Morphy Richards 47508 User manual

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
Pump espresso coffee maker
Please read and keep these instructions
Getting the best from your new coffee maker...
Warning :Hot water and steam
Safety first
Caution must be used when handling hot water,
coffee or steam
Run water through your machine before first use
It is important to run water through your coffee maker
in order to rinse the machine. You can also run water
through to warm your coffee machine.
Descale as appropriate for the hardness of the water in
your area
It is important to descale as the performance of your
coffee maker may be impaired by limescale and other
impurities in the water supply.
CM47507 Rev2
For replacement parts, help with using your Morphy Richards, problems
and lots more, contact us by phone or through our website.
UUKKHHeellpplliinnee::0088770000660022661100
RReeppllaacceemmeennttppaarrttss::0088770011667766664411
IIrreellaanndd11880000440099111199
47507 rev2 29/6/06 14:14 Page 1

UUKKHHeellpplliinnee0088770000660022661100RReeppllaacceemmeennttPPaarrttss0088770011667766664411IIrreellaannddHHeellpplliinnee11880000440099111199
IMPORTANT SAFETY
INSTRUCTIONS
The use of any electrical
appliance requires the following
common sense safety rules.
Primarily there is danger of injury
or death and secondly the
danger of damage to the
appliance. These are indicated in
the text by the following two
conventions:
IMPORTANT: Damage to the
appliance! In addition we offer
the following safety advice.
Location
• Remove all the packaging and
retain for future reference.
• Ensure the coffee maker is used
on a firm, flat surface.
• Do not use the coffee maker
outdoors or in a bathroom.
• Do not place the coffee maker
on a highly polished wooden
surface as damage may occur to
the surface.
• Do not place the coffee maker
on or near hot surfaces such as
a hot plate or radiant rings or
near a naked flame.
•WWAARRNNIINNGG::DDoonnoottppllaacceetthhee
ccooffffeeeemmaakkeerroonnttooaammeettaall
ttrraayyoorrmmeettaallssuurrffaacceewwhhiillsstt
iinnuussee..
• Do not lift the coffee maker by
gripping the water reservoir. Hold
the body of the coffee maker.
Personal safety
• Disconnect the coffee maker
from the mains supply when
filling, cleaning or not in use.
• If the unit stops producing
coffee, unplug and see cleaning
instructions page 8.
• Keep the outside of the coffee
maker area clean and dry at all
times.
• Do not touch hot surfaces.
Always use handles or knobs.
• Do not touch metal parts until
the unit has cooled.
•WWAARRNNIINNGG::DDoonnoottiimmmmeerrssee
tthheeccooffffeeeemmaakkeerriittsseellffiinn
wwaatteerraannddaallwwaayysseennssuurree
tthheeeelleeccttrriiccaal
lccoonnnneeccttiioonnss
aarreekkeeppttddrryy..
• Do not operate any appliance
with a damaged cord or plug or
after the appliance malfunctions
or has been damaged in any
manner. Ring the helpline
number for advice on
examination and repair.
• The use of attachments or tools
not recommended or sold by
Morphy Richards may cause fire,
electric shock or injury.
• Do not use abrasive cleaners on
the outside of the coffee maker,
they may scratch the surface.
Clean only with a soft damp
cloth.
• Do not use the coffee maker for
anything other than its intended
purpose.
• Caution must be used when
handling hot water, coffee or
steam.
Children
• Children do not understand the
dangers associated with
operating electrical appliances.
Never allow children to use this
appliance.
Product safety
• Never use warm or hot water to
fill the water reservoir.
• Do not overfill the water
reservoir.
• Operate the appliance only with
the drip tray in place.
Treating scalds
• Run cold water over the affected
area immediately. Do not stop to
remove clothing, get medical
help quickly.
47507 rev2 29/6/06 14:14 Page 2

2233UUKKHHeellpplliinnee0088770000660022661100RReeppllaacceemmeennttPPaarrttss0088770011667766664411IIrreellaannddHHeellpplliinnee11880000440099111199
Choice of coffee
• Choose a finely ground
espresso coffee to use with
this machine.
Note: Avoid blends that are
very powdery. When the
coffee is too finely ground
it may block the filter.
ELECTRICAL
REQUIREMENTS
Check that the voltage on
the rating plate of your
appliance corresponds
with your house electricity
supply which must be A.C.
(Alternating current).
If the socket outlets in your
home are not suitable for
the plug supplied with this
appliance the plug should
be removed and the
appropriate one fitted.
WWAARRNNIINNGG::TThheepplluugg
rreemmoovveeddffrroommtthhee
mmaaiinnsslleeaadd,,iiffsseevveerreedd,,
mmuussttbbeeddeessttrrooyyeeddaassaa
pplluuggwwiitthhaabba
arreedd
fflleexxiibblleeccoorrddiiss
hhaazzaarrddoouussiiffeennggaaggeedd
iinnttooaalliivveessoocckkeett
oouuttlleett..
Should the fuse in the 13
amp plug require changing
a 13 amp BS1362 fuse
must be fitted.
WWAARRNNIINNGG::TThhiiss
aapppplliiaanncceemmuussttbbee
eeaarrtthheedd..
DISPLAY GUIDE
• <Flashing>
Warming up to make coffee
or hot water
• Ready to make coffee or hot
water
or making coffee (lever
down)
• <Flashing>
Warming up to make steam
• Ready to make steam
or making steam (lever up)
• Making hot water (lever up)
47507 rev2 29/6/06 14:14 Page 3

33
Features
⁄Warming plate
¤Power light
‹Hot water/steam selector
›On/off switch
fiBrewing head
flFilter lock
‡Filter holder
·Drip tray water level
indicator
‚Non slip rubber feet
„1 cup filter
‰2 cup filter
ÂMeasuring spoon
ÊTamper
ÁRemovable drip tray
ËFroth attachment
ÈSteam nozzle
ÍDisplay
Î1.7L removable water
reservoir
Ï‘Hard’ Pod filter
ÌCoffee or steam lever
Before use
Before using your coffee
maker for the first time or if
you have not used it for
some time, rinse the
machine by running water
through. Follow the
procedure for making
espresso coffee overleaf,
without coffee in the filter
holder.
For best results before
making your
espresso/cappucino the
cups should be warmed.
This can be done on the
warming plate but please
note that this may take up
to 20 minutes depending
upon the type of cup used.
44
wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
⁄
¤
‹
›
fi
fl
‡
·
‚
„Â
‰
Ê
Á
Ë
È
STEAM
COFFEE
OFF
Î
Ì
Ï
Í
47507 rev2 29/6/06 14:14 Page 4

55UUKKHHeellpplliinnee0088770000660022661100RReeppllaacceemmeennttPPaarrttss0088770011667766664411IIrreellaannddHHeellpplliinnee1188000044009911119944
OPERATING THE
APPLIANCE
Filling the water
reservoir
11Remove to fill the water
reservoir, Aslide the water tank
upwards using the handle. Open
the lid of the water reservoir Î
by pulling up and sliding
backwards.
IMPORTANT: Do not overfill or
carry with the handle when full.
22Fill the water reservoir Îusing
cold tap water, 1.7 litres
maximum. B
33Replace the water reservoir by
sliding it back into place. C
Using with ground
coffee
Ensure the coffee/steam lever
Ìis in the off position.
11Plug the unit into the power
outlet.
22Switch the unit on by pressing
the on/off switch ›. The blue
'power light' ¤and the display
Í will illuminate.
33Pre-heat your coffee cups by
placing them upside down on
the warming
plate ⁄.
Note: This machine is designed
for use with espresso or
cappucino cups only. The coffee
will emerge much weaker if
larger cups are used.
44Select the required filter „for 1
cup or ‰for 2 cups and place
in the filter holder ‡. D
55Using your measuring spoon Â
supplied, place one or two
measures of ground coffee into
the filter, depending on filter
choice. With the other end of
the measuring spoon, use the
tamper Êto tamp down the
coffee. E
IMPORTANT: Be sure not to
overfill the filter with too much
coffee, and wipe around the
edge of the filter to remove any
coffee grounds.
66Place the filter holder ‡on the
brewing head fiand position
the handle so it points to the
left. F
• Ensure the filter holder is flat
against the brewing head and
turn the handle towards the right
Gas far as it will go.
77Place 1 or 2 pre-heated cups
below the outlet holes of the
filter holder Hand I. When the
coffee maker is at the correct
temperature the sign will be
displayed.
88Move the lever down to the
coffee setting. You will hear the
machine make a pumping noise,
this is normal.
99Once the cups are filled to the
desired level, move the lever to
the off position. Water will still
filter through for approximately 8
seconds after the lever has been
moved to the off position.
1100Carefully remove the filter holder
by turning the handle sslloowwllyyto
the left.
1111To remove the used coffee
grounds from the filter, push the
filter lock flforward over the
edge of the filter and turn the
filter holder upside down. Gently
tap out the coffee. J
1122Once the sign shows, your
machine is ready to make the
next espresso.
Note: It is normal for the
symbols on the display to cycle
on and off during the water heat
up process.
A
B
C
D
E
F
G
47507 rev2 29/6/06 14:14 Page 5

6655
Using with coffee
pods
Note: This coffee machine can
use both ‘soft and ‘hard’ coffee
pods. When using ‘hard’ coffee
pods use the special pod filter
holder Ï. When using ‘soft’
coffee pods use the 1 cup filter
holder „.
11Select the required filter Ïfor
‘hard’ pod or „for ‘soft’ pod
and place in the filter holder. K
22Remove the espresso pod from
the packaging. L
33Place the coffee pod in the filter
Ï. Ensure that the flap is
placed inside the filter. M.
Note: If any part of the pod,
including the flap, is outside the
filter holder the sealing system
will not function properly. This
will affect the functioning of the
machine and the coffee quality.
44Place the filter holder ‡on the
brewing head fiand position
the handle so it points left.
Ensure the filter holder is flat
against the brewing head and
turn the handle towards the right
Nas far as it will go.
55Place a pre-heated cup below
the outlet holes of the filter
holder. O
Note: One coffee pod has the
measured amount of coffee for
one single espresso. When the
coffee is at the correct
temperature the sign will be
displayed.
66Move the lever down to the
coffee setting. You will hear the
machine make a pumping noise,
this is normal.
77Once the cup is filled to the
desired level, move the lever
back to the off position. Water
will still filter through for
approximately 8 seconds after
the lever has been moved to the
off position.
88Carefully remove the filter holder
by turning the handle sslloowwllyyto
the left.
99To remove the pod from the
filter, push the filter lock fl
forward over the edge of the
filter and turn the filter holder
upside down, gently tap out the
pod. P
1100Once the sign shows, your
machine is ready to make the
next espresso.
Note: It is normal for the
symbols on the display to cycle
on and off during the water heat
up process.
wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
H
I
J
K
L
M
N
O
P
47507 rev2 29/6/06 14:14 Page 6

77UUKKHHeellpplliinnee0088770000660022661144RReeppllaacceemmeennttPPaarrttss0088770011557766664455IIrreellaannddHHeellpplliinnee1188000044009911119966
Steam function
The froth attachment makes it
easy to produce frothy milk for
cappucino.
Ensure the coffee/steam lever is
in the off position.
11Before using the steam nozzle,
remove the filter holder.
22Attach the froth attachment Ë
to the end of the steam nozzle
ÈQ.
IMPORTANT: For the froth
enhancing attachment to work
you must ensure that it is
pushed firmly onto the steam
nozzle.
33Fill the water reservoir with cold
tap water.
44Swing the steam nozzle with the
froth attachment to the side of
the machine.
55Press the steam button ‹,
when the unit is ready to make
steam the sign shows. This
sign will flash on the display
until the machine reaches the
correct temperature to make
steam when it becomes fixed.
66Pour cold milk into a suitable
jug. Use approximately 100ml
for each cappucino.
Note: For best results we
recommend to use refrigerated
milk and a stainless steel jug
that is well chilled.
77Hold the jug under the steam
nozzle so that the head of the
froth attachment is immersed in
milk and push the lever up to
the steam setting R.You will
hear the machine making a
pumping noise, this is normal.
IMPORTANT: Do not allow the
tip of the nozzle to touch the
bottom of the jug because this
could obstruct the passage of
steam.
88Once the froth has been
produced push the lever down
to the off position and remove
the jug.
Note: Do not be alarmed by the
escaping steam from the base.
Note: It is normal to hear a
pumping sound when switching
from steam mode to coffee
mode or hot water mode.
The milk is ready as soon as it
forms a soft, thick layer of foam
on the top. If the milk starts to
make large popping bubbles,
you have boiled the milk and it
will therefore not froth. If this
happens replace with chilled
milk. Do not boil the milk.
Frothing tips
• For best results use fresh, cold
milk from the refrigerator.
• Skimmed milk or fat reduced
milk will make frothing easier.
UUKKHHeellpplliinnee0088770000660022661100RReeppllaacceemmeennttPPaarrttss0088770011667766664411IIrreellaannddHHeellpplliinnee11880000440099111199
Q
R
66
47507 rev2 29/6/06 14:14 Page 7

UUKKHHeellpplliinnee0088770000660022661100RReeppllaacceemmeennttPPaarrttss0088770011667766664411IIrreellaannddHHeellpplliinnee11880000440099111199
HOT WATER DRINKS
You may want to top up your
espresso with hot water for a
longer drink or to make other
hot water drinks such as tea or
instant soups using the steam
nozzle.
If the machine has
been in use:
11Take care when removing he
froth attachment Ëfrom the
steam nozzle, Èit may be
extremely hot.
22Ensure the water reservoir Îis
filled with cold tap water.
33Swing the steam nozzle Èto
the side of the coffee maker.
Take extreme care when
handling the steam nozzle it
may be extremely hot.
If the machine has
not been in use:
44Ensure the unit is cold before
removing the froth attachment
Ë from the steam nozzle.
55Ensure the water reservoir Îis
filled with cold tap water.
66Swing the steam nozzle Èto
the side of the coffee maker.
77Switch the unit on by pressing
the on/off switch ›. The blue
‘power light’ ¤and display Í
will illuminate.
Operation
88When the coffee maker is at the
correct temperature for hot
water the sign will be
displayed.
99Push the lever Ìup to the
steam/hot water function.
Note: You will hear the machine
making a pumping noise, this is
normal.
1100The symbol will show on the
digital display as water is
dispensed through the steam
nozzle.
Note: If the icon is shown
on the digital display the
machine is in the steam function
position. Press the hot
water/steam selector switch ‹
to change the machine to the
hot water function, the icon
will change to the icon on
the digital display.
1111Once the water has reached the
desired level, push the lever Ì
down to the off position.
Note: It is normal for the
symbols on the display to cycle
on and off during the water heat
up process.
Preheating your
coffee maker
To make hotter coffee and to
warm your coffee cups you may
wish to preheat your machine.
This can be achieved by
following the 'espresso
operation' by passing hot water
through the coffee maker but
without using coffee.
Cups should be placed upside
down on the warming plate.
Please note that this may take
up to 20 minutes depending
upon the type of cup used.
77
47507 rev2 29/6/06 14:14 Page 8

99
wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
99
HINTS AND TIPS
Cleaning and
maintenance
You must clean the steam
nozzle and froth attachment
immediately after each use.
11Simply wipe the steam nozzle,
warming plate and exterior with
a clean, damp cloth. Do not use
any abrasives or metal scourers
as this will damage the finish on
the unit.
Briefly push the lever to the
steam setting to clear any
remaining milk out of the steam
nozzle.
WWAARRNNIINNGG::SStteeaammffrroommtthhee
nnoozzzzlleeiisseexxttrreemmeellyyhhoottaanndd
ccaannssccaalldd..
22Place the froth attachment
under warm running water to
remove excess milk.
IMPORTANT: Never wash your
coffee machine accessories in a
dishwasher.
33The filters, filter holder and
water reservoir should be
washed after each use by
rinsing them under water. To
assist in keeping the filters
clean we recommend you
periodically run the machine
with the filter in place, without
coffee, using water only.
Should the holes in the filters
become blocked with coffee
granules use a fine bristled
brush.
When your coffee maker is not
being used, we recommend
that you do not leave the filter
holder attached to the machine
as this will reduce the life of the
gasket.
Descaling
• If you live in a harder water
area, we recommend that your
coffee maker is descaled at
regular intervals, eg. every 2 - 3
months. In areas of moderately
hard water you should descale
every 6 months.
• If the water filters through more
slowly than usual, it is a sign
that descaling is necessary.
• We recommend you to use
proprietary liquid descaler
which is especially made for
coffee makers and plastic
kettles. Follow the instructions
on the bottle or sachet, and
then operate the coffee maker
with just water 3 times before
making coffee.
• Do not use kettle descaler
unless the packet specially
states it is suitable for coffee
makers.
Drip tray
11The water level indicator ·
appears through the grid to
indicate that the drip tray is full.
22Remove the grid of the drip tray
by placing fingers in the two
holes in the centre of the drip
tray and lift off. SThis must be
done regularly or as soon as the
red water level indicator
appears through the grid.
33Lift the front of the drip tray up
and slide it out. T
44Lift off the plastic lining of the
drip tray. UClean the drip tray
and its grid with water and a
little washing up liquid, rinse
and dry.
55Reverse the procedure to
reassemble.
Note: Ensure that when you are
replacing the drip tray that the
plastic lining is in the correct
position.
S
T
U
88
wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
47507 rev2 29/6/06 14:14 Page 9

99UUKKHHeellpplliinnee0088770000660022661100RReeppllaacceemmeennttPPaarrttss0088770011667766664411IIrreellaannddHHeellpplliinnee11880000440099111199
Helpline
If you have any difficulty with
your appliance, do not hesitate
to call. We are more likely to be
able to help than the store from
where you bought it.
Please have the following
information ready to enable our
staff to deal with your enquiry
quickly:
• Name of the product
• Model number as shown on the
underside of the appliance.
• Serial number as shown on
underside of the appliance.
UK Helpline 0870 060 210
Replacement Parts 0870 167 6641
Ireland Helpline 1800 409119
47507 rev2 29/6/06 14:14 Page 10

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm
YOUR TWO YEAR
GUARANTEE
It is important to retain the
retailers receipt as proof of
purchase. Staple your
receipt to this back cover
for future reference.
Please quote the following
information if the product
develops a fault. These
numbers can be found on
the base of the product.
Model no.
Serial no.
All Morphy Richards
products are individually
tested before leaving the
factory. In the unlikely event
of any appliance proving to
be faulty within 28 days of
purchase it should be
returned to the place of
purchase for it to be
replaced.
If the fault develops after 28
days and within 24 months
of original purchase, you
should contact the Helpline
number quoting Model
number and Serial number
on the product, or write to
Morphy Richards at the
address shown.
You will be asked to return
the product (in secure,
adequate packaging) to the
address below along with a
copy of proof of purchase.
Subject to the exclusions
set out below (see
Exclusions) the faulty
appliance will then be
repaired or replaced and
dispatched usually within 7
working days of receipt.If
for any reason this item is
replaced during the 2 year
guarantee period, the
guarantee on the new item
will be calculated from
original purchase date.
Therefore it is vital to retain
your original till receipt or
invoice to indicate the date
of initial purchase.
To qualify for the 2 year
guarantee the appliance
must have been used
according to the
manufacturers instructions.
For example coffee makers
should have been regularly
descaled.
EXCLUSIONS
Morphy Richards shall not
be liable to replace or
repair the goods under the
terms of the guarantee
where:
11The fault has been caused
or is attributable to
accidental use, misuse,
negligent use or used
contrary to the
manufacturers
recommendations or where
the fault has been caused
by power surges or
damage caused in transit.
22The appliance has been
used on a voltage supply
other than that stamped on
the products.
33Repairs have been
attempted by persons other
than our service staff (or
authorised dealer).
44Where the appliance has
been used for hire
purposes or non domestic
use.
55Morphy Richards are not
liable to carry out any type
of servicing work, under the
guarantee.
66Plastic filters for all Morphy
Richards kettles and coffee
makers are not covered by
the guarantee.
• This guarantee does not
confer any rights other than
those expressly set out
above and does not cover
any claims for
consequential loss or
damage. This guarantee is
offered as an additional
benefit and does not affect
your statutory rights as a
consumer.
• This guarantee is valid in
the UK and Ireland only.
For electrical products sold within the
European Community. At the end of the
electrical products useful life it should
not be disposed of with household
waste.
Please recycle where facilities exist.
Check with your Local Authority or
retailer for recycling advice in your
country.
Morphy Richards products are intended for household use only.
Morphy Richards has a policy of continuous improvement in product quality and
design. The company, therefore reserves the right to change the specification of its
models at any time.
The After Sales Division
Morphy Richards Ltd
Mexborough, South Yorkshire,
England, S64 8AJ
Helpline (office hours)
UK 0870 060 2610
Republic of Ireland 1800 409119
47507M UK Rev2 06/06
FFoorrddeettaaiillssooffootthheerrpprroodduuccttssiinntthheeMMoorrpphhyyRRiicchhaarrddssrraannggeepplleeaasseesseeeeoouurrwweebbssiittee......
1100
47507 rev2 29/6/06 14:14 Page 11

UUKKHHeellpplliinnee0088770000660022661144RReeppllaacceemmeennttPPaarrttss0088770011557766664455IIrreellaannddHHeellpplliinnee11880000440099111199
47507 rev2 29/6/06 14:14 Page 12
