Monster MTS DESK User manual

MTS DESK
Instruction Manual
Bedienungsanleitung
Mode d‘emploi

2MTSIM MTS DESK INSTRUCTION MANUAL
2x
1x
PARTS
1x
[dimensions in mm / different scales]
No extra or spare parts listed!
555
40
80
530
40
80
threads
1x
200
40
80
1x
518
40
80
threads
on both sides

3MTSIM MTS DESK INSTRUCTION MANUAL
24x
M8
6x
30
Ø8
16
8
23x
black
6x
1x 1x
3x2x
80
40
80
40
8
30
4x
extrem flat head
black
8,4
16
4x black

4MTSIM MTS DESK INSTRUCTION MANUAL
2x
4x
25
Ø32
Ø6
4,1
15
12,8
4x
M6
4x
8x
6,4
12
6,5
10,8
4x 4x
4
20
PRE-ASSEMBLED
with this parts:

5MTSIM MTS DESK INSTRUCTION MANUAL
==
518 mm
200 mm
ASSEMBLY
fix in middle
position
pre-assembled
universal
connector
pre-assembled
universal
connector

6MTSIM MTS DESK INSTRUCTION MANUAL
2x
slot nut
M8
cap
2x
M8x16
flat head
black

7MTSIM MTS DESK INSTRUCTION MANUAL
2x roller
2x bearing
2x M4x20 flat head
2x curved spring washer
USUALLY PRE-ASSEMBLED
2x
2x
slot nut
M6
2x
star knob
M6x25
4x
washer
Ø12

8MTSIM MTS DESK INSTRUCTION MANUAL
cap
screwable
washers Ø16
black
2x
M8x30
extrem flat head
black
2x
M8x30
extrem flat head
black
cap
screwable
washers Ø16
black

9MTSIM MTS DESK INSTRUCTION MANUAL

10MTSIM MTS DESK INSTRUCTION MANUAL
555 mm
530 mm
4x pre-assembled
universal connector
Use a plan surfaceUse a plan surface
for assembly.for assembly.
caps
threadsthreads
threadsthreads

11MTSIM MTS DESK INSTRUCTION MANUAL
4x
slot nut
M8
4x
slot nut
M8
4x
M8x16
flat head
black
for both sides
min. 80 mm

12MTSIM MTS DESK INSTRUCTION MANUAL

13MTSIM MTS DESK INSTRUCTION MANUAL
4x
slot nut
M8
on the
other
side
too
4x
M8x16
flat head
on the
other
side too

14MTSIM MTS DESK INSTRUCTION MANUAL
roll into the
upper slots
Detail view

15MTSIM MTS DESK INSTRUCTION MANUAL
4x
M8x16
flat head
black
2x
screwable
cap
Detail view
M8x16
flat head
black
screwable
cap

16MTSIM MTS DESK INSTRUCTION MANUAL
Loosen the
red marked
bolts on each
side to adjust
the height.
OPERATION
Loose the 4 star knobs
on each side.
Grab on both sides
and move evenly!

17MTSIM MTS DESK INSTRUCTION MANUAL
Loosen the screws
marked in red to
change the distance of
the desk.
Loosen the screws
marked in red to tilt
the desk.
25°
5°

18MTSIM MTS DESK INSTRUCTION MANUAL
OPTIONAL BIG DESK
ASSEMBLY
3x
slot nut
M8

19-10-2023
3x
M8x16
flat head
black
