Morphy Richards 73106 User manual

www.morphyrichards.co.uk
www.morphyrichardsindia.com
Please read and keep these instructions
Getting the best from your
new cleaner...
Vacuum cleaner -
73106

lNever use in the presence of explosive
Important safety liquids or vapours.
instructions lNever pick up inflammable or poisonous
liquids such as petrol, copier toner, or
The use of any electrical appliance requires
other volatile substances. Never pick up
the following common sense safety rules.
acids, asbestos or asbestos dust.
Primarily there is danger of injury or death and
lAlways disconnect the appliance from the
secondly the danger of damage to the
mains supply after use or prior to cleaning
appliance. These are indicated in the text by
or replacing filters.
the following two conventions:
lThe appliance should never be left running
WARNING: Danger to the person!
unsupervised.
IMPORTANT: Damage to the appliance! In
lNever modify the cleaner in any way.
addition we offer the following safety advice.
lRepairs to electrical appliances are only to
Location be undertaken by trained personnel
lDo not use or keep this product outside unprofessional repairs can be dangerous
when it is raining. for users.
lDo not store the appliance near hot ovens lUse only genuine Morphy Richards spare
or heating appliances. parts and accessories
Main lead Electrical requirements
lDo not allow the mains lead to become
strained or run this appliance over it. Check that the voltage on the rating plate of
lIf the electrical cable becomes damaged your charger unit corresponds with your
house electricity supply which must be A.C.
the complete cable assembly must be
replaced. Do not attempt this task yourself, (alternating current).
contact Morphy Richards Service Centre. For appliances with fitted plug
If the socket outlets in your home are not
lChildren suitable for the plug supplied with this
appliance the plug should be removed and
lChildren do not understand the dangers the appropriate one fitted.
associated with operating electrical Warning: The plug removed from the
appliances. Never allow children to use this mains lead, if severed, must be destroyed
appliance. as a plug with a bared flexible cord is
hazardous if engaged into a live socket
Other safety considerations outlet.
lNever use the appliance without the filters
installed.
lNever use appliance to vacuum hot ashes,
broken glass, sharp objects or liquids.
2

On/off power switch Air bed inflater nozzle
Hooks for carrying strap Medium nozzle
Hose inlet Large nozzle
Dust compartment (opens from beneath) Hose handle with air bleed
Exhaust filter cover with blower function Extension tubes x3
Dust compartment release button Floor nozzle
Carry handle Turbo nozzle (pets model only)
Hose Accessory bag
Hepa filter
Accesories
Mesh filter cover
Hose adaptor Long brush nozzle
Crevice nozzle (fits directly onto vacuum) Pre-motor filter (Not featured on this page,
Carry strap see page 7)
Brush nozzle (fits directly onto vacuum) Exhaust filter (Not featured on this page,
Blower adapter see page 7)
Features:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
3

Quick start
1 Assemble the desired accessories as
shown on page 5.
2 Unwind the cable to it’s full length and plug
in to the mains supply.
3 Switch on by pressing the on/off power
switch.
Accessories
1 Fit the hose to the cleaner by first inserting
the hose adapter to the hose inlet. Carry strap
Attach the hose to the hose adapter. A
Your vacuum cleaner comes with a carry strap
for added convienience.
The carry strap can be clipped on the two
hooks one at rear of the handle and the
other in front of the on/off switch.
Floor Nozzle
The floor nozzle adjusts to suit either carpet
or hard floor.D
2 The brush nozzle and crevice nozzle Press down on the symbol for hard floors or
can be fitted directly into the hose inlet. press down on the symbol to retract the
without the need for hose adapter. Bbrushes for use on the carpet.
Turbo Nozzle (pets models only)
The turbo nozzle is ideal for use on carpets or
upholstery to remove stubborn pet hair.
Attach to the turbo nozzle directly to the hose
To store the brush nozzle and crevice handle to remove stuborn pet hairs from
nozzle, insert brush nozzle vertically into upholstery or small areas of carpet. (Turbo
clip then slide crevice nozzle horizontaly nozzle is designed for small areas only for
until it clips into place. Cexample pet beds and chairs)
3 All the other accessories attach to the
hose. The extension tubes can be WARNING Do not attach the turbo nozzle
attached to the hose using the hose handle to the extension tubes.
for floor cleaning or extra reach.
4
9 3
12 10
18
11
2
19
20
17

Cleaning turbo nozzle
(pets models only)
If the turbo nozzles rotating brush becomes
entangled with hair it may require taking apart
and cleaning
1 Unclip the top half of the nozzle by pulling
the upper casing out slightly & lifting off. E4 Ensuring that the brush bar, the turbo
wheel and the belt are correctly located
and positioned, take the top casing and
position the slots over the teeth at the front
of the lower casing and clip back into
position.
After re-assembly fit turbo nozzle on unit and
ensure the brush bar is rotating correctly.
Assembling the product
Clear out any blockages /pet hair, remove Assembling Assembly
all components.and clean if necessary.
Vacuum
2 The main turbo wheel has a removable
collar, this must be re-assembled correctly,
other wise the nozzle will not go back
together.
3 To re-assemble nozzle, take the brush bar
with the toothed belt positioned over the
track on the bar (notice the rectangular
locators on either side of the brush bar). F
Note Make sure the correct end is fixed to the
blower adapter, (smooth end).
Nozzle
Slot the brush bar into the When using the brush nozzle to get extra
relevant tracks on either suction place your finger over the hole. This is
side of the lower casing. only for vacuuming. H
Ensuring that the turbo
wheel is correctly placed, loop the toothed
wheel through the belt and lower the turbo
wheel into the grove, provided in the lower
casing. The internal assembly should be
complete.
24
5

Leave to air dry thoroughly before
Dust disposal replacing into the cleaner.
To obtain the best results from your cleaner DO NOT USE DETERGENTS
be sure to check and empty the dust
3 Replace the pleated
compartment regularly, otherwise the airflow
filter into the mesh
and cleaning power will be reduced and you
filter cover
may damage your cleaner.
Making sure the yellow
1 Ensure the cleaner is switched off and
tab on the Hepa Filter
disconnected from the mains supply.
moulding is adjacent to
2 Hold over a dustbin and press in the dust
the clip on the mesh
compartment release button , the dust
filter cover Land
compartment door will automatically drop
replace back into the
down. Shake the vacuum to release the dirt
cleaner. Ensure the
and make sure it is completely empty. I
hepa filter is securely fitted back into place.
Blocked filters will reduce the airflow to the
Hepa Filter cleaning
motor, should the airflow become
Warning: The dust compartment must be substantially blocked, the product will then be
emptied BEFORE the Hepa filter is liable to overheat and the thermal fuse will
removed. Every time you empty the activate. Should this activate, the product will
cleaner the Hepa filter must be cleaned. stop functining, unplug the product and allow
it to cool down (ths can take between 30-40
1 Once the dust compartment is empty, minutes depending on the ambient
remove the pleated hepa filter & mesh temperature conditions).
filter by pushing the tab to release. J
2 Pull the pleated hepa filter out of the Inserting Hepa Filter M
mesh filter cover & clean both by gently Warning: Make sure that the Hepa filter has
brushing over the dustbin. Wash the filters been placed in correctly.
regularly in warm water. K
DO NOT USE THE PRODUCT WITHOUT
THE HEPA FILTER FITTED.
IMPORTANT
• All filters should be checked regularly for
signs of damage, preferably after each
cleaning task. The filters must be replaced
immediately if they become
6
22
23
22
23
6

•
Technical Data
Power Supply : AC 230V 50Hz
Wattage : 800W
Always disconnect the cleaner from the Using the blower function
mains when checking or replacing the
filters. 1 Remove the exhaust filter cover and
foam exhaust filter
• Always make sure the filters are fitted
correctly before use. Failure to do so may 2 Push and twist clockwise Pthe blower
result in damage to your product. connector into the back of the cleaner
to lock into place.
Pre Motor Filter 3 Attach the hose to the correct end of the
blower connector .
The pre-motor filter can be found by 4 The blower function can be used for a
opening the dust compartment using the variety of uses including blowing dust from
dust compartment release button delicate surfaces and also drying pet fur.
Remove pleated hepa filter and mesh filter. If using to dry pet fur:
Remove the pre-motor foam filter from its • Never use the product in a wet
securing tabs and clean or replace. environment.
Replace the foam filter over the small tabs • Do not use if the animal is frightened
making sure it’s located correctly. Nor distressed.
• Never leave the product alone with the
Exhaust Filter Oanimal. Never allow the animal to chew
the product.
The exhaust-filter must be cleaned
regularly to remove the fine dust particles
collected. This can be done by shaking it.
The exhaust filter is located behind the
exhaust filter covers . To remove, push
down on the tab and remove the cover. Pull
out the foam filter & clean or replace.
25
4
6
22 23
25
25
26
5
26
5
26
13
8
13
7

Morphy Richards products are intended
for household use only
Morphy Richards has a policy of
continuous improvement in product quality
and design. The Company, therefore,
reserves the right to change the
specification of its models at any time.
Products & parts are indicative only, the
actual product may differ.
Morphy Richards Ltd, Mexborough,
South Yorkshire, England, S64 8AJ
