Morphy Richards IB71053 User manual

IQ Cyclonic vacuum cleaner
Please read and keep these instructions
www.morphyrichards.com
getting the best from your
new cleaner...
If your cleaner is not picking up as well as it
should, please check
• Filters
It is important to clean the motor protection filter every time you
empty the dust container, otherwise the performance of the
cleaner will be impaired. See page 6 - Cleaning the filter. A spare
is provided.
• Blockages
Check the nozzle, tubes and hose for blockages.
•Allergy sufferers
See page 5 for allergy details.
71053 Rev 2 11/4/05 9:24 AM Page 1

Important safety
instructions
The use of any electrical appliance
requires the following common sense safety
rules.
Primarily there is danger of injury or
death and secondly the danger of damage
to the appliance. These are indicated in the
text by the following two conventions:
WARNING: Danger to the person!
IMPORTANT: Damage to the appliance!
In addition we offer the following safety
advice.
Location
•Do not use or keep this product outside
when it is raining.
•Do not store the appliance near hot
ovens or heating appliances.
Mains lead
•Do not allow the mains lead to become
strained or run this appliance over it.
•If the electrical cable becomes damaged
the complete cable assembly must be
replaced. Do not attempt this task
yourself, contact Morphy Richards using
the replacement parts number on the
front of this leaflet.
Children
•Children do not understand the dangers
associated with operating electrical
appliances. Never allow children to use
this appliance.
Personal safety
•WARNING: To protect against fire,
electric shock and personal injury
do not immerse cord, plug or
cleaner in water or other liquid.
•The plug must be removed from the wall
socket before cleaning or maintaining
the appliance.
•Never modify the cleaner in any way.
•Never use in the presence of explosive
liquids or vapours.
•Never pick up inflammable or poisonous
liquids such as petrol, copier toner or
other volatile substances. Never pick up
acids, asbestos or asbestos dust.
•Repairs to electrical appliances are only
to be undertaken by trained personnel.
Unprofessional repairs can be dangerous
for users.
•Use only genuine Morphy Richards spare
parts and accessories.
•The appliance must never be left running
when unsupervised.
•This vacuum cleaner is intended for
domestic use only. Misuse or use for
commercial or any other purpose will
render the guarantee invalid.
Product safety
•Never use the appliance without the
filters being installed.
•Never use the appliance to vacuum hot
ashes, broken glass, sharp objects or
liquids.
Electrical requirements
Check that the voltage on the rating
plate corresponds with your house
electricity supply which must be A.C.
(alternating current).
If the socket outlets in your home are
not suitable for the plug supplied with this
appliance the plug should be removed and
the appropriate one fitted.
If you cut off the plug and let go of the
cable it will rewind into the machine.
Therefore you must pull out a length of
cable and secure it before cutting off the
plug and refitting a new one.
WARNING: The plug removed from
the mains lead, if severed, must be
destroyed as a plug with a bared
flexible cord is hazardous if engaged
into a live socket outlet.
Should the fuse in the 13 amp plug
require changing a 13 amp BS1362 fuse
must be fitted.
2
71053 Rev 2 11/4/05 9:24 AM Page 2

Features
⁄Hose inlet
¤Cable rewind pedal
‹Carrying handle
›On/off power foot pedal
fiVariable power switch
flDust container release button
‡Pleated, washable motor protection filter
·Dust collection container
‚Tool storage drawer
„Parking slot
‰Exhaust filter cover
ÂAirflow regulator
⁄
¤‹
›
fi
fl
‡
‚
Ê
‰
Á
3
„
Â
Illustration
Accessories you should have
ÊHose handle
ÁFlexible hose
ËTelescopic tube (length adjustable)
ÈFilter cleaning brush
ÍCrevice tool
ÎUpholstery nozzle
ÏClip on brush (attaches to Î)
ÌFloor nozzle
ÓStair cleaning stretch hose (not shown)
ÔHard floor brush
Note: È,Í,Î and Ïare stored in the
tool storage drawer ‚.
 Dust release button with cover
Ë
È
A
·
Í
Î
Ï
ÌÔ

71053 Rev 2 11/4/05 9:24 AM Page 3

Quick start
1Assemble the nozzle, telescopic tube
and hose as shown A.
2Pull out the mains cable to it’s full length
and plug into the mains supply.
3Switch on by pressing the foot pedal ›.
Accessories
1Fit the hose to the cleaner by inserting
the hose end into the hose inlet ⁄.
When removing, squeeze the clips either
side and pull.
2Attach the telescopic tube to the handle
end of the hose. Extend to the required
length by pressing down the slider
release and pulling out the tube B.
The hose handle features an airflow
regulator Âwhich allows suction to be
reduced as required.
3Attach the wheeled floor nozzle Ìto the
tube.
4The floor nozzle can be adjusted to suit
different floor surfaces. Retract the
brushes for use on carpet. The brushes
must be down for use on hardfloors or
damage may occur.
The crevice tool Í(for awkward places,
behind radiators etc) and the upholstery
nozzle Îwith clip on brush Ï(for curtains
and upholstery) are stored in the tool
drawer ‚. The crevice tool is used for hard
surfaces, pelmets, delicate objects etc C.
Using the hard floor
brush
Designed specifically for use on wood,
tiles and all other hard floor types.
Attach to the telescopic tubes.
Stair cleaning hose Ó
An additional stretch hose is also
provided for use on stairs. Fit the hose to
the cleaner by inserting the hose end into
the hose inlet. When removing squeeze the
clips either side and pull.
WARNING: For safety, always leave
the cleaner at the bottom of the stairs
and clean upwards.
4
B C
Î
Í
Ï
71053 Rev 2 11/4/05 9:24 AM Page 4

5
Controls
Power
The on/off control is operated by the
foot pedal ›.
Variable power
A sliding switch fivaries the suction
power as required. For example, maximum
suction can be used for cleaning carpets,
hard floors etc. and reduced suction for
cleaning upholstery and curtains.
Suction can also be controlled using the
airflow regulator on the handle Â. Closed
for maximum suction, open for reduced
suction.
Automatic cable rewind
After use, unplug and press the cable
rewind button ¤to retract the cable.
WARNING: When using the cable
rewind, always hold the plug as the
cable will rewind quickly.
Dust disposal
To obtain the best results from your
cleaner empty the dust container regularly,
otherwise the airflow and cleaning power
will be reduced.
1Remove the dust container from the
product by pressing the dust container
release button fland pulling the dust
container away from the product. D
2Holding the dust container over a
dustbin slide the dust release cover 
forwards and press the dust release
button as shown E, the bottom of the
dust container will drop down to release
the dirt.
3Close the bottom of the dust container
by pressing the base upwards until it
clicks into place.
4Push the dust container back onto the
product to refit. The dust release cover
will slide back into place automatically.
Allergy sufferers
If the allergy sufferer is emptying the
product it is recommended that the
container is placed into a plastic bag to
empty.
1Place the container inside the plastic
bag, releasing the container with one
hand whilst holding the top of the bag
closed with the other, leave the dust to
settle for a few seconds before carefully
removing the empty container. The
plastic bag can then be sealed and
disposed of.
D E
71053 Rev 2 11/4/05 9:24 AM Page 5

6
Cleaning the motor
protection filter
1Remove the dust container from the
product by pressing the dust container
release button fland pulling the
container away from the product. After
emptying any dirt into the dustbin as
detailed in E.
2Remove the motor protection filter ‡
from the top of the dust container by
pushing the filter release switch to release
the filter and lift the filter out of the
container from the top F. The filter can be
gently knocked against the side of the
dustbin to remove excess dust. Use the
filter cleaning brush Èto remove dirt from
between the pleats.
3To re-fit the filter, drop the cartridge into
the hole in the top of the dust container.
Ensure the top of the filter is located
under the lug and push the filter release
switch to allow the filter to drop into
place. The filter release switch will then
automatically flick back when released to
lock the filter in place.
The filter should be regularly washed in
cold water and left to air dry before inserting
back into the machine.
IMPORTANT: Do not use detergents to
clean the filter. The filter must be thoroughly
dry before the machine is used.
A spare filter is provided.
IMPORTANT: The dust container will not
lock back onto the machine unless the filter
is fitted correctly
Cleaning the exhaust
filter
The exhaust filter ‰is located at the side
of the cleaner. To remove, push the catch
and pull the cover away. GTake out the
filter. Wash regularly in warm water, but do
not use detergent. Allow to dry naturally and
ensure it is totally dry before replacing it.
IMPORTANT
•All filters should be checked regularly for
signs of damage, preferably after each
cleaning task. The filters must be replaced
immediately if they become damaged.
•Always disconnect the cleaner from the
mains when checking filters.
•Always make sure all filters are fitted
before use. Failure to do so may result in
damage to your product.
GF
Filter
release
switch locating
lug
71053 Rev 2 11/4/05 9:24 AM Page 6

Storage position
When finished you can store the tubes
and accessories by locating the tube storage
clip into the slot on the side of the cleaner as
shown H.
Care and maintenance
Your cleaner is manufactured to withstand
normal day-to-day use, but an occasional
wipe over with a damp cloth will help
maintain its good looks. Abrasive cleaners
should not be used.
Purchasing filters
Use original Morphy Richards spares &
consumables. These can be purchased by
telephoning the Morphy Richards
replacement parts line.
Safety cut-out
If the cleaner overheats a motor
protection thermostat will automatically
switch the motor off. If this happens, switch
the cleaner off, unplug from the power
supply and leave the cleaner to cool for
at least 30 minutes. Check the airways for
blockages and clean the filters before
restarting.
Helpline
If you have any difficulty with your
appliance do not hesitate to call us. We are
likely to be more help than the store from
where it was bought.
Please have the following information
ready to enable our staff to help you.
•Name of product
•Model number as shown on the underside
of the appliance.
7
H
71053 Rev 2 11/4/05 9:24 AM Page 7

Your two year guarantee
It is important to retain the retailers
receipt as proof of purchase. Staple your
receipt to this back cover for future
reference.
Please quote the following information if
the product develops a fault. These numbers
can be found on the base of the product.
Model no. Serial no.
All Morphy richards products are
individually tested before leaving the factory.
In the unlikely event of any appliance proving
to be faulty within 28 days of purchase it
should be returned to the place of purchase
for it to be replaced.
If the fault develops after 28 days and
within 24 months of original purchase, you
should contact the Helpline number quoting
Model number and Serial number on the
product, or write to Morphy Richards at the
address shown. You will be asked to return
the product (in secure, adequate packaging)
to the address below along with a copy of
proof of purchase. Subject to the exclusions
set out below (1-5) the faulty appliance will
then be repaired or replaced and dispatched
usually within 7 working days of receipt.
If you suspect a fault, follow the simple
checks detailed below before returning the
appliance or calling the helpline.
•Check the filters for blockages.
•Check the tools / tubes for blockages.
•Check the plug is firmly in the socket and
the supply is switched on.
•Make sure the socket is working by trying
another appliance.
•Check the fuse in the plug.
If for any reason this item is replaced
during the 2 year guarantee period, the
guarantee on the new item will be calculated
from original purchase date. Therefore it is
vital to retain your original till receipt or
invoice to indicate the date of initial
purchase.
To qualify for the 2 year guarantee the
appliance must have been used according to
the manufacturers instructions. For example,
the filter must be cleaned regularly.
EXCLUSIONS
Morphy Richards shall not be liable to
replace or repair the goods under the terms
of the guarantee where:
1The fault has been caused or is
attributable to accidental use, misuse,
negligent use or used contrary to the
manufacturers recommendations or where
the fault has been caused by power
surges or damage caused in transit.
2The appliance has been used on a voltage
supply other than that stamped on the
products.
3Repairs have been attempted by persons
other than our service staff (or authorised
dealer).
4Where the appliance has been used for
hire purposes or non domestic use.
5The guarantee excludes consumables
such as filters.
This guarantee does not confer any rights
other than those expressly set out above and
does not cover any claims for consequential
loss or damage. This guarantee is offered as
an additional benefit and does not affect your
statutory rights as a consumer.
•This guarantee is valid in the UK and
Ireland only.
Morphy Richards products are intended for
household use only.
Morphy Richards has a policy of continuous
improvement in product quality and design.
The company, therefore reserves the right
to change the specification of its models at
any time.
The After Sales Division
Morphy Richards Ltd, Mexborough
South Yorkshire, England, S64 8AJ
Helpline (office hours)
UK 0870 060 2604
Republic of Ireland 1800 409119
VC71053M UK Rev 2 04/05
71053 Rev 2 11/4/05 9:24 AM Page 8
