Morris MDE-2016 User manual

MDE-2016
MDE-2417
DEHUMIDIFIER
T o prevent damage and voiding your ZDUUDQW\3OHDVHSODFHWKH XQLWLQLWV
ULJKWSRVLWLRQIRUDPLQLPXPRIWZRKRXUVEHIRUHRSHUDWLQJ
)RUEHVWUHVXOWIURP
\RXUSRUWDEOHGHKXPLGLᚏHUSOHDVHUHDGWKLV
LQVWUXFWLRQPDQXDOFDUHIXOO\DQG
VDYHLWIRUIXWXUHUHIHUHQFH
IMPORTANT NOTICE
01
Operationmanual


DIRECTORY










IMPORTANT SAFEGUARDS
SPECIFICATIONS
GENERAL DESCRIPTION
CONTROL PANEL
CONTROL PANEL
EMPT<ING THE WATER TANK
CONTINUOUS DRAINAGE OPERATION
REPLACEMENT AND MAI1TENANCE OF AIR FILTER
OTHER NOTICE
CARE AND CLEANING
FAULT CODE
TROUBLE SHOOTING 
02

Operationmanual
03
IMPORTANT SAFEGUARDS
Whenusingelectricalappliances, basicsafety precautionsshould alwaysbe followed
includingthe following:
※If the machine`s power supply cord is damaged, you must entrust the
manufacturers of the machine. Maintenance service center or qualified
technicians will change for you, in case of any danger.
Leavethe applianceto standfor atleast twohours beforepower on,especially after
transportation.
Makesurethatthe voltagematchingwiththerelevantdataindicatedontheratinglabel.
Thesocketmust be with grounding.
Keeptheappliance dry. Make sure nowateronthetoporthebody.
Donotunpin the plug when theapplianceisworking.
Ifmovingneeded, please switch it off andunpintheplug.
Allowafree space of 20 cmaroundairinletoftheappliance.
Donotinsert any object into theairinletoroutletopenings.
Donotplacethedehumidifiernearaheatingsource(esp.aradiator)orindirectsunlight.
Ensurethattheappliance does not becomehot.
Emptythewater tankregularly.(Inextremeconditionsthewater tankmaybefullafter
afewhoursoperation.)
Cleantheairinletfilterifitbecomescontaminated:theapplianceismosteffectivewhen
thefilterisclean.
Pleasedonotexpecttheairdehumidifiertobeeffectivewhentoomanydoorsorwindows
areopenedorwhen something in theroomisproducingalotofhumidity.
Theairdehumidifier will come into effect immediately. However, the reduction of
humiditymanyhardlybe measureable during thefirstfewdays.
Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,itsservuceagent
orsimilarlyqualifiedpersons in order toavoidahazard.
a)Thisappliancecanbe usedbychildrenagedfrom8 yearsandaboveandpersonswith
reducedphysical,sensoryormentalcapabilitiesorlackofexperienceandkonwledgeif
theyhavebeeengivensupervisionorinstructionconcerninguseoftheapplianceinasafe
wayandunderstandthe hazards involved.
b)Childrenshallnot play with theappliance.
c)Cleaninganduser maintenance shall notbemadebychildrenwithoutsupervision.

SPECIFICATIONS
d)The refrigerantin thisunit witha fluorinatedgreenhouse gascovered bythe Kyoto
Protocol, whichdangerous forthe environmentand forthe globalwarming ifitisenters
intoatmosphere.
e)Chemicalnameofrefrigerant(R-134a)isafluorinatedgreenhousegascovered by the
KyotoProtocol,Itsglobal warming potential(GWP) isthe1430.
04
ModelNo.:
DehumidifyCapacity:
RatedVoltage:
RatedFrequency:
InputPower:
WaterTankCapacity:
AirflowVolume:
NoiseLevel:
RefrigerantCharge:
NetWeight:
SuctionPressure:
DischargePressure:
MDE-2016
20L/day(30℃RH80%)
9.5L/day(26.7℃RH60%)
AC220-240V
50Hz
370W
240W
4L
120m³/h
39dB(A)
R134a/160g
14.3kgs
0.5MPa
1.5MPa
MDE2417
24L/day(30℃RH80%)
12L/day(26.7℃RH60%)
AC220-240V
50Hz
375W
320W
4L
130m³/h
42dB(A)
R134a/180g
14.3kgs
GrossWeight: 15.3kgs 15.3kgs
0.5MPa
1.5MPa
ȫȹȶȲȾȳȺȶȿɅɅȶȾɁȶɃȲɅɆɃȶɀɁȶɃȲɅȺȿȸɃȲȿȸȶȺɄȳȶɅɈȶȶȿ℃Ȳȿȵ℃ɈȺɅȹȲɃȶȽȲɅȺɇȶ
ȹɆȾȺȵȺɅɊɃȲȿȸȺȿȸȷɃɀȾɅɀȝɀɃȾȲɉȺȾɆȾȶȷȷȺȴȺȶȿȴɊɆɄȶɅȹȶɆȿȺɅȳȶɅɈȶȶȿ℃
Ȳȿȵ℃.

Operationmanual
05
GENRERAL DESCRIPTION
9. Filter
12.Powercord
11.Backcover
10.Continuousdrainport
8.Watertank
7.Airinlet
6.Handle
5. Wheel
4. Lamp
3. Airoutlet 2.Controlpanel
1.Oscillationlouver

CONTROL PANEL
06
Select the functions of the unitfor:
AUTO/HIGH /LOW/and FAN. The appliance
willgo.
AUTOfunction thefirsttime itisswitchedonand
remainsinthismodeuntilothertypeofprogramming
ischosen.
Depending on your relative humidity conditions,
turnthe fanspeedswitch tohighorlow.
MODE
MODE Control
FAN(VentilationKey):press"MODE"
key to select "FAN", and "FAN" indicator light
comeson.
FAN (Ventilation Key)
MODE
Startsor Stopsappliance.
P0WER
POWER
Startthe appliance,thelamp willturn
onautomatically.
Thelampcolorwillchangeaccordingtothehumidity
condition(with100secondsasintervalbetweencolor
changing)
Redcolor meanshighhumidity, RH≥80%
Greencolor meanscomfortable,
80%>RH≥60%
Orangecolor meansdry,RH<60%
Press”LAMP” key,thelamp willbeofforon.
LAMP
LAMP
Waterfullindicator
Operationindicator
Timer Ion
UP
key
DOWN
key
UV
Lamp
Oscillation
Defrostindicator
Power
Mode

CONTROL PANEL
Operationmanual
07
TIMER
Theappliancewilldefrostautomatically
asprogrammedoncethecoilsensordetectstemperatue
belowsomefigure,and thedefrostingindicatorwill
lightup atthesame time.Oncedefrostingfinishes,
theappliancewillrecovertopreviousrunningmode.
DEFROST
Ifthe watertankis full,theindicator
lightcomes onandflash.
TANK-FULL
PressUP/DOWNkeytoselect
thedesired relativehumiditylevel, defaultrelative
humidityis55%.Relativehumidity35%isselected,
thecompressorwill not stopuntil water tankfull.
UV(Sterilizationfunction): To select"UV", press
the"UV" keyandthe lightwillcomeon.
FAN(VentilationKey):press"MODE"keytoselect
"FAN",and "FAN"indicatorlight comeson.
HUMIDITY SETTING
press timer to program time and
"TIMER"lightcomesonwhiletimerisprogrammed.
Befpreprogrammingmakesurethatthetimerfunction
hasnot beenactived(the lightmustbeoff)!
Thefollowing timerprogramsare available.
a) Delayed power-on function (the appliance is in
stand-bystatus)
USEkey "UP"and"DOWN" tosetthetimeperiod
(0～24hours)
The appliance will start once time reaches setting
value.
b)Delayed power-offfunction(the appliancesisin
workingstantus)
Theappliancewillstoponcetimereachsettingvalue.
TIMER (timer function)
CONTROL PANEL
Thearethreedifferentdirections,45/90
degreeanduniversal, thelouverswillmove orfixed
asselected position.
OSC. (oscillating function)
Caebon filter(deodor function)
Takeoutthecarbonfilterfrombagandinsertitonthe
filter.Seepicturebelow.
Suggesttochangethecarbonfilterevery3months,it
alwayskeeptheroomfresh.
To select "UV", press the "UV" key
andthe lightwillcome on.
UV (Sterilization function)
UV
Toselect"Ion", pressthe "ION"key
and the light will come on. Anion can refresh air,
it'sso calledairvitamin.
ION.(ionization function)
ION
OSC

EMPTYING THE WATER TANK
CONTINUOUS DRAINAGE OPERATION
08
Emptythe watertank regularlywhenfull,theairdehumidifier
turnsoff automaticallyand thetankfullindicatoristurnedon.
Openthe frontcover ofyourdevice
Holdthe watertank byitshandle
Pullit outcarefully
Emptythe watertank
Return theempty water tankto itspositionafterwiping
itoff fromany waterresidue.
Yourdevice has adrainage portthat allowsyouto havecontinuous drainage.Connecta 10mmdiameter
PVCpipe (optional-not providedin thepackage) withthe drainageportlocated onback partof theunit,
forcontinuousdrainage purpose,asbelow figure.Ensuringthehoseis directeddownwards,allowing water
to flow by gravity to an external drain. Ensure that the end of the hose is lower than the drain opening,
otherwisethe waterwill notdrainandfloodingmayoccur.
REPLACEMENT AND MAINTENANCE
OF AIR FILTER
Whenused regularly, thefilter maybecome cloggedwithdust
andparticles. Therefore thefilter shouldbe cleanedeveryone
ortwo weeks. Followthese steps:
1. Removethe filter bypulling itout carefully.
2.Clean the filter with a vacuumcleaner orwith water.Tap
thefilter toremoveexcesswaterandletitdrycompletely.Once
youmakesurethatyour filteriscompletely dry,re-installit on
yourdevice.Donotwashyourfilterinthedishwasherandnever
usehair dryers or

OTHER NOTICE
Operationmanual
09
1. The machine uses the temperature range of 5 C ~32 C, please use the machine in this scope,
(otherwise it will start the protection action, causing the machine automatically stop running.)
2. At room temperature at 5 C and the absolute temperature of the environment is very low. It is
not necessary to use the machine.
3. When the machine is running, it will produce a small portion of the heat, the room temperature
will be a little higher, this is a normal phenomenon, please feel at ease.
4. automatically stop running, please send the water in the water drained, and put back to the water
tank, the machine will continue to operate.
5. In order to ensure the normal operation, do not open the water tank float cover, or place any
foreign body in the water tank.
6. When the machine can not start or unknown cause, please check with the following steps:
(1) check whether the plug or the power cord is normal.
(2) Above all is normally, just please re-start the machine after 10 minute.
(3) If you are still unable to start, please contact the local dealer or the company's customer
service department.
7. Air inlet and outlet and the distance between the adjacent material to keep 15 cm above.
8. After the machine is stopped, please restart in five minutes to make sure that the machine is used
for longer service life.
9. if the long time does not use the desiccant, please unplug the power plug.
10. the machine inlet frosting, automatically defrost.

10
CARE AND CLEANING
Do not put the body in the soft,
unevenground,in ordertoavoid
vibration or sound
Do not use any fine rod, hard
object into thebody,so as to
avoid failure or danger.
Clean the body,gently wipe with a
damp cloth,do not splash water, to
avoiddamagetoelectricalinsulation
Do not put heavy or water body
above the vase, items。Please stay away from the fuselage. The heat source side
heaters to avoid danger and
waste electricity
Pleaseclosethedoorsandwindows
when usedtoachievetheeffectof
thedesiccant

Operationmanual
11
Please clean filter once every two
weeks(nottouse40degreesabove
the hot water or alcohol, gasoline,
toluene and other dangerous
flammableliquid).
After filtering the net, please do
not dry in the sun, so asnot to
deformation.
Aroundthe bodyorout oftheair
outletdo notputitems, toensure
thatthe effectofthe desiccantair.
Power failure or long-term no
use, please unplug the power
cable plug, so as to avoid
leakage, and fire.
Beforeyour movingthemachine ,
pour out the water within the
watertank
Whennotinuse,pleaseputinthe
positionofventilation,andunplug
thepowerplugtoavoiddanger.

FAULT CODE
12
FaultcodeCode
Roomtemperature (ambienttemperature)sensor forshortcircuit
Roomtemperature sensoropencircuit
ȟɆȾȺȵȺɅɊ sensorshort circuit
ȟɆȾȺȵȺɅɊ sensorɀɁȶȿ circuit
Coilertemperature sensorshortcircuit
Coilertemperature sensoropencircuit
E1
E2
E3
E4
E5
E6

TROUBLE SHOOTING
Whenthe followingproblemsoccur, pleasecontactthelocalsellers andcustomerservice:
1.When thefusebreaker andfusejumpoffor fused.
2.When waterandother dirtygetintothemachine.
3.When thepowerline orplugisabnormallyhot.
Whenyou needtocall thecustomerservices
AnythingWrong?
……,Please checkyourmachine withthefollowingsteps
(onlythe servicepersoncan openthesidedoor)
ISSUES
Theoperation switchis“ON”,
butthe machineisnot operation.
1.Is thewatertank placedintherightposition?
2.Is thepowerplug insertedrightposition?
3.Is thefusebroken?
4.Is thepoweroff?
Thedehumidification amount
istoo low.
Longtime operationcannot
reachthe suitablehumidity
condition.
1.Does thedooror windowtoowidelyopen?
2.Is thereanygenerated waterevaporator?
3.Is theinteriorspace toobig?
Whenthe machineismaking
hugenoise.
Thelamp iscontinuouslyon.
Pleasecheck asfollowing
1.Is thefrontfilter netdirty?
2.Is theinteriortemperature andthehumiditytoolow?
3.Is theairoutlet andairinlet jammed?
1.Is thefloorflat andhard?
2.Is thedehumidifierin therightposition?
1.Is thetemperatureor humidifysensoris
damagedor loosen?
Wasteelectricalproductsshould notbedisposedofwith householdwaster. Pleaserecyclewherefacilities
exist.Checkwithyour LocalAuthorityorretailerfor recycling.
Operationmanual
13
