Please read this manual and save it with your original sales receipt.
Please read this manual and save it with your original sales receipt.
Tools needed for assembly: Phillips Screwdriver, Slotted Screwdriver
Tools needed for assembly: Phillips Screwdriver, Slotted Screwdriver
and Safety Scissors (not included); Assembly Tool (included).
and Safety Scissors (not included); Assembly Tool (included).
Use only with a Power Wheels
Use only with a Power Wheels
®
®
6 Volt Battery with A-Style Connector
6 Volt Battery with A-Style Connector
and Built-in Thermal Fuse and a Power Wheels
and Built-in Thermal Fuse and a Power Wheels
®
®
Super 6 Volt Charger
Super 6 Volt Charger
(both included).
(both included).
Owner's Manual
Owner's Manual
with Assembly Instructions
with Assembly Instructions
For Model
For Model
J5244
J5244
Product features may vary from the picture above.
Product features may vary from the picture above.
©2005 SFX Motor Sports, Inc. d/b/a Clear Channel Entertainment-Motor Sports United States Hot Rod Association
©2005 SFX Motor Sports, Inc. d/b/a Clear Channel Entertainment-Motor Sports United States Hot Rod Association
®
®
, Monster Jam
, Monster Jam
®
®
, and Blacksmith
, and Blacksmith
®
®
,
,
Blue Thunder
Blue Thunder
®
®
,Bulldozer
,Bulldozer
®
®
, El Toro Loco
, El Toro Loco
®
®
, Grave Digger
, Grave Digger
®
®
, High Roller
, High Roller
TM
TM
, Inferno
, Inferno
TM
TM
, Junkyard Dog
, Junkyard Dog
TM
TM
,Maximum Destruction
,Maximum Destruction
®
®
, Monster Mutt
, Monster Mutt
TM
TM
,
,
Power Forward
Power Forward
TM
TM
, Radical Rescue
, Radical Rescue
TM
TM
, Raging Steel
, Raging Steel
TM
TM
, and Sergeant Smash
, and Sergeant Smash
TM
TM
are trademarks of Clear Channel Entertainment-Motor Sports.
are trademarks of Clear Channel Entertainment-Motor Sports.
®

2
TABLE OF CONTENTS
A
J5244pr-0920
2
TABLE OF CONTENTS
J5244pr-0920
• Your new vehicle requires adult assembly. Please set aside at least
45 minutes for assembly.
• You must charge your battery for 18 - 30 hours before you use your
vehicle for the first time. We recommend that you start charging
your battery before beginning assembly. Please see Battery Charging
beginning on page 7 for detailed instructions.
• Read this manual carefully for important safety information and
operating instructions before using your vehicle. Keep this manual
for future reference as it contains important information.
• This vehicle is designed for use on: grass, asphalt and other hard
surfaces; on generally level terrain; and by children 2 - 6 years of age.
• Make sure children know and follow these rules for safe driving
and riding:
- always sit on the seat.
- always wear shoes.
- only 1 (one) rider at a time.
• Use this vehicle ONLY outdoors. Most interior flooring can be
damaged by riding this vehicle indoors. Fisher-Price®will not be
responsible for damage to the floor if the vehicle is used indoors.
• To prevent damaging the motors and gears, teach your child to stop
the vehicle before switching direction. Do not tow anything behind the
vehicle or overload it. Do not exceed the maximum weight capacity of
65 lbs (29.5 kg).
• This vehicle has adjustable play seat belts. Please note that the
adjustable seat belts are designed to be a play feature only and do
not function as protective safety restraints.
• If you have any questions about your Power Wheels®vehicle,
please call our toll-free service lines at 1-800-348-0751 from
8 AM to 6 PM (EST) Monday through Friday. Trained customer service
representatives are available to take your call in English or French.
Habla Español? Si usted tiene alguna pregunta ó necesita asistencia
llame gratis 1-800-348-0755 para los Estados Unidos. Tenemos
representantes que hablan español para atender su llamada.
• For your convenience, Power Wheels®maintains an independently
owned and operated Authorized Service Center Network with more
than 400 authorized service centers nationwide. The authorized
service centers will repair or replace parts under warranty at no extra
charge, and can perform non-warranty repairs for a minimal charge.
To find the authorized service center nearest you, please visit us
on-line at www.powerwheels.com or call 1-800-348-0751.
• To register your vehicle, please visit us on-line at
www.powerwheels.com.
IMPORTANT INFORMATION
A
A Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
B Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
C Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
D Parts Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
E Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
F Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
G Decoration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
H Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
I Battery Care and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
J Safe Driving Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
K Vehicle Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
L Vehicle Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
M Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
N Problems and Solutions Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

J5244pr-0920 3
WARNINGS AND CAUTIONS
B
J5244pr-0920
RIDING HAZARD
• In the unassembled state, this package contains small parts. Adult assembly is required.
• Use the charger in dry locations only.
• Prevent Injuries and Deaths
• Direct Adult Supervision Required
• Never Ride at Night.
• Keep Children Within Safe Riding Areas.
These areas must be:
- away from swimming pools and other bodies of water to prevent drownings
- generally level to prevent tipovers
- away from steps, cars, steep inclines, roads and alleys.
ELECTRICAL HAZARD
WARNING
CAUTION
• Battery can fall out and injure a child if vehicle tips over. Always use battery retainer.
• PREVENT FIRE
- Never modify the electrical system. Alterations could cause a fire resulting in serious injury
and could also ruin the electrical system.
- Use of the wrong type battery or charger could cause a fire or explosion resulting in
serious injury.
- Use of Power Wheels®components in products other than Power Wheels®vehicles could
cause overheating, fire or explosion.
• The battery must be handled by adults only. The battery is heavy and contains sulfuric acid
(electrolyte). Dropping the battery could result in serious injury.
• Never allow children to charge the battery. Battery charging must be done by adults only. A child
could be injured by the electricity involved in charging the battery.
• Read the safety instructions on the battery.
• Examine the battery, charger and their connectors for excessive wear or damage each time
you charge the battery. If damage or excessive wear is detected, do not use the charger or the
battery until you have replaced the worn or damaged part.
• HOT motors. Handle carefully.
WARNING

J5244pr-0920
4
PARTS
C
J5244pr-0920
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product
to the store.
• Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
• Metal parts have been coated with a lubricant to protect them during shipment. Wipe all metal parts with a paper towel to remove any
excess lubricant.
Dash Cover
Seat Belt Strap - 2
Hood
Seat
Steering Wheel
TM
Vehicle
Steering Column
Tailgate

5
TABLE OF CONTENTS
A
J5244pr-0920
5
PARTS
C
J5244pr-0920
6 Volt Battery
Super 6 Volt Charger
®
Steering Wheel Cap
Key
Knob
#8 x 1" Screw – 6
#6 x 1/2" Screw – 2
Fasteners Shown Actual Size
For your convenience, extra fasteners
are included.
3/8" -16 Lock Nut – 2
Taillight Lens Set
(Left) (Right)
Assembly Tool
#6 x 3/
8" Screw – 2
Part Not Shown: Label Sheet

6
TABLE OF CONTENTS
A
J5244pr-0920
6
PARTS PICTURE
D
TM
1
3
2
9
1 Hood
2 Steering Column
3 Steering Wheel
4 Steering Wheel Cap
5 3/8"-16 Lock Nut - 2
6 Dash Cover
7 Key
8 Knob
9 Seat
10 Tailgate
11 Left Taillight
12 Right Taillight
13 Vehicle
14 6 Volt Battery
Label Sheet
Assembly Tool
15 Seat Belt Straps - 2
16 Super 6 Volt Charger
17 #8 x 1" Screw - 6
18 #6 x
1/2" Screw - 2
19 #6 x
3/
8" Screw - 2
Part Not Shown
14
10
11
13
4
7
8
15
6
12
17
17
18
19
®
16
5
5
17

J5244pr-0920 7
BATTERY CHARGING
E
J5244pr-0920
Use the charger in dry locations only.
ELECTRICAL HAZARD
Important Notes
• Your new battery must be charged for at least 18 hours before
you use it in your vehicle for the first time.
• We recommend that you start charging your battery before
beginning assembly of your new vehicle.
• The battery must be upright while charging.
• The charger is not a toy.
• Do not short circuit the battery.
• You do not need to remove the battery from your vehicle to
recharge it.
• Before charging the battery, examine the battery case for cracks
and other damage which may cause sulfuric acid (electrolyte) to
leak during the charging process. If damage is detected, do not
charge the battery or use it in your vehicle. Battery acid is very
corrosive and can cause severe damage to surfaces it contacts.
• Do not charge the battery on a surface (such as kitchen counter
tops) which could be damaged by the acid contained inside the
battery. Take precautions to protect the surface on which you
charge your battery.
• Charge the battery in a well ventilated area.
• Use only a Power Wheels Super 6 Volt charger with an A-style
connector (120VAC 60 Hz 15W with an output of 6VDC 7.2W) to
charge your 6 volt battery.
• Adults Note: Regularly examine the charger for damage to the
cord, plug, housing, or other parts that may result in the risk of fire,
electric shock or injury. In the event of any damage, do not use the
charger until the damage has been properly repaired. Please call
1-800-348-0751.
• If your battery is old and will not accept a charge, do not leave it in
the vehicle. Always remove a dead battery from the vehicle.
About Thermal Fuses
Your Power Wheels 6 volt battery is equipped with a built-in thermal
fuse. The thermal fuse is a self-resetting safety device which
automatically “trips” and shuts down operation of the vehicle if the
vehicle is overloaded or the driving conditions too severe. Once a
fuse has “tripped”, it will automatically reset itself after approximately
25 seconds and allow the vehicle to resume normal operations.
To avoid repeated automatic shut-downs, do not overload the vehicle
by exceeding the 65 lbs (29.5 kg) maximum weight capacity or by
towing anything behind the vehicle. Avoid severe driving conditions,
such as driving up slopes or running into fixed objects, which can
cause the wheels to stop spinning while power is still being supplied
to the motors and make sure your child stops the vehicle before
switching speeds or direction.
If a thermal fuse in a battery continually trips under normal driving
conditions, please contact your local Power Wheels®Authorized
Service Center. For the location of the Authorized Service Center
nearest to you, visit us on-line at www.powerwheels.com,
or call 1-800-348-0751.
• Battery can fall out and injure a child
if vehicle tips over. Always use battery
retainer.
• PREVENT FIRE
- Never modify the electrical system.
Alterations could cause a fire resulting
in serious injury and could also ruin the
electrical system.
- Use of the wrong type battery or charger
could cause a fire or explosion resulting
in serious injury.
- Use of Power Wheels®components in
products other than Power Wheels®
vehicles could cause overheating, fire
or explosion.
• The battery must be handled by adults only.
The battery is heavy and contains sulfuric
acid (electrolyte). Dropping the battery
could result in serious injury.
• Never allow children to charge the battery.
Battery charging must be done by adults
only. A child could be injured by the elec-
tricity involved in charging the battery.
• Read the safety instructions on the battery.
• Examine the battery, charger and their
connectors for excessive wear or damage
each time you charge the battery. If
damage or excessive wear is detected, do
not use the charger or the battery until you
have replaced the worn or damaged part.
WARNING CAUTION

8
TABLE OF CONTENTS
A
J5244pr-0920
8
BATTERY CHARGING
E
J5244pr-0920
®
WARNING
PREVENTFIRE
•Donotb
ypassaPo
w
er
Wheel
•Useonly a RedPo
w
er
Wheels
•Ne
v
ermodifytheelectrical
PREVENTFIRE
•Donotb
ypassaP
o
w
er
Wheel
•UseonlyaRedP
o
w
er
Wheels
•Ne
v
ermodifytheelectrical
Avertissement
1
• Plug the charger and battery connectors together. Push firmly to
make sure the two connectors are completely joined.
A-Style Battery
Connector
A-Style Charger
Connector
INCORRECT
GAP
CORRECT
NO GAP
2
WARNING
PREVENTFIRE
•Donotb
ypassaP
o
wer
Wheel
•UseonlyaRedP
o
w
er
Wheels
•Ne
v
ermodifytheelectrical
PREVENTFIRE
•Donotb
ypassaP
o
wer
Wheel
•UseonlyaRedP
o
w
er
Wheels
•Ne
v
ermodifytheelectrical
Avertissement
• Plug the charger into a standard wall outlet.
Note: If power flow to the wall outlet is controlled by a switch, make
sure the switch is “ON”.
• Before first time use, charge the battery for at least 18 hours.
Never charge the battery longer than 30 hours.
• Recharge the battery for at least 14 hours after each use of your
vehicle. Do not charge the battery longer than 30 hours.
• Once the battery is charged, disconnect the charger connector from
the battery connector. Unplug the charger from the wall outlet. The
battery is now charged and is ready to be installed in your vehicle.
Please see page 15 for detailed battery installation instructions.

9
ASSEMBLY
F
J5244pr-0920
3
Hint: Y ou may want the help of another adult to complete assembly steps
3 through 6.
• Wipe the steering column with a paper towel to remove any
excess lubricant.
• Carefully lift the front end of the vehicle.
• Insert the straight end of the steering column under the front axle,
through the slot in the vehicle and out through the large hole in the
center of the dash.
• Position the dash cover as shown. Make sure the three tabs
are upright.
• Fit the knob into the hole in the right side of the dash cover.
• Fit the key into the hole in the left side of the dash cover.
• Insert a #6 x 3/8" screw into the back of the knob and into the back
of the key. Tighten the screws.
• Insert the tabs on the top of the dash cover into the slots in the dash.
• Lower the bottom of the dash cover.
• Insert two #6 x ½" screws through the dash cover and into the dash.
Tighten the screws.
Children can be harmed by small parts,
sharp edges and sharp points in the
vehicle’s unassembled state, or by
electrical items. Care should be taken in
unpacking and assembly of the vehicle.
Children should not handle parts, including
the battery, or help in assembly of
the vehicle.
WARNING
Knob
Key
Dash Cover
Tabs
Tabs
Slots Dash
Cover
2
Steering Column
Slot
Front Axle
1
BOTTOM VIEW
DASH VIEW

Assembly Tool
10
ASSEMBLY
F
J5244pr-0920
• Place a
3/8"-16 lock nut (rounded side out) on to the end of the
steering column.
• Tighten the lock nut firmly using the closed end of the assembly tool.
• Hold the steering column in place and gently lower the vehicle.
• Position the steering wheel so that the spokes form a “Y” as shown.
• While supporting the steering column, fit the steering wheel onto the
steering column.
• Place a
3/8"-16 lock nut (rounded side out) on to the end of the
steering column.
• Tighten the lock nut firmly using the closed end of the assembly tool.
• Align the slot on the steering wheel cap with the tab in the center of
the steering wheel.
• Fit the steering wheel cap into the center of the steering wheel.
• Insert two #8 x 1" screws into the steering wheel cap. Tighten
the screws.
7
5
Steering
Column
Front Axle Lock Nut
Steering Wheel
Lock Nut
“UP”
Steering
Wheel Cap
6
• Fit the curved end of the steering column into the hole in the front axle.
Note: You may need to straighten the wheels and rotate the steering
column to fit it into the hole in the front axle.
4
Steering Column Hole
Front Axle
Assembly
Tool
DASH VIEW

10
11
ASSEMBLY
F
J5244pr-0920
• Insert both tabs on the seat into the slots in the vehicle.
9
Slots
Seat Tabs
11
• Using safety scissors, remove the taillight lenses from the plastic
connector. Dispose of the plastic connector.
• Face the rear of the vehicle.
• Insert the tabs on the back of the right and left taillight lenses into the
taillight slots in the vehicle body.
Note: The left and right taillight lenses are NOT interchangeable.
• Press firmly to snap the tabs into the slots.
Right
Taillight
Lens
Left
Taillight
Lens
Left Right
Slots
Tab
• Make sure both seat belt straps are fastened together. If they are
not fastened together, connect them to form one seat belt.
• Insert the T-tab at one end of the seat belt through the slot in one
arm of the seat. Do not pull the second T-tab through the slot.
• Repeat this procedure to secure the other end of the seat belt in the seat.
• Pull up on the seat belt to make sure it is securely attached to the seat.
Slot
Second
T-tab
Second
T-tab
Bottom
T-tab
Seat Belt Straps
Seat
8
Note: The seat can be assembled in either of two positions for your
child’s comfort.
• Push down on the center of the seat and slide it toward the rear of
the vehicle.
• Align the screw holes in the back of the seat with the 1st or 2nd set
of holes in the vehicle.
• Check your child’s fit in the vehicle by observing foot to pedal
distance and adjust the position of the seat, if necessary.
• Insert two #8 x 1" screws through the holes in the back of the seat
and into the holes in the vehicle.
• Insert two #8 x 1" screws through the holes in the armrests and into
the vehicle.
• Tighten the screws.
1st
Position
2nd
Position
PUSH
HERE
REAR VIEW

12
F
J5244pr-0920
ASSEMBLY
TM
13
Note: If you have already charged your Power Wheels®battery for
at least 18 hours, you may want to install it in the battery compartment
before assembling the hood. Please refer to the Battery Installation
section on page 15 for instructions.
• Fit the peg on one side of the hood into one of the hood openings
near the base of the windshield area.
• Gently bend the hood to insert the peg on the other side of the
hood into the opening on the other side of the vehicle.
• Lower the hood.
Hood
Openings
Pegs
• Position the tailgate with the flat side facing up.
• Fit the peg on one side of the tailgate into the tailgate opening in
the rear of the vehicle.
• Slide the peg on the other side of the tailgate into the tailgate
opening in the other side of the vehicle.
• Lift the tailgate and press firmly to snap it closed.
12
Pegs
Tailgate
Tailgate
Openings
Flat Side
FRONT VIEW

DECORATION
13 J5244pr-0920 13
G
J5244pr-0920
Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind:
• Wash your hands before applying the labels.
• Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils.
• Place the labels exactly as shown in the illustrations.
• For best results, avoid repositioning a label once it has been applied to the vehicle.
• After applying a label, rub the label firmly with a clean, dry cloth to make sure the label is adhered to your vehicle.
Start at the center of a label, and smooth towards the outer edges to remove air bubbles.
DASH VIEW
FUEL
EF
RPM x 100
CH
TEMP
MPH
23
25
9
1011
24
5
22
REAR VIEW

J5244pr-0920
14
DECORATION
G
J5244pr-0920
TM
®
VOLT
SUPER
6
RECHARGEABLE
BATTERY POWERED
FRONT LEFT VIEW
TM
VOLT
SUPER
6
RECHARGEABLE
BATTERY POWERED
FRONT RIGHT VIEW
18
20
1
4
19
6
14
2
8
16
13
3
3
7
15
2
8
17
12
18
21

15
BATTERY INSTALLATION
J5244pr-0920 15
H
J5244pr-0920
WARNING
PREVENTFIRE
•Donotb
ypassaP
o
wer
Wheel
•UseonlyaRedP
o
wer
Wheels
•Ne
v
ermodifytheelectrical
PREVENTFIRE
•Donotb
ypassaP
o
w
er
Wheel
•UseonlyaRedP
o
w
er
Wheels
•Ne
v
ermodifytheelectrical
Avertissement
3
IMPORTANT! Use only a Power Wheels®6 volt battery with A-style
connector and built-in thermal fuse. Use of any other battery will
damage your vehicle. Make sure that you charge the battery for
at least 18 hours using the enclosed Power Wheels® Super 6 volt
charger before operating your vehicle for the first time. Charge the
battery for at least 14 hours after each use of the vehicle. Never
charge the battery longer than 30 hours. Failure to follow these
instructions may damage your battery and will void your warranty.
Hint: It is easier to install the battery before assembling the hood to
your vehicle. If you have already assembled the hood to your vehicle,
you may want to remove it to install the battery.
• Push and hold the battery retainer in.
• Fit the battery upright in the battery compartment. Make sure
the bottom of the battery is flat on the bottom of the battery
compartment and that the battery connector extends toward the
rear of the vehicle.
• Release the battery retainer to secure the battery.
Motor Harness
Connector
• Plug the motor harness and battery connectors together. Push firmly
to make sure both connectors are completely joined.
1
Hood
• Re-assemble the hood to the vehicle if you have removed it to
install your battery. See Assembly step 13 on page 12.
• Lower the hood.
• Using a slotted screwdriver, turn the lock fasteners to the
unlocked position .
• Press down on the hood so that the lock fastener tabs on the
underside of the hood fit into the lock fastener slots under the
hood in the battery compartment.
• Using a slotted screwdriver, turn the lock fasteners to the locked
position .
• Pull up on the hood to be sure it is securely fastened.
BOTTOM VIEW
Lock
Fasteners Lock
Fasteners
INCORRECT
GAP
CORRECT
NO GAP
2
Battery Connector
Battery
WARNING
PREVENTFIRE
•Donotb
ypassaP
o
w
er
Wheel
•UseonlyaRedP
o
w
er
Wheels
•Ne
v
ermodifytheelectrical
PREVENTFIRE
•Donotb
ypassaP
o
wer
Wheel
•UseonlyaRedP
o
wer
Wheels
•Ne
v
ermodifytheelectrical
Avertissement
Battery Connector
Battery Retainer
Battery

16
BATTERY CARE AND DISPOSAL
J5244pr-0920
16
I
J5244pr-0920
• Your Power Wheels®battery is a non-spillable, sealed lead-acid
battery. They must be recycled or disposed of in an environmentally
sound manner.
• Do not dispose of a lead-acid battery in a fire. The battery may
explode or leak.
• Do not dispose of a lead-acid battery in your regular, household
trash. The incineration, landfilling or mixing of sealed lead-acid
batteries with household trash is prohibited by law in most areas.
• Return an exhausted battery to a federal or state approved lead-acid
battery recycler, such as a Power Wheels®authorized service center
or a local seller of automotive batteries. For the authorized service
center location nearest to you, please visit us on-line at
www.powerwheels.com or call 1-800-348-0751. Contact your
local waste management officials for other information regarding
the environmentally sound collection, recycling and disposal of
lead-acid batteries. If you live in the State of Florida or the State of
Minnesota, it is prohibited by law for anyone to throw away lead-acid
batteries in the municipal waste stream.
Care
If a battery leak develops, avoid contact with the leaking acid and
place the damaged battery in a plastic bag. See information below
for proper disposal.
If acid comes in contact with skin or eyes, flush with cool water for
at least 15 minutes and call a physician.
If acid is internally ingested, give water, milk of magnesia or egg
whites immediately. Never give emetics or induce vomiting. Call
a physician.
• Charge a new battery for at least 18 hours before first use.
Never charge the battery longer than 30 hours. Overcharging or
undercharging the battery may shorten battery life and decrease
vehicle running time.
• After the first charge, recharge the battery for at least 14 hours
after each use. Never charge the battery longer than 30 hours.
Charge the battery after each use, regardless of how long the
vehicle was used.
• The battery must be upright while charging.
• Do not allow the battery to run down completely before charging.
• Charge the battery before storing the vehicle.
• Charge the battery at least once per month, even if the vehicle has
not been used.
• Leaving the battery in a discharged condition will ruin it.
• Always remove an exhausted battery from the vehicle. Battery
leakage and corrosion can damage the vehicle.
• Do not store the battery on a surface (such as a kitchen counter
top) which could be damaged by the acid contained inside the
battery. Take precautions to protect the surface on which you store
the battery.
• Do not store the battery in temperatures above 75° F or below -10° F.
• Use only a Power Wheels®6 volt battery. Remember to charge the
new battery for at least 18 hours before first use.
• Prevent the battery from moving freely inside the battery compart-
ment. Always use the battery retainer to secure the battery in
the battery compartment.
• Examine the battery, charger and their connectors for excessive
wear or damage each time you charge the battery. If damage is
detected, do not use the charger or the battery until you have
replaced the worn or damaged part.
Disposal

17
SAFE DRIVING RULES
J5244pr-0920 17
J
J5244pr-0920
Teach Safety Rules to Children
While children can quickly develop the skill necessary to drive this
vehicle, it is important to remember that their judgment skills are still
very immature. Unsupervised driving by children can lead to serious
injury. Before children use this vehicle, an adult should carefully
evaluate the driving area as well as the children’s skill level and ability
to drive this vehicle safely. Children are not always able to recognize
or anticipate hazards, even when they have been taught about them.
There is no acceptable substitute for direct adult supervision.
Teach appropriate safety rules to your child before allowing operation
of this vehicle. These rules should also be reviewed with neighborhood
children or other playmates who want to drive this vehicle.
Riding Rules
Make sure children know and follow these rules for safe driving:
1. Always sit on the seat.
2. Always wear shoes.
3. Only 1 (one) rider at a time. A child who is not sitting on the seat or
who is standing on the vehicle could fall off, cause a tip-over or block
the driver’s view. A child could be seriously injured.
4. Do not allow any child to drive the vehicle in the street or near
moving (motorized) vehicles.
5. Do not allow any child to drive near bodies of water (such as pools
or creeks), obstructions (such as furniture, low tree limbs or play
equipment), or drop-offs (such as stairs or decks).
6. Do not allow any child to drive the vehicle in the dark.
A child could encounter unexpected obstacles and have an accident.
Operate the vehicle only in the daytime or a well-lit area.
7. Do not allow your child to drive on sloped or inclined surfaces.
Restrict your child’s driving to generally level ground ONLY!
8. Do not allow your child to drive down or across a steep slope.
- The vehicle may gain unsafe speed, even if the pedal is released
to stop.
- The vehicle may tilt and tip over.
- The wheels could lose traction, causing the vehicle to slip.
RIDING HAZARD
• Prevent Injuries and Deaths
• Direct Adult Supervision Required
• Never Ride at Night.
• Keep Children Within Safe Riding Areas.
These areas must be:
- away from swimming pools and other
bodies of water to prevent drownings
- generally level to prevent tipovers
- away from steps, cars, steep inclines,
roads and alleys.
WARNING
9. Do not allow your child to drive up steep inclines. The motor may
stop and the vehicle could roll backwards at an unsafe speed.
10. Never put anything near any moving parts. Rotating parts such as
motors, gear boxes and wheels can snag fingers, hair, etc., causing
serious injury. Do not allow operation of the vehicle when it is on its
side or in an upside-down position.
11. Do not operate the vehicle near flammable vapors (gasoline, paint
thinner, acetone, liquid wax, etc.). The vehicle’s electrical switches,
like most electrical switches, emit an internal spark when first turned
on or turned off. The presence of flammable liquids or vapors could
cause an explosion or a fire. Keep all flammable products in tightly
sealed containers and away from the vehicle.
12. Do not allow a child to operate the vehicle without direct adult
supervision. To prevent unsupervised use of the vehicle, disconnect
the motor harness from the battery when the vehicle is not in use.
To disconnect the motor harness connector and battery connector:
• Rotate the lock fasteners (¼ turn), to the unlocked position using
a slotted screwdriver.
• Lift or remove the hood.
• Unplug the motor harness connector from the battery connector.
• Lower or replace the hood.
• Rotate the lock fasteners (¼ turn), to the locked position using a
slotted screwdriver.

K
18
VEHICLE OPERATION
J5244pr-0920
18 J5244pr-0920
IMPORTANT! Use this vehicle ONLY outdoors. Most interior floor-
ing can be damaged by riding this vehicle indoors. Fisher-Price®
will not be responsible for damage to the floor if the vehicle is
used indoors.
• Your vehicle has a patented, electronic braking system that
automatically stops the vehicle when your child’s foot is lifted from
the pedal.
• Make sure your child is comfortable with steering the vehicle and
automatically knows how to stop.
To Stop
IMPORTANT! To avoid damaging the motors and gears, stop the
vehicle before shifting from forward to reverse.
• Once your child is completely comfortable driving, introduce reverse.
• Make sure the shifter is in the reverse position.
• Press down on the foot pedal. The vehicle moves in reverse at a
maximum of 3½ mph.
• Help your child practice steering to learn how far and how quickly to
turn the steering wheel when driving in reverse.
To Back Up
To Drive
• Make sure the shifter is in the forward position.
• Press down on the foot pedal. The vehicle moves forward at a
maximum of 3½ mph.
• Help your child practice steering to learn how far and how quickly
to turn the steering wheel when driving forward.

19
J5244pr-0920
VEHICLE CARE
LM
• Check all screws, cap nuts and their protective coverings regularly
and tighten as required. Check plastic parts on a regular basis for
cracks or broken pieces.
• During snowy or rainy weather, the vehicle should be stored inside
or under a protective cover. Remember to charge the battery at
least once per month while your vehicle is not in regular use.
• Avoid operating the vehicle in wet or snowy conditions, and do not
spray the vehicle with a hose. Do not wash the vehicle with soap
and water. Water or moisture in the motors or electrical switches
can cause them to corrode, and could cause switch or motor failure.
• Avoid operating the vehicle on sand, loose dirt or gravel. Sand,
loose dirt or gravel in the motors or electrical switches can cause
them to jam, and could cause switch or motor failure.
• The vehicle can be wiped down with a soft, dry cloth. For a shiny
finish, you can wipe plastic parts with a non-wax furniture polish
applied to a soft-cloth. Do not use automotive wax. Do not use
soap and water or spray the vehicle with a hose.
• To ensure that your vehicle stays in good operating order, we
recommend that you periodically have your vehicle checked by a
Power Wheels®authorized service center. For the location of the
authorized service center nearest you, please visit us on-line at
www.powerwheels.com or call 1-800-348-0751.
Bumper-to-Bumper* Limited Warranty
*One year limited warranty from the date of
purchase on the Power Wheels®vehicle.
Six month limited warranty on the 6 volt battery.
For the original purchaser, this one year limited warranty
covers the Power Wheels®ride-on vehicle (purchased from
Power Wheels®) against defects in materials and workmanship.
The six month limited warranty applies only to the 6 volt battery
included by Power Wheels®with the original purchase of the
vehicle. This warranty covers normal use and does not cover the
Power Wheels®vehicle or battery if damaged by unreasonable
use, neglect, accident, abuse, misuse, improper service or other
causes not arising out of defects in materials or workmanship.
Evidence of any attempt at consumer repair will void this
warranty. THIS WARRANTY DOES NOT COVER, AND IS
INTENDED TO EXCLUDE, ANY LIABILITY ON THE PART OF
POWER WHEELS®, WHETHER UNDER THIS WARRANTY OR
IMPLIED BY LAW FOR ANY INDIRECT OR CONSEQUENTIAL
DAMAGES FOR BREACH OF WARRANTY. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION SO THIS
LIMITATION MAY NOT APPLY TO YOU.
Should you need service or assistance with your vehicle during
the warranty period, do not return the vehicle to the store.
Power Wheels®has provided a nationwide network of authorized
service centers. If there is not an authorized service center in
your area, please visit us on-line at www.powerwheels.com or
call Consumer Relations for information, 1-800-348-0751.
This warranty gives you specific legal rights, and you may also
have other rights which may vary from state to state.
PLEASE SAVE YOUR ORIGINAL SALES RECEIPT.
LIMITED WARRANTY

PROBLEMS AND SOLUTIONS GUIDE
20
J5244pr-0920
20
N
J5244pr-0920
PROBLEM POSSIBLE CAUSE SOLUTION
Vehicle does not run Undercharged battery Charge the battery. A new battery should have been
charged for at least 18 hours before using the vehicle for
the first time. After first-time use, recharge the battery for
at least 14 hours after each use. Never charge the battery
longer than 30 hours.
Check all connectors. Make sure the battery connector is
tightly plugged into the charger, and that the
charger is plugged into the wall.
Make sure power flow to the wall outlet is “ON”.
Charger is not working There is no sure way to tell if your charger is working unless
you have a volt meter. If you suspect there is a problem with
your charger, contact your local Power Wheels®authorized
service center. They can test your charger for you.
Tripped thermal fuse The built-in thermal fuse may "trip" and shut down operation
of the vehicle if the vehicle is overloaded or the driving
conditions too severe. The fuse will automatically reset
itself after approximately 25 seconds, allowing the vehicle
to resume normal operation. To avoid repeated automatic
shutdowns, do not overload the vehicle by exceeding the
60 lbs (29.5 kg) maximum weight capacity or by towing
anything behind the vehicle. Do not drive up hills or run into
fixed objects, which can cause the wheels to stop spinning
while power is still being supplied to the motors. If a thermal
fuse continually trips, contact your local Power Wheels®
authorized service center.
Loose wires or loose connectors Check all wires and connectors. Make sure the battery
connector is tightly plugged into the motor harness connector
and that there are no loose wires around the motors.
Dead battery If your battery is old or if you have not followed Battery
Care instructions, your battery may be dead. If you are
unsure whether or not the battery is dead, you can have
it tested at your local Power Wheels®authorized
service center.
Electrical switch damage The electrical switches can become corroded due to
exposure to water or moisture, or can jam due to loose dirt,
sand or gravel. Contact your local Power Wheels®authorized
service center for diagnosis and repair.
Motor damage Contact your local Power Wheels®authorized service center
for diagnosis and repair.
IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience
a problem, please contact Power Wheels®Consumer Relations, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday
through Friday. Or, contact your local Power Wheels®authorized service center. For the location nearest you, please visit us on-line at
www.powerwheels.com, or call 1-800-348-0751.
