PV4
Anchoring Jig
Installation and Operation Instructions for the following models:
Before attempting to connect or operate this product,
please read these instructions completely.
CERTIFIED
81-IN5222
07-09-2010
©2009, Videolarm, Inc. All Rights Reserved

!
CAUTION
RISK OF
ELECTRIC SHOCK!
CAUTION: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, DO NOT EXPOSE
COMPONENTS TO WATER OR MOISTURE.
SAFETY PRECAUTIONSIMPORTANT SAFEGUARDS
1. Read Instructions - All the safety and operating instructions should be read
before the unit is operated.
2. Retain Instructions -Thesafetyandoperating instructions should be retained
for future reference.
3. Heed Warnings - All warnings on the unit and in the operating instructions
should be adhered to.
4. Follow Instructions - All operating & user instructions should be followed.
5. Electrical Connections - Only a qualified electrician should make electrical
connections.
6. Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Cable Runs - All cable runs must be within permissible distance.
8. Mounting - This unit must be properly and securely mounted to a supporting
structure capable of sustaining the weight of the unit. Accordingly:
a. Installation should be made by a qualified installer.
b. Installation should be in compliance with local codes.
c. Care should be exercised to select suitable hardware to install the unit,
taking into account both the composition of the mounting surface and
the weight of the unit. Be sure to periodically examine the unit and the
supporting structure to make sure that the integrity of the installation
is intact. Failure to comply with the foregoing could result in the unit
separating from the support structure and falling,with resultant damages
or injury to anyone or anything struck by the falling unit.
UNPACKING
Unpackcarefully. Electroniccomponentscan be damagedifimproperlyhandled
or dropped. If an item appears to have been damaged in shipment,replace it
properly in its carton and notify the shipper. Be sure to save:
1. The shipping carton and packaging material. They are the safest material in
which to make future shipments of the equipment.
2. These Installation and Operating Instructions.
!
The lightning flash with an arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of non-insulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intendedtoalerttheusertopresenceofimportantoperating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
24 HOUR TECHNICAL SUPPORT
1-800-554-1124
SERVICE
If the unit ever needs repair service,customer should contact Videolarm
(1-800-554-1124) for return authorization & shipping instructions.
TECHNICAL SUPPORT
Videolarm has set-up a 24 hour technical support line for their customers.
LIMITED WARRANTY FOR VIDEOLARM INC. PRODUCTS
VIDEOLARM INC. warrants this Product to be free from defects in material or workmanship, as follows:
PRODUCT CATEGORY PARTS LABOR
All Enclosures and Electronics Five (5) Years Five (5) Years
Pan/Tilts Three (3) Years **6 months if used in autoscan Three (3) Years **6 months if used in autoscan
Poles/PoleEvators Three (3) Years Three (3) Years
Warrior/Q-View/I.R. Illuminators Five (5) Years Five (5) Years
Controllers Five (5) Years Five (5) Years
Power Supplies Five (5) Years Five (5) Years
Accessory Brackets Five (5) Years Five (5) Years
During the labor warranty period, to repair the Product,Purchaser will either return the defective product, freight prepaid, or deliver it to Videolarm Inc. Decatur GA.
The Product to be repaired is to be returned in either its original carton or a similar package affording an equal degree of protection with a RMA # (Return Materials
Authorization number) displayed on the outer box or packing slip. To obtain a RMA# you must contact our Technical Support Team at 800.554.1124, extension 101.
Videolarm will return the repaired Product freight prepaid to Purchaser.Videolarm is not obligated to provide Purchaser with a substitute unit during the warranty
period or at any time.After the applicable warranty period, Purchaser must pay all labor and/or parts charges.
The limited warranty stated in these product instructions is subject to all of the following terms and conditions:
1. NOTIFICATION OF CLAIMS: WARRANTY SERVICE: If Purchaser believes that the Product is defective in material or workmanship,then written notice
with an explanation of the claim shall be given promptly by Purchaser to Videolarm but all claims for warranty service must be made within the warranty period.
If after investigation Videolarm determines that the reported problem was not covered by the warranty,Purchaser shall pay Videolarm for the cost of investigating
the problem at its then prevailing per incident billable rate. No repair or replacement of any Product or part thereof shall extend the warranty period as to the entire
Product.The specific warranty on the repaired part only shall be in effect for a period of ninety (90) days following the repair or replacement of that part or the
remaining period of the Product parts warranty, whichever is greater.
2. EXCLUSIVE REMEDY: ACCEPTANCE: Purchaser’s exclusive remedy and Videolarm’s sole obligation is to supply (or pay for) all labor necessary to repair
any Product found to be defective within the warranty period and to supply, at no extra charge,new or rebuilt replacements for defective parts.
3. EXCEPTIONS TO LIMITED WARRANTY: Videolarm shall have no liability or obligation to Purchaser with respect to any Product requiring service during
the warranty period which is subjected to any of the following:abuse, improper use: negligence, accident,lightning damage or other acts of God (i.e., hurricanes,
earthquakes), modification, failure of the end-user to follow the directions outlined in the product instructions, failure of the end-user to follow the maintenance
procedures recommended by the International Security Industry Organization, written in product instructions, or recommended in the service manual for the Product.
Furthermore,Videolarm shall have no liability where a schedule is specified for regular replacement or maintenance or cleaning of certain parts (based on usage)
and the end-user has failed to follow such schedule; attempted repair by non-qualified personnel; operation of the Product outside of the published environmental
and electrical parameters, or if such Product’s original identification (trademark, serial number) markings have been defaced, altered, or removed. Videolarm
excludes from warranty coverage Products sold AS IS and/or WITH ALL FAULTS and excludes used Products which have not been sold by Videolarm to the Purchaser.
All software and accompanying documentation furnished with, or as part of the Product is furnished “AS IS” (i.e., without any warranty of any kind),except where
expressly provided otherwise in any documentation or license agreement furnished with the Product.
4. PROOF OF PURCHASE: The Purchaser’s dated bill of sale must be retained as evidence of the date of purchase and to establish warranty eligibility.
DISCLAIMER OF WARRANTY EXCEPT FOR THE FOREGOING WARRANTIES,VIDEOLARM HEREBY DISCLAIMS AND EXCLUDES ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING,BUT NOT LIMITED TO ANY AND/OR ALL IMPLIED WARRANTIES OF MERCHANTABILITY,FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY WARRANTY WITH REGARD TO ANY CLAIM
OF INFRINGEMENT THAT MAY BE PROVIDED IN SECTION 2-312(3) OF THE UNIFORM COMMERCIAL CODE AND/OR IN ANY OTHER COMPARABLE STATE STATUTE.VIDEOLARM HEREBY DISCLAIMS
ANY REPRESENTATIONS OR WARRANTY THAT THE PRODUCT IS COMPATIBLE WITH ANY COMBINATION OF NON-VIDEOLARM PRODUCTS OR NON-VIDEOLARM RECOMMENDED PRODUCTS
PURCHASER CHOOSES TO CONNECT TO PRODUCT.
LIMITATION OF LIABILITY THE LIABILITY OF VIDEOLARM,IF ANY,AND PURCHASER’S SOLE AND EXCLUSIVE REMEDY FOR DAMAGES FOR ANY CLAIM OF ANY KIND WHATSOEVER,
REGARDLESS OF THE LEGAL THEORY AND WHETHER ARISING IN TORT OR CONTRACT, SHALL NOT BE GREATER THAN THE ACTUAL PURCHASE PRICE OF THE PRODUCT WITH RESPECT TO WHICH
SUCH CLAIM IS MADE. IN NO EVENT SHALL VIDEOLARM BE LIABLE TO PURCHASER FOR ANY SPECIAL,INDIRECT,INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY KIND INCLUDING, BUT NOT
LIMITED TO, COMPENSATION, REIMBURSEMENT OR DAMAGES ON ACCOUNT OF THE LOSS OF PRESENT OR PROSPECTIVE PROFITS OR FOR ANY OTHER REASON WHATSOEVER.
/ tour operation / tour operation
**6 months if used in autoscan
/ tour operation **6 months if used in autoscan / tour operation
SView Series Five (5) Years Five (5) Years

5
MODEL: Brackets, Mounts, and Poles
PV4
Please read these instructions carefully before
proceeding, and heed all cautions.
STANDARD INSTALLATION PROCEDURE
Requires MODELS: PV4 Anchor Jig
NOTE: If you'll be using the optional PV4 anchor
jig, see the attached instructions for
assembly of the jig.
Anchor Jig Kit Parts List
Single Straps (4)
Cross Strap (1)
3/4" - 10 Bolts (4)
3/4" Flat Washers (4)
3/4" - 10 Hex Nut (20)
Lock
Washers (4)
1. Thread two (2) nuts onto each of the (4) bolts (Figure 1). The
end with 6" of clearance will be the top of the Anchor Jig , the
end with 1 1/2" clearance will be the bottom.
NOTE: Because of surface conditions it may be necessary to use
leveling nuts. See step 5 below for information.
NOTE: The Flat Washers,Lock Washers, and remaining Hex
Nuts will be used to fasten the pole to the Anchor Jig.
4. Before using the Anchor Jig verify that the center to center
dimensions between the bolts are even (Figure 4). If not,
adjust accordingly. Firmly tighten all Hex Nuts .
With Leveling Nuts Without Leveling Nuts
Figure 1
2. Place the short end of each Bolt into the outside holes of the
Cross Strap. Place Hex Nuts onto each Bolt and finger
tighten (Figure 2).
3. Turn the Anchor Jig over and place Single Straps over the
Bolts (Figure 3). Use the inside hole of each strap. Place
Hex Nuts onto each Bolt and finger tighten.
3erugiF2erugiF
Figure 4
5. If, due to conditions or other requirements, leveling nuts are
needed, adjustments will have to be made to the Anchor Jig .
Below are diagrams comparing the Anchor Jig with and
without leveling nuts. Leveling nuts and washers are NOT
provided with the pole,
!
!
11/2"
6"
18"
725/32"
725/32"
11"
diameter
I. Pole Installation Instructions

6
24"
36"
24"
36"
24"
6"
24" 6"
8" 8"
12"
12"
32"
36"
32"
32"
1" diameter
maximum
II. Site Preparation
•Select a suitable site for the POL EVATOR™ and prepare the pad site
using a hole 36" x 36" x 36" deep. The top of the concrete foundation
should be flush with the ground.
• Special attention must be paid to the size of
the conduit and its location within the jig and
concrete foundation. The Wiring Conduit
can be no more than 1" in diameter. Use
reducers if necessary. Also, make sure that
the Wiring Conduit is in the center of the
Anchor Jig during installation.
!
Schematic view of
concrete foundation
Top View
Side View
Reinforcement
Bars (12) Anchor Jig
Wiring Conduit
Wiring conduit
• The Wiring Conduit must be 1" (see above). The maximum height of
the conduit above the foundation is 2", however more height may be
left during the preparation process. Simply trim the conduit once the
concrete foundation has set.
•To help reinforce the concrete foundation, place (12) 1/2" diameter x
32" long Reinforcement Bars("rebar") as shown in the diagram. Use
suitable preparation methods to place the rebar.
•Suspend the assembled Anchor Jig in the center of the pad hole.
Leave 2" to 3" of the Bolts protruding above the pad (unless you're
using leveling nuts, see previous page). Make sure that the Conduit
is in the center of the Anchor Jig. Both the jig and the conduit must
be securely suspended to prevent shifting when the concrete is
poured.
CALL BEFORE DIGGING! Be sure that there are no
underground electric or phone cables, gas or water
lines in the area where the pole will be located.
!
Prepare the concrete per manufacturer's directions. The
concrete must have a compressive strength of 3000 psi,
and must be fabricated following ACI318-89 requirements.
Allow the concrete foundation to cure thoroughly before
proceeding with the installation of the POLEVATOR™.

14
X. Wind Load Rating Report
The PolEvator™ has undergone rigorous testing to assure its quality and longevity. As part of this procedure, we had its Wind Loading
capabilities tested. Below is the certified result of this test.
Deflection Curve for PV16
0.01 0.12
0.48
1.08
1.47
1.91
2.42
3.09
4.17
0.00
0.50
1.00
1.50
2.00
2.50
3.00
3.50
4.00
4.50
5 204060708090100110
Wind Speed (mph)
Deflection (in.)

Product Registration/Warranty
Thank you for choosing Videolarm. We value your patronage and are solely committed to
providing you with only the highest quality products available with unmatched customer service
levels that are second-to-none in the security industry.
Should a problem arise, rest assure that Videolarm stands behind its products
by offering some of the most impressive warranty plans available: 3 Years
on all Housings, Poles, Power Supples, and Accessories and 5 Years on
all camera systems (SView, QView, Warriors), and InfraRed Illuminators.
Register Your Products
Option 1: Online Option 2: Mail-In
Take a few moments and validate your purchase with our Online Product Registration Form
at www.videolarm.com/productregistration.jsp
or complete and mail-in the bottom portion of this flyer.
Register your recent Videolarm purchases and benefit from the following:
Simple and Trouble-Free RMA process
Added into customer database to receive product updates / news
Eliminate the need to archive original purchase documents:
Receipts, Purchase Orders, etc…
•
•
•
Main Contact Info
First Name: Last Name:
Professional Title: Company:
Address 1: Address 2:
City: State / Province/Country:
Zip / Postal Code: Phone Number: E-mail Address:
Product Information Please Circle One: Business Personal
Name & Location of Company / Store where Purchased:
(City, State, Country)
Videolarm Product ID Product Description
Serial #
(Available only for Camera Systems, IR Illuminators, Wireless Devices)
PO#
Cut at the dotted Line
Place in envelope, affix stamp and mail to: Videolarm ATTN: Warranty
2525 Park Central Ave.
Decatur, GA 30035
