Mooreco Best-rite visionary bst-83845-xx User manual

1234567890123456789012345678901212345678901234567890123456789012123456789012

Visionary Boards

2’ X 3’, 3’ X 4’, 4’ X 4’, 4’ X 6’ and 4’ X 8’

Assembly Instructions

Part Drawing Description Qty

Missing Parts or UPS Damaged Parts

For Your Convenience you can

EMAILusat

[email protected]

24HOURS 7 DAYSAWEEK

Do not use unless all screws are tight. At least every six months, check all screws to be sure

they are tight. If parts are missing, broken, damaged, or worn, stop use of the product until

repairs are made by your dealer using factory authorized parts.

Important Information

Hardware List

P-1 Glass Board 1 EA

EVisionary Board

A Outer Cap Chart

B Wall Mount Chart

C PlasticAnchor Chart

D CS Screw Chart

Part Drawing Description Qty

Hardware Chart by Model # & Board Size

2’X3’ GBoard - 4 pcs. (A), (B)

6pcs. (C),(D),(E)

3’X4’ GBoard - 4 pcs. (A), (B)

6 pcs. (C), (D), (E)

4’X4’ PJWBoard - 4 pcs. (A), (B)

6 pcs. (C), (D), (E)

4’X6’ GBoard - 6 pcs. (A), (B)

8 pcs. (C), (D), (E)

4’X8’ GBoard - 8 pcs. (A), (B)

10 pcs. (C), (D), (E)

4’X4’ PJGBoard- 4 pcs. (A),(B)

6 pcs. (C), (D), (E)

4’X6’ PJWBoard- 6 pcs. (A), (B)

8 pcs. (C), (D), (E)

4’X6’ PJGBoard-6 pcs. (A),(B)

8 pcs. (C), (D), (E)

See

Should you require assistance during assembly,

please call our

Customer Service Department

Monday - Friday 8 a.m. - 5 p.m.

Central Standard Time

Toll-Free Customer Service

1-800-749-2258

83847

83845

83843

83844

83846

83849

83850

83848

E DrywallAnchor See

Chart

F Phillips Tray Screw See

Chart

P-2

P-3 Aluminum Tray 1 EA

Tray Mount 1 EA

2 pcs. (F)

Measurethelength and widthofyournew board. Determine the wallcenterline and height

offthe floor thatyouwant your newboard to belocated. Hold your boardupin position and

drawa line3/8” abovethe topedge ofyour boardand 3/8”below thebottom edgeof your

board. Ifyourwallhasstuds,determine the centerlineof thestuds. Itis recommendedthat

you tie into as many studs as possible when mounting your board. .

aring to InstallPreparing to Install Your New Visionary Board

NOTE: The proper installation of your board will require at least two people.

Tools required: Tape measure, chalkline, electric drill / screwdriver, drill and

screwdriver bits, stud finder and level. .

Installing the Aluminum Marker Tray

1.) InstalltheAluminumMarkerTraytothewallbefore you installyourVisionaryBoard.

2.) Determine where you want your tray to be located and mark a line 1” above the

bottomedge ofyour board. Drill two 5/16” diameter holes in the wall 5 3/4” apart.

5 3/4”

Bottomof

Board

Line for Board

Mounts

TrayMount

Line

Pushintwo PlasticAnchors(C)into thepredrilledholes. Place theTray Mount(P-2) overthe

PlasticAnchors(C) andsecurewith two CSScrews (D) asshown in Illustration#1.

3.)

Illustration #1

Place theAluminumTray(P-3) inthefront slot oftheTrayMount(P-2)andalign the holes.

SecuretheAluminumTray (P-3)totheTray Mount (P-2)usingtwo PhillipsTray Screws (F).

See Illustration #2. .

4.)

Illustration #2

83843-83850ALM_3-13-12

To Assemble and Attach to Wall:

IdentifyandSeparate all thePartsandHardware.

Afteryouhave followed theguidelinesfrom the previouspage,installthe correctnumberofBoard

Mounts(B)forthe size boardyouaremounting to the wall. InstalltheBoardMounts as shownin

Illustration#1 and Illustration#1a.

1.)

Illustration # 3

Illustration # 1

2.)

3.) For all walls except sheet rock: .

Predrilla 5/16” diameter holeon theline that wasdrawn 3/8”belowand 3/8” abovethe

top andbottom edgesof yournew board. Pushin a PlasticAnchor (C)into thepredrilled

hole. Place the bottomhole in theWall Mount(B) on topof the PlasticAnchor(C)and

attachusing oneCS Screw(D). Repeat this Stepfor eachWall Mountthat isrequired

for your size board. . .

5/16” Predrilled

Holein Wall

DrawnLine

4.) YourattachedWallMounts(B)shouldbe

turnedasshowninIllustration #2.

Illustration # 2

TopWall

Mounts

BottomWall

Mounts .

5.) Place theGlass Board(P1) between and resting on the stepledge oneach WallMount (B).

Secure the Glass Board (P1) in place by screwing in aTop Cap (A) into each treaded hole in

the Wall Mounts (B) as shown in Illustration #3 .

83843-83850ALM_3-13-12

3a.) For sheet rock walls: .

Screwin a DrywallAnchor (F)on the linethat was drawn3/8” below and3/8” above the

top and bottomedges ofyour new board. Place the bottomhole inthe WallMount (B)

ontop ofthe Drywall Anchor (F)and attachusing oneCS Screw (D). Repeatthis Step

for each Wall Mount that is required for your size board. . .

Illustration # 1a

DrawnLine
