Morphy Richards POD CYCLONE VACUUM CLEANER - REV 1 User manual

POD Cyclone vacuum cleaner
Please read and keep these instructions
www.morphyrichards.co.uk
getting the best from your
new cleaner...
If your cleaner is not picking up as well as it
should, please check
•Filters
It is important to clean the dust compartment filter every time you
empty the dust container, otherwise the performance of the
cleaner will be impaired. See page 6 - Cleaning the filter. A spare
filter is provided.
• Blockages
Check the nozzle, tubes and hose for blockages.
POD CYCLONE VC73115M REV 1 16/12/03 1:21 pm Page 1

Important safety
instructions
The use of any electrical appliance
requires the following common sense safety
rules.
Primarily there is danger of injury or
death and secondly the danger of damage
to the appliance. These are indicated in the
text by the following two conventions:
WARNING: Danger to the person!
IMPORTANT: Damage to the appliance! In
addition we offer the following safety advice.
Location
•Do not use or keep this product outside
when it is raining.
•Do not store the appliance near hot
ovens or heating appliances.
Mains lead
•Do not allow the mains lead to become
strained or run this appliance over it.
•If the electrical cable becomes damaged
the complete cable assembly must be
replaced. Do not attempt this task
yourself, contact Morphy Richards using
the replacement parts number on the
front of this leaflet.
Children
•Children do not understand the dangers
associated with operating electrical
appliances. Never allow children to use
this appliance.
Personal safety
•The plug must be removed from the wall
socket before cleaning or maintaining
the appliance.
•Never modify the cleaner in any way.
•Never use in the presence of explosive
liquids or vapours.
•Never pick up inflammable or poisonous
liquids such as petrol, copier toner or
other volatile substances. Never pick up
acids, asbestos or asbestos dust.
•Repairs to electrical appliances are only
to be undertaken by trained personnel.
Unprofessional repairs can be
dangerous for users.
•Use only genuine Morphy Richards
spare parts and accessories.
•The appliance must never be left running
when unsupervised.
•This vacuum cleaner is intended for
domestic use only. Misuse or use for
commercial or any other purpose will
render the guarantee invalid.
Product safety
•Never use the appliance without the
filters being installed.
•Never use the appliance to vacuum hot
ashes, broken glass, sharp objects or
liquids.
•To protect against fire, electric shock and
personal injury do not immerse cord,
plug or cleaner in water or other liquid.
Electrical requirements
Check that the voltage on the rating
plate corresponds with your house
electricity supply which must be A.C.
(alternating current).
If the socket outlets in your home are not
suitable for the plug supplied with this
appliance the plug should be removed and
the appropriate one fitted.
If you cut off the plug and let go of the
cable it will rewind into the machine.
Therefore you must pull out a length of
cable and secure it before cutting off the
plug and refitting a new one.
IMPORTANT: The plug removed from
the mains lead, if severed, must be
destroyed as a plug with a bared flexible
cord is hazardous if engaged into a live
socket outlet.
Should the fuse in the 13 amp plug
require changing a 13 amp BS1362 fuse
must be fitted.
2
POD CYCLONE VC73115M REV 1 16/12/03 1:21 pm Page 2

Features
⁄ Hose inlet
¤ Cable rewind & carrying handle
(press handle down to rewind)
‹ On/off power foot pedal
›Lid release catches
fi Dust compartment filter (see page 6)
fl Dust collection container
‡ Tool storage hook
· Parking slot
‚ Exhaust filter cover
„ Airflow regulator
‰ Tube parking slot
⁄
¤
‹
›fl
‡
‚
Á
Â
‰
3
„
Ê
Illustration
Accessories you should have
 Hose handle
Ê Flexible hose
Á Extension tubes
Ë Crevice tool and brush
È Wheeled combination floor nozzle
Ë
A
·
È
fi
POD CYCLONE VC73115M REV 1 16/12/03 1:21 pm Page 3

Quick start
1Assemble the nozzle, extension tubes
and hose as shown A.
2Pull out the mains cable to it’s full length
and plug into the mains supply.
3Switch on by pressing the foot pedal ‹.
Accessories
1Fit the hose to the cleaner by inserting
the hose end into the hose inlet ⁄.
When removing, press the button on the
top and pull.
2Attach the tubes to the handle end of the
hose.
The hose handle features an airflow
regulator „which allows suction to be
reduced as required.
3Attach the wheeled floor nozzle Èto the
tubes. The nozzle features an adjustment
pedal, that can be adjusted to suit the
floor surface. B
•Brushes down
for hard floors.
• Brushes
retracted for
carpets and
rugs.
The crevice tool with brush Ë is ideal for
use in awkward places and for curtains and
upholstery.
Controls
Power
The on/off control is operated by the foot
pedal ‹.
Suction control
Suction can be controlled using the
airflow regulator on the handle „ closed
for maximum suction, open for reduced
suction.
Automatic cable rewind
After use, unplug and press the carry
handle fully down ¤ to retract the cable.
WARNING: When using the cable
rewind, always hold the plug as the cable
will rewind quickly.
4
B
POD CYCLONE VC73115M REV 1 16/12/03 1:21 pm Page 4

5
Dust disposal
To obtain the best results from your
cleaner empty the dust container regularly,
otherwise the airflow and cleaning power
will be reduced.
1Remove the dust container from the
product by pressing the lid release
catches ›and lifting up the lid. C
2Press the dust container release catch
and lift the dust container away from the
product. D
3Remove the dust container lid and empty
the dirt into the dustbin. E
4Replace the lid onto the dust container.
F
5Re-insert the dust container into the
product and close the lid to re-fit the
product. G
C
D
E
F
G
POD CYCLONE VC73115M REV 1 16/12/03 1:21 pm Page 5

6
Cleaning the dust
compartment filter
•It is important that filters are cleaned
regularly to maintain performance.
1Remove the dust container from the
product as detailed in the previous
section.
2With the dust container lid removed E
twist the filter clockwise to remove from
the lid. H
3Slide the mesh filter from the pleated
filter. I
4The filter can be gently knocked against
the side of the dustbin to remove excess
dust.
•Use the crevice tool/brush to remove dirt
from between the the pleats.
5To re-fit the filter, slide the mesh cover
back over the pleated filter and screw
the filter onto the lid anti-clockwise.J
The filter should be regularly washed
in cold water and left to air dry before
inserting back into the machine.
IMPORTANT: Do not use detergents to
clean the filter. The filter must be thoroughly
dry before the machine is used.
A spare filter is provided.
IMPORTANT: The dust container will not
lock back onto the machine unless the filter
is fitted correctly.
Cleaning the exhaust
filter
The exhaust filter ‚is located at the
back of the cleaner. To remove, push the
catch and pull the cover away. KTake out
the filter. Wash regularly in warm water, but
do not use detergent. Allow to dry naturally
and ensure it is totally dry before
replacing it.
H
I
J
K
POD CYCLONE VC73115M REV 1 16/12/03 1:21 pm Page 6

IMPORTANT
•All filters should be checked regularly for
signs of damage, preferably after each
cleaning task. The filters must be replaced
immediately if they become damaged.
•Always disconnect the cleaner from the
mains when checking filters.
•Always make sure all filters are fitted
before use. Failure to do so may result in
damage to your product.
Storage position
•During use the tubes and nozzle can be
stored in the park position Lfor short
breaks whilst cleaning.
•For storage after use the tubes can be
stored using the tube storage slot on the
base of the product. M.
Care and maintenance
Your cleaner is manufactured to withstand
normal day-to-day use, but an occasional
wipe over with a damp cloth will help
maintain its good looks. Abrasive cleaners
should not be used.
Purchasing filters
Use original Morphy Richards spares &
consumables. These can be purchased by
telephoning the Morphy Richards
replacement parts line.
Helpline
If you have any difficulty with your
appliance do not hesitate to call us. We are
likely to be more help than the store from
where it was bought.
Please have the following information
ready to enable our staff to help you.
•Name of product
•Model number as shown on the underside
of the appliance.
7
L
M
POD CYCLONE VC73115M REV 1 16/12/03 1:21 pm Page 7

Your two year guarantee
It is important to retain the retailers
receipt as proof of purchase. Staple your
receipt to this back cover for future reference.
Please quote the following information if the
product develops a fault. These numbers can
be found on the base of the product.
Model no. Serial no.
All Morphy richards products are individually
tested before leaving the factory. In the unlikely
event of any appliance proving to be faulty
within 28 days of purchase it should be returned
to the place of purchase for it to be replaced.
If the fault develops after 28 days and within
24 months of original purchase, you should
contact the Helpline number quoting Model
number and Serial number on the product, or
write to Morphy richards at the address shown.
You will be asked to return the product (in
secure, adequate packaging) to the address
below along with a copy of proof of purchase.
Subject to the exclusions set out below (1-5) the
faulty appliance will then be repaired or
replaced and dispatched usually within 7
working days of receipt.
If you suspect a fault, follow the simple
checks detailed below before returning the
appliance or calling the helpline.
•Check the filters for blockages.
•Check the tools / tubes for blockages.
•Check the plug is firmly in the socket and the
supply is switched on.
•Make sure the socket is working by trying
another appliance.
•Check the fuse in the plug.
If for any reason this item is replaced during
the 2 year guarantee period, the guarantee on
the new item will be calculated from original
purchase date. Therefore it is vital to retain your
original till receipt or invoice to indicate the date
of initial purchase.
To qualify for the 2 year guarantee the
appliance must have been used according to
the manufacturers instructions. For example, the
filter must be cleaned regularly.
EXCLUSIONS
Morphy richards shall not be liable to replace
or repair the goods under the terms of the
guarantee where:
1The fault has been caused or is attributable
to accidental use, misuse, negligent use or
used contrary to the manufacturers
recommendations or where the fault has
been caused by power surges or damage
caused in transit.
2The appliance has been used on a voltage
supply other than that stamped on the
products.
3Repairs have been attempted by persons
other than our service staff (or authorised
dealer).
4Where the appliance has been used for hire
purposes or non domestic use.
5The guarantee excludes consumables such
as filters.
This guarantee does not confer any rights
other than those expressly set out above and
does not cover any claims for consequential
loss or damage. This guarantee is offered as an
additional benefit and does not affect your
statutory rights as a consumer.
•This guarantee is valid in the UK and Ireland
only.
Morphy richards products are intended for
household use only.
Morphy richards has a policy of continuous
improvement in product quality and design.
The company, therefore reserves the right
to change the specification of its models at
any time.
The After Sales Division
Registered address
Morphy richards Ltd, Mexborough
South Yorkshire, England, S64 8AJ
Helpline (office hours)
UK 0870 060 2604
Republic of Ireland 1800 409119
VC73115M Rev 1
POD CYCLONE VC73115M REV 1 16/12/03 1:21 pm Page 8
