Monogram ZV48R User manual

INSTALLATION
INSTRUCTIONS
30”, 36” and 48”
Professional Restaurant Style
Vent Hoods
Monogram.com

249-80152 Rev. 8
Safety Information
READ AND SAVE THESE INSTRUCTIONS
BEFORE YOU BEGIN
Read these instructions completely and carefully.
■IMPORTANT — Save these instructions
for local inspector’s use.
■
IMPORTANT — Observe all governing
codes and ordinances.
■Note to Installer — Be sure to leave these
instructions with the Consumer.
■Note to Consumer — Keep these instructions with
your Owner’s Manual for future reference.
■Skill Level — Installation of this appliance requires
basic mechanical and electrical skills.
■Completion Time — 1 to 3 Hours.
■Properinstallationistheresponsibilityofthe
installer.Productfailureduetoimproperinstallation
is not covered under the warranty.
■ForMonogramlocalserviceinyourarea,call
1.800.444.1845.
■ForMonogramserviceinCanada,call
1.800.561.3344.
■ForMonogramPartsandAccessories,call
1.800.626.2002.
CAUTION Due to the weight and size of these
vent hoods and to reduce the risk of personal injury
ordamagetotheproduct, TWO PEOPLE ARE
REQUIRED FOR PROPER INSTALLATION.
WARNING To reduce the risk of fire or electrical
shock,donotusethisrangehoodwithanyexternal
solid-statespeedcontroldevice.Anysuchalteration
from original factory wiring could result in damage to
the unit and/or create an electrical safety hazard.
TO REDUCE THE RISK OF FIRE, USE ONLY
METAL DUCTWORK.
WARNING TOREDUCETHERISKOFFIRE,
ELECTRICALSHOCKORINJURYTOPERSONS,
OBSERVETHEFOLLOWING:
A.Usethisunitonlyinthemannerintendedbythe
manufacturer.Ifyouhaveanyquestions,contact
the manufacturer.
B.Beforeservicingorcleaningtheunit,switchthe
power off at the service panel and lock the service
disconnecting means to prevent the power from
beingswitchedonaccidentally.Whentheservice
disconnectingmeanscannotbelocked,securely
fastenaprominentwarningdevice,suchasatag,
to the service panel.
CAUTION FORGENERALVENTILATINGUSE
ONLY.DONOTUSETOEXHAUSTHAZARDOUS
MATERIALS,EXPLOSIVEMATERIALSORVAPORS.
WARNING TOREDUCETHERISKOFFIRE,
ELECTRICALSHOCKORINJURYTOPERSONS,
OBSERVETHEFOLLOWING:
■Installationworkandelectricalwiringmustbedoneby
qualified person(s) in accordance with all applicable
codesandstandards,includingfire-ratedconstruction.
■Sufficientairisneededforpropercombustionand
exhaustingofgasesthroughtheflue(chimney)offuel
burningequipmenttopreventback-drafting.Follow
the heating equipment manufacturer’s guidelines
andsafetystandards,suchasthosepublishedby
theNationalFireProtectionAssociation(NFPA),the
AmericanSocietyforHeating,RefrigerationandAir
ConditioningEngineers(ASHRAE)andthelocalcode
authorities.Whenapplicable,installanymakeup
(replacement) air system in accordance with local
building code requirements. Visit GEAppliances.com
for available makeup air solutions.
■Whencuttingordrillingintowallsorceilings,donot
damage electrical wiring and other hidden utilities.
■Ductedsystemsmustalwaysbeventedtotheoutdoors.
■Localcodesvary.Installationofelectrical
connections and grounding must comply with
applicablecodes.Intheabsenceoflocalcodes,the
ventshouldbeinstalledinaccordancewithNational
ElectricalCodeANSI/NFPA70-1990orlatestedition.
CAUTION To reduce risk of fire and to properly
exhaustair,besuretoductairoutside—donotvent
exhaustairintospaceswithinwallsorceilingsorinto
attics,crawlspacesorgarages.

49-80152 Rev. 8 3
Installation Instructions
CONTENTS
Safety Information ......................................................... 2
ProductDimensions ...................................................... 3
Installation Clearances .................................................. 4
OptionalDuctCoverAccessories ................................. 4
InstallationHeight,DuctCoverAccessories ................. 5
AdvancePlanning ......................................................... 6
PowerSupply ................................................................ 6
DuctFittings .................................................................. 7
Tools and Materials Required ....................................... 7
RemovethePackaging ................................................. 8
PartsProvided............................................................... 8
Step1,DetermineDuctworkandWiringLocations ...... 9
Step2A,InstallHoodOntoWall ................................. 10
Step2B,InstallHoodBeneathSoffit........................... 11
Step3,ConnectDuctwork .......................................... 12
Step4,ConnectElectrical........................................... 12
Step5,InstallDuctCovers.......................................... 12
Step6,InstallMotor .................................................... 12
Step7,InstallFilters.................................................... 13
Step8,InstallBackguardandShelf............................ 13
Step9,InstallShelfOnly............................................. 14
Step10,InstallImplementRods ................................. 14
PRODUCT DIMENSIONS
Each hood is
shipped with a
stainless steel
backguard and
a warming shelf.
Hoods may be
installed with
the shelf or
backguardalone,
or with both as
shown.
ModelZV36R
ModelZV48R
ModelZV30R
Warming
Shelf
Backguard
1” = 2.5 cm; 1’ = 0.3 m

449-80152 Rev. 8
Advance Planning
INSTALLATION CLEARANCES
These vent hoods are designed to be installed onto a
wall or beneath a soffit or cabinet.
Installation with Warming Shelf
■Hoodsmustbeinstalled32”min.,38”max.overany
type cooking surface when warming shelf is used.
Installation without Warming Shelf
■Installthesehoods30”min.to36”max.above
the cooking surface when installed over any
professional style cooktop or range.
■Thesehoodsmaybeinstalled24”min.aboveagas
or electric drop-in style cooktop.
NOTE: Clearances may vary due to type of cooking
product and local codes. Check with local inspectors
to be sure standard is applicable.
In this installation the ductwork running from the top
of the hood will be concealed in the soffit or upper
cabinetry.
Forthisinstallation,adecorativeductcoverisavailable
to conceal the ductwork running from the top of the hood.
Use of the duct cover requires special consideration to
the installation height above the countertop.
OPTIONAL DUCT COVER
ACCESSORIES
Standard decorative duct covers are available in 6"
and12"heights.Ductcoversmaybestacked,in
variouscombinations,toconcealtheductworkrunning
from the top of the hood to the ceiling.
■Beforeyoubegin,youshoulddeterminethe
installation height of the hood and order the
correct size duct cover. The duct covers should
be ordered at the same time as the vent hood and
be on site before installation. Order the duct cover
corresponding to your model.
6" Duct Cover
12" Duct Cover
Standard Duct Covers
6" Duct Covers
Hood Model 6” Duct Cover Dimensions
ZV48R ZX48DC6 6"Hx19-11/16"Wx11-7/8"D
ZV36R ZX36DC6 6"Hx15-3/4"Wx11-7/8"D
ZV30R ZX36DC6 6"Hx15-3/4"Wx11-7/8"D
12" Duct Covers
Hood Model 12” Duct Cover Dimensions
ZV48R ZX48DC12 12"Hx19-11/16"Wx11-7/8"D
ZV36R ZX36DC12 12"Hx15-3/4"Wx11-7/8"D
ZV30R ZX36DC12 12"Hx15-3/4"Wx11-7/8"D
Install these hoods 30" min. to
36"max.overaprofessional
style cooktop or range.
Allow32"min.and36"max.
clearance above any cooking
surface when installed with shelf.
SOFFIT
SOFFIT
Soffit Installation
32" Min.
38" Max.
30" Min.
36" Max.
Wall Mount Installation
32" Min.
38" Max.
30" Min.
36" Max.
Install these hoods 30" min. to
36"max.overaprofessional
style cooktop or range.
Allow32"min.and36"max.
clearance above any cooking
surface when installed with shelf.
1” = 2.5 cm; 1’ = 0.3 m

49-80152 Rev. 8 5
Advance Planning
DETERMINE INSTALLATION HEIGHT, DUCT COVER ACCESSORIES
These vent hoods must be installed
30”min.to36”max.abovethe
standard 36” high cooking surface.
Wheninstalledwiththewarming
shelf,allow32”min.to38”max.
clearance.Theexacthood
installation height is determined by
the ceiling height.
1.Measuretheexactceilingheight.
2. Review the chart at right to
determine the range of possible
hood installation heights that can
be accomplished with one or
more duct covers.
3. Increase or decrease hood
installation height to accommodate
thefixed6”or12”ductcovers.
4.Ductcoversmaybestacked,in
variouscombinations,toreach
ceiling heights.
NOTE:Whendeterminingthe
installationheight,consideration
must be given to the use of the
warming shelf.
*Based on 36" countertop height.
NOTE:Additionalductcoversmaybeusedtoreachhigherceilings.
Restaurant-Style Hoods without
Warming Shelf Installed
Restaurant-Style Hoods with Shelf
Installed
Actual
Ceiling
Height
*Possible
Hood
Installation
Height
6” Duct
Covers
12” Duct
Covers
*Possible
Hood
Installation
Height
6” Duct
Covers
12” Duct
Covers
7'11" 31" 1 1 37" 1
8'0"
8'0" 32" 1 1 32"
38" 11
1
8'1" 33" 1 1 33" 1 1
8'2" 34" 1 1 34" 1 1
8'3" 35" 1 1 35" 1 1
8'4"
8'4"
30"
36" 1
2
1 36" 1 1
8'5" 31" 2 37" 1 1
8'6"
8'6" 32" 2 32"
38" 1
2
1
8'7" 33" 2 33" 2
8'8" 34" 2 34" 2
8'9" 35" 2 35" 2
8'10"
8'10"
30"
36" 12
2 36" 2
8'11" 31" 1 2 37" 2
9'0"
9'0"
32" 1 2 32"
38" 12
2
9'1" 33" 1 2 33" 1 2
9'2" 34" 1 2 34" 1 2
9'3" 35" 1 2 35" 1 2
9'4"
9'4"
30"
36" 1
3
2 36" 1 2
9'5" 31" 3 37" 1 2
9'6"
9'6" 32" 3 32"
38" 1
3
2
9'7" 33" 3 33" 3
9'8" 34" 3 34" 3
9'9" 35" 3 35" 3
9'10" 30"
36" 13 3 36" 3
9'11" 31" 1 3 37" 3
10'0"
10'0" 32" 1 3 32"
38" 13
3
32" Min.
38" Max.
30" Min.
36" Max.
10"
Duct Cover(s)
Duct Cover(s)
10"
Ceiling
Height
to Floor
Ceiling
Height
to Floor
1” = 2.5 cm; 1’ = 0.3 m

649-80152 Rev. 8
Advance Planning
ADVANCE PLANNING
Ductwork Planning
■Theseventhoodsareequippedfor10”round
ductwork.Forbestperformance,use10”round
ductwork on the 48” wide hoods. 30” and 36” hoods
may be transitioned to 8” round.
■Thishoodmaybeventedverticallythroughupper
cabinets,soffitorceiling.Aducttransitionpieceis
suppliedforverticalexhaust.Uselocallysupplied
elbows to vent horizontally through the rear wall.
■Determinetheexactlocationoftheventhood.
■Plantherouteforventingexhausttotheoutdoors.
■Usetheshortestandstraightestductroutepossible.
Forsatisfactoryperformance,ductrunshould
notexceed150ft.equivalentlengthforanyduct
configurations.
■Referto“DuctFittings”charttocomputethe
maximumpermissiblelengthforductrunstothe
outdoors.
■Usemetalductworkonly.
■Installawallcaporroofcapwithdamperatthe
exterioropening.Orderthewallorroofcapandany
transition needed in advance.
■Whenapplicable,installanymakeup(replacement)
air system in accordance with local building
code requirements. Visit GEAppliances.com for
available makeup air solutions.
Wall Framing for Adequate Support
■Theseventhoodsareheavy.Adequatestructural
support must be provided. Hoods must be secured
to vertical studs in the wall.
■Itisstronglyrecommendthattheventhoodwith
duct cover be on site before final framing and wall
finishing. This will also help to accurately locate the
ductwork and electrical service.
Decorative Duct Covers
Decorativeductcovers,6”and12”high,areavailable
to fit all models. The duct cover conceals the ductwork
running from the top of the hood to the ceiling or
soffit. Stack one or more duct covers over the top of
the hood to reach your ceiling height.
POWER SUPPLY
IMPORTANT - (Please read carefully)
WARNING FORPERSONALSAFETY,THIS
APPLIANCEMUSTBEPROPERLYGROUNDED.
Remove house fuse or open circuit breaker before
beginning installation.
Donotuseanextensioncordoradapterplugwith
thisappliance.FollowNationalelectricalcodesor
prevailing local codes and ordinances.
Electrical supply
Theseventhoodsmustbesuppliedwith120V,60Hz,
andconnectedtoanindividual,properlygrounded
branchcircuit,andprotectedbya15or20ampcircuit
breaker or time delay fuse.
■Wiringmustbe2wirewithground.
■Iftheelectricalsupplydoesnotmeettheabove
requirements,callalicensedelectricianbefore
proceeding.
■Routehousewiringasclosetotheinstallation
location as possible on the back wall or ceiling.
■Connectthewiringtothehousewiringin
accordance with local codes.
Grounding instructions
The grounding conductor must be connected to
agroundmetal,permanentwiringsystem,oran
equipment-grounding terminal or lead on the hood.
WARNING The improper connection of the
equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or
service representative if you are in doubt whether the
appliance is properly grounded.
1” = 2.5 cm; 1’ = 0.3 m

49-80152 Rev. 8 7
Advance Planning
Installation Preparation
DUCT FITTINGS
Hoods Are Equipped
For 10" Round Duct
Usethischarttocomputemaximumpermissiblelengths
for duct runs to outdoors.
Forbestresults,use10"diameterduct.
NOTE:Donotexceedmaximumpermissibleequivalent
lengths!
Maximum recommended duct
length for these hoods: 150 feet
Flexible ducting
Ifflexiblemetalductingisused,alltheequivalentfeet
valuesinthetableshouldbedoubled.Theflexiblemetal
ductshouldbestraightandsmoothandextendedas
much as possible.
DoNOTuseflexibleplasticducting.
NOTE:Anyhomeventilationsystem,suchasa
ventilationhood,mayinterrupttheproperflowof
combustionairandexhaustrequiredbyfireplaces,gas
furnaces,gaswaterheatersandothernaturallyvented
systems. To minimize the chance of interruption of such
naturallyventedsystems,followtheheatingequipment
manufacturer’s guidelines and safety standards such
asthosepublishedbyNFPAandASHRAE.When
applicable,installanymakeup(replacement)airsystem
in accordance with local building code requirements. Visit
GEAppliances.com for available makeup air solutions.
TOOLS AND MATERIALS REQUIRED
(NOT SUPPLIED)
Duct Piece Dimensions
Equivalent
Length*
Quantity
Used
Total
Equivalent
Length
10" round
to 8" round
5 ft.
Round,
straight
1 ft. (per foot
length)
90°elbow 8”Dia.17ft.
10” Dia. 24 ft.
45°elbow 8” Dia. 10 ft.
10” Dia. 14 ft.
Round wall
cap with
damper
8” Dia. 32 ft.
10” Dia. 41 ft.
Round roof
cap
8” Dia. 44 ft.
10” Dia. 56 ft.
*Hoods are supplied with a 10” round transition.
Alocallysuppliedtransitionisrequiredfor
other sizes.
NOTE:Outletontopofhoodis8-1/8”x8”.
*Actuallengthofstraightductplusductfitting
equivalent. Equivalent length of duct pieces
arebasedonactualtestsconductedbyGE
AppliancesEvaluationEngineeringandreflect
requirements for good venting performance
with any ventilation hood.
Total Duct Run
Pencilandtapemeasure
Pliers
Pliers
Electric or battery operated drill
and1/8",3/8"bits
120V60Hz.15or20Amp,
2-wirewithground.Properly
grounded branch circuit.
Electrical Cable
Key Hole Saw
Key Hole Saw
Hammer
Wire Cutter/Stripper
Wirecutter/
stripper
Step ladder
Ladder
Metal Snips
Metal Snips Saber saw
or Sawzall
Saber Saw
Wirenuts
Wire Nuts
Phillipsandflat
blade screwdrivers
Strain relief for
junction cover.
Strain Relief I
Spirit level
Level 2
Flashlight
Safety glasses
Safety Glasses
762Dia5
10" round metal
duct,lengthto
suit installation.
Duct tape
Duct Tape
1” = 2.5 cm; 1’ = 0.3 m

849-80152 Rev. 8
Installation Preparation
REMOVE THE PACKAGING
■Removepackages
from the "V" shaped
cardboard section.
Remove shipping pads.
■Liftthehoodoutofthebox.
IMPORTANT: Lift the hood
by grasping the outside
edgesoftheexhaust
opening on the top.
■Theventhoodmotor
is shipped secured to
the skid with 4 screws.
Locate and remove 2
screws on each side of
the motor. Discard the
shipping skid and screws.
■Greasefiltersmustbe
removed.Graspthe
latch,pullthefilterup
and lift out.
■Lifttoremovethe
grease trays. Set
grease filters and trays aside
forlaterinstallation.DONOT
DISCARD.
■Fromtheinsideofthehood,
loosen (do not remove) the
2 screws holding the wood
mounting support to the back of
the hood. The screws should be backed out of the wood
to 1/4". Remove the set aside the mounting support with
screwsforlaterinstallation.DONOTDISCARD.
■Removetapeandpackingmaterialfromthehoodand
all supplied parts.
Hood Parts
Wood
Mounting
Support
Motor
Mounted
on Skid
Shipping Carton
Duct
Transition
PARTS PROVIDED
Locate the parts packed with the hood.
HARDWARE PACKAGE
Locate and check contents.
Screws shown actual size.
2StainlessSteelGreaseFilters
(3 filters with 48" models)
AllenWrench
ForImplementRods
Duct Transition
with Damper
Backguard
2 Implement Rods
and 4 Stand-offs
GreaseTray
Heat Lamp
(2 with 48" models)
761Dia28
490Dia57
490Dia66
WoodSupport
with Original Screws
WarmingShelf
761Dia30
2 shoulder screws
to secure shelf to
bottom of hood.
2Phillipshead
machine screws
to secure shelf to
bottom of hood.
10Phillipsheadscrews:
Use 6 to secure hood to
thewoodsupport:(2are
secured to wood support)
Use 2 to secure 30" and 36"
backguards to wall. Use 4 to
secure a 48" backguard.
4Phillipsheadscrewsto
secure the transition to the
hood outlet on the top
6 (3/16") hollow wall
anchorswithscrews,
use 2 to secure
hood to the wall at
the bottom. Use 4 to
secure backguard
and shelf.
4 screws to secure the
wood support to the wall
POZIDRIV3
1hexheadscrewand
lockwasher,tosecure
the blower
658Dia9
2 flat washers
for wall anchors
1” = 2.5 cm; 1’ = 0.3 m

49-80152 Rev. 8 9
Installation Instructions
1DETERMINE HOOD, DUCTWORK AND WIRING LOCATIONS
■Usealeveltodrawthecooktopcenterlinelocation.
Draw the line to ceiling height.
■Measuredesireddistancefromthebottomofthehood
to the cooking surface.
NOTE:Ifyouareinstallingthehoodwithductcovers,
besuretoread“UsingDuctCoverAccessories”page4.
Exactinstallationheightmaybedeterminedbyuseof
one or more duct covers.
■Determinebottom
of hood location
(DimensionA)by
subtracting 12-1/2”
from the desired
installation height.
■Usealeveltodraw
a straight horizontal
pencil line indicating
the bottom of the
hood.
■Fromthelineindicatingthebottomofthehood,
measure 20” up and draw another line for the location
of the wood support. See illustration.
FOR VERTICAL (Straight Up) DUCTING
■Usealeveltodrawacenterlinefromthebottomofthe
hood to ceiling or soffit.
■Ifventingouttheceiling,extendthecenterlineforward
on the ceiling or soffit.
■Locatethecenterlineofa10-1/2”holeontheceiling
or soffit by measuring 6” from the wall.
FOR DUCTING THROUGH REAR WALL
■Measure9-7/8”abovethemarkedlineforthetopof
thehood.Atthecenterline,marklocationfora10-1/2”
diameter hole.
*See recessed
location below.
Top of Hood
Bottom of Hood
22-1/2"
20"
Wood
Support
*House Wiring
Location
Dimension A
Cooking Surface
9-7/8"
House Wiring Location
■Thejunctionboxisfastenedtothebackofthehood
on the right side.
■Therecessedbacksideofthehoodprovidesalarge
areaforthehousewiringtoexitthewallandberouted
totherearknockoutandjunctionbox.
■Thelocationforthehousewiringdependsonthe
installation height of the hood and the width of the hood.
■Removejunctionboxcoverandknockout.Install
strain relief.
Alternate Knockout Locations
Iftheinstallationrequires,thejunctionboxcanbe
relocated from the back to the top of the hood. Remove
3screws,alignboxtotopknockoutandsecurewith
original screws.
■Removejunctionboxcoverandknockout.Installstrain
relief.
14-1/4"
14" for 48" Models
8" for 36" Models
5" for 30" Models
Electrical
Area
6-1/2"
18-1/16" for 48" Models
12-1/16" for 36" Models
9-1/16" for 30" Models
Dim. A
Installation
Height
1” = 2.5 cm; 1’ = 0.3 m

10 49-80152 Rev. 8
Installation Instructions
2A INSTALL HOOD ONTO WALL
SKIP THIS STEP IF INSTALLING BENEATH A
SOFFIT OR CABINET, GO TO STEP 2B.
■Locateatleast2verticalstudsatthewoodsupport.
■Centerthesuppliedwoodsupport,lefttorightand
below the 20" marked line.
■Securethewoodsupportto2ormoreverticalstuds,
using at least 2 of the 4 supplied long screws.
IMPORTANT: Screws must penetrate at least 1-1/2" into
vertical studs. Countersink screws into support.
NOTE: The mounting screws must remain in their
original shipping location. These screws are positioned
to engage the keyhole slots in the back of the hood.
■Adjustdepthoforiginalmountingscrewsinthewood
support until they protrude 1/4" forward. This 1/4" gap
will provide clearance to hang the hood.
IMPORTANT:Framingmustbecapableof
supporting up to 150 lbs.
Install Transition Onto Top of Hood
IMPORTANT: Remove
shipping tape from damper
and check that damper
moves freely.
■Placetheducttransition
piece over the hood
exhaustandsecurewith
4 screws provided.
■Useducttapetosealtheconnection.Checktobe
sure the damper moves freely.
Hang Hood On Wood Support
■Liftthehoodandholdclosetotheinstallationlocation.
Route house wiring through the knockout and into the
junctionbox.
■Placethehoodoverthewoodsupport.Besurethe
mounting screws engage the keyhole slots in the back
of the hood. Tighten the screws.
WARNING
Continue to provide additional support
while the hood is mounted with only these 2 screws.
These screws will not support the weight of the hood. The
hood could fall resulting in damage or personal injury.
■Checktobesure
the hood is level
and centered.
Test Duct Cover Fit
■Placeductcover(s)
over the top of the
hood to check for
gaps.Adjustthe
hood up or down if
necessary.
Install Bottom Mounting Screws
■Drill1/8"pilotholesintothetwolowermounting
holes. Enlarge the holes if they did not enter studs
to 3/8". Insert anchors for wall fasteners into bottom
holes. Remove anchor screws and add flat washers
provided. Drive screws into anchors and tighten.
■Install4additionalscrewsthroughthebackofthe
hood and into the wood support.
Centerline of
Installation
Space
20"
Bottom
of
Hood
Wood
Support
1/4"
Gap
Original Mounting
Screws as Shipped
Duct
Transition
Top of
Hood
Centerline of
Installation
Space
Bottom
Mounting
Holes
30"
to
36"
1” = 2.5 cm; 1’ = 0.3 m

49-80152 Rev. 8 11
Installation Instructions
2B Alternate Mounting Method
INSTALL HOOD TO SOFFIT OR
BENEATH CABINETS
SKIP THIS STEP IF USING WALL MOUNTING
METHOD
Whennecessary,thehoodmaybeinstalledsothatitis
supported by the soffit.
■Thesoffitshouldbeconstructedwith2x4’s.
■Determinetheinstallationlocationonthewall.
■Continuethecenterlineforwardonthebottomofthe
cabinet or soffit.
■Theopeningabovethehoodshouldallowforthe
10" round duct and clearance to slide the hood back
against the wall.
■The2x4studsmustbelocatedasshowninthe
chart,Dim.A.toacceptmountingscrews.
■Drill1/8"pilotholesintothestudsatthelocations
shown in the top view illustration.
IMPORTANT: Soffit framing must be capable of
supporting up to 150 lbs.
Install Transition Onto Top of Hood
IMPORTANT: Remove
shipping tape from damper
and check that damper
moves freely.
■Placethetransitionpiece
overthehoodexhaust
and secure with 4 screws
provided.
■Useducttapetosealtheconnection.Checktobe
sure the damper moves freely.
Mount Hood onto Soffit or Cabinet
NOTE: If mounting to the underside of a cabinet with a
recessedbottom,installshimstofillthegap.
■Drivemountingscrewsintothestudsuntilthey
protrude 1/4". The 1/4" gap will provide clearance to
engage the keyhole slots in the top of the hood.
■Lifthoodtoinstallationposition.Locatehousewiring
and route through the knockout (from the back or top
of the hood).
■Lifthoodontomountingscrews.Slidebackagainstthe
rear wall.
■Tightenmountingscrews.
IMPORTANT:Foradditionalsupportandto
minimizevibrationduringoperation,thehoodmust
be secured to the back wall. Use wall anchors to
fasten bottom back of hood to the wall.
A
Requires 10-1/2" Min.
Opening For Ductwork
and Hood Installation
A
“A” Centerline to Stud
and Keyhole Slots
“B” Hood Width At
the Top
ZV48R 23-9/16" 47-15/16"
ZV48R 17-9/16" 35-15/16"
ZV36R 14-9/16" 29-15/16"
2"
7-1/2"
A
B
2-9/16"
8"
8-1/8"
6"
Back of Hood
Top View
Front of Hood
Duct
Transition
Top of
Hood
1/4" Gap
Push Back
to Wall
Add Shims
If Bottom
Is Recesse
d
Back
Wall
Soffit
Engage Top
Keyhole Slots
1” = 2.5 cm; 1’ = 0.3 m

12 49-80152 Rev. 8
Installation Instructions
3CONNECT DUCTWORK
■Installductwork,makingconnectionsindirectionof
airflow as illustrated.
■Securejointsinductworkwithsheetmetalscrews.
■Wrapallductjoints
with duct tape for an
airtight seal.
■Useducttapeto
seal the flange
connection. Reach
inside the hood and
push the damper up
to be sure it moves
freely.
5INSTALL DUCT COVERS
NOTE: Foreasierhandling,removecardboardinsert
after film is peeled off.
Remove protective film from duct covers. If more than
oneductcoverisused,secureeachpiecetogether
with screws provided.
■Placetheductcover(s)ontopofthehood.
■Frominsidethehood,securetheductcovertothe
topwiththesmallPhillipsheadscrewssupplied
with the covers.
6INSTALL MOTOR
■Fromtheinsideofthehood,slipmotorintothe
attachment slot on the left.
■Rotatemotorupwardsuntilitsnapsintothespring
clip on the right.
■Securethemotortothehoodwiththemachine
screw and lock washer. (Screw is marked with red
or blue paint.)
■Plugconnectorintothemotor.
IMPORTANT: Connector ends are designed to mate
only one way. Match flat and round connectors as
shown.
4CONNECT ELECTRICAL
Verify that power is turned off at the source.
WARNING If house wiring is not 2-wire with
agroundwire,agroundmustbeprovidedbythe
installer.Whenhousewiringisaluminum,besure
touseU.L.approvedanti-oxidantcompoundand
aluminum-to-copper connectors.
■Usewirenutstoconnectincominggroundtogreen,
white to white and black to black.
■Pushwiresintojunctionboxandreplacecover.Be
sure wires are not pinched.
Screw
Duct Tape
Over Seam
and Screw
Air Flow
Duct Tape
Over Transition
White
Ground Black
Remove
Junction Box
Cover
Insert Power
Conduit Thru
Strain Relief
and Tighten
Use UL Listed
Wire Nuts
AB
C
Top
Attachment
Screw
Spring
Clip
Spring
Clip
Outlet
Attachment
Slot
1” = 2.5 cm; 1’ = 0.3 m

49-80152 Rev. 8 13
Installation Instructions
7INSTALL FILTERS
■Dropgreasetrayintothehood.Thereartabsshould
engage the slots in the hood track.
■Insertthegreasefilterintotheopeninganddropinto
the bottom. Raise filter to the top and lock into place.
■Toremovethefilters,graspthehandle,pushthefilter
up and lift out.
8INSTALL BACKGROUND AND SHELF
INSTALL BACKGUARD
■Removepackaging.
■Placebackguardagainstthebottomofthehoodto
useasatemplate.Markupperscrewlocations"A"
and "B".
■Removebackguard.
■Drillfour1/8"pilotholesatscrewlocations"A"and"B".
■Ifdrilldidnotenterstuds,enlargetheholesto3/8".
■Insertthewallanchorsintotheenlargedholes.
Remove screws from the wall anchors.
■Alignandsecurethebackguardtothewallusing2
wallanchorscrewsorwoodscrewsinlocations"A".
■For30"and36"models,install2screwsthroughhole
locations"C"atthebottomofthebackguard.For48"
models,install4screws.
■Ifinstallingthebackguardalone,withouttheshelf,
drive screws in all locations shown.
This hood can be installed with the warming shelf
and backguard together or with the warming shelf or
backguard alone.
INSTALL SHELF OVER BACKGUARD
■Installtwoshoulderscrewsintoholes"D"inthe
bottom of hood flange leaving 1/8" gap.
■Removeshelfpackagingandprotectivefilm.
■Engageshoulderscrewsintothekeyholeslotsinthetop
of the shelf. Slide shelf towards the left to lock into place.
■Installtwo3/4"longmachinescrewsthroughthebottom
oftheshelfintothebottomhoodflange,location"E".
■Installanchorscrewsthroughtheshelfandintothewall
holes "B".
■Removeallprotectivefilm.
Mounting
Holes for
Backguard (A, C)
and Shelf (B)
C
BACKGUARD
A
A
B
B
1/8"
Gap
D
B
E
DE
B
1” = 2.5 cm; 1’ = 0.3 m

14 49-80152 Rev. 8
Installation Instructions
9INSTALL SHELF "ONLY"
■Removeshelfpackagingandprotectivefilm.
■Ifinstallingtheshelfalone,withoutthebackguard,
place shelf against the bottom of the hood and mark
the screw hole locations "B" on the wall.
■Drilltwo1/8"pilotholes.
■Ifthedrilldidnotenterthestuds,enlargeholesto3/8".
■Insertthewallanchorsintotheenlargedholes.
Remove the screws from the wall anchors.
■Install2shoulderscrewsintoholes"D"inthe
bottom of the hood flange leaving 1/8" gap.
■Engageshoulderscrewsintothekeyholeslotsin
the top of the shelf. Slide the shelf towards the left
to lock into place.
■Installtwo3/4"longmachinescrewsthroughthe
bottom of the shelf into the bottom hood flange
location "E".
10 INSTALL IMPLEMENT RODS
■Useaflatbladescrewdrivertoinstallthestand-offs
into the bottom of the hood.
■Aligntheimplementrodtothestand-offswiththe
screw hole towards the inside of the hood. Secure the
rodtothestand-offswiththesuppliedAllenwrench.
■Followthesameprocedureontheoppositeside.
FINALIZE INSTALLATION
■Installthesuppliedinfraredbulb(s).
■SeetheOwner’sManualforinstructionstotest
operation.
1/8"
Gap
D
E
Mounting
Holes
for Shelf (B)
DE
B
B
Screw
Stand-offs
Into
Hood
Use Allen
Wrench to
Secure Rod
to Stand-offs
1” = 2.5 cm; 1’ = 0.3 m

49-80152 Rev. 8 15
Notes

NOTE:Whileperforminginstallationsdescribedinthis
book,safetyglassesorgogglesshouldbeworn.
ForMonogram®localserviceinyourarea,call
1.800.444.1845.
NOTE:Productimprovementisacontinuingendeavor
atGEAppliances.Therefore,materials,appearance
and specifications are subject to change without notice.
49-80152Rev.8
05-19GEA
PrintedinMexico

INSTRUCTIONS
D'INSTALLATION
Hottes professionnelles de type
restaurant de 30po, 36po et 48po
Monogram.com
TOUT ÉLEVER

249-80152 Rév. 8
Consignes de sécurité
LISEZ ET CONSERVEZ CES INSTRUCTIONS
AVANT DE COMMENCER
Lisez attentivement toutes ces instructions.
■IMPORTANT – Conservez ces instructions
pour l'inspecteur local.
■IMPORTANT – Respectez tous les codes et
règlements en vigueur.
■Remarque destinée à l'installateur – Assurez-vous de
laisser ces instructions au consommateur.
■Remarque destinée au consommateur – Conservez
ces instructions avec votre Manuel de l'utilisateur pour
vous y reporter ultérieurement.
■Niveau de compétence – L'installation de cet appareil
nécessite des compétences de base en mécanique et
en électricité.
■Durée de l'installation – 1 à 3 heures
■L'installateurestresponsabledelaqualitédel'installation.
La panne du produit due à une mauvaise installation n'est
pas couverte par la garantie.
■PourleserviceàlaclientèleMonogramdansvotre
région, appelez le 1-800-444-1845.
■PourleserviceàlaclientèleMonogramauCanada,
appelez le 1-800-561-3344.
■PourlespiècesetaccessoiresMonogram,appelezle
1-800-626-2002.
ATTENTION Compte tenu du poids et de la dimension
de ces hottes, et afin de réduire les risques de blessure et
pour ne pas endommager le produit, LEUR INSTALLATION
DOIT ÊTRE EFFECTUÉE PAR DEUX PERSONNES.
AVERTISSEMENT
Pourréduirelesrisquesd'incendieoude
décharge électrique, n'utilisez pas cette hotte de cuisinière
avec un dispositif de contrôle de vitesse à semi-conducteurs
externe. Toute modification de ce type au câblage d'origine
de l'usine pourrait endommager l'appareil et/ou créer un
risque pour la sécurité électrique.POUR RÉDUIRE LES
RISQUES D'INCENDIE, UTILISEZ UNIQUEMENT DES
CONDUITS MÉTALLIQUES.
AVERTISSEMENT
POURDIMINUERLESRISQUES
D'INCENDIE,DEDÉCHARCHEÉLECTRIQUEOUDE
BLESSURES,SUIVEZLESCONSIGNESSUIVANTES:
A. Cet appareil doit uniquement être utilisé aux fins prévues
parsonfabricant.Sivousavezdesquestions,contactez
le fabricant.
B. Avant de réparer ou de nettoyer l'appareil, coupez
l'alimentation au tableau de distribution et bloquez
le disjoncteur pour éviter que le courant ne soit
accidentellementrétabli.S'iln'estpaspossibledebloquer
le disjoncteur, posez un avertissement bien visible,
comme une étiquette, sur le tableau de distribution.
ATTENTION
POURUNEUTILISATIONDE
VENTILATIONGÉNÉRALEUNIQUEMENT.NEPASUTILISER
POURÉVACUERDESMATIÈRESDANGEREUSES,DES
MATIÈRESEXPLOSIVESOUDESVAPEURS.
AVERTISSEMENT
POURDIMINUERLESRISQUES
D'INCENDIE,DEDÉCHARCHEÉLECTRIQUEOUDE
BLESSURES,SUIVEZLESCONSIGNESSUIVANTES:
■ L'installationetlecâblageélectriquedoiventêtreeffectués
par une personne qualifiée et conformément à tous les codes
et toutes les normes applicables, incluant les règlements
concernant les constructions classées résistantes au feu.
■Unequantitéd'airsuffisanteestnécessaireàune
combustion et à une évacuation appropriées des gaz
par le conduit d'évacuation (cheminée) de l'équipement
àcombustiblepourévitertoutrefoulement.Suivez
les instructions et normes de sécurité du fabricant de
l'appareilchauffant,commecellespubliéesparlaNational
FireProtectionAssociation(NFPA),l'AmericanSociety
forHeating,RefrigerationandAirConditioningEngineers
(ASHRAE)etlesautoritéslocales.Lecaséchéant,
installez un système d'air d'appoint (de remplacement)
conformément aux exigences du code du bâtiment local.
Visitezlesiteelectromenagersge.ca pour connaître les
solutions d'air d'appoint offertes.
■Lorsquevouseffectuezdesdécoupesouquevouspercez
dans des murs ou des plafonds, n'endommagez pas le
câblage électrique ou les installations des services publics.
■Lessystèmesquidisposentdeconduitsd'aération
doivent toujours être évacués vers l'extérieur.
■ Lescodeslocauxpeuventvarier.L'installation,lesconnexions
électriques et la mise à la terre doivent se conformer aux
codesapplicables.Enl'absencedecodeslocaux,lahottedoit
être installée conformément au Code national de l'électricité
ANSI/NFPA70-1990ouàladernièreédition.
ATTENTION
Pourréduirelesrisquesd'incendieet
permettre une évacuation de l'air vers l'extérieur adéquate,
assurez-vousd'acheminerlesconduitsversl'extérieur.N'évacuez
pas l'air dans des espaces intra-muraux, dans le plafond, dans le
grenier, dans un vide sanitaire ou dans le garage.

49-80152 Rév. 8 3
Instructions d'installation
TABLE DES MATIÈRES
Consignes de sécurité............................................................. 2
Dimensionsduproduit............................................................. 3
Dégagementspourl'installation .............................................. 4
Cache-conduits en option........................................................ 4
Hauteurd'installation,cache-conduits..................................... 5
Planificationpréliminaire ......................................................... 6
Alimentation électrique ............................................................ 6
Raccords de conduit................................................................ 7
Outilsetmatérielnécessaires ................................................. 7
Déballage ................................................................................ 8
Piècesfournies........................................................................ 8
Étape1:Déterminerlesemplacementsd'installation
des conduits et du câblage ................................................... 9
Étape2A:Installerlahottesurlemur.................................. 10
Étape2B:Installerlahottesousuneretombéedeplafond... 11
Étape3:Raccorderleconduit............................................. 12
Étape4:Brancherl'appareilàl'alimentationélectrique ....... 12
Étape5:Installerlescache-conduits ................................... 12
Étape6:Installerlemoteur .................................................. 12
Étape7:Installerlesfiltres................................................... 13
Étape8:Installerledosseretetlatablette........................... 13
Étape9:Installerlatabletteuniquement.............................. 14
Étape10:Installerlestigesd'ustensiles .............................. 14
DIMENSIONS DU PRODUIT
Chaque hotte
est livrée avec
un dosseret en
acier inoxydable
et une tablette
de réchaud. Les
hottes peuvent
être installées
avec la tablette ou
le dosseret seuls,
ou avec les deux
comme illustré.
ModèleZV36R
ModèleZV48R
ModèleZV30R
35-15/16 po
12 po
22-1/2 po
25 po 35-15/16 po
10 po
Tablette de
réchaud
Dosseret
47-15/16 po
12 po
22-1/2 po
25 po 47-15/16 po
10 po
29-15/16 po12 po
22-1/2 po
25 po 29-15/16 po
10 po
1 po = 2,5 cm; 1 pi = 0,3 m

449-80152 Rév. 8
Préparatifs
DÉGAGEMENTS POUR L'INSTALLATION
Ces hottes sont conçues pour être installées sur un mur ou
sous une retombée de plafond ou une armoire.
Installation avec tablette de réchaud
■Leshottesdoiventêtreinstalléesàunehauteurminimale
de 32 po et maximale de 38 po au-dessus de la surface
de cuisson lorsque la tablette de réchaud est utilisée.
Installation sans tablette de réchaud
■Installezceshottesàunehauteurminimalede30poet
maximale de 36 po au-dessus d'une surface de cuisson
ou d'une cuisinière de style professionnel.
■Ceshottespeuventêtreinstalléesàunedistance
minimale de 24 po au-dessus d'une surface de cuisson
au gaz ou électrique encastrable.
REMARQUE : Les espaces de dégagement peuvent varier
enfonctiondutypedehotteetdescodeslocaux.Vérifiez
auprès des inspecteurs locaux pour vous assurer que la
norme est applicable.
Pourcetteinstallation,leconduitd'évacuationdelapartie
supérieure de la hotte sera dissimulé dans la retombée de
plafond ou dans l'armoire supérieure.
Pourcetteinstallation,uncache-conduitdécoratifpermetde
dissimuler le conduit d'évacuation de la partie supérieure de
la hotte. L'utilisation d'un cache-conduit décoratif exige des
hauteurs d'installation spécifiques au-dessus du comptoir.
CACHE-CONDUITS EN OPTION
Les cache-conduits décoratifs standard sont disponibles en
hauteurs de 6 po et 12 po. Les cache-conduits peuvent être
superposés dans diverses combinaisons, pour dissimuler
les conduits du haut de la hotte jusqu'au plafond.
■Avantdecommencer,vousdevezdéterminerlahauteur
d'installation de la hotte et commander le cache-conduit
de la bonne grandeur. Les cache-conduits doivent être
commandés en même temps que la hotte et être sur
place avant l'installation. Commandez le cache-conduit
correspondant au modèle de votre hotte.
Cache-conduit de 6 po
Cache-conduit de 12 po
Cache-conduits standard
Cache-conduits de 6 po
Modèle de
la hotte
Cache-conduit
de 6 po Dimensions
ZV48R ZX48DC6 H6poxL19-11/16poxP11-7/8po
ZV36R ZX36DC6 H6poxL15-3/4poxP11-7/8po
ZV30R ZX36DC6 H6poxL15-3/4poxP11-7/8po
Cache-conduits de 12 po
Modèle de
la hotte
Cache-conduit
de 12 po Dimensions
ZV48R ZX48DC12 H12poxL19-11/16poxP11-7/8po
ZV36R ZX36DC12 H12poxL15-3/4poxP11-7/8po
ZV30R ZX36DC12 H12poxL15-3/4poxP11-7/8po
Installezceshottesàunehauteur
minimale de 30 po et maximale de 36 po
au-dessus d'une surface de cuisson ou
d'une cuisinière de style professionnel.
Prévoyezunedistancededégagementde
32 po min. et 36 po max. au-dessus de
toute surface de cuisson lorsque la hotte
est installée avec une tablette de réchaud.
RETOMBÉE DE PLAFOND
RETOMBÉE DE PLAFOND
Installation sur retombée de plafond
32 po min.
38 po max.
30 po min.
36 po max.
Installation murale
32 po min.
38 po max.
30 po min.
36 po max.
Installezceshottesàunehauteur
minimale de 30 po et maximale de 36 po
au-dessus d'une surface de cuisson ou
d'une cuisinière de style professionnel.
Prévoyezunedistancededégagementde
32 po min. et 36 po max. au-dessus de
toute surface de cuisson lorsque la hotte
est installée avec une tablette de réchaud.
1 po = 2,5 cm; 1 pi = 0,3 m
