Morphy Richards IB29015 User manual

Stereo CD
Clock Radio
29015 OPERATING INSTRUCTIONS
Electrical requirements
Check the voltage on the rating plate of your CD clock radio corresponds
with your house electricity supply which must be A.C. (Alternating current).
If the socket outlets in your home are not suitable for the plug supplied with
this appliance the plug should be removed and the appropriate one fitted.
WARNING: The plug removed from the mains lead, if severed, must be
destroyed as a plug with a bared flexible cord is hazardous if engaged
into a live socket outlet.
Should the fuse in the 13 amp plug require changing a 3 amp BS1362 fuse
must be fitted.
Battery back-up facility (unit will work without a battery being fitted)
Your alarm CD clock radio is equipped with a battery back-up facility.
1Remove the battery compartment cover (located underneath the unit) by
pushing in the clip and lifting off.
2Insert a battery size 9 volts PP3/6LR61 (Ensure battery is inserted correctly)
3Replace the battery compartment cover.
Should a power interruption occur the clock will continue to run, however, time
keeping will not be accurate. The display will be extinguished to conserve battery
life but the memory will retain details of the clock time and alarm settings.
If the optional battery is not installed in case of the AC power failure the display
will blink to indicate the power was interrupted. You will need to reset the clock
and alarm.
Battery back-up is designed to operate for a short period only.
If the unit is not to be used for a prolonged period, remove the battery to
avoid battery leakage.
In the interests of environmental safety : dispose of batteries safely.
More information
• Do not use your cd clock radio immediately after moving from a cold place
to a warm place as there may be condensation problems.
• Make sure that you keep your unit away from water and high temperatures.
• Clean the player with a soft cloth, or a damp chamois leather. Never use
solvents.
Notes on compact discs
• If there is a scratch, dirt or fingerprints on the CD, it may cause a tracking
error.
• Before playing, clean the CD with a cleaning cloth. Wipe the CD from the
centre out. Don’t store discs in places with high temperatures or high
humidity, they can become warped. After playing, store the CD in it’s case.
P. 2
P. 3 P. 4
Location of controls
1. CD Door open.
2. CD Compartment.
3. Tuning knob : To select your radio station
4. Band switch AM-FM-FM ST.
5. Volume control
6. Alarm Mode : Off / Buzzer / Auto
7. Alarm Selector : AL 1 / AL 1+2 / AL 2
8. Function selector : CD / Radio
9. SNOOZE : Interval alarm repetition
10. Phones jack
11. FM wire antenna
12. AC power cord
13. Battery compartment
14. Speakers
15. REPEAT : To play the disc continuously
16. RANDOM : To select the random play mode
17. Skip Search (backward / forward) / MINUTE / HOUR
- CD track skip and fast search within the track
- All clock functions - minute and hour setting
18. STOP : To stop playing the disc
19. PLAY/PAUSE : To start playing the CD or to stop the disc player momentarily
20. FM stereo LED indicator
21. CD repeat function LED indicator
22. CD Random function LED indicator
23. CD Program LED indicator
24. Power LED indicator
25. POWER
26. PTS (PROGRAM) : to set programmable CD tracks
27. ALARM 1 : set
28. SLEEP
29. TIME : set
30. ALARM 2 : set
31. ALARM 1 LED Indicator
32. Digital Display
33. Dial scale and pointer
34. ALARM 2 LED Indicator
35. PM indicator
Maintenance
Do not expose your cd clock radio to extremes of temperature. The product should
be kept in a warm environment free from dust and damp. For external cleaning
use only a soft, clean, damp cloth. Use of detergents may damage the finish.
Illustration
1
2
3
4
5
6
7
8
9
10
11 12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31 32 33 34
35

P. 5 P. 6
P. 7
Switching on, and setting the clock time
Before any alarm functions can be used on your cd alarm clock radio you
must first set the clock to the correct time.
1Place the unit on a flat surface. Plug the mains plug into the wall socket and
switch on the wall socket.
2The clock LED display will show 12:00.
3Press and hold the TIME button (29) and MINUTE or HOUR (17) to adjust to
your desired time.
4Release the TIME button (29) to store your setting in memory.
5The PM indicator (35) will illuminate to indicate 12.00 midday has been
reached.
Listening to the radio
FM wire aerial
To obtain the maximum FM reception fully extend the wire FM aerial (which is
located at the rear of the unit) and alter the direction of the wire for best results.
The aerial for the AM waveband is located inside the unit. To obtain the maximum
AM reception rotate the cd clock radio.
1Switch to radio position with the FUNCTION SELECTOR (8).
2Select your desired band by using the BAND switch (4).
3Press the POWER button (25).
4Adjust the VOLUME (5) to the desired level.
5Select your desired radio station (3) and (33).
6To stop listening to the radio press POWER button (25).
Listening to the cd player
1Open the CD door (1). Load your disc (label side up) into CD compartment
(2).
2Switch to the CD position using the FUNCTION SELECTOR (8).
3Press POWER (25), the Display (32) will show total track numbers. It will
return to the clock time after a few seconds.
4Press (19) PLAY/PAUSE button to start listening from the first track. The
Display (32) will show 01.
NOTE: Also use this button to momentarily suspend the playing track.
Press once again to continue playing.
5Rotate the VOLUME (5) to adjust the desired level.
6Press (18) STOP button to stop listening to the disc.
Other CD Player Functions
SKIP SEARCH (17) : Press SEARCH to skip forward to the next track or
repeatedly to skiptracks. Press SKIP to return to the beginning of the track, or
press repeatedly to skip backwards several tracks. Press and hold SKIP or
SEARCH to search quickly within a track.
REPEAT (15)
Press once to repeat your selected track. REPEAT indicator (21) blinks.
Press twice to play the disc continuously. REPEAT indicator (21) illuminates.
Press again to switch off this function. REPEAT indicator (21) goes off.
PROGRAM (26)
To set your own musical program.
1Insert the disc (1,2). The total number of tracks is displayed (32).
2Press (26), the display shows “P01”. PROGRAM indicator (23) blinks.
3Select with SKIP or SEARCH (17) to find your desired track, then press the
PTS PROGRAM button (26) to store your program in memory. Repeat this
operation as many times as necessary. 20 tracks can be stored.
4Press (19) PLAY/PAUSE to start playing.
5Press STOP (18) to stop the disc.
6To cancel this function, open the CD compartment.
RANDOM :
1Press RANDOM (16) to select RANDOM play mode and it will randomly play
all the tracks on the CD. The RANDOM indicator (22) will illuminate.
Setting the alarm and wake up mode
This unit allows you to set two different wake up times which you can choose to
use independently or simultaneously AL1 or AL2, AL1 and 2.
Setting the Alarm
1st Alarm (AL1) : Press and hold the ALARM 1 button (27), and press SKIP or
SEARCH (17) to adjust your desired alarm time, then release ALARM 1 (27) to
store your setting in memory.
2nd Alarm (AL2) : Press and hold the ALARM 2 button (30) and repeat the same
operation as above.
• Select your alarm wake-up mode (6) in AUTO (for RADIO or CD), BUZZER
(for alarm sound) or OFF to switch off the alarm.
• Select your wake-up time with the alarm selector (7).
Wake Up to the Buzzer Sound
Switch to the BUZZER position using ALARM MODE switch (6), the alarm LED
indicator (31 and/or 34) will light.
Wake Up to the Radio
1Follow procedures 1 to 6 in “LISTENING TO THE RADIO”, to select your
desired radio station.
2Switch the ALARM MODE switch to the AUTO position (6), the alarm indicator
(31 and/or 34) will light.
Wake up to the CD
1Follow procedures 1 to 6 in “LISTENING TO THE CD PLAYER”.
2Switch ALARM MODE switch to the AUTO (6) position, the alarm LED
indicator (31 and/or 34) will light.
3Press POWER (25) and POWER indicator (24) goes off.
NOTE: If the CD play time is longer than 60 minutes, the music will stop
after playing 60 minutes.
Wake Up to the Programmable CD Tracks
1Switch to the CD position (8) and press POWER (25). POWER indicator (24)
will light.
2Follow procedures 1 to 5 in “LISTENING TO THE CD PLAYER - PROGRAM”.
3Switch the ALARM MODE switch to the AUTO (6) position, the alarm LED
indicator (31 and/or 34) will light.
4Press POWER (25) and POWER and PROGRAM indicators (23, 24) will go
off.
NOTE: The music will stop after the programmed tracks, eg, if one track is
programmed the alarm will stop at the end of this track. The programmed
memory will be erased once the CD door is opened.
Stopping the alarm
The alarm is programmed to run for 60 mins.
1 SNOOZE (9) : Press to stop the alarm temporarily, the alarm will stop and
ring again automatically, after 6mins.
2 POWER (25) : The alarm will stop, and will sound again 24 hours later.
3OFF (6) : To turn off the alarm permanently switch the ALARM MODE switch
to the off position. The alarm LED indicators (31, 34) will go off.
Sleep to music
1Select the FUNCTION SELECTOR to CD/Radio (8) for the sleep mode.
2Press SLEEP (28), the display shows “—“, press again to select the desired
sleep time. (there are three sleep times 90-60-30 minutes). It will countdown
after a few seconds.
3If in CD mode, press  PLAY/PAUSE (19) to play the CD.
4Press POWER (25) to stop.
NOTE : If the CD play time is shorter than your selected sleep time, the
music will stop at the end of the disc.
Technical specification
AC Power supply : 230v 50Hz
Battery back-up : 9V DC type 6LR61/PP3 (not included)
Radio : FM 88Mhz - 108MHz
: AM 530Khz - 1600kHz
Warning labels
WARNING: to reduce the risk of electric shock, do not expose this appliance
to rain or moisture.
Guarantee
Morphy Richards products are manufactured to internationally accepted quality
standards. In addition to your statutory rights, Morphy Richards guarantee your
product to be free from manufacturing and component defects for a period of TWO
YEARS from date of purchase.
If your product proves to be defective within 28 days of purchase, your Morphy
Richards dealer from whom the product was purchased will be pleased to replace it
free of charge.
Should your product develop a defect within the guarantee period but after
the replacement period, please return the product to the following address,
together with the proof of purchase, brief details of the symptoms and your own
name and address.
Registered address
Morphy Richards Limited
Mexborough
South Yorkshire
S64 8AJ
Your post office will provide a certificate of posting. The product will be
repaired and returned to you promptly.
Helpline (8:30-5:00 Mon-Thur/ 8:30-4:00 Fri) UK 0870 060 2614
Republic of Ireland 1800 409119
Replacement parts 0870 167 6645
www.morphyrichards.co.uk
AD29015M UK Rev 2
ATTENTION: To reduce the risk of electric shock, do not remove
the cover. There are no user serviceable parts inside the unit. Refer
any servicing to qualified personnel.
The lightning flash with arrowhead symbol within the triangle is a warning sign
alerting the user of ‘dangerous voltage’ inside the unit.
The exclamation point within the triangle is a warning sign alerting the user
of important instructions accompanying the product.
To prevent fire or shock hazard do not expose this apparatus to dripping or
splashing.
CAUTION: Invisible laser radiation when open and interlocks defeated. Avoid
exposure to the beam.
