montpellier MCA52S User manual

Cod:0103087495-00.02
52cm Canopy Cooker Hood
MCA52S - 52cm

We recommend that you keep this manual in a safe place for future reference.
Your &RRNHU+RRGis covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your +RRG,
you can rest assured that you are fully protected against WKHFRVWRIUHSDLUVIRU
WKHILUVWPRQWKV3OHDVHQRWHWKDWDQ\FODLPPXVWbe accompanied by the
model reference number, serial number and proof of purchase.
To activate your guarantee, you will need your product serial number. This can
be found on the rear of the machine.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post:6LPSO\GHWDFKDQGƮOOLQWKHIRUPSURYLGHGDWWDFKDVWDPSDQGVHQG
it in the post. Don’t forget to include your e-mail address so that we can send
FRQƮUPDWLRQWKURXJKWR\RX
Welcome
Thank you for choosing this Montpellier Canopy &RRNHU+RRG.
Our +RRGVhaYH been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your &RRNHU+RRG to ensure you get the most from your purchase.
Note: We are unable to take registrations over the phone.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & LA B O U R
www.montpellier-appliances.com

3

4
Using your Extractor
For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run
for approximately 15 minutes after the end of cooking.
Control Panel
B – Power switch
Light switch
C – Speed levels
Slide the light switch (A) to operate the light.
To switch on the extractor or to change the speed at any time when the extractor is running
Slide the power switch to the required position depending on the speed you require.
Slide the power switch to position (B) on the control panel.

5
The grease filter should be kept clean to minimize the risk of fire.
At least once a month the grease filters should be removed and cleaned with warm soapy water. You can also wash the
grease filters in a dishwasher, ensuring that the filters are put in an upright position to prevent damage from other items in the
dishwasher. After rinsing and drying, replace the filter.
To remove the grease filter, push in the button on the handle and then pull down
on the filter at the front. When you have released it at the front, then you can pull
out the filter. To replace the grease filter, repeat the steps in reverse.
Please note:
Cleaning the grease filter in the dishwasher may lead to discolouration.
This is normal and does not constitute a fault with the appliance.
In re-circulating mode, air is vented back into the kitchen through the opening in the cooker hood.
This method is advised if you are not using your hob intensively. Re-circulated air requires the use of charcoal filters to remove
odours.
Charcoal filter
To ensure the best performance from your cooker hood, the charcoal filter should be replaced every 3-6 months, dependent
on use.
Note: This charcoal filter is non-washable and must be replaced as required.
Fig. 3-I Fig. 3-III
Fig. 3-II
To attach a new charcoal filrer, follow the steps below:
1.Remove the grease filter (fig.3-I).
2. Place the charcoal filter on the centre of the motor support. Once firmly located, turn the charcoal filter clockwise 90 degrees
until the filter locks into position(fig.3-II).
3.Replace the grease filter(fig.3-III)
Fig. 2

6
E14 LED 4Wx2 DR-4-H-E14-37
MCA52S
Changing the Light Bulb
Remove the grease filter as previously described, unscrew the light bulb and replace it with the required bulb as
shown in the table below. Finally, replace the grease filter.
Spare bulbs are available from Montpellier Customer Care or from a local DIY shop.
Do not touch bulbs or adjacent areas during or straight after prolonged use of the lights.
Table 1
Bulb replacement is not covered by the guarantee.
Only use bulbs recommended for your extractor. Do not fit bulbs of a higher power rating. Bulbs of a lower power
rating may be adequate for use, generally last longer and use less energy.
The light is designed for use during cooking and not for general room illumination. Extended use of the light can
reduce the life span of the bulb.

FUSE 5A
PROTECTION LINE
5A Fuse is installed inside the plug to protection line.
7
48W

service engineer
8

9
If the instructions provided with your gas hob state that the required distance between the hob and the extractor must be
greater than 700mm, then that is the distance which should be observed. This is a legal requirement and may lead to your hob
being disconnected from the gas supply and the installation reported to RIDDOR (the height

10
INSTALLATION
Extractor dimensions.
Mark out the dimensions of the cut-out based on your
extractor.
173
10
260 292
200
280
298
480
515
360
499
520
A
B
D
E F
C
A
B
C
D
E
F
MCA52S
499
360
268
200
280
487

11
Remove the grease filter, unscrew the 4 screws of the
fixed panel and remove it.
Place the extractor into the cabinet opening and secure
it with screws.
Secure the panel on with the 4 previously removed
screws (Fig 7) and insert the grease filter.
Connect the exhaust pipe to the ducting adaptor and
locate on the extractor as indicated.
INSTALLATION
7.giF 8.giF
9.giF 10.giF

evreserREILLEPTNOM.ylnoecnadiugrofdedivorperasnoitartsullidnasnoisnemid,snoitcurtsnillA.EO&E
the right to change specifications without prior notice.
12
Attribute Symbol Value Units
Model Identification MCA52S
Annual Energy Consumption AECHood 29.4 kWh
Time Increase factor f 1.7
FDEHood 9.4
EEIHood 72.4 (C)
Measured Airflow at Best QBEP 94.7 m3/h
Measured Pressure at Best PBEP 136 Pa
Maximum Airflow QMAX 206.4 m3/h
Measured Electric Power at Best WBEP 38.0 W
Nominal Lighting Power WL 8.0 W
Average Illumination of the
lighting system on the cooking
surface
EMiddle 84 Lux
Measured Power Consumption
in standby
PSN/A W
Measured Power Consumption PO0.0 W
Noise level LWA 63 dBA
GFEHood 49.1 (F) %
LEHood 10 (E) %

Here For You
Here For You
After-sales assistance
If you continue to experience problems with your Canopy Cooker+RRG, please call the Montpellier customer
service helpline on: 01759 487839
Please have all your product details available, including the model number, serial number, date of purchase,
and your retailer’s details before registering a fault.
The service call cannot progress without this information.
Your 2 year Manufacturer’s guarantee
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the
ƮUVWPRQWKVIURPGDWHRISXUFKDVHSURYLGHGWKDW
Any claim is accompanied by evidence of the model reference, model serial number and proof of purchase, such
DVD6DOHV5HFHLSWVKRZLQJWKDWWKHDSSOLDQFHZDVSXUFKDVHGZLWKLQWKHPRQWKVSULRUWRWKHGDWH
of claim.
What is not covered under the Guarantee
•Any appliance not correctly installed and operated in accordance with the manufacturer’s instructions.
•Any appliance that is used for anything other than domestic purposes.
•$Q\GHIHFWFDXVHGE\DFFLGHQWPLVXVHXQDXWKRULVHGPRGLILFDWLRQRULQH[SHUWUHSDLU
•Cost of Call-out where a fault cannot be found with the appliance.
•&RVWRI&DOORXWIRUZRUNFRYHULQJURXWLQHPDLQWHQDQFHVXFKDVEXWQRWH[FOXVLYHO\FOHDQLQJRIILOWHUVRU
defrosting.
•Cost of Call-out for work required to correct the alignment of doors following door reversal procedures
carried out by you.
•Use of the appliance by anyone other than the Householder.
•Use in any commercial environment.
•Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable items which require
routine replacement.
•Repair costs incurred that have not been authorised by 0RQWSHOOLHUVHUYLFH and/or carried out by a non-
approved 0RQWSHOOLHU engineer.
•Montpellier Appliances do not accept claims for consequential loss, rusting, corroding, delivery damage
or scratches.
YOUR GUARANTEE IS VALID ONLY IN THE UK.
7RUHJLVWHU\RXUDSSOLDQFHVLPSO\FRPSOHWHWKHFDUGLQ\RXUDSSOLDQFHSDFNDQGUHWXUQLWZLWKDVWDPSDƱ[HGRU
alternatively you can register online at www.montpellier-appliances.com/support
SERVICE HELP-LINE
Should your appliance develop a fault, please call the Montpellier customer service helpline on: 01759 487839
Please remember to have all your product details available, including the model number, serial number, date of
purchase and your retailer’s details before registering a fault.



 






