Montessori Furniture Wood and Hearts Kitty User manual

ASSEMBLY DETAILS
1 - 1484*70*20 Front base
1 pc.
2 - 1484*70*20 Back base
1 pc.
3 - 1200*50*20 Side Base
2 pcs.
4 - 1440*50*20 Rope ladder side 1
1 pc.
5 - 1440*50*20 Rope ladder side 2
1 pc.
6 - 1440*50*20 Ladder with 5 steps side 1
1 pc.
7 - 1440*50*20 Ladder with 5 steps side 2
1 pc.
8 - 1440*50*20 Ladder with 3 steps side 1
1 pc.
9 - 1440*50*20 Ladder with 3 steps side 2
1 pc.
10 - 1440*50*20 Ladder with 7 steps side 1
1 pc.
11 - 1440*50*20 Ladder with 7 steps side 2
1 pc.
12 - 1440*50*20 Plywood Ladder side 1
1 pc.
13 - 1440*50*20 Plywood Ladder side 2
1 pc.
14 - 1484*50*20 Upper Ladder side 1
1 pc.
15 - 1484*50*20 Upper ladder side 2
1 pc.
16 - 452*50*20
Upper ladder lintel
2 pcs.
18 - Rope
ladder
1 pc.
20 - Long nog
with holes
8 pcs.
19 - Long nog
21 pcs.
21 - Plywood
4 pcs.
17 - Sidewall
2 pcs.
Scandinavian complex "Kitty"
a - Flat head
35 mm screw
94 pcs. +
5 pcs. spare
b - Flat head
30 mm screw
12 pcs. +
2 pcs. spare
c - Flat head
17 mm dull nut
12 pcs. +
2 pcs. spare
d - Screw 30 mm
16 pcs. +
2 pcs. spare
e - 4 mm hex key
2 pcs.

Pic. 2
Lay the Bases (1) and (2) on the floor as shown in the Pic. 1. Mark the position
of holes in the middle. Round grooves in the Side bases (3) should look outside.
Screw the parts (1), (2) and (3) with screws (a), using hex key (e).
Pic. 1
Assemble the Rope Ladder with 4 steps as shown in the Pic. 2. Take the sides
of the Ladder (4, 5) and rope ladder (18). Screw parts together using screws (a)
and hex key (e).
a
a
a
a
a
a
a
a
e
a
a
2
3
3
13
2
a
a
a
a
a
a
a
a
a
e
5
4
5
18
18

Pic. 4
Assemble the Ladder with 5 steps as shown in the Pic. 3. Take the sides of
the Ladder (6, 7) and 5 long nogs (19). Screw the parts together with
screws (a), using hex key (e).
Pic. 3
Assemble the Ladder with 3 steps as shown in the Pic. 4. Take the sides of
the Ladder (8, 9) and 3 long nogs (19). Screw the parts together with
screws (a), using hex key (e).
a
a
a
a
a
a
a
a
a
a
a
e
6
7
19
7
19
a
a
a
a
a
a
a
e
8
9
19
9
19

Pic. 6
Assemble the Ladder with 7 steps as shown in the Pic. 5. Take the sides of
the Ladder (10, 11) and 7 long nogs (19). Screw the parts together with
screws (a), using hex key (e).
Pic. 5
Screw nogs with holes (20) and plywood (21) with screws (d) using a
screwdriver as shown in the Pic. 6
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
e
a
10
11
19
19
10
Pic. 5
d
d
d
d
d
20
21
21
x 4

Pic. 8
Assemble the Plywood ladder as shown in the Pic. 7. Take the sides of
the Ladder (12, 13) and plywood with long nogs. Screw the parts
together with screws (a), using hex key (e).
Pic. 7
Assemble the Upper ladder. Start with Upper ladder side (14), and both
Upper ladder lintels (16), Sidewalls and 6 long nogs (19). Please note
the position of the holes with round grooves on the sides of the ladder -
they should look inside. See Pic. 8. Connect the Lintels (16), nogs (19)
to Upper ladder side (15) with screws (a) using hex key (e).
a
a
a
aa
a
a
aa
a
a
aa
a
a
a
a
e
a
12
13
21
20
20
13
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
e
a
a
16
16
15
14
19
19
14

Pic. 10
Connect the Sidewalls (17) to Lintels (16) using screws (b), nuts (c) and both
hex keys (e) as shown in the Pic. 9.
Pic. 9
Assmeble the Rope Ladder and Plywood Ladder with Sidewall (17) using
screws (b), nuts (c) and both hex keys (e). Screw the Rope Ladder and
Plywood Ladder with Upper Ladder with screws (a), using hex key (e).
See Pic. 10.
e
16
17
16
b
bb
b
15
14
12
13
4
5
17
b
e
b
17
5
15 12

Pic. 12
Assemble the Ladder with 5 steps with Upper Ladder side 1 (14) with screws (a),
using hex key (e). See Pic. 11.
Pic. 11
Assemble the Ladder with 3 and 7 steps with Sidewall (17) using screws (b),
nuts (c) and both hex keys (e). Screw the Ladder with 3 and 7 steps with
Upper Ladder with screws (a), using hex key (e). See Pic. 12.
15
14 14
7
6
b
b
b
b
15
14
15
c
e
c
9
17
17

Pic. 13
Assemble the Vertical Ladders with Front (1) and Back (2) base using screws (a)
and hex key (e). See Pic. 13.
a
a
a
a
a
a
a
a
a
a
8
6
2
1
e
a
1
3
3
To be used for its intended purpose only and under
the direct supervision of an adult!
All the responsibility for children’s injuries received during
games on the furniture lies on adults watching after them.
Always be vigilant during children's games!
