Morphy Richards Redefine User manual

Instruction
manual
Please read and keep these
instructions for future use
KT131000 MUK REV7
KT131004 MUK REV1.indd 3 18/02/2015 10:34

this is where the similarity ends
this is where the exceptional begins
... the premium, highly innovative Morphy Richards product group.
Driven by principles of innovation and providing exceptional quality, the
Redefine range is designed to fulfil the consumer need for brilliantly performing
products that have equal aesthetic consideration.
KT131004 MUK REV1.indd 1 18/02/2015 10:34

2
Location
• Always locate your appliance away from the edge of the
worktop.
• Ensure that the appliance is used on a firm, flat surface.
• Do not use the appliance outdoors or near water.
• WARNING: Do not place the appliance onto a metal tray or
metal surface whilst in use.
Mains cable
• Do not let the mains cable hang over the edge of the
worktop where a child could reach it.
• Do not let the mains cable run across an open space e.g.
between a low socket and a table.
• Do not let the mains cable run across a cooker or other hot
area which might damage the cable.
• The mains cable should reach from the socket to the base
unit without straining the connections.
Personal safety
• WARNING: To protect against fire, electric shock and
personal injury do not immerse cord, plug and appliance in
water or any other liquid.
• Unplug from the outlet before cleaning.
• Allow to cool before putting on or taking off parts and
before cleaning.
Health & Safety
The use of any electrical appliance requires the following common sense safety rules.
Please read these instructions carefully before using the product.
• This appliance can be used by children aged from 8 years and above if
they have been given supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall
not be made by children unless they are older than 8 and supervised.
• Appliances can be used by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
• Children shall not play with the appliance.
• If the mains cable is damaged, it must be replaced by the manufacturer,
it’s service agent or similarly qualified person in order to avoid a hazard.
• This appliance is intended to be used in household and similar
applications such as: farm houses, by clients in hotels, motels and other
residential type environments, bed and breakfast type environments. It
is not suitable for use in staff kitchen areas in shops, offices and other
working environments.
Other safety considerations
• The use of attachments or tools not recommended or sold
by Morphy Richards, may cause fire, electric shock or injury.
• Do not use the appliance for any use other than to boil
water.
• Do not place the appliance on or near a hot gas or electric
burner or in a heated oven.
• The Water Tank must not be in the Main Unit when being
filled with water.
• Unplug from the outlet when not in use.
• WARNING: The appliance must not be immersed for
cleaning.
• CAUTION: To prevent damage to the appliance, do not use
alkaline cleaning agents when cleaning. Use a soft cloth
and detergent.
Electrical requirements
• Check that the voltage on the rating plate of your appliance
corresponds with your house electricity supply which must
be A.C. (Alternating Current).
• Should the fuse in the mains plug require changing, a 13
amp BS1362 fuse must be fitted.
• WARNING: This appliance must be earthed.
KT131004 MUK REV1.indd 4 18/02/2015 10:34

19
20
21
23
13 14
15
16
17
18
7
7
22 89
10
11
12
1
1
2
2
3
3
4
4
5
5
6
1 Start / Stop Button
Starts and pauses the heating process. Can also be
used to pause dispense while in progress and put the
Hot Water Dispenser into standby mode.
2 Water Volume Dial
Controls the volume of water to be heated and
dispensed. Volume is displayed on the LCD screen (15).
3 LCD Screen
Displays volumes, temperatures, functions, and
warnings.
4 Temperature Button
Adjusts the temperature of dispensed water, turns
sounds on and off.
5 Dispense Button
Switches the Auto Dispense feature on and off.
6 Dispense Nozzles
7 Water tank
Contains the BRITA MAXTRA Cartridge 19, BRITA Memo
20 and BRITA Hopper 21.
8 Drip Tray
9 Drip Tray Cover
10 Drip Tray Indicator
‘Full’ icon indicates when the Drip Tray needs to be
emptied.
11 Heat Icon
Displays when the heat cycle is in process.
12 Water Tank Icon
Displays when the tank needs to be refilled.
13 Dispense Icon
Displays when water is ready for dispense.
14 Auto Dispense Icon
Displays when the auto dispense feature is enabled.
15 Dispense Volume Display
Displays the volume of water to be heated and
dispensed.
16 Descale Icon
Displays when the Hot Water Dispenser requires
descaling.
17 Temperature Icon
Displays the temperature the water will be heated to
prior to dispense.
18 Standby Light
19 BRITA MAXTRA Cartridge
20 BRITA MEMO
Monitors the life of the MAXTRA Cartridge.
21 BRITA Hopper
22 Water Level Sensor
23 Main Unit
KT131004 MUK REV1.indd 6 18/02/2015 10:34

3Place a vessel underneath the Dispense Nozzles (6) and press the Dispense Button (5) to reset the
system. This takes approx. 35 seconds. Any water
dispensed during resetting should be discarded.
5Press the Start/Stop Button (1), the Hot Water Dispenser will pump 240ml of water into the
heating chamber and start to heat.
4
Using the Water Volume Dial (2), adjust the
Dispense Volume (15) to 240ml. Place a cup on the
Drip Tray (8) under the Dispense Nozzles (6).
6When heated the water will automatically dispense from the Dispense Nozzels (6) into your
cup.
1Remove the Water Tank (7) from the Main Unit
(23). Remove the BRITA MAXTRA Cartridge (19) and
BRITA Hopper (21) from the Water Tank. 2
Fill the Water Tank with cold water and return to
your Hot Water Dispenser. Plug your Hot Water
Dispenser into the electrical socket.
Quick
Start
Guide
This quick start guide shows you the basic steps
for dispensing 240ml of hot water for a single
cup of tea or coffee. This quick start guide does
not detail the steps to use the BRITA Filtration
System.
For more detailed information on using your
new Hot Water Dispenser or BRITA Filtration
System, please read this instruction manual.
KT131004 MUK REV1.indd 7 18/02/2015 10:34

4
Resetting
The System
Before using your Hot Water Dispenser for the
first time, or after it has been unplugged from
the mains. You must perform the following steps
to reset your Hot Water Dispensers’ heating
chamber.
Your Hot Water Dispenser will not function
if the system has not been reset.
3
Place an empty vessel, such as a measuring jug
or saucepan underneath the Dispense Nozzles (6). 4Press the Dispense Button to reset the system.
Any remaining water will be dispensed from the
system into the vessel below. This takes
approximately 35 seconds. It is now ready for use.
2
The Dispense Button (5) will flash and the
‘Dispense Icon’ (13) will appear on the screen.
1
Plug your Hot Water Dispenser into the mains
outlet and switch on at the socket.
35
seconds
KT131004 MUK REV1.indd 8 18/02/2015 10:34

BRITA filtration
Filtering your water improves the taste and
appearance of beverages by reducing limescale, lead,
chlorine and other impurities.
The BRITA MAXTRA Filter Cartridge offers improved
filtration due to MAXTRA Technology. The natural
MicroporeFilter in combination with the powerful
Protect Filter reduces chlorine and limescale for a great
natural taste and further reduces metals such as lead
and copper. Unique flow control ensures the perfect
filtration time for best results.
For maximum filter performance and for optimum
taste, it is important to change your BRITA MAXTRA
Filter Cartridge regularly. BRITA recommends that you
replace the cartridge every 4 weeks.
Using the BRITA filtration system is optional. If you do
not wish to use the filtration system, simply remove
the BRITA Hopper (21) and MAXTRA Filter Cartridge (19)
from the Water Tank (7).
Filtering water through the BRITA Filtration System takes
roughly 4 minutes to filter 1.5L of water. You can use
the system while filtering, providing enough water has
filtered into the Water Tank.
Installing a BRITA MAXTRA Cartridge
1
Unwrap the BRITA MAXTRA Cartridge (19) and immerse
in water, gently shake to loosen any bubbles.
2
Push the BRITA MAXTRA Cartridge into place in the
BRITA Hopper.
3
Place the BRITA Hopper into the Water Tank.
Before returning the Water Tank to the Main Unit, fill
the BRITA Hopper with Cold Water and allow the
water to filter through the BRITA MAXTRA Cartridge.
Discard the filtered water. Repeat this step twice.
4
Fill the BRITA Hopper with fresh water and return the
Water Tank to the main unit. Your BRITA Cartridge is
ready for use with your Hot Water Dispenser.
BRITA Memo
The BRITA Memo (20) measures the recommended
time of use of your MAXTRA Filter Cartridge (19). The
BRITA Memo is located in the top of the BRITA Hopper
(21).
To reset the BRITA Memo, please press and hold down
the Start Button on the Memo until all four bars appear
in the display and flash twice. The Cartridge Active
Indicator Light in the bottom right corner of the BRITA
Memo indicates that it is working. After four weeks,
all four bars will disappear and a flashing arrow will
indicate that the cartridge should now be changed.
After changing the cartridge, reset the Memo.
Replacing the
BRITA Memo
The BRITA Memo (20) has a life of approximately 5
years. To remove the exhausted BRITA Memo, place a
screwdriver in the notch next to the BRITA Memo and
push it out. Please note that BRITA Memo should not be
removed for any other reason than to dispose of it.
More information on the use of BRITA filter cartridges
and the BRITA Memo can be found in the BRITA
information guide supplied with your hot water
dispenser.
Telephone our replacement parts helpline (0344 871
0945) for your new BRITA Memo. If you require
assistance on using your BRITA MAXTRA filter cartridge
or BRITA Memo, please call BRITA Customer Care team
on 0844 742 4800.
KT131004 MUK REV1.indd 9 18/02/2015 10:34

6
3Place the required vessel (cup, pan, pot etc.) under the Dispense Nozzles (6). One or two vessels can
be filled at the same time during each dispense
cycle, provided they are the same size.
4
Adjust the temperature of the water by pressing
the Temperature Button (4) to cycle through the
options (85,95 & 100oC). The water temperature
will be displayed on the screen (17).
1If required, follow steps of 1-6 of ‘Resetting the system’ (see page 4) to reset the system and then
discard the water. If the Hot Water Dispenser is in
standby mode, press any button to wake.
2
Pull out the Drip Tray (8) from the Main Unit (23)
(if needed).
Using the Hot
Water Dispenser
Before using your Hot Water Dispenser, or if
it has not been used for over a week, follow
these instructions to boil the maximum amount
of water, then discard to ensure the system is
flushed through.
The following instructions detail the steps to
follow to use your Hot Water Dispenser. For
Installation of the BRITA Filtration system see the
previous page.
Filtering water through the BRITA Maxtra
Cartridge takes around 4 minutes for 1.5L.
Ensure enough water has been filtered and is
ready for use in the water tank before heating.
KT131004 MUK REV1.indd 10 18/02/2015 10:34

5Turn the Water Volume Dial (2) to adjust the Dispense Volume (15). Your Hot Water Dispenser
can heat between 150ml to 1.5L of water per cycle. 6You can automatically dispense volumes of water
at 600ml and below. To turn this feature on or off,
press the Dispense Button (5). This function cannot
be selected for volumes over 600ml. These must
be dispensed manually.
9To pause the water flow whilst dispensing, press either the Start/Stop or the Dispense Button. 10
To resume the water flow, press the Dispense
Button again. It is recommended to dispense
any remaining water to enable your Hot Water
Dispenser to enter standby mode.
NOTE: You must dispense all water heated
before you can start the heating cycle again.
7Press the Start / Stop Button (1) to begin heating. Your Hot Water Dispenser will sound and the heat
cycle will begin. Once started, the volume and
temperature can only be changed during the first
few seconds of the heating cycle.
8Once ready your Hot Water Dispenser will sound. The hot water will be dispensed automatically. If
the manual dispense function has been selected,
press the Dispense Button (5) to begin dispensing.
KT131004 MUK REV1.indd 11 18/02/2015 10:34

8
Drinks Temperature
Getting the correct water temperature is essential if you
are to enjoy your favourite hot drinks with maximum
flavour and taste. E.g. If you’re a green tea drinker then
water that is brewed too hot will scorch the leaves
creating a bitter taste.
Press the Temperature Button (4) to cycle through the
options (85,95 & 100oC). The water temperature will be
displayed on the screen (17).
The guide (below) includes some of the most popular
drinks, to help you get the most from your Hot Water
Dispenser.
Your Hot Water Dispenser has been pre-programed
with 3 of the most popular temperatures for drinks; 85,
95 and 100 degrees.
By choosing the correct temperature for your drink, not
only will you create better tasting drinks, you will also
save time and energy too.
85oC
Green, white and herbal teas, powder based cold and
flu remedies, black instant coffee.
95oC
French press/cafetiere coffee, instant coffee with milk,
hot toddies, malted milk, hot chocolate.
100oC
Black teas e.g. darjeeling, assam, ceylon, english
breakfast and earl grey, noodle / pasta snacks, instant
soup type drinks.
Auto / Manual
Dispense
The auto dispense feature allows you to automatically
dispense volumes of water below 600ml. For safety
reasons it is not possible to automatically dispense
volumes above 600ml.
Before heating, press the Dispense Button (5) to switch
the auto dispense feature on or off. The Icon (14) will
appear on the LCD Screen (3) when the feature is
enabled. After heating, if the volume is above 600ml,
or if the auto dispense is turned off, your Hot Water
Dispenser will sound and the Dispense Button will
Illuminate. Press the Dispense Button to begin
dispensing water from the Dispense Nozzles (6).
NOTE: All water must be dispensed before you can
start the heating cycle again.
KT131004 MUK REV1.indd 12 18/02/2015 10:34
