MONOPRICE
Blackbird 4K Pro 2x1 HDMI® Switch with HDCP 2.2
Support
P/N 15261
User's Manual

Introduction
ThisisahighperformancethreeHDMIinputandoneHDMIoutputswitcher. 
Thesystemsupportsall3DTVformatsinadditiontoallHDTVformatsupto
4Kx2K.Furthermore,theremotecontrolgivesusestocompletecontroloverthe
selectionofsourcesandmakesthedeviceincrediblyuserfriendly.
Package
UHD2x1HDMISwitcher‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐1Pcs
5V/1ADCpoweradaptor‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐1Pcs
RemoteControl‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐1Pcs
38KHzIRReceiverCable‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐1Pcs
Usermanual‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐1pcs
Feature
CompliantwithHDMI2.0,HDCP2.2andDVI1.0;
Supportvideoformatupto4k2k@30Hzwith24bitRGB/YcbCR4:4:4/YCBCR
4:2:2,andupto4k2k@60Hzwith12bitYCBCR4:2:0;
Support3Dframesequentialvideoformatupto1080p@60;
SupporthighresolutionVESAmodevideoformatuptoQSXGA@60Hz;
SupportsLPCM7.1CH,DolbyTrueHD,andDTS‐HDMasterAudio;
Supportssmartautoswitchfunction;
SupportsIRandPanelbuttoncontrol;
Specification
VideoBandwidth  300MHz/10.2Gbps
InputPorts  2xHDMI(Femaletype)
OutputPorts  1xHDMI(Femaletype)
OutputResolution  480i~1080p50/60,4Kx2K@24/30, 
 4k2k@60Hzwith12bitYCBCR4:2:0,VGA~UXGA
ESDProtection HumanBodymodel: ±8kV(air‐gapdischarge)
 ±4kV(contactdischarge)
PowerSupply  5V/1ADC 
Dimensions  64mm(W)×155mm(D)×17mm(H)
Weight  180g  
ChassisMaterialMetal
SilkscreenColorBlack
OperatingTemperature  0°C~40°C/32°F~104°F
StorageTemperature −20°C~60°C/−4°F~140°F
RelativeHumidity 20~90%RH(non‐condensing)
PowerConsumption2W

ConnectandOperate
ConnectthesignalsourcessuchasBlu‐RayPlayer,PlayStation3,satellite
receiversandcomputersequippedwithHDMIoutputinterfaceswithashort
high‐speedHDMIcabletotheHDMISwitcher input. 
ConnecttheHDMIoutputsfromtheHDMISwitchertohigh‐definitiondisplay
devicessuchasHD‐LCD,HD‐DLPandHDprojectorswithHDMIinputinterfaces.
Usehigh‐speedHDMIcablesthatarerecommendedforthedistancesthatare
requiredforeachconnection.
TheSwitcherispoweredbyanexternalpowersupplywhichisincluded.Connect
powerfirsttothesource,thentotheSwitcherandthentoeachHDTVor
projector.

1. IR:Remotecontrolreceiver,the3.5mmphoneforHDMIswitcherIRextension.

2.POWERLED:ThisblueLEDilluminateswhenthedeviceisconnectedwith

powersupply.
3.INLED:TheseblueLEDsilluminatewhentheSourceselected.
4.INPUTBUTTON:Pressthisbuttontoselecttheinputsource.
5.SERVICE: Manufactureruseonly.
6.HDMIIN1,2,:ConnecttheinputporttotheHDMIorDVIoutputofyoursource
devicesuchasaDVDplayerorset‐topboxwithHDMIcables.
7.HDMIOUT:ConnecttheHDMIoutputtoanHDMIdisplay.
8.DC5V:Plugthe5VDCpowersupplyintotheunitandconnecttheadaptortoan
ACoutlet

RemoteControl

Inputsourceselectbuttons,thepanelLEDwillindicate
theinputsourcestatus.






ConnectionDiagram

