace the impellor unit in the pump chamber ensuring the seal (4) is in place and
fasten with the thumb screws (1)
These screws should only be finger tight as the use of tools to over tighten could lead
to the chamber cover fracturing.
8.0 Wipe over all external surfaces with mild detergent/sanitiser and hot water.
Never immerse the base console in water.
1
2
3
4

FG053 -JAMMER 22-08-14 Rev A14
10
8.0 OPERATING CONDITIONS
1.0 For best results the electronic jammer should be placed on a level surface
at a normal work top height.
2.0 All cleaning and operation instructions should be followed meticulously.
3.0 Never immerse the base console in water.
9.0 OPERATING INSTRUCTIONS
1.0 Plug the socket of the moulded cable assembly into the rear of the base console.
2.0 Insert the plug of the cable into a 13amp wall socket.
3.0 Press the green “ON” area (1) on the membrane panel and the display will show zero.
4.0 Clip actuator tray (2) to centre support bar (3).
5.0 Insert each nozzle (4) into the filler unit (5) with the flat of the plastic ring facing down.
When the nozzle has been inserted as far as the ring , twist it through 90 degrees.
6.0 Place the filled hopper unit against the rear wall of the base console.
Lower the unit into place.
If any difficulty is experienced in locating the hopper onto the drive, press blue
“FAST FORWARD” on the membrane panel to advance the digital display to any
number. Then touch the actuator tray to cycle the hopper drive which will allow the
hopper to drop into place.
The machine is now ready for use
1
5
4
2 3

FG053 -JAMMER 22-08-14 Rev A14
11
10.0 SETTING
1.0 Press the green panel (1) on the membrane to activate the display.
2.0 Press the blue panel (2) to move the display to the required number.
Or
Press the blue panel (3) to move the display by one digit at a time.
(To set back to zero turn off (4) and back on (1)
NOTE
THE FIGURES ON THE DISPLAY DO NOT REFER TO ANY QUANTITY OR TIME
BUT ARE FOR REFERANCE PURPOSES. When the correct settings for each
product are found it is suggested they are noted down for future reference.
3.0 By pushing the products onto the nozzles and against the actuator tray an exact
amount of filling will be delivered time after time.
When finished the machine is turned off by pressing the red (4) panel.
Be aware that if the actuator tray is operated, filling will be dispensed out of the nozzles
ON
OFF
FAST FORWARD
FORWARD 1 DIGIT
1
4
2
3
DISPLAY

FG053 -JAMMER 22-08-14 Rev A14
12
11.0 MAINTENANCE
By keeping the machine cleaned after every use it should operate
smoothly, hygienically and economically.
No other maintenance should be required.

FG053 -JAMMER 22-08-14 Rev A14
13
12.0 PROBLEM SOLVING
NO JAM DELIVERED
1.0 Check lead is plugged into the machine and the power socket.
2.0 Check that there is filling in the hopper
3.0 Check that the filling is not solid.
NOTE – Always break down jam from its jell state and only use seedless jam
and fillings.
4.0 Check that the read out is not set to “0”
If machine still has a problem please contact Mono Service Dept.
JAM LEAKS FROM HOPPER BASE
1.0 Check that the pump plate seal (1) has not been left out after cleaning.
2.0 Check that pump assembly is not damaged.
3.0 Check that the thumbscrews (2) are tight but not over-tight (finger-tight only)
If machine still has a problem please contact Mono Service Dept. (see last page).
2
1
1

FG053 -JAMMER 22-08-14 Rev A14
14
13.0 SPARES AND SERVICE
If a fault arises please contact MONO customer service dept.
(see last page of manual)

FG053 -JAMMER 22-08-14 Rev A14
15
14.0
ELECTRICAL INFORMATION

FG053 -JAMMER 22-08-14 Rev A14
16

FG053 -JAMMER 22-08-14 Rev A14
17

FG053 -JAMMER 22-08-14 Rev A14
18
.
