montpellier MMFSO70SS User manual

70ltr Multi-Function Single Fan Oven
MMFSO70SS - Stainless Steel
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING

We recommend that you keep this manual in a safe place for future
reference.
Your appliance is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your
appliance, you can rest assured that you are fully protected against the cost of
repairs for the first 24 months . Please note that any claim must be accompanied
by the model reference number, serial number and proof of purchase.
To activate your guarantee, you will need your product serial number. This can
be found inside your appliance.
NB: Please make sure that you keep a copy of your original sales invoice as this
will be needed if any service call is required.
There are three ways to register your Guarantee:
•
•
Online: Visit the Support page on our website and complete the online
Product Registration form. www.montpellier-appliances.com
By Post: Simply detach and fill in the form provided, attach a stamp and send
it in the post. Don't forget to include your e-mail address so that we can send
confirmation through to you.
By Phone: Contact our warranty registration department on 0808 1961388
Welcome
Thank you for choosing this Montpellier appliance.
Our appliances have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing or
using your appliance to ensure you get the most from your purchase.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
•
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the operation and
maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this book for
future reference.
The design and specifications are subject to change without prior notice for product improvement.

IMPORTANT SAFETY INSTRUCTIONS
PRODUCT INSTALLATION Cabinet diagram (Standing Cabinet)
Cabinet diagram (Ground Cabinet)
Installation Important Instructions
Installation steps
1
5
6
7
PRODUCT INTRODUCTION Oven
Accessories
Accessories use
Control Panel
Before using for the first time
Setting the clock
Start/Pause/Cancel function
Function setting
Lamp function
Inquiring function
Reminder function
Energy-Saving function
Child lock function
8
8
9
10
11
11
12
12
12
12
13
13
13
CLEANING AND MAINTENANCE Cleaning
Lamp replacement
Removing the oven door
14
15
TROUBLESHOOTING 16
SPECIFICATIONS 16
PRODUCT RECYCLING 17
CONTENTS
HERE FOR YOU 18
4
14

1
THESE WARNINGS ARE PROVIDED IN THE INTEREST OF
SAFETY. PLEASE READ THEM CAREFULLY BEFORE
INSTALLING OR USING THE APPLIANCE.
To maintain the EFFICIENCY and SAFETY of this appliance, we
recommend:
Call only the Service Centers authorized by store where you buy the cooker
Always use original Spare Parts
•When the oven is first switched on, it may give off an unpleasant smell.
This is due to the bonding agent used for the insulating panels within the
oven. Please run the new empty product with the conventional cooking
function, 250°C, 90 minutes to clean oil impurities inside the cavity.
•During the first use, it is completely normal that there will be slight smoke
and door. If it does occur, you should wait for the smell to be cleared before
putting food into the oven.
•Please use the product under an open environment.
•The appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements. Children less than 8
years of age shall be kept away unless continuously supervised.
•If the surface is cracked, switch off the appliance to avoid the possibility of
electric shock.
•This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appli-ance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
•During use, the appliance becomes very hot. Care should be taken to
avoid touching heating elements inside the oven.
•Do not allow children to go near the oven when it is operating, especially
when the grill is on.
IMPORTANT SAFETY INSTRUCTIONS

2
•Ensure that the appliance is switched off before replacing the oven lamp to
avoid the possibility of electric shock.
•The means for disconnection must be incorporated in the fixed wiring in
accordance with the wiring specifications.
•Children should be supervised to ensure that they do not play with the
appliance.
•This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by person responsible for their safety.
•Accessible parts may become hot during use. Young children should be
kept away.
•An all-pole disconnection means must be incorporated in the fixed wiring in
accordance with the wiring rules.
•If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
•Do not use harsh abrasive cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
shattering of the glass.
•A steam cleaner is not to be used.
•The appliance is not intended to be operated by means of an external timer
or a separate remote control system and should not be used with any kind
of extension lead.
•The instructions for ovens that have shelves shall include details indicating
the correct installations of the shelves.
•Do not use the oven unless you are wearing something on your feet. Do
not touch the oven with wet or damp hands or feet.
•For oven: Oven door should not be opened often during the cooking period.
•The appliance must be installed by an authorized technician and put into
use. The producer is not responsible for any damage that might be caused
by defective placement, and installation by unauthorized personnel.

•When the door or drawer of oven is open do not leave anything on it, or
you may unbalance your appliance or break the door.
•Some parts of appliance may keep its heat for a long time; it is required to
wait for it to cool down before touching onto the points that are exposed to
the heat directly.
•If you will not use the appliance for a long time, it is advised to plug it off.
3
DECLARATION OF COMPLIANCE
When you have unpacked the oven, make sure that it has not been damaged in
any way. If you have any doubts at all, do not use it: contact a professionally
qualified person. Keep packing materials such as plastic bags, polystyrene, or
nails out of the reach of children because these are dangerous to children.

4
PRODUCT INSTALLATION
600
Min.590
Min.50
Air vents
+8
560
*
590
5
20
20
If there is any discrepancy between the illustration and the actual product,
please refer to the actual product.
Cupboard diagram (Standing Cupboard)
Min.570
Minimum bottom ventilation area: 250 mm2
Ｇ
10
583
Ｇ5
595
595 20
555
Native appliance
Reserve 5 mm for the door panel at the
top and bottom respectively.
Reserve 20 mm for the door panel on
the left and right respectively.
Reserve 20 mm for the door panel in
thickness.
The thickness of the cupboard board is 20 mm.
If the power socket is installed on the back of the appliance, the depth
of the cupboard opening shall be increased from a minimum of 590 mm
to 620 mm.
The dimensions in the figures are in mm.

5
Minimum bottom ventilation area: 250 mm2
*
Min.570
If the appliance is installed under the
hob, the minimum thickness of worktop A
is shown below:
Ｇ
5
Native appliance
Without hob
583
Ｇ
5
595
595 20
555
Cupboard diagram (Ground Cupboard)
600
Min.50
600+2
Min.590
+8
560
Air vents
Hob type
Induction hob 37 mm
worktop A
Full-surface induction hob 47 mm
Gas hob
Electric hob
30 mm
27 mm
5
20
20
Hob
Ｇ
5
A
With hob
Ｇ
5
Native appliance
583
The thickness of the cupboard board is 20 mm.
If the power socket is installed on the back of the appliance, the depth
of the cupboard opening shall be increased from a minimum of 590 mm
to 620 mm.
The dimensions in the figures are in mm.
Reserve 5 mm for the door panel at the
top and bottom respectively.
Reserve 20 mm for the door panel on
the left and right respectively.
Reserve 20 mm for the door panel in
thickness.

6
Installation Important Instructions
Content that means [mandatory]
•The safe operation of this appliance can only be guaranteed if it has
been installed to a professional standard in accordance with these
installation instructions. The installer shall be liable for any damage
resulting from incorrect installation.
•The entire installation process requires two professional installers. Wear
dry protective gloves during installation to avoid scratch or electric
shock.
•Fitted units must be heat-resistant up to 90°C, and adjacent unit fronts up
to 70°C.
•The oven may be connected by a 13A plug into a standard 13A
switched socket outlet. Alternatively it can be hard wired into a fused
spur with a maximum fused rating of 16A.
Content that means [prohibit ]
•Do not install the appliance behind a decorative door or the door of a
kitchen unit, as this may cause the appliance to overheat.
•Check the appliance for damage after unpacking it. Do not connect the
appliance if it has been damaged in transit.
•Do not block the vent of the appliance and the gap between the
cupboard and the appliance.
•Use extreme caution when moving or installing the appliance. It is very
heavy, do not lift the appliance by the door handle.
•If the power cord or power plug is damaged, stop using the appliance
immediately, to avoid fire, electric shock or other injuries.
Content that means [note]
•Be very careful when moving or installing the appliance to avoid damage
to the appliance or damage to the cupboards.
•Before starting up the appliance, remove all packaging materials and
accessories from the cavity.
•The power socket shall be easily accessible to users (such as next to the
cupboard) for easy power-off.
•After installation is complete, make sure that the power plug is firmly
inserted into the socket.
•Please refer to the "Cupboard Diagram" for the requirements of net
depth of the cupboard. The clearance between the cupboard bottom
board and the rear board (or wall) shall not be less than 50 mm.

7
•Please customize the cupboard according to the "Cupboard Diagram".
•Before installation, please check for normal power socket and appropriate
grounding, and check whether the cupboard dimension meets the
installation requirements.
•Place the appliance in designated locations in the kitchen, install it in a
vertical cupboard, and connect the power supply.
•To locate the mounting fixing holes, open the appliance door and look at
the side frame of the appliance (position shown below).
•Fix the appliance to the cupboard with two rubber plugs A and screws B
provided with the appliance.
Installation steps
Mounting fixing hole
B
A

8
PRODUCT INTRODUCTION
Oven
When removing food, please wear heat insulating gloves to prevent burns! At
the moment of opening the door of the oven, pay attention to the heat/steam.
Please open the door at a small angle to avoid the heat/steam burning your
face.
Control panel
Mounting fixing hole
Handle
Accessories
Grill / Baking tray
Cook large portions of food or
catch food scraps
Shelf / Grill rack
Place heat-resistant cooking
containers or Grill food
Small grill rack
Cook smaller portions of
food
Ventilating openings
Mounting fixing hole
Glass door
Removable metal side
runners

9
Accessories use
For the oven to work properly, the accessories should only be placed between
the first and fifth levels. When used together, place the Grill tray under the grill
rack. For regular grilling use the Grill tray and small grill rack together.
1
2
4
3
5

10
Control panel
The cooking process can be observed under illuminated
conditions. Except ECO function.
The radiant heating element and top heating element are working with fan.
The radiant heating element and top heating element are working.
Function Function introduction
Lamp
Single grill
Double grill with fan
Double grill
Defrost
The circulation of air at room temperature enables quicker thawing of
frozen food (without the use of any heat).
The inner grill element switches on and off to maintain temperature.
Can be used to grill a small amount of food.
The combination of fan and the top and bottom heating elements provides
more even heat penetration and coloration, primarily for cooking meat.
Conventional+fan
The top and bottom heating elements work together to provide
convectional cooking.
Conventional
Heating is provided by the heating element at the bottom of the oven.
Mainly used for keeping warm and the colouring of the food.
Bottom heating
For energy-saving cooking. Cooking the selected ingredients in a
gentle manner, and the heat comes from the top and the bottom.
ECO
In convection mode, the fan turns on automatically to provide even heat
for single or multi-layer baking. This is particularly suitable for baking
foods that require even coloring.
Convection
StopK1 Reminder/Clock Display screen
Remind Start
K2
NOTE: ALL cooking functions are to be carried out with the door closed!

11
1.Press " " key, the hour digit flashes.
2.Turn knob "K2" to adjust the hour digit.
3.Press " " key, the minute digit flashes.
4.Turn knob "K2" to adjust the minute digit.
5.Press " " key to complete the clock setting.
Setting the clock
When the oven is first connected to the electrical supply and powered on, the
clock will need to be set.
1.The clock is a 24 hour clock.
2.Before using the oven, please complete the clock setting.
3.During the clock setting process, you can press " " key to cancel the
current clock setting.
4.If you need to reset the clock, please follow the "Setting the clock" steps in
standby mode.
Notes:
Function Temperature Time
250℃90mins
Before using for the first time
•The oven must not be operated until it has been correctly installed.
•To avoid fire, remove all transport protection materials and ensure that the
oven is free of residual packaging items and accessories (e.g. foam,
cardboard, grill tray, grill rack, etc.).
•Clean the oven cavity and accessories with soapy water and a soft cloth.
•Open kitchen windows and cooker hoods to maintain high ventilation.
•Do not let children or pets into the kitchen and close the doors of adjacent
rooms.
•After connecting the power, activate the oven mode, time, and
temperature in the table below to remove odors in the cavity.
•After the first use, please open the oven door at a small angle and wait for
the cooling to complete.
Conventional

12
Lamp function
Turning on the lamp can better observe the cooking situation of food. If you need
to turn off or turn on the lamp, you can follow these steps:
Function setting
Notes
1.During cooking, the time can be adjusted by turning the knob "K1". After
adjusting the time, please press the " " key within 3 seconds to confirm.
2.During cooking, the temperature can be adjusted by turning the knob "K2". After
adjusting the temperature, please press the " " key within 3 seconds to confirm.
1.In standby or reminder state, turn knob "K1" to select the function.
2.Turn knob "K2" to adjust the temperature.
3.Press the " " key to start cooking.
4.If you skip step 2, press the " " key to start cooking. The default time is 9 hours,
and the display screen shows the default temperature.
1.Turn knob "K1" to select " ".
2.Press the " " key to confirm.
Start/Pause/Cancel function
1.If the cooking time has been set, press the " " key to start cooking. If the
cooking is paused, press the " " key to continue cooking.
2.During cooking process, press the " " key once to pause the cooking. Press
the " " key twice to cancel the cooking
Inquiring function
1.During cooking process, if the clock has been set, press the " " key to check
the current time; If the reminder function is set, press the " " key to check the
reminder time.
2.In reminder state, if the clock is set, press the " " key to check the current
time.

13
Energy-Saving function
1.In standby or reminder state, press the " " key for 3 seconds to turn off the
LED screen and enter the energy-saving mode.
2.In standby state, If there is no operation in 10 minutes, the LED screen will go
off and enter the energy-saving mode.
3.In the energy-saving mode, press any key or turn the knob to exit the energy
saving mode.
Child lock function
1.Enter the child lock: Press the " " and " " keys for 3 seconds at the
same time, the buzzer will beep, and the icon " " will light up, indicating that
the child lock is entered.
2.Release the child lock: Press the " " and " " keys for 3 seconds at the
same time, and the buzzer will beep, indicating that the child lock is released.
3.In the child lock state, pressing the " " key can cancel the cooking, any other
keys and knobs are invalid.
Reminder function
This function will help to remind you to start cooking in a certain time. Only when
the oven is in standby mode and the clock is set can the reminder be set.
1.Press the " " key, and the hour digit flashes.
2.Turn knob "K2" to adjust the hour digit.
3.Press the " " key, and the minute digit flashes.
4.Turn knob "K2" to adjust the minute digit.
5.Press the " " key to complete the setting, and the icon " " is always on, and
the countdown starts. After the countdown is completed, the buzzer sounds and
the icon " " goes out.

14
CLEANING AND MAINTENANCE
•After cooking, wait for the oven to cool completely.
•Remove oven accessories including the metal side runners, rinse with
warm water and dry.
•Clean up food debris from the oven chamber.
•Wipe the oven with a soft cloth stained with detergent, then dry with a dry
soft cloth.
Lamp replacement
Warning
To avoid electric shocks-please ensure that the electricity supply to the
appliance is switched off and the appliance is fully cold. before
removing the lamp lens.
•Switch off and disconnect the power from the oven. Ensure that the
internal parts are cool before touching internal parts.
•Remove the lamp cover by turning it counter-clockwise (note, it may be
stiff), replace the bulb with a new one of the same type.
•Insert the new bulb, which should be resistant to 300°C. For
replacement bulbs contact your local service centre.
•If in any doubt, consult a qualified electrician for help.
Cleaning
Disconnect the power supply before cleaning and maintenance.
In order to ensure the life of the oven, it should be thoroughly cleaned
frequently.
Cleaning steps are as follows:
Notes
•Do not use sharp cleaning tools, hard brush and corrosive cleaning
products, so as not to damage the oven and its accessories.
•Do not use rough scrubbing agent or sharp metal spatula to clean the
door glass.
•Do not place foil or any objects on the base of the oven while in use as
this may damage the oven interior

15
Removing the oven door for cleaning.
Disassembly of oven door components
1.
2.
3.
4.
To remove the door, open the door to the
maximum angle. Then pull the buckle at the
door hinge backward.
Close the door to an angle approximately 30°.
Hold the door with one hand on each side.
Lift up and slowly pull the door out from the
oven.
Open the door rotation bracket assembly, refer
the action in the following picture.
Lift up the door outer glass and pull it out, then
take the door middle glass out in the same way.
WARNING:
Don't forcibly pulled out the door to prevent the glass breaking during the
dismantling process.
WARNING:
The hinge springs could loosen, causing personal injury.
WARNING:
Do not lift or carry the oven door by the door handle.
30˚

SPECIFICATIONS
Model MMSFO70SS
Usable Volume 70L
Rated voltage 220-240V~
Rated frequency 50Hz-60Hz
Electric power 3.0 kW
16
TROUBLESHOOTING
If the problem cannot be solved or other problems occur, please contact the
after-sales service.
Has a pungent odor
or smoke
first use No processing required
Unable to start
Power is not connected connect power supply
Problem Possible reason Solution
The main power switch
is not turned on
Cooking mode is not set
Turn on the power switch
Check settings
Lamp does not
come on
It's broken Contact after-sales service
Food is not cooked
Burnt or uneven food
Temperature is too low
Food portion is too large
The temperature is set
too high or the heating
time is too long
Adjust the cooking
temperature or time
Fan delays blowing
for heat dissipation
No processing required
Use a higher temperature
The food is too close
to the heating tube
Adjust the placement
layers of accessories
The fan did not stop
working after
stopping the heating
Cook food in smaller
pieces or extend the
cooking time.

17
PRODUCT RECYCLING
When you have unpacked the oven, make sure that it has not been damaged in
any way. If you have any doubts at all, do not use it: contact a professionally
qualified person. Keep packing materials such as plastic bags, polystyren, or
nails out of the reach of children because these are dangerous to children.
This symbol on the product or instruction manual indicates that your device
should be disposed of separately from your household waste at the end of its
useful life. There is a separate recycling system locally for recycling. For more
information, please contact the local authority or retailer where you purchased
the product.
