montpellier CACH510 User manual

52cm Canopy Hood
CACH510 - Stainless Steel
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING

Thank you for choosing this Montpellier Canopy Cooker Hood.
Our Hoods has been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your Cooker Hood to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your Cooker Hood is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your Hood,
you can rest assured that you are fully protected against the cost of repairs for the
first 24 months . Please note that any claim must be accompanied by the model
reference number, serial number and proof of purchase.
To activate your guarantee, you will need your product serial number. This can be
found on the rear of the machine.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post: Simply detach and ll in the form provided, attach a stamp and send
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
Welcome
Note: We are unable to take registrations over the phone.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com

Description of the Appliance
1. 2.
1.
3.
1. Lights
2. Function Control Panel
3. Filter
3

CONTENTS:
Section 1. Installation
Section 2. Safety Advice
Section 3. Operating the Appliance
Section 4. Maintenance
Section 5. Circuit Diagram
4

Section 1. Installation
A qualified installer must carry out the installation.
N.B. To ensure that your cooker hood operates efficiently the
hose length must not exceed 2m with a maximum of one bend.
This appliance can be used fully ‘vented’ via a ducting hose and external wall
vent, or in ‘re-circulation’ mode by using the charcoal filter provided.
The cooker hood should ideally be installed between 65-75cm above the
work surface/cooker hob. DO NOT INSTALL BELOW 65cm.
Install the cooker hood into a designated kitchen cabinet, making a cut-out
for the appliance (as shown below) ensuring a minimum gap of 35mm from
the front edge of the cabinet:
Remove the aluminium filter and then fix the unit into the cabinet as shown
below:
5
