Montigo H36PVN Instruction Manual


H36PVN  

PowerVent
FlushFace
Fireplace
®
C US
Read and understand this manual.
Improper installation, adjustment,
alteration, service or maintenance
can cause serious injury, property
damage or even death. For
assistance or additional information
consult a qualified installer, service
agency or the gas supplier.
DANGER
XW2002
XW2004
Glass doors on gas fireplaces are
extremely hot while the fireplace is
on and remain hot even after the
fireplace has been turned off. Safety
screens are available and can reduce
the risks of severe burns. Please
keep children away from the fireplace
at all times.
CAUTION

Do not store or use gasoline or any
other flammable vapors and liquids in
the vicinity of this or any other gas
burning appliance. A fire or explosion
my occur causing serious injury,
property damage or even death.
WARNING
XW2006
Installer: Leave this manual with the
appliance. Do not remove.
Consumer: Retain this manual for
maintenance and future reference. Do
not Discard.
NOTICE
XW2012
IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier
from a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
NOTICE
XW2014
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
XG0694 030711
H36PVN Shown
Langley, BC V4W 4A1 |  Ferndale, WA 98248
H36PVN Shown
H36PV Manual

Page2
You must read and understand this
manual prior to installation, operation or
troubleshooting this appliance. Please
retain this owner’s manual for furure
reference and maintenance.
NOTICE
XW2010
XG0649 - 031511


SafetyAlertKey 3
Introduction 3
Model 3
Installation 4
SectionA:BeforeYouBegin 4
Important Message 4
Beforeyoustart 4
Pre-Installation Checklist                            4
Understanding Basic Operation                      4
Installation Checklist                               4
Section1:InstallationOverviewandProductDimensions      5
The H36 PV Fireplace                              5
Fireplace dimensions                             5
Clearances 5
Section2:FramingtheFireplace 6
Rough frame-in Dimensions                         6
Fireplace Installation                               6
Section3:Finishing 7
Installing Non-combustible materials                  7
Installing Combustible Materials                      7
Combustible mantles and facings                     8
Fireplace facing 8
Mantles and surrounds                             8
Section4:InstallingthePowerVent 9
Installing the roof mounted power vent                 9
Venting Layout 9
Typical Vertical Vent 9
Multi-Elbow Vertical Vent 9
Downward Vertical Vent 9
Venting Components                              10
Installation of the External roof mounted power vent        11
Installing the external roof mounted power vent module       12
Installing a Wall Mounted Vertical Exterior Power Vent     13
Venting Layout 13
Multi-Elbow Installations 13
Downward Vertical Venting 13
Venting Components 14
Installation of the external wall mounted power vent        15
Installing the external wall mounted power vent module     16
Installing In-Line Linear Power Vent 17
Venting Layout 17
Typical Vertical Vent 17
Multi-Elbow Vertical Vent 17
Downward Vertical Vent 17
Venting Components 18
Section5:Wiring 19
Installation Of Electrical Supply                      20
Installing The Remote Switch                       21
HSI Wiring Schematic                             22
Conduit & Wiring clearances                       23
IPI Wiring Schematic                              23
Section6:InstallingtheGasLine 24
Fuel Consumption 24
Pressure requirements:                            24
Gas Connection 24
Section7:Removing&InstallingtheDoor 25
Removing the doors:                              25
Installing the Door: 25
Section8:InstallingtheLogset 26-27
Operation 28
Section9:Start-upSequence 28
Honeywell Intermittent Pilot                         28
For Your Safety - READ BEFORE LIGHTING          29
Lighting Instructions                               29
Maintenance 30
Section10:CleaningandMaintenance 30
Removing the log grate                            30
Removing the Brick lining / Refractory                30
Removing the standoffs                            31
Removing the rebox access Panel                  32
General 32
Cleaning 32
Troubleshooting 33
Replacement Parts 33
AppendixA 34
PowerVentLocations 34
Vertical Power Vent Detail                          35
Horizontal Power Vent Detail                        35
AppendixB 36
Warranty 36
AppendixC 37
State of Massachusetts                              37

Page3
XG0649 - 031511




Congratulations on your purchase of a MontigoFireplace
With over 30 years of experience, Montigo is committed to
providing you with a gas replace that is not only a beautiful
addition to your space, but that is also designed and manufactured
to the highest safety, reliability and engineering standards
We strongly encourage you to read and carefully follow
the instructions laid out in this Installation, Operation and
Maintenance Manual and retain it for your future reference
Pay special attention to all cautions, warnings, and notices
throughout this manual intended to ensure your safety
This manual covers installation, operation and maintenance
Lighting, operation and care of this replace can be easily
performed by the homeowner All installation and service work
should be performed by a qualied or licensed installer, plumber
or gas tter as certied by the state, province, region or governing
body where the replace is being installed
This installation, operation and maintenance manual is applicable
to the models described below Refer to your rating plate to
verify included options
WarrantyandInstallationInformation:(SeeAppendixB)
The Montigo warranty will be voided by, and Montigo disclaims
any responsibility for, the following actions:
► Modication of the replace and/or components including
Direct-Vent assembly or glass doors
► Use of any component part not manufactured or approved
by Montigo in combination with this Montigo replace system
► Installation other than as instructed in this manual
Consult your local Gas Inspection Branch on installation
requirements for factory-built gas replaces Installation & repairs
should be done by a qualied contractor

Model# NaturalGas Propane VentingType BurnerType IgnitionType
H36PVN 55,000 --- Top Power Vent Traditional IPI Electronic Ignition
 
Hot glass will cause
burns Do not touch
glass until unit is cooled
Never allow children to
touch glass
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Indicates a hazardous situation which, if not
avoided, WILL result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, COULD result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, WILL result in minor or moderate
injury.
Address practices that are important, but
not related to personal injury
DANGER WARNING
CAUTION NOTICE


Page4 XG0649 - 031511

Section:SectionA:BeforeYouBegin
Installation and repairs should be done by an
authorized gas fireplace service technician. The
appliance should be inspected before use and at
least annually by a professional. More frequesnt
cleaning may be required due to exessive lint from
carpeting, bedding material, ect. It is imperative
that control compartments, burners and circulating
air passageways of the fireplace are kept clean.
NOTICE
XW2016
Important Message
Save these Instructions
The H36PV Power Vent replaces must be installed in
accordance with these Instructions Carefully read all the
Instructions in this manual rst Consult the Local Gas Branch to
determine the need for a permit prior to starting the installation
It is the responsibility of the installer to ensure this replace is
installed in compliance with the manufacturers instructions and
all applicable codes
BEFOREYOUSTART:
Pre-Installation Checklist
■ Determine the desired install location of your replace
■ See Section 1, Dimensions on Page 5, and refer to the
Framing Section 2 for details
■ Select your type and location of your Power Vent
run: Roof Mounted (EDVRSPV58) or Wall Mounted
(EDVWSPV58)
■ Your termination location should be selected to provide
the shortest possible vent run
■
Lay out the Vent run; calculating the required elbows
and straight runs of 5"/8" ex or rigid pipe
■ Refer to the Section 4 on Page 10, "Installing the Power
Vent" for details
■
Montigo supplies 20' of low voltage wire, which can be
spliced to any length This wire CANNOT run in conduit
with any other wire
■ Refer to Section 5 on Page 18, for Wiring Details
■
The gas connection is located on the bottom side of the
replace
■ Refer to local codes and guidelines for installation
requirements
■
Installation and repairs should be done by a qualied
contractor and must conform to:
 • InstallationsinCanada must conform to the current
CAN/CGA B-1491 and
2 Gas Installation Code and
local regulations
• InstallationsintheUSA must conform to local
codes, or in the absence of local codes to the National
Fuel Gas Code, ANSI Z2231-1988
• SeeAppendixCforinstallationwithintheState
ofMassachusetts. This replace must comply with
NFPA-54 Chapter 10
■ Refer to Section 6 Page 21, "Installing the Gas Line" for
Details
Understanding the Basic Operation
Residential H36PV replace
To operate the replace, Montigo has supplied and installed
twenty feet of low voltage wire to this electrical control panel
Connect the two wire harness to a standard single pole ON/
Off switch located at a location of your choice You may also
extent these wires to any length, as long as you select a wire
of equal quality
XW2018
Due to high operating temperatures, this appliance
should be located out of traffic & away from
furniture and draperies.
Children and adults should be alerted to the
hazards of the high surface temperature, which
could cause burns or clothing ignition.
Young children should be carefully supervised
when they are in the same room as the appliance.
Clothing or other flammable materials should not
be placed on or near the appliance.
CAUTION
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
When this appliance is installed directly
on any combustible material other than
wood flooring, it must be installed on a
metal or wood panel extending the full
width and depth of the appliance or a
fire will occur causing serious injury,
property damage or even death.
XW2020
DANGER
XW2020-When-Installed_[EN].pdf 1 1/24/2011 12:48:53 PM


Page5
XG0649 - 031511

Section1:InstallationOverviewandProductDimensions
PleasereviewthePre-InstallationChecklistonPage4
forgeneralinformationonpreparingforasuccessful
installationofyourreplace.
The H-Series H36PVN & replace
TheH36PVNreplaces may be installed in any location that
maintains proper clearances to air conditioning ducts, electrical
wiring and plumbing Safety, as well as efciency of operation,
must be considered when selecting the replace location Try
to select a location that does not interfere with room trafc,
has adequate ventilation, and offers an accessible pathway for
Power Vent installation
The replace dimensions are shown below:
Clearances
To ensure the H-Series H36PVN Fireplaces operate safely, all
models must maintain the following clearances
*Note: Finishing hardwood, laminate ooring, or tile may be placed
directly in front of replace, however Montigo waives responsibility for
discoloration of ooring materials Ability to withstand heat should be
discussed with the ooring manufacturer If carpet is to laid there must
be a 12" clearance or hearth between the front of the replace and the
start of the carpet
The H36PVN & H36PVL are power vented
fireplace systems. Under no circumstances can
these model(s) be installed without a power vent
module.
For regular Horizontal vent installation use 5"/8"
model EDVWSPV58 with the rough-in kit,
EDVWSPV58F for the
For regular Vertical vent installation use 5"/8"
model EDVRSPV58 with the rough-in kit, EPVF58
for the H36PVN & H36PVL.
WARNING
XW2022

Model# Top Sides Back Floor
(under)
Floor
(front)*
H36PVN 8" 0" 1" 0" 0"
Figure1.Fireplace dimensions.
23”
32”
8 3/4”
C
L
8”
5”
41 ¼”
46”
2” 2”
¾”
9”
31 ½”
38 ½”
Nailing
Flange
Nailing
Flange
1”
5 ¾”
23”
Power Vent
Communication
Harness Port
Main Incoming A/C
Power Connection
Wht Access Panel
Wall Switch
LVT Connection
10”
4”
Flexible Incoming
Gas Connection
Access
Panel
Blk
Top View
Front ViewLeft
Side View
Right
Side View
23”
32”
8 3/4”
C
L
8”
5”
41 ¼”
46”
2” 2”
¾”
9”
31 ½”
38 ½”
Nailing
Flange
Nailing
Flange
1”
5 ¾”
23”
Power Vent
Communication
Harness Port
Main Incoming A/C
Power Connection
Wht Access Panel
Wall Switch
LVT Connection
10”
4”
Flexible Incoming
Gas Connection
Access
Panel
Blk
Top View
Front ViewLeft
Side View
Right
Side View


Page6 XG0649 - 031511

Section2:Framing
Step1. To frame in the unit rst frame a rough-in enclosure with
combustible framing materials, using typical framing practices The
rough-in frame opening for the assembled replace is 46" wide, x
50" high x 24" deep See Figure 2
NOTE:Whenconstructingtheframedopening,pleaseensure
thatyourcombustible2x4headerisat50"minimumand
thatthereisaccesstoinstallthegaslinewhentheunitis
installed.SeeFigures1and2a.
Step2 Place the Fireplace in the enclosure and install the Vent pipe,
and Power Vent module Next, Connect the Gas line and provide a
gas service shut-off valve; according to local gas codes, then secure
in place with 1/4" wood screws Install supplied Non-combustible
header at 45½" from oor
46”
24”
50”
(minimum)
Flexible
incoming gas
connection
Secure nailing
flange to 2 x 4’s
using ¼" wood
screws.
Non-combustible Header (supplied by montigo), install to allow
15½” of Non-combustible cement board to fasten above the
glass of the unit and Non-combustible header.
Figure 2a. Fireplace installation, (Inlet Gas & Power Vent) .
Figure 2. Fireplace installation (combustible frame dimensions)


Page7
XG0649 - 031511

Section3:Finishing
Step1. As shown in Figure 3; Use Non combustible Cement board,
supplied by Montigo, screw to Non-combustible Header and 2 x 4's
at sides of unit (see gure 2a on page 6) using sheet metal screws
Step2. As shown in gure 3a; Cut standard Drywall / Wall board
to complete the installation of replace surround
Non-combustible Cement Board
(supplied by montigo).
Fasten above the glass of the
unit to Non-combustible header
and 2 x 4’s at side of unit.
Combustible Drywall / Wall
Board or equivelant.
Fasten above the glass of the
unit to Non-combustible header
and 2 x 4’s at side of unit.
Figure 3. Non-combustible Cement Board the Fireplace, (supplied by Montigo).
Figure 3a.


Page8 XG0649 - 031511

Figure 3b. Combustible mantle and facings. (Not to scale)
Fireplace Facing
When selecting the nish material for your replace, it is important
to remember the following:
If the surround of the replace is to be painted to match the room decor,
heat-resistant paint must be provided  Also, decorative facing must
not extend past the replace opening at all, because it will interfere
with the access to retainers for removal of glass door and access to
the lower compartment
Mantels & Surrounds
National Canadian Gas Association mantel test requirements are for
re hazard prevention to combustible materials
Please be aware; temperatures over the mantel will rise above normal
room temperature and walls above replace may be hot to touch
XW2034
We recommend careful consideration
be given to the effects of elevated
mantel temperatures which may be in
excess of product design, for example:
candles, plastic or pictures. This can
cause melting, deformation, discolor-
ation or premature failure of T.V. radio,
and other electronic components.
CAUTION
When covering the upper metal
portion of the fireplace, (as shown,
Fig.16) with a non-combustible
material, Please Note: The
decorative facing materials may
be subject to temperatures in
excess of 250° F. This should be
considered when selecting facing
materials.
CAUTION
XW2036
Non-Combustible
Cement Board
(supplied by Montigo)
Non-Combustible
Cement Board
(supplied by Montigo)
Drywall/
Combustible Construction
To Ceiling
Horizontal Run
12” 11” 10” 9” 8” 7” 6” 5” 4” 3” 2” 1”
Vertical Run
Glass
16”
15”
14”
13”
12”
11”
10”
9”
8”
7”
6”
5”
4”
3”
2”
1”
Non-combustible
Header (supplied by
Montigo @ 6½”)
Combustible Construction
allowed in shaded area
First Combustible
Header @ 50"
from floor or 8”
from top of unit

H36PVN Power Vent Indoor Gas Fireplace
Page 9
XG0649 - 031511
Installation
Section 4: Installing the Power Vent
Figure4a. Multi-elbowVentingInstallations.
Multi-ElbowInstallations
Multi-elbow installations are possible up to a maximum of six
at 90° elbows
Figure4b. DownwardVentingInstallations.
DownwardVerticalVenting
Note: The downward vent run must not exceed 6' of vent run
Figure4TypicalstraightVentingInstallations.
Montigosuppliesavariety ofpowerventingoptions Thelocationof
thepowerventshouldbeselectedandlaidouttoprovidetheshortest
possibleruntoanexternalwallorthroughtheroof Intheevent that
the external power vent is not aesthetically acceptable or otherwise
infeasible,anin-linepowerventcanbeusedwiththisandisincluded
on page 17 of this instruction manual (contact Montigo for Details)
Installing a Roof Mounted Vertical Exterior Power Vent
(EDVRSPV58)
Thissectionappliesto installationswheretheshortestpossible vent
runisthroughtheroof RefertoAppendixA-PowerVentlocations,
to ensure the planned Power vent location is acceptable Once the
vent location has been established, please refer to the appropriate
section below for installation details
Venting Layout
Selectionofcomponentsanddetailsofventinglayoutshouldadhere
to the following guidelines:
■Ensure there is a minimum run of 2’ of straight pipe before
the power vent
■Ensure the maximum vent run does not exceed 80’
■Ensure the number of 90° elbows does not exceed 6
■Ensure the number of 45° elbows does not exceed 12
Straight Venting Layout
Venting Installation
V (Maximum Length) Max. # Elbows
100 Feet 0
Multi Elbow - Venting Installation
V1 + H1 + V2 + H2 + V3
(Maximum Length) Max. # Elbows
40 Feet 6
V
Elbow1
Elbow 2 Elbow 3
Elbow5
Elbow 4
H2
H1
V1
V2
V3
Elbow1
Elbow2 Elbow3
Elbow
H1
V1 D = 6’ foot
MAX
V3
H2
Elbow4
Multi Elbow - Venting Installation
V1 + H1 + V2 + H2 + V3
(Maximum Length) Max. # Elbows
80 Feet 6
WARNING:
MUST
on the door gasket and/or explosion ports will result in
products of combustion leaking into the living space and
may result in carbon monoxide poisoning.


Page10 XG0649 - 031511






Connect all vent sections using a minimum of three sheet
metal screws on the outer pipe ue
Ensure the pipe ends male to female slide in a minimum
of 1 1/2“ of overlap
Ensure all runs are supported with a minimum of 3 supports
per 10’ of venting
When hanging/ supporting venting, ensure that 1” clearance
is maintained on all sides to any combustible material
Ensure when cutting sections of rigid pipe to maintain
integrity of internal supports
Place the springs, supplied with the pipe kit, between the
outer and inner pipes to keep the pipes separate and avoid
any possible hot spots
Montigo recommends the use of a ex section for the nal
pipe connected directly to the replace offering greater
exibility of installation and absorption of movement
All exterior joints in venting should be sealed with high heat
silicone 706 High Temp
A - Termination EDVRSPV58
B - Rough-in Frame EDVRSPV58F
C - Flex Sections PLF-1 (12" Section)
PLF-2 (24" Section)
PFL-3 (36" Section)
PFL 4 (48" Section)
D - Rigid Sections PEXT-1 (12" m/f Section)
PXT-20 (20" Section)
PEXT-2 (24" m/f Section)
PEXT-3 (36" m/f Section)
PEXT-4 (48" m/f Section)
E - Elbows PEL-90MM (m/m 90º Elbow
PEL-90FF (f/f 90º Elbow
PEL-90FM (f/m 90º Elbow)
PEL-45FM (f/m 90º Elbow)
F - Power Cord
Harnesses
EPVH10-10 foot power cord & harness
EPVH20-20 foot power cord & harness
EPVH30-30 foot power cord & harness
EPVH40-40 foot power cord & harness
EPVH50-50 foot power cord & harness
EPVH60-60 foot power cord & harness
EPVH70-70 foot power cord & harness
EPVH80-80 foot power cord & harness
EPVH70-70 foot power cord & harness
EPVH70-70 foot power cord & harness
EPVH80-80 foot power cord & harness
EPVH90-90 foot power cord & harness
EPVH100-100 foot power cord & harness
Installation of the EDVRSPV58 External roof mounted power vent
module.
Refer to Appendix A - Power Vent locations, to ensure the planned
Vertical Power vent location is acceptable
The EDVRSPV58F Rough-in Frame dimensions:
The EDVRSPV58 Power Vent dimensions:
Top View
Front View
Ø14”
8 1/2”
19 1/4”
Ø 1/2”
2”
18”
18”
Top View
Front View
Ø 8”
14”
6”
18”
18”


Page11
XG0649 - 031511

Figure 5. Construction, Rough-in framing.
Step1.
Construct a Vertical Chase for the termination opening to meet
the following requirements:
■ Opening Size must be: 14 1/2" x 14 1/2" x 18" Min height
Step2.
Install the Vent pipe female end up, and 2" to 3" MAX from the
top of the Constructed Chase Also, at this point install the Electrical
harness, (EPVH-(10-100) that will communicate with the Power
Vent Module
Figure5a.Installation, Vertical Vent pipe (female end top end).
Figure 5b. Installation of Rough-in Kit
Step3.
Install the Power Vent Rough-in Kit Pull wire harness through
the supplied hole in the bottom corner of the rough-in box, and snap
into the slot provided, (See gure 5b inset)
Figure 5c. (Fasten Rough-in Kit to framing)
Step4.
Install fasteners around perimeter of Rough-in Kit (Holes supplied
for ease of installation)
Figure 5d. (Installed Stainless steel cover)
Installing the external roof mounted power vent module
All venting material must be sealed with high heat
silicone sealant RV230. All venting material to be
Montigo flex pipe, with as few joints as possible.
All joints use MVA vent splice, sealed thoroughly
with silicone. Montigo will not be held responsible
for any water damage that may occur from not
installing the equipment as specified by this
document.
WARNING
XW2024
14½"14½"
18"
Vent Chase
Electrical Harness
with connection
2" to 3" Max.
Vent Pipe
Power Vent
Rough-in Kit
Electrical
Harness
Electrical Harness
Connerctor Location
Install Fasteners around
perimeter of Rough-in Kit


Page12 XG0649 - 031511

Figure 5g. (Installation of Power Vent Module)
Install Power Vent Module
with Power / Communication
Harness
Vertical Roof Top
Power Vent
Vertical Roof Top
Power Vent Rough-
in Kit
Step5.
Install the Power Vent, Roof-top Stainless steel cover over the
Installed Rough-in Kit (You can see the Electrical harness connector
in the top right corner)
Figure 5e. Figure 5f.
Step6.
Install the Power Vent Module Power / communication harness
Hold the Power Vent in close proximity of the assembled Chase,
(with stainless steel cover attached) and plug in the Power Vent
communication / Power Cord (Note the direction and orientation of
the plug socket) (See Figure 5e & Figure 5f)
Electrical Harness
from Power Vent
Step7.
Install the Power Vent Module Place the Power Vent Module
over the stainless steel cover ange and vent pipe, aligning the
Power Vent into nal position Ensure the Harness is placed down
in the Rough-in box when placing the Power Vent Module into place
The Power Vent Module will sit ush with the stainless steel cover
if installed correctly
Figure 5h. (Installed Power Vent Module)
Step8.
Install (3) three stainless steel fasteners around Power Vent
Module @120 degrees (penetrating through the inner stainless steel
vent cover)
Stainless Steel
Fasteners
CAUTION!
 Vent terminations can be very hot. The termination is to be installed higher than 7 feet above a public walkway.
 Do not obstruct, or attempt to conceal, the vent termination. These actions will aect the operation of the replace, and may be hazardous.
 In heavy snow areas, take extra care to prevent snow buildup from obstructing the vent termination.
■ Vent terminations can be very hot. The
termination is to be installed higher than 7 feet
above a public walkway.
■ Do not obstruct, or attempt to conceal, the vent
termination. These actions will affect the operation
of the fireplace, and may be hazardous.
■ In heavy snow areas, take extra care to
prevent snow buildup from obstructing the vent
termination.
CAUTION
XW2026


Page13
XG0649 - 031511

Venting Layout
Selection of components and details of venting lay out should adhere
to the following guidelines:
■ Ensure there is a minimum run of 2’ of straight pipe before
the power vent
■ Ensure the maximum vent run does not exceed 100’
■ Ensure the number of 90° elbows does not exceed 6
■ Ensure the number of 45° elbows does not exceed 12
Figure 6. Typical Venting Installations.
Multi-Elbow Installations
Multi-elbow installations are possible up to a maximum of six
at 90° elbows
Figure 6a. Multi-elbow Venting Installations.
Figure 6b. Downward Venting Installations.
Downward Vertical Venting
Note: The downward vent run must not exceed 6' of vent run
Installing a Wall Mounted Vertical Exterior Power Vent
(EDVWSPV58)
This section applies to installations where the shortest possible vent
run is through an exterior wall Refer to Appendix A - Power Vent
locations, to ensure the planned Power vent location is acceptable
Once the vent location has been established, please refer to the
appropriate section below for installation details
Once the vent location has been established, please refer to the
appropriate section below for installation details
All venting material must be sealed with high heat
silicone sealant RV230. All venting material to be
Montigo flex pipe, with as few joints as possible.
All joints use MVA vent splice, sealed thoroughly
with silicone. Montigo will not be held responsible
for any water damage that may occur from not
installing the equipment as specified by this
document.
WARNING
XW2024
VentingInstallation
V+H(MaximumLength) Max.#
Elbows
80 Feet 6
MultiElbow-VentingInstallation
V1+H1+V2+H2+V3=H3
(MaximumLength)
Max.#
Elbows
80 Feet 6
MultiElbow-VentingInstallation
V1+H1+D+H2
(MaximumLength)
Max.#
Elbows
40 Feet 6
H
V
Elbow 1
Elbow 2
Elbow 3
Elbow 5
Elbow 4
Elbow 6
H3
H2
H1
V1
V2
V3
H2
H1
VD


Page14 XG0649 - 031511

Venting Components
The following venting components and associated Montigo part
numbers are available for the EDVWSPV58:
Connectionandinstallationoftheventcomponentsshould
adheretothefollowingguidelines:
■ Connect all vent sections using a minimum of three sheet
metal screws on the outer pipe ue
■
Ensure the pipe ends male to female slide in a minimum
of 1 1/2“ of overlap
■ Ensure all runs are supported with a minimum of 3 supports
per 10’ of venting
■ When hanging/ supporting venting, ensure that 1” clearance
is maintained on all sides to any combustible material
■ Ensure when cutting sections of rigid pipe to maintain
integrity of internal supports
■
Place the springs, supplied with the pipe kit, between the
outer and inner pipes to keep the pipes separate and avoid
any possible hot spots
■ Montigo recommends the use of a ex section for the nal
pipe connected directly to the replace offering greater
exibility of installation and absorption of movement
■
All exterior joints in venting should be sealed with high heat
silicone RV230
Installation of the EDVWSPV58 external wall mounted power vent
module.
Refer to Appendix A - Power Vent locations, to ensure the planned
Vertical Power vent location is acceptable
The EDVWSPV58 Power Vent dimensions:
The EPVF58 Rough-in Frame dimensions:
9 3/4"
10 9/16"
5
9.0
11 1/16"
11 1/16"
11 1/16"
10 9/16"
5
9.0
14 1/4"
14 1/16"
1 1/2"
4 9/16"
8
12 1/8"
9 11/16"
12 5/16"
4
9 11/16"
ISOMETRIC VIEW
EPVF58 DIMS (2).pdf 1 3/7/2011 9:16:30 AM
A - Termination EDVRSPV58
B - Rough-in Frame EDVRSPV58F
C - Flex Sections PLF-1 (12" Section)
PLF-2 (24" Section)
PFL-3 (36" Section)
PFL 4 (48" Section)
D - Rigid Sections PEXT-1 (12" m/f Section)
PXT-20 (20" Section)
PEXT-2 (24" m/f Section)
PEXT-3 (36" m/f Section)
PEXT-4 (48" m/f Section)
E - Elbows PEL-90MM (m/m 90º Elbow
PEL-90FF (f/f 90º Elbow
PEL-90FM (f/m 90º Elbow)
PEL-45FM (f/m 90º Elbow)
F - Power Cord
Harnesses
EPVH10-10 foot power cord & harness
EPVH20-20 foot power cord & harness
EPVH30-30 foot power cord & harness
EPVH40-40 foot power cord & harness
EPVH50-50 foot power cord & harness
EPVH60-60 foot power cord & harness
EPVH70-70 foot power cord & harness
EPVH80-80 foot power cord & harness
EPVH70-70 foot power cord & harness
EPVH70-70 foot power cord & harness
EPVH80-80 foot power cord & harness
EPVH90-90 foot power cord & harness
EPVH100-100 foot power cord & harness


Page15
XG0649 - 031511

Figure 7. Framing the Opening for Power Vent
14 1/2”
14 1/2”
(Opening)
(Opening)
Step2.
Insert the Power Vent Rough-in Box as shown in Figure 7a
Fasten the Box securely in place with Screws or nails Apply exterior
sheathing and nishing if required
Step3.
Next, remove the bottom collar and conduit mounting frame as
shown Figure 7b (Place removed hardware in a handy location for
re-assembly)
Figure 7a. Orientation, Placing the Power Vent Inner Box
Framing
Rough-in Frame
Fasteners
Figure 7b. Installation of Rough-in Kit
Installing the external wall mounted power vent module
Step1. Construct a frame for the termination opening to meet the
following requirements:
■ Opening Size must be: 14 1/2" x 14 1/2"
Figure 7c. Installation of Power Vent Conduit
Power Vent Conduit
Strain Relief
Nut
Step4.
Insert the conduit from the Power Vent Module into the rough-in
frame through the two top right entry holes Remove the nut from the
supplied strain relief and place as shown, Figure 7c
Strain Relief
Figure 7d. (Installing Conduit connector & conduit mounting frame)
Power Vent Conduit
Strain Relief & tightened nut
Power Vent
Connector
Conduit
mounting
frame
Step5.
Securely fasten bottom Collar pan into the Rough-in frame using
the existing hardware, (4-pcs) Tighten Strain Relief nut onto Strain
relief
Step6.
Pull Power Vent Connector, (from behind) half-way through
supplied hole in conduit mounting frame, and snap into place, (notches
in two plastic wing clips Orientation not critical)
Tightened hardware, 4-pcs.
Step7.
Fasten Conduit mounting frame into place using existing hardware,
(6-pcs) (Coil conduit in behind cover)


Page16 XG0649 - 031511

CAUTION!
 Vent terminations can be very hot. The termination is to be installed higher than 7 feet above a public walkway.
 Do not obstruct, or attempt to conceal, the vent termination. These actions will aect the operation of the replace, and may be hazardous.
 In heavy snow areas, take extra care to prevent snow buildup from obstructing the vent termination.
■ Vent terminations can be very hot. The
termination is to be installed higher than 7 feet
above a public walkway.
■ Do not obstruct, or attempt to conceal, the vent
termination. These actions will affect the operation
of the fireplace, and may be hazardous.
■ In heavy snow areas, take extra care to
prevent snow buildup from obstructing the vent
termination.
CAUTION
XW2026
Step8.
Install the Power Vent Power / communication harness Hold
the Power Vent in close proximity of the assembled Rough-in Kit,
and plug in the Power Vent communication / Power Cord (Note the
direction and orientation of the pins inside the Power Vent connector,
snap together). (Figure 7f)
Step9.
Install the Power Vent Place the Power Vent into the Rough-in
frame, aligning the Power Vent into nal position Ensure the Harness
is placed down in the Rough-in box when placing the Power Vent
(Secure the Power Vent in Place with the supplied hardware).
Figure 7f. (Installation of Power Vent communication harness)
TOP of Power Vent,
(Note Quantity of
louvers).
Note louver
direction
Tightened hardware,
4-pcs.
Communication
Harness.
Figure 7g. (Completed Installation of Power Vent)
Figure 7e. (Assembled Rough-in Kit)
Tightened hardware, 6-pcs.
Installed Power Vent
Connector


Page17
XG0649 - 031511

InstallinganIn-LineLinearPowerVent(LDVPV58)
Thissectionappliestoinstallationswhereanexternalroof
orwallmountedpowerventisnotaestheticallyacceptable
orfeasible.
VentingLayout
Selectionofcomponentsanddetailsofventinglayoutshould
adheretothefollowingguidelines:
Ensure there is a minimum run of 2’ of straight pipe between
the replace and the power vent
Ensure the maximum vent run does not exceed 60'
Maximum vent run must be reduced by 10’ for 1’ of pipe
running in a vertical downward direction
Ensure the number of 90º elbows does not exceed 3 (maximum
allowable vent run must be reduced by 10’ for every additional
90º elbow added)
Ensure the number of 45º elbows does not exceed 6
LinearPowerVent-HorizontalTermination
ExampleA. Vertical mounting with horizontal termination
** from fireplace to in-line power vent
Maximum allowable vent run must be reduced by ten feet (10'-0"
for every additional 90° elbow added With a snorkel Termination,
reduce the total vent run by an additional twenty feet (20'-0") Figure's
7 and 7a
Figure7. Vertical Mounting for the Linear Power Venter
Figure 7a. Horizontal Vent for the Linear Power Venter.
ExampleB. Horizontal mounting with horizontal termination
** from fireplace to in-line power vent
Example C. Horizontal mounting with downward vent run and
horizontal termination
** from fireplace to in-line power vent
Maximum allowable vent run must be reduced by ten feet (10'-0")
for every additional 90° elbow added Also, deduct ten feet (10'-0")
of vent length for every one foot (1'-0") of vent run traveling in a
downward direction
Figure7b. HorizontaI Linear Power Vent with Downward vent
and Horizontal Vent Run to Termination.
CAUTION!
 Vent terminations can be very hot. The termination is to be installed higher than 7 feet above a public walkway.
 Do not obstruct, or attempt to conceal, the vent termination. These actions will aect the operation of the replace, and may be hazardous.
 In heavy snow areas, take extra care to prevent snow buildup from obstructing the vent termination.
■ Vent terminations can be very hot. The
termination is to be installed higher than 7 feet
above a public walkway.
■ Do not obstruct, or attempt to conceal, the vent
termination. These actions will affect the operation
of the fireplace, and may be hazardous.
■ In heavy snow areas, take extra care to
prevent snow buildup from obstructing the vent
termination.
CAUTION
XW2026
VentingInstallation
Maximum
VentRun
Minimum
VentRun**
Max.#
Elbows
60 Feet 2 Feet 3
VentingInstallation
Maximum
VentRun
Minimum
VentRun**
Max.#
Elbows
60 Feet 20 Feet 3
VentingInstallation
Maximum
VentRun
Minimum
VentRun**
Max.#
Elbows
40 Feet 2 Feet 3
2’-0 ”
MIN
Vertical Installed
Linear Power Vent
Horizontal Run Flex Pipe
Vertical
Flex Pipe
90deg
Elbow
90deg
Elbow
90deg
Elbow
Termination
Snorkel
Termination
LDVPV58
Flush
Termination
VLWB-8
Option
Option
LDVPV58
Horizonta
l
Insta
ll
e
d
Linear Power Vent
Horizontal Run Flex Pipe
Vertical
Flex Pipe
90deg
Elbow
90deg
Elbow
90deg
Elbow
Termination
Snorkel
Termination
Flush
Termination
VLWB-8
Option
Option
Horizontal Installed
Linear Power Vent
Horizontal Run Flex Pipe
Vertical
Flex Pipe
90deg
Elbow
90deg
Elbow
Termination
6’-0”
Max.
LDVPV58


Page18 XG0649 - 031511

LinearPowerVent-VerticalTermination
** from fireplace to in-line power vent
Maximum allowable vent run must be reduced by ten feet (10'-0") for
every additional 90° elbow added Figure's 8 and 8a
Figure8 Vertical Vent for the Linear Power Venter
ExampleA. Vertical Mounting with Vertical Termination
ExampleB. Vertical Mounting with Vertical Termination
Figure8a VerticaI Linear Power Vent with Vertical Vent Run





Connect all vent sections using a minimum of three sheet
metal screws on the outer pipe ue
Ensure the pipe ends male to female slide in a minimum
of 1 1/2" of overlap
Ensure all runs are supported with a minimum of 3 supports
per 10’ of venting
When hanging/ supporting venting, ensure that 1” clearance
is maintained on all sides to any combustible material
Ensure when cutting sections of rigid pipe to maintain
integrity of internal supports
Place the springs, supplied with the pipe kit, between the
outer and inner pipes to keep the pipes separate and avoid
any possible hot spots
Montigo recommends the use of a ex section for the nal
pipe connected directly to the replace offering greater
exibility of installation and absorption of movement
All exterior joints in venting should be sealed with high
heat silicone RV230
A - Termination DVPV58
C - Control Module
D - Flex Sections
G - Power Cord
Harnesses:
F - Elbows
B - Power Vent LDVPV58
RHSIT05
EPVH10 -10 foot power cord and harness
EPVH20 -20 foot power cord and harness
EPVH30 -30 foot power cord and harness
EPVH40 -40 foot power cord and harness
EPVH50 -50 foot power cord and harness
EPVH60 -60 foot power cord and harness
EPVH70 -70 foot power cord and harness
EPVH80 -80 foot power cord and harness
EPVH90 -90 foot power cord and harness
EPVH100 -100 foot power cord and harness
PEL-90MM (m/m 90° Elbow)
PEL-90FF (f/f 90° Elbow)
PEL-90FM (f/m 90° Elbow)
PEL-45FM (f/m 45° Elbow)
E - Rigid Sections PEXT - 1 (12" m/f Section)
PEXT - 2 (24" m/f Section)
PEXT - 3 (36" m/f Section)
PEXT - 4 (48" m/f Section)
PXT-20 (20" section)
PFL-1 (12" Section)
PFL-2 (24" Section)
PFL-3 (36" Section)
PFL-4 (48" Section)
VentingInstallation
Maximum
VentRun
Minimum
VentRun**
Max.#
Elbows
80 Feet 2 Feet 3
2’-0 ”
MIN
Vertical Installed
Linear PowerV ent
Vertical
Flex Pipe
90deg
Elbow
90deg
Elbow
90deg
Elbow
90deg
Elbow
Termination
2’-0 ”
MIN
LDVPV58
Vertical Installed
Linear Power Vent
Vertical
Flex Pipe
90deg
Elbow
90deg
Elbow
90deg
Elbow
90deg
Elbow
Termination
2’-0 ”
MIN
LDVPV58


Page19
XG0649 - 031511


1 The linear power vent can be installed to existing stud
construction or directly to cement wall or roof TheLDVPV58
must maintain the clearance to combustibles as shown in Figure
9a The required service access panel must be framed at 28"
X 18" To enclose the service access panel, (at less than 2") a
minimum 30% free air must be supplied at all times
2 Plug the power cord into the available slot in the linear power
vent
3 Secure all venting joints with at least three screws and ensure
that the joints are properly sealed by applying high temperature
silicone
Figure9 LDVPV58 Power Vent overall dimensions.
Top View Side View
Figure9b LDVPV58 Power Vent framing dimensions.
FramingDimensions
Figure9a LDVPV58 Power Vent framing dimensions.
The VLWB-8 termination is
designed to be installed ush
with the exterior of the building
This recessed design uses 5"/8"
vent and allows the installation to
be clean and ush so it does not
interfere or have an impact with
your architectural design
NOTE:
The H36PVN requires a specic volume of atmospheric interchange
to operate properly and efciently

The replace requires a MIN 80in/sq air movement to function
 The grille must also be able to shed water, not allowing any
moisture to enter the unit
Recessed Termination Installation (VLWB-8) Refer to Appendix A -
Termination locations
Figure10. Linear Power Vent recessed Termination.
13 5/16"
21 3/8" 18 1/8"
58
20 3/16"
12 9/64"
7 13/16" 2
1
ISOMETRIC VIEW
(NTS)
NTS
SIZE
DWG. NO.
A
REV.
SHEET 1 OF 1
WEIGHT:
VLWB-8
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/32"
TWO PLACE DECIMAL
.015"
THREE PLACE DECIMAL
.005"
ALL BENDS ARE ASSUMED
TO BE 90
UNLESS NOTED
OTHERWISE.
CHECKED BY
DRAWN BY
LF
DATE
NAME
7/29/2010
304 S.S.T.
TERMINATION, VERTICAL MOUNT, 5/8", 12" X 20" BOX
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CANADIAN HEATING PRODUCTS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CANADIAN HEATING PRODUCTS IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
Z:\CADD\2007 CADD\Standard\TERMINATIONS\VERTICAL TERMS\VLWB-8\VLWB-8
Thursday, July 29, 2010 10:14:21 AM
SCALE
Access Cover
16 1/2
33 8
11
34 7/8
Access Cover
181/2
28 clearance
for Cover access
5 MIN
5 MIN
Must be left clear on both
ends of Power Vent for
adequate ventilation.
2 MIN
5
MIN
5
MIN
1/2
MI
N
Louvres
Vent


Page20 XG0649 - 031511

Section5:Wiring
The Fireplace A/C power and Power Vent harness's must be installed
before completing the installation of the  Fireplace. These
connections are made from the RH-Side of the replace, Figure 12
through Figure 12f.
Figure 12. Incoming A/C Power , (connect per. Local Codes).
Figure 12a. Remove Exterior Access Cover.
Install the Power Vent connections as described
below:
Step1. Remove the exterior Access cover, shown Figure 12a
Step2.
Locate all the Power vent connections & ports, Figure 12b
Figure 12b. Locate Power vent connections.
Note:Toaccessthereplaceelectricalconnectionsfromthe
reboxfollowtheproceduresdescribedingure 22 through 26.
Power Vent,
& A/C Access
Cover
Power Vent,
Communica-
tion port.
Power vent communi-
cation conduit, A/C
connection port
Incoming A/C
Power Connection
Step4. Place the cover plate on the Conduit, then tighten the strain
relief nut onto the threads protruding through backside of cover plate,
Figure 12e
Step3. Remove the Power Vent communication port cover from
cabinet, (as supplied) Figure 12c (Philips head screwdriver
required).
