MONOPRICE
Blackbird™ 4K Pro HDBaseT™ Extender Kit
P/N 21609
User's Manual

2
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the device. If moisture does get in or on
the device, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.
Do not touch the device, the power cord, or any other connected cables with wet
hands.
Do not expose this device to excessively high temperatures. Do not place it in, on,
or near heat sources, such as a fireplace, stove, radiator, etc. Do not leave it in direct
sunlight.
Do not expose this device to excessive vibration.
Use only in a well-ventilated area. Do not use in close, confined spaces.
Never unplug the unit by pulling on the power cord. Always grasp the connector
head or adapter body.
Ensure that power is turned off and disconnected before making any electrical
connections.
Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.

3
INTRODUCTION
Thank you for purchasing this Blackbird™4K Pro HDBaseT™Extender Kit! This kit allows you
to extend High Speed HDMI® signals using a single Cat6 Ethernet cable. It supports
extension of 4K video to distances up to 115 feet (35 meters) and 1080p video to distances
up to 230 feet (70 meters). It delivers 10.2Gbps bandwidth and is compliant with HDCP 2.2.
It supports the Power over Cable (PoC) feature, which uses the Cat6 cable to deliver power
to either the transmitter or receiver, so it can be installed without the need for a nearby AC
power outlet.
FEATURES
Supports HDMI® video to resolutions up to 4K@60Hz 4:2:0, including 1080p@60Hz
Delivers 10.2 Gbps bandwidth
HDCP 2.2 compliant
Extends 4K video to distances up to 115 feet (35m) and 1080p video to distances up
to 230 feet (70m)
Extends RS232 serial data to distances up to 230 feet (70m)
Supports bi-directional IR control signals
Supports the Power over Cable feature, which allows either the transmitter or
receiver to be installed in locations without an AC power outlet
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-
6pm PT) or via email at [email protected]

4
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x HDBaseT™ Transmitter
1x HDBaseT Receiver
4x Mounting Brackets
4x Screws
8x Plastic feet
2x 3-pin Euroblock/Phoenix Connectors
1x AC Power Adapter (12 VDC, 1A)
1x User's Manual
PRODUCT OVERVIEW
Transmitter
1. HDMI In: HDMI® port for connecting the video source device (e.g., Blu-ray Disc™ or
DVD player).
2. IR In: 3.5mm jack for connecting an IR Receiver (not included).
3. IR Out: 3.5mm jack for connecting an IR Transmitter (not included).
4. RS232: Euroblock/Phoenix connector for connecting an RS232 data device.
5. DC 12V: DC barrel connector for connecting the included AC power adapter.

5
6. Power LED: Illuminates red when power is applied.
7. HDBT Out: RJ45 jack for connecting the Cat6 cable to the Receiver.
8. RS232 Mode Switch: Switch for determining the behavior of the RS232 connection.
When in the Ctrl position, it serves as an RS232 serial extender. When in the Update
position, it allows you to update the Valens IC program by connecting to a PC and
running the batch file.
Receiver
1. HDMI Out: HDMI® port for connecting the video display.
2. IR In: 3.5mm jack for connecting an IR Receiver (not included).
3. IR Out: 3.5mm jack for connecting an IR Transmitter (not included).
4. RS232: Euroblock/Phoenix connector for connecting an RS232 data device.
5. DC 12V: DC barrel connector for connecting the included AC power adapter.
6. Power LED: Illuminates red when power is applied.
7. HDBT In: RJ45 jack for connecting the Cat6 cable to the Transmitter.
8. RS232 Mode Switch: Switch for determining the behavior of the RS232 connection.
When in the Ctrl position, it serves as an RS232 serial extender. When in the Update
position, it allows you to update the Valens IC program by connecting to a PC and
running the batch file.

6
SAMPLE CONNECTION DIAGRAM
INSTALLATION
Perform the following steps to install this extender kit.
1. Ensure that all equipment to be connected is powered off and unplugged from its
power source.
2. Place or mount the receiver and transmitter in their intended locations.
3. Using a High Speed HDMI Cable (not included), plug one end into the HDMI® input
on your display, then plug the other end into the HDMI Out port on the Receiver.
4. (Optional) Using a 3-pin Euroblock connector (not included), construct an RS232
serial cable to connect to your computer or other RS232 enabled device. Plug the
Euroblock connector into the RS232 port on the Receiver, then plug the other end
into your RS232 enabled device.
5. (Optional) Plug an IR receiver (not included) into the IR In jack on the Receiver, then
position the receiving "eye" so that it can receiver infrared signals from your remote
control.

7
6. (Optional) Plug an IR transmitter (not included) into the IR Out jack on the Receiver,
then position the IR emitter so that it can transmit infrared signals to the display.
7. Route a Cat6 Ethernet cable (not included) between the Receiver and the
Transmitter. If the cable will be routed inside or through walls, the cable must be
rated for in-wall use. The cable must be no longer than 230 feet (70m). If you will be
transmitting 4K video signals, the cable must be no longer than 115 feet (35m). Plug
one end of this cable into the HDBT In port on the Receiver, then plug the other end
into the HDBT Out port on the Transmitter.
8. (Optional) Using a 3-pin Euroblock connector (not included), construct an RS232
serial cable to connect to your computer or other RS232 enabled device. Plug the
Euroblock connector into the RS232 port on the Transmitter, then plug the other
end into your RS232 enabled device.
9. (Optional) Plug an IR receiver (not included) into the IR In jack on the Transmitter,
then position the receiving "eye" so that it can receiver infrared signals from your
remote control.
10. (Optional) Plug an IR transmitter (not included) into the IR Out jack on the
Transmitter, then position the IR emitter so that it can transmit infrared signals to
the video source device (e.g., Blu-ray Disc™ or DVD player).
11. Using a High Speed HDMI Cable (not included), plug one end into the HDMI In port
on the Transmitter, then plug the other end into the HDMI® output on your video
source device (e.g., Blu-ray Disc or DVD player).
12. Plug the DC barrel connector on the included AC power adapter into the DC 12V
port on either the Receiver or Transmitter, then plug the adapter into a nearby AC
power outlet. The device not connected to the AC power adapter will receive its
power over the Cat6 Ethernet cable via the Power over Cable feature.
13. Plug in and power on all connected devices. Start video playback on your video
source device and verify that video can be seen on the remote display.
14. (Optional) If you are using the RS232 extender function, verify that you have serial
data at each end.

8
15. (Optional) If you are using the infrared repeater function, use your remote control(s)
to verify that you can control the video source and/or display from the other end.
Congratulations, your extender is installed and fully operational!
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
during regular business hours, 7 days a week. You can also get assistance through email by
sending a message to [e-mail]

9
SPECIFICATIONS
Model
21609
Maximum Video Resolution
4K@60Hz 4:2:0, including 1080p@60Hz
Transmission Medium
HDBaseT™
Transmission Distance
1080p signals to 70m, 4K signals to 35m
Bandwidth
10.2 Gbps
Video Standard
HDMI® 1.4 with HDCP 2.2
Input Power
12 VDC, 1A or Power over Cable (PoC)
AC Adapter Input Power
100 ~ 240 VAC, 50/60 Hz
Power Consumption
10 watts
Operating Temperature
+14 ~ +122°F (-10 ~ 50°C)
Operating Humidity
0 ~ 90% RH, non-condensing
Dimensions (each)
4.7" x 0.6" x 2.9" (120 x 16 x 74 mm)
Weight (each)
8.5 oz. (240g)
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice’s authorization may result in the equipment
no longer complying with FCC requirements for Class B digital devices. In that event, your

10
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Blackbird™ is a trademark of Monoprice Inc.
HDBaseT™ is a trademark of HDBaseT Alliance.
HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
Blu-ray Disc™, Blu-ray™, and the logos are trademarks of the Blu-ray Disc Association.
