Monoprice Blackbird User manual

MONOPRICE
Blackbird™ 4K 5x1 HDMI® Presentation Switch
P/N 21906
User's Manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES.......................................................................................................................................4
INTRODUCTION................................................................................................................................................................................................4
FEATURES..............................................................................................................................................................................................................5
CUSTOMER SERVICE....................................................................................................................................................................................5
PACKAGE CONTENTS.................................................................................................................................................................................6
PRODUCT OVERVIEW.................................................................................................................................................................................6
Front Panel.....................................................................................................................................................................................................6
Rear Panel....................................................................................................................................................................................................... 7
IR Remote Control...................................................................................................................................................................................8
AUTO SWITCHING.........................................................................................................................................................................................8
VGA INPUT...........................................................................................................................................................................................................9
INSTALLATION................................................................................................................................................................................................10
OSD MENU.........................................................................................................................................................................................................12
Main Menu...................................................................................................................................................................................................12
Picture Submenu....................................................................................................................................................................................12
Aspect Ratio Submenu..................................................................................................................................................................... 13
Screen Submenu ....................................................................................................................................................................................13
EDID Submenu..........................................................................................................................................................................................14
Software Update Submenu..........................................................................................................................................................14
Resolution Submenu...........................................................................................................................................................................15
RS232 CONTROL............................................................................................................................................................................................15
Port Switch Command......................................................................................................................................................................16
Port Switch Query.................................................................................................................................................................................16
Input Auto Configure.........................................................................................................................................................................16
Input Auto Query................................................................................................................................................................................... 17

3
Aspect Ratio Configure.................................................................................................................................................................... 17
Aspect Ratio Query.............................................................................................................................................................................. 17
Enable Beep Configuration...........................................................................................................................................................18
Enable Beep Query...............................................................................................................................................................................18
Resolution Configure..........................................................................................................................................................................18
Resolution Query....................................................................................................................................................................................19
PQ Regulate...............................................................................................................................................................................................20
PQ Query ......................................................................................................................................................................................................20
Reset Sys Configure.............................................................................................................................................................................21
USB Upgrade Configure...................................................................................................................................................................21
EDID Configure.........................................................................................................................................................................................21
EDID Query ..................................................................................................................................................................................................21
Audio Mute Configure .....................................................................................................................................................................22
Audio Mute Query...............................................................................................................................................................................22
Audio + Configure................................................................................................................................................................................22
Audio - Configure................................................................................................................................................................................. 23
Audio Value Configure.....................................................................................................................................................................23
Audio Value Query ..............................................................................................................................................................................23
IR Commands............................................................................................................................................................................................24
RS232 INTERFACE........................................................................................................................................................................................25
TECHNICAL SUPPORT..............................................................................................................................................................................26
SPECIFICATIONS........................................................................................................................................................................................... 27
REGULATORY COMPLIANCE............................................................................................................................................................. 27
Notice for FCC ......................................................................................................................................................................................... 27
Notice for Industry Canada..........................................................................................................................................................28

4
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the device. If moisture does get in or on
the device, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.
Do not touch the device, the power cord, or any other connected cables with wet
hands.
Do not expose this device to excessively high temperatures. Do not place it in, on,
or near heat sources, such as a fireplace, stove, radiator, etc. Do not leave it in direct
sunlight.
Ensure that power is turned off and disconnected before making any electrical
connections.
Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.
INTRODUCTION
Thank you for purchasing this Blackbird 4K 5x1 HDMI® Presentation Switch! This switch
features four HDMI inputs, plus a combination input that can accept VGA, Component
(YPbPr), or Composite (CVBS) video. It supports HDMI video resolutions up to 4K@60Hz
4:4:4 and is fully compliant with the HDMI 2.0 and HDCP 2.2 standards. It supports
automatic and manual switching and includes support for automatic EDID management.

5
FEATURES
Four HDMI® and one combination input that can accept VGA, Component (YPbPr),
or Composite (CVBS) video
Supports HDMI video resolutions up to 4K@60Hz 4:4:4
Supports automatic and manual switching
Automatic EDID management
Includes IR remote control and RS232 control options
Fully compliant with the HDMI 2.0 and HDCP 2.2 standards
2-channel analog audio pass-through option
USB port for firmware updates
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-
6pm PT) or via email at [email protected]

6
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x Blackbird™ 4K 5x1 HDMI® presentation switch
2x Mounting brackets
1x IR remote control
1x AC power adapter (12 VDC, 1A)
1x IR receiver
1x Video cable (VGA to 3x RCA male)
1x Audio cable (3.5mm to 2x RCA female)
1x User's manual
PRODUCT OVERVIEW
Front Panel
1. POWER BUTTON AND LED: Press the button to enter or exit standby mode. The LED
illuminates blue when the switch is turned on and illuminates red when in standby
mode.
2. IR RECEIVER: IR receiver "eye" for receiving IR signals from the included IR remote
control.
3. SOURCE SELECT BUTTONS AND LED INDICATORS: Press one of the buttons to
directly select an input. The LED corresponding to the selected input will illuminate.

7
Press the AUTO button to toggle automatic switching on or off. When automatic
switching is enabled, the LED will illuminate blue.
4. OUTPUT RESOLUTION BUTTONS: Press the buttons to set the output resolution to
4K@60Hz, 4K@30Hz, 1080p, or 720p. The switch/scaler will automatically scale the
resolution to match the selected resolution. To select other resolutions, use the
included IR remote control or the RS232 control option.
Rear Panel
1. OUTPUT: An HDMI® video output port and a 3.5mm stereo analog audio output.
2. INPUT: Four HDMI video input ports, a VGA port that is capable of accepting VGA,
Component (YPbPr), and Composite (CVBS) video, and a 3.5mm stereo analog audio
input
3. CONTROL: A USB port for connecting a USB flash drive for firmware updates, a 3-pin
terminal block for connecting to a computer's RS232 serial port, and a 3.5mm jack for
connecting the included IR receiver.
4. DC 12V: DC barrel connector for connecting the included AC power adapter.
5. POWER SWITCH: Power switch for turning the unit on or off.

8
IR Remote Control
1. POWER SWITCH: Press the button to power
the unit on or to put it into standby mode.
2. MUTE BUTTON: Press the button to mute or
unmute the audio output.
3. ADJ BUTTON: Press the button to
automatically adjust the VGA screen settings.
4. INPUT BUTTONS: Press the HD1~4 and VGA
buttons to directly select the input. Press the
AUTO button to toggle automatic switching on
or odd. Press the arrow buttons to cycle
through the inputs.
5. RES BUTTON: Momentarily press the button to
access the Resolution screen in the OSD. Press
and hold the button for about 5 seconds to set
the output resolutions to 720p@60Hz.
6. MENU BUTTONS: Press the MENU button to enter the OSD menu. Press the EXIT
button to exit the OSD menu. Press the arrow buttons to navigate the OSD menu.
Press the OK button to select the highlighted menu option.
7. VOLUME BUTTONS: Press the VOL- and VOL+ buttons to adjust the volume. The
MIC-and MIC+ buttons are unused.
AUTO SWITCHING
The switch supports both automatic and manual switching modes. When automatic
switching mode is enabled, it functions according to the following principles.
When a new input signal is detected, the unit will automatically switch to that
input.
When the unit is powered off, it remembers the last selected input and will return
to that input when power is reapplied. If the last input is no longer available, the

9
unit will detect all inputs in the order HDMI 1 > HDMI 2 > HDMI 3 > HDMI 4 > VGA
and will automatically select the first active input.
If the currently selected input is removed, the unit will detect all inputs in the order
HDMI 1 > HDMI 2 > HDMI 3 > HDMI 4 > VGA and will automatically select the first
active input.
VGA INPUT
The VGA input can accept VGA, Component (YPbPr), and Composite (CVBS) video signals.
The unit will automatically detect the input type and will convert and scale it to the HDMI®
output.
When connecting to a VGA input, use a standard DB15 VGA cable (not included).
When connecting to a Component (YPbPr) video source, connect the Red, Blue, and
Green plugs to the corresponding video outputs on your Component source device.
When connecting to a Composite (CVBS) video source, plug the red connector into
the video output (normally yellow).

10
INSTALLATION
Perform the following steps to install this switch.
1. Ensure that all equipment to be connected is powered off and unplugged from its
power source.
2. Using a High Speed HDMI® Cable (not included), plug one end into the HDMI input
on your display, then plug the other end into the HDMI port in the OUTPUT section
on the scaler/switcher.
3. Using the included audio cable, plug one end into the 3.5mm AUDIO jack in the
OUTPUT section, then plug the other end into the inputs of powered speakers, a
stereo amplifier, or other analog audio device.

11
4. Using a High Speed HDMI® Cable (not included), plug one end into one of the HDMI
ports in the INPUT section on the scaler/switcher, then plug the other end into the
HDMI output on your video source device. Repeat for up to three additional HDMI
video sources.
5. Using a VGA cable, plug one end into the VGA port in the INPUT section on the
scaler/switcher, then plug the other end into the VGA output on your computer,
laptop, or other device. Alternatively, plug the included video cable into the VGA
port in the INPUT section on the scaler/switcher, then plug the other end into the
RGB outputs of a component (YPbPr) video source or plug the red connector into
the video output jack of a composite (CVBS) video source.
6. Using a 3.5mm audio cable (not included), plug one end into the AUDIO jack in the
INPUT section on the scaler/switcher, then plug the other end into the audio output
jack on your computer or laptop. Alternatively, using the included audio cable, plug
one end into the AUDIO jack in the INPUT section on the scaler/switcher, then plug
the other end into the stereo RCA audio output on your component or composite
video source device.
7. (Optional) If you want to use your computer for RS232 control of the
scaler/switcher, plug one end of a serial cable (not included) into the 3-pin RS232
terminal block in the CONTROL section on the scaler/switcher, then plug the other
end into one of the COM ports on your computer or laptop.
8. (Optional) If the IR "eye" on the front panel will be obscured, such as when installing
this system into a closet or cabinet, plug the included IR receiver into the IR jack in
the CONTROL section on the scaler/switcher, then position the IR "eye" where it can
receive IR signals from the included remote control.
9. Plug the DC barrel connector on the included AC power adapter into the 12V DC
jack on the scaler/switcher, then plug the adapter into a nearby AC power outlet.
10. Plug in and power on all connected equipment, then start video playback on all
video source devices. Verify that the video from each device can be viewed on the
connected display and that the audio can be heard.

12
OSD MENU
Pressing the MENU button on the included remote control accesses the built-in On Screen
Display (OSD) menu.
Main Menu
The Main menu gives access to the Picture, Aspect Ratio, Screen, EDID Switch, Software
Update, and Resolution submenus. The Screen submenu is only available when the
selected input is set to VGA.
Picture Submenu
The Picture submenu allows you to control the
image Contrast, Brightness, Color, Sharpness,
and Tint.

13
Aspect Ratio Submenu
The Aspect Ratio submenu allows you to set
the output aspect ratio to 4:3 or 16:9.
Screen Submenu
The Screen submenu allows you to set the
Horizontal Position, Vertical Position, Size, and
Phase. It also allows you to select the Auto
Adjust feature, which automatically sets the
screen parameters for the optimal display. This
screen is only accessible when the VGA input is
selected.

14
EDID Submenu
The EDID submenu allows you to determine
how the source device obtains its EDID
information. The EDID 1.4 option is for use with
devices that conform to version 1.4 of the
HDMI® specification. The EDID 2.0 option is for
use with devices that conform to version 2.0 of
the HDMI specification. The EDID AUTO option
allows the source device to obtain its EDID
information from the connected display.
Software Update Submenu
The Software Update submenu allows you to update the switch's firmware in the event
that an update is made available. To do this, first copy the MERGE.bin file to the root
directory of a USB flash drive. Next, plug the flash drive into the USB port on the rear panel.
Finally, select the Software Update option from the Main menu. The system will ask you to
confirm the update. Select Yes to start the update.

15
Resolution Submenu
The Resolution submenu allows you to set the
output resolution of the switch to a fixed
value. You can also select the AUTO option,
which automatically sets the output resolution
to the best resolution for the connected
display. The Resolution sub menu is also
accessible by pressing the RES button on the
included remote control.
RS232 CONTROL
In addition to control using the front panel controls and the included remote control, you
can control the switch using a third party RS232 control software. The communications
parameters for RS232 are:
Baud Rate: 115200
Data Bits: 8
Stop Bits: 1
Parity: None
The switch responds to the following commands.

16
Port Switch Command
Package Length: 18 bytes
[0x50+0x56+0x54+0x02+0x03+inputport(1~5)+0x00+0x01+0x00+0x00+0x00+0x00+0x0
0+0x00+0x00+0x00+0x00+checksum]
All you need to change is "input port" and "checksum".
Checksum=0x100–
(0x50+0x56+0x54+0x02+0x03+inputport(1~5)+0x00+0x01+0x00+0x00+0x00+0x00+0x0
0+0x00+0x00+0x00+0x00)
inputport(1~5): HDMI 1, HDMI 2, HDMI 3, HDMI 4, VGA
For example, to select Input 2:
50 56 54 02 03 02 00 01 00 00 00 00 00 00 00 00 00 02
Port Switch Query
Package Length: 18 bytes
This is a query command, which means you must send the query package and then
receive an answer.
For example, to query the Input:
Send package: 50 56 54 02 01 01 00 00 00 00 00 00 00 00 00 00 00 FE
Receive package: 50 56 54 02 01 01 00 02 00 00 00 00 00 00 00 00 00 00
The blue 02 is the input port number, it should be 1~5.
Input Auto Configure
Package Length: 18 bytes
[0x50+0x56+0x54+0x24+0x01+InputAutoON/OFF+0x00+0x00+0x00+0x00+0x00+0x00
+0x00+0x00+0x00+0x00+0x00+checksum]
All you need to change is "InputAutoON/OFF" and "checksum".

17
For example, to set the Input Auto to OFF:
50 56 54 24 01 F0 00 00 00 00 00 00 00 00 00 00 00 0F
Input Auto Query
Package Length: 18 bytes
This is a query command, which means you must send the query package and then
receive an answer.
For example, to query the Input Auto status:
Send package: 50 56 54 24 02 00 00 00 00 00 00 00 00 00 00 00 00 20
Receive package: 50 56 54 24 02 F0 00 00 00 00 00 00 00 00 00 00 00 10
The blue F0 means to set input auto to OFF. Change the F0 to 0F to set input auto to
ON.
Aspect Ratio Configure
Package Length: 18 bytes
[0x50+0x56+0x54+0x24+0x11+AspectRatioIndex+0x00+0x00+0x00+0x00+0x00+0x00+
0x00+0x00+0x00+0x00+0x00+checksum]
All you need to change is "AspectRatioIndex" and "checksum".
For example, to set the Aspect Ratio to 4:3:
50 56 54 24 11 01 00 00 00 00 00 00 00 00 00 00 00 30
Aspect Ratio Query
Package Length: 18 bytes
This is a query command, which means you must send the query package and then
receive an answer.
For example, to query the Aspect Ratio:

18
Send package: 50 56 54 24 12 00 00 00 00 00 00 00 00 00 00 00 00 30
Receive package: 50 56 54 24 12 01 00 00 00 00 00 00 00 00 00 00 00 31
The blue 01 indicates a 4:3 aspect ratio. Change 01 to 02 for a 16:9 aspect ratio.
Enable Beep Configuration
Package Length: 18 bytes
[0x50+0x56+0x54+0x06+0x01+EnableBeepON/OFF+0x00+0x00+0x00+0x00+0x00+0x0
0+0x00+0x00+0x00+0x00+0x00+checksum]
All you need to change is "EnableBeepON/OFF" and "checksum".
For example to set Enable Beep to OFF:
50 56 54 06 01 F0 00 00 00 00 00 00 00 00 00 00 00 F1
Enable Beep Query
Package Length: 18 bytes
This is a query command, which means you must send the query package and then
receive an answer.
For example, to query the Enable Beep status:
Send package: 50 56 54 01 0B 00 00 00 00 00 00 00 00 00 00 00 00 06
Receive package: 50 56 54 01 0B 00 00 FF 00 00 00 00 00 00 00 00 00 05
The blue FF means that Enable Beep is set to OFF. Change the FF to 00 for Enable Beep
ON.
Resolution Configure
Package Length: 18 bytes
[0x50+0x56+0x54+0x0A+0x06+resolution(1~13)+0x00+0x00+0x00+0x00+0x00+0x00+0
x00+0x00+0x00+0x00+0x00+checksum]

19
All you need to change is "iresolution" and "checksum".
Checksum=0x100 –
(0xa5+0x5b+0x02+0x03+resolution(1~13)+0x00+0x00+0x00+0x00+0x00+0x00+0x00)
resolution(1~13)
1. 3840x2160@60
2. 3840x2160@30
3. 1920x1080@60
4. 1920x1080@50
5. 1280x720@60
6. 1280x720@50
7. 1920x1200@60
8. 1680x1050@60
9. 1400x1050@60
10. 1360x768@60
11. 1280x800@60
12. 1024x768@60
13. AUTO
For example, to set the output Resolution 1920x1080@60:
50 56 54 0A 06 03 00 03 00 00 00 00 00 00 00 00 00 10
Resolution Query
Package Length: 18 bytes
This is a query command, which means you must send the query package and then
receive an answer.
For example, to query the Resolution:
Send package: 50 56 54 90 06 00 00 00 00 00 00 00 00 00 00 00 00 90

20
Receive package: 50 56 54 90 06 03 00 00 00 00 00 00 00 00 00 00 00 93
The blue 03 indicates that the resolution is 1920x1080@60. Change to 03 to a
hexadecimal version of integers 1~13.
PQ Regulate
Package Length: 18 bytes
[0x50+0x56+0x54+0x08+TYPE(1~4)+DATA+0x00+0x00+0x00+0x00+0x00+0x00+0x00+
0x00+0x00+0x00+0x00+checksum]
All you need to change is "TYPE", "DATA", and "checksum".
Checksum=0x100 –
(0x50+0x56+0x54+0x08+TYPE(1~4)+DATA+0x00+0x00+0x00+0x00+0x00+0x00+0x00+
0x00+0x00+0x00+0x00)
TYPE 1~4: Contrast, Brightness, Color, Sharpness
Contrast and Brightness DATA from 0 to 100; Color DATA from 0 to 60; Sharpness DATA
from 0 to 20.
For example, to set the Contrast to 72:
50 56 54 08 01 48 00 48 00 00 00 00 00 00 00 00 00 93
PQ Query
Package Length: 18 bytes
This is a query command which mean you must send query package and then receive
an answer.
For example, to query the Contrast setting:
Send package: 50 56 54 09 01 00 00 00 00 00 00 00 00 00 00 00 00 04
Receive package: 50 56 54 09 01 48 00 00 00 00 00 00 00 00 00 00 00 4C
The red 01 means to query the contrast setting. Replace the 01 with 02 for brightness,
03 for color, and 04 for sharpness.
