Monoprice™ 18G HDBaseT 150M
P/N 44570
User Manual
4K60 Extender with KVM USB 2.0

2
Thank You for Purchasing this Product
Surge Protection Device Recommended
Safety Warnings and Guidelines
To ensure optimum performance and safety, read the following
instructions before connecting, operating, or adjusting the product.
Keep this manual for future reference.
This product contains sensitive electrical components that may be
damaged by electrical spikes, surges, electric shocks, lightning strikes,
etc. The use of surge protection systems is highly recommended to
protect and extend the life of your equipment.
Please read this entire manual before using this device, paying extra
attention to these safety warnings and guidelines. Please keep this
manual in a safe place for future reference.
• This device is intended for indoor use only.
• Do not expose this device to water or moisture of any kind. Do not
place drinks or other containers with moisture on or near the device.
• If moisture does get in or on the device, immediately unplug it from
the power outlet and allow it to fully dry before reapplying power.
• Do not touch the device, the power cord, or any other connected
cables with wet hands.
• Do not expose this device to excessive vibration.
• Do not subject the product to extreme force, shock, or uctuations
in temperature or humidity.
• Do not expose this device to excessively high temperatures. Do not
place it in, on, or near a heat source, such as a replace, stove,
radiator, etc. Do not leave it in direct sunlight.

3
• This device ventilates excessive heat through the slots and openings
in the case.
• Do not block or cover these openings. Ensure that the device is in an
open area where it can get sucient airow to keep from
overheating.
• Prior to operation, check the unit and power cord for physical
damage. Do not use if physical damage has occurred.
• Before plugging the unit into a power outlet, ensure that the outlet
provides the same type and level of power required by the device.
• Never unplug the unit by pulling on the power cord. Always grasp
the connector head or adapter body.
• Ensure that power is turned o and disconnected before making any
electrical connections.
• Clean using a soft, dry cloth only. Do not use chemical cleaners,
solvents, or detergents. For stubborn deposits, moisten the cloth
with warm water.
• This device has no user serviceable parts. Do not attempt to open,
service, or modify this device.
Table of Contents
Introduction..................................................................................................................4
Features..........................................................................................................................4
Package Contents.......................................................................................................5
Operation Controls and Functions......................................................................5
Transmitter Panel........................................................................................................5
Receiver Panel..............................................................................................................7
IR Pin Denition...........................................................................................................8
Application Example.................................................................................................9
Specications.............................................................................................................10

4
1. Introduction
2. Features
The 18Gbps HDBaseT Extender is a versatile device that allows you
to extend the HDMI signal, bi-directional IR control signal, and USB
KVM signal up to 150m away using just a single CAT6 cable. It does
this by converting the HDMI signal to a standard HDBaseT signal,
which can be transmitted via a LAN cable. With its bi-directional IR
signal pass-through function, you can easily control source devices or
display devices from the remote end. It supports video resolution up
to 4K2K@60Hz YUV 4:4:4 and also comes with USB 2.0 transmission
and POC function. This extender can be used in a variety of fields,
including video conference systems, multimedia signal broadcasting,
HDMI signal extension, and more.
• HDMI 2.0b and HDCP 2.2 compliant
• 18Gbps Video Bandwidth
• Up to 4K2K@60Hz YUV 4:4:4 Video Resolution
• With Mode DIP switch to select HDBaseT Mode & Long Reach Mode
HDBaseT Mode:
USB supports USB 2.0 transmission (support connecting with USB
camera, USB ash drive and other devices); the audio & video signal
transmission distance can be extended up to 328ft/100m for 4K60
Long Reach Mode:
USB only supports HID (Human Interface Device) device; the audio
& video signal transmission distance can be extended up to 492ft
/150m for 1080P or 394ft/120m for 4K60

5
• Bi-Directional IR Signal and USB KVM Signal pass-through
• Bi-Directional POC (Power over Cable) Function
• USB 2.0 Transmission
• EDID Management
• Compact design for easy and exible installation
• 1 × 18Gbps HDBaseT Extender (Transmitter)
• 1 × 18Gbps HDBaseT Extender (Receiver)
• 1 × IR Blaster cable (1.5 meters)
• 1 × IR Wideband Receiver cable (1.5 meters)
• 4 ×Mounting Ears
• 8 × Machine Screws (KM3*4)
• 1 ×24V/1A Locking Power Supply
• 1 ×User Manual
3. Package Contents
4. Operation Controls and Functions
Transmitter Panel
PWR
COPY
STD SERVICE
EDID
HDBT OUT
HDMI IN IR IN IR OUT
PC
DC 24V
13
2
458 9 11
6710

6
No. Name Function Description
1 PWR LED The red LED is on when the Transmitter is powered on.
2EDID DIP
switch
Used for audio EDID setting (dial to COPY by default).
COPY: Copy the EDID of the HDMI OUT port of the Receiver.
STD: Default 1080P 2CH
3 SERVICE Firmware update port.
4 DC 24V
DC 24V/1A power input port.
Note that the extender supports the POC function, which
means that either Transmitter or Receiver is connected to
a 24V/1A power supply, the other doesn’t need a power
supply.
5 HDBT OUT HDBT output port, connecting to the HDBT IN port of
the Receiver with CAT6 cable.
6
Link Signal
Indicator
(Green)
• Illuminating: Transmitter and Receiver are in good
connection status.
• Flashing: Transmitter and Receiver are in poor
connection status.
• Dark: The transmitter and Receiver are not connected.
7
Data Signal
Indicator
(Yellow)
• Illuminating: HDMI signal with HDCP.
• Flashing: HDMI signal without HDCP.
• Dark: No HDMI signal.
8 HDMI IN HDMI signal input port, connecting to HDMI source device
such as DVD play or Set Top Box.
9 IR IN
When connecting to the IR receiver cable, the IR receive
signal will emit to the IR OUT port of the
Receiver.
10 IR OUT When connecting to the IR blaster cable, the IR emits a
signal from the IR IN port of the Receiver.
11 PC USB-B port, connecting to PC.

7
13
458 9
6 7 10 11
SERVICE
PWR
HDBT
Long Reach
MODE
IR IN IR OUTHDMI OUT
HDBT IN
USB 2.0 USB 2.0DC 24V
2
Receiver Panel
No. Name Function Description
1 PWR LED The red LED is on when the Receiver is powered on.
2MODE DIP
switch
Used for Mode switching (dial to HDBT by default).
HDBT: Switching to the HDBaseT Mode.
Long Reach: Switching to the Long Reach Mode.
3 SERVICE Firmware update port.
4 DC 24V
DC 24V/1A power input port.
Note that the extender supports the POC function, which
means that either Transmitter or Receiver is connected to
a 24V/1A power supply, the other doesn’t need a power
supply.
5 HDBT IN HDBT input port, connecting to the HDBT OUT port
of the Transmitter with CAT6 cable.
6
Link Signal
Indicator
(Green)
• Illuminating: Transmitter and Receiver are in good
connection status.
• Flashing: Transmitter and Receiver are in poor connection
status.
• Dark: The transmitter and Receiver are not connected.

8
No. Name Function Description
7
Data Signal
Indicator
(Yellow)
• Illuminating: HDMI signal with HDCP.
• Flashing: HDMI signal without HDCP.
• Dark: No HDMI signal.
8 HDMI OUT HDMI signal output port, connecting to HDMI display device
such as TV or monitor.
9 IR IN Connect to the IR receiver cable. The IR signal will send to
the IR OUT port of the Transmitter.
10 IR OUT Connect to the IR blaster cable, the IR signal is from IR IN
port of the Transmitter.
11 USB 2.0
ports
Two USB-A ports, connecting to USB 2.0 devices.
(The maximum output current of a single USB 2.0 port is
500mA, exceeding which it will not work.)
IR Pin Denition
IR Receiver and Blaster pin’s denition as below:
Note: When the angle between the IR receiver and the remote
control is ± 45 °, the transmission distance is 0-5 meters; When the
angle between the IR receiver and the remote control is ± 90°, the
transmission distance is 0- 8 meters.
IR RECEIVER
IR BLASTER
IR Blaster
IR Receiver
IR Blaster Signal
Power
NC
IR Signal
Power
Grounding

9
5. Application Example
Transmitter
Receiver
PWR
COPY
STD SERVICE
EDID
HDBT OUT
HDMI IN IR IN IR OUT
PC
DC 24V
HDBT IN
HDMI OUT IR IN IR OUT
DC 24V USB 2.0
USB 2.0
Power Supply
LAN
LAN
DVD or Blu-ray
Player
IR Receiver
IR Blaster
UHDTV
IR Receiver
IR Blaster
CAT6 Cable PC
USB Camera
USB Disk
SERVICE
PWR
HDBT
Long Reach
MODE

10
6. Specications
Technical
HDMI Compliance HDMI 2.0b
HDCP Compliance HDCP 2.2
USB Compliance USB 2.0
Video Bandwidth 18Gbps
Video Resolution Up to 4K2K@60Hz YUV 4:4:4
Transmission Distance 1080P@60--150m, 4K60 --120m
Color Space RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Color Depth 8-bit, 10-bit, 12-bit (1080P) 8-bit (4K60)
8-bit, 10-bit, 12-bit (4K24/30)
HDR HDR, HDR10, HDR10+, Dolby Vision, HLG
Audio Format LPCM 7.1CH, Dolby True HD and DTS-HD Master
ESD Protection Human-body Model:
±8kV (Air-gap discharge), ±4kV (Contact discharge)
Connection
Transmitter
Input: 1 × HDMI IN [Type A, 19-pin female]
1 × IR IN [3.5mm Stereo Mini-jack]
1 × SERVICE [Micro-USB]
1 × USB [USB-B, 4-pin female]
Output: 1 × HDBT OUT [RJ45]
1 × IR OUT [3.5mm Stereo Mini-jack]
Receiver
Input: 1 × HDBT IN [RJ45 with light]
1 × IR IN [3.5mm Stereo Mini-jack]
1 × SERVICE [Micro-USB]
Output: 1 × HDMI OUT [Type A, 19-pin female]
1 × IR OUT [3.5mm Stereo Mini-jack]
2 × USB 2.0 [USB-A, 4pin female]
