Motech CBP2 User manual

User Guide
Control Box Model: CBP2
MOTORIZE OUR WORLD
R
A. Installation
1. Control Box
Step 1. Put two mounting bolts (M5 with 8mm head) onto the frame according to the drawing.
Step 2. Turn the locker to “Unlock Position” (CCW) , then mount Control Box onto the bolts of the frame.
Step 3. Turn the locker clockwise to “Locked Position” to fix the Control Box.
Step1 : Step2 : Step3 :
Locked Position
Unlocked Position
2. Battery Pack
2.1 Insert:
2.1.1 Hold the battery pack downward (Fig. 1)
2.1.2 Tilt the pack a little bit to get a smooth installation and keep pressing the release button
(Fig. 2 / ).
2.1.3 Push the pack downward till you hear "click"(Fig. 3), make sure the pack will not be pulled
out by hand without pressing release button.
2.2 Remove:
2.2.1 Press release button and pull the pack out upward (Fig. 4 / ).
2.2.2 Tilt the pack a little bit at the beginning of pulling (Fig. 5), then pull out the battery pack.
click!
1
Tilt
234
5
Tilt
1

Step1 : Step2 :
Click!
Click!
3. Hook
2
B. Interface
Emergency button
LCM display
Lifting actuator extends
Battery indicator (optional)
Lifting actuator retracts
Battery pack release button
Hook
Spread actuator retracts
Spread actuator extends
Hook
1. Connection
There are 4 connection ports as indication on following drawing.
Handset
Lifting actuator (M1)
(Φ13.6 or 16.7mm)
Spread actuator(M2) (Optional)
(Φ13.6 or 16.7mm)
Charging plug
2. LCM Display
A
B
E
Low Batt.
KG
A = Over Load
B = Overduty (overused)
C = Battery Volume
D = Battery Low (Blink)
E= Time to replace actuator
C
D
Battery is charged to around 100%. Battery is charged to around 50%.
Battery is charged to around 25%.
Battery is charged to around 75%.
AB
In order to keep the
batteries stay in good condition
for long, we strongly recommend
you to press this button when
not going to use this device for
a couple days.
3. Emergency Stop
Press the button firmly to make it locked with click sound. It cuts off the power and actuator stop instantly.
i. Lock: Press the red button as shown in , then the button locked and the power is cut off.
ii. Unlock: Turn the red button in clockwise, as shown in , then the button bounded and the power is restored.
A
B

3
D. Operation
Box Panel
LED
2- 2+
1+
1-
HTF handset
1+
2-
1-
2+
1 means lifting actuator (M1)
1+：represents M1 extends
1-： represents M1 retracts
2 means spread actuator (M2)
2-： represents M2 retracts
2+：represents M2 extends
1. Basic control function
over 600K sec.
over 450K sec.
2. Soft start/stop & key tone
Feedback
(LED blinks or sound)
Blinks 4 times, no sound
Blinks 2 times, no sound
Blinks 2 times, beep once
Blinks 2 times, no sound
Method
Function
soft start/stop
ON
OFF
key tone
(for 2-motor model only)
ON
OFF
Keep pressing "1+" button on HTF handset,
then unlock the emergency button
Press 2+, 2- buttons on handset or panel
at the same time.
3.1 Press 1+,1- buttons on the HTF or panel at the same time.
3.2 The number of level bar on the LCM means the cumulative running time.
3.3 It’s approximate cumulative running time.
3. Check cumulative running time
Level bar
over 150K sec.
over 300K sec.
Cumulative running time
Box Panel
1+
1-
HTF handset
1+ 1-
2. CHP1 Charger (Optional)
2.1 CHP1 is an optional stand alone charger for BTP1 battery pack. User can charge additional battery
pack (option) while CBP2 is on duty for use. Be noted that CHP1 equips EI type transformer and has to
follow the AC voltage of the country.
2.2 The Charge LED keeps blinking (1Hz) during charging, and all functions are locked. The LED indicator keeps
lighting means charging is done.
CHP1 charger + battery pack
Battery pack release button
Charge LED (Yellow)
AC on LED (Green)
Battery indicator (optional)
Power plug
1. Charging on CBP2
C. Battery Charging
Model with external SMPS
Model with AC charging cable
Waterproof Cap
Waterproof Cap
C-clamp
1.1 When battery level remains only one bar on LCM display, Low Batt. icon keeps blinking or continuous 4 beeps
in every 4 seconds sound, it is reminding users to charge the battery immediately.
1.2 Remove the cap and connect the charging cable properly.
1.3 If the model is with AC charging cable, insert the C-clamp to fix the cable.
1.4 The level bar on LCM and indicator on control panel keep blinking (1Hz) during charging, and all functions
are locked.
1.5 The level bar and indicator keep lighting means charging is done.
1.6 When not charging, cover with waterproof cap properly to prevent water ingress.

MO-FAM-I-0002-2.0
4
4. Error code trouble shooting
Display Information
Disposal
Lifting actuator over duty
(after 4mins continuous operating)
Stop operation for a while. The error message
will gone automatically after sufficient rest.
Lifting or Spread actuator over load Find out and remove obstruction or improper load.
Please call the agency if the error code keeps on.
Cumulative running time over 600K
seconds on lifting actuator.
Call agency to replace the actuator.
Low battery
(less than 20V DC, lifting actuator can
only retract.)
Charging battery pack at once.
5.4.2 Detect the M1 actuator current limit by self-learning
i. Press “1+” for 1 second
ii. The lifting actuator extends automatically for 2.5 seconds
iii. The level bar disappeared means self-learning is on going, till the level bar appears
again means the self-learning is done and CBP2 got a new current limit as shown below.
iv. The available range is 5~9A, step 1A.
done
detecting
5.4.3 Switching the "Over duty protection on M1" active or inactive by pressing "2+" & "2-" at the
same time.
5.4.4 Reset
i. Pressing "1+" & "1-" at the same time over 2.5 seconds.
ii. Then the device backs to default value, as shown below
iii Default: Key tone and soft start/stop off, over duty protection active, current limit 7A.
active inactive
5. Setting mode (only available with service handset by service agency )
5.1 How to get in setting mode?
Press the SET button (the fifth key) over 2 seconds to go into set mode.
5.2 The over load icon keeps blinking means CBP2 is under setting mode now.
5.3 How to quit setting mode?
5.3.1 Press the SET button over 2 seconds or without any input over 10 seconds.
The set data will be saved automatically.
5.3.2 If pressing the emergency button or remove the handset directly at this moment,
then all the set data is nullity.
Service handset
SET
5.4 When CBP2 under setting mode, we can:
5.4.1 Set the M1 actuator current limit on demand (operation available on handset or panel as well)
i. Press “2+“ to increase the current limit on handset or panel
ii. Press “2-” to decrease the current limit on handset or panel
iii. The available range is 5~9A, step 1A.
Display
6A 7A 8A 9A5A
Value
