Motif Medical Motif Luna Quick start guide

Motif Luna®
Operational
Manual

2
1. Introduction
Meet The Luna
Innovated with the modern mom in mind,
the battery-powered Motif Luna® is a
sophisticated, strong, and portable breast
pump, designed for on-the-go pumping with a
modern aesthetic.
All Motif Medical® products purchased from authorized retailers come
with a manufacturer’s warranty stating that product will be free from
defects in workmanship and materials; for 2-years on double-electric
breast pumps, for 1-year on internal batteries, and for 90-days on breast
pump parts.
Be sure to register your breast pump upon receiving it:
motifmedical.com/warranty-registration/

3MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL

1. Introduction 2
2. Highlights 7
3. Intended Use (Indications of Use) 8
4. Symbols 9
5. Safety 10
5.1 Prohibitions, Warnings, and Cautions 10
6. Parts 13
6.1 What’s Included 13
6.2 Buttons and Features 15
6.3 Settings and Modes 17
7. Sterilization and Cleaning 18
8. Operating Your Breast Pump 21
8.1 Breast Shield Sizing 21
8.2 Assembling The Luna Pump 24
8.3 How to Use The Dual Pump 25
8.4 Turning On/Off The Luna Pump 26
Index

9. Using Your Motif Luna Pump 27
9.1 Pumping Guide 27
9.2 Getting Ready to Pump 28
9.3 Aligning the Breast Shield 29
9.4 Expressing Your Milk 30
9.5 After Pumping 31
9.6 Storing Breast Milk 32
10. Troubleshooting 34
10.1 Troubleshooting 34
10.2 Disposal 37
10.3 When to Replace Parts 38
11. Warranty 40

6

7MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL
2. Highlights
Compact Elegance
Innovated with Moms in mind, the
Motif Luna® is a powerful breast
pump designed to blend in with a
modern aesthetic.
The Motif Luna® is proven to
provide More Milk in Less Time®.
Massage & Expression Modes
Effortlessly switch from Massage
to Expression Mode, by pressing
a single button.
The Motif Luna® Double Electric
Breast Pump utilizes a vacuum to
express breast milk.
Battery-powered & Rechargeable
Made for the mom on-the-go, with
2+ hours of battery life per charge
and portable with a lightweight
design.
Full Control
Easily adjust suction level and
cycles for maximum comfort and
an effective pumping session.
Night Light
Choose from three different light
levels; great for pumping at night.
Double Pumping
Expressing from both breasts at
the same time saves time and
supports milk supply.
Based on a 3rd-party study, 5 out of 6 moms agree the Luna
pumps More Milk In Less Time®! You can read the full report at
motifmedical.com/more-milk-less-time.

8
3. Intended Use (Indications of Use)
The Motif Luna® Double Electric Breast Pump is intended for use by
lactating women to express and collect breast milk. The Luna can be
used as a single or double pump and is only intended for personal use.
Please read this document completely and follow the instructions
exactly. To prevent personal injury and material damage, please
observe the warning and safety information provided in this document.
Caution: To avoid minor injury
• Sharing a breast pump can cause health hazards and void manufacturers
warranty.

9MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL
4. Symbols
Warning: Potentially dangerous situation that could result in serious injury.
Caution: A possibly dangerous situation that could result in slight bodily injury.
Notice: Useful information or information you need to know when using this product.
Manufacturer
Date of manufacturer
Serial number
Refer to instruction manual
Type BF applied part
Class II equipment
Keep dry
IP22 Degree of protection against harmful ingress of water or particulate matter.
This product should not be mixed with other commercial waste for disposal
Power
Increase the level of suction or cycle
Decrease the level of suction or cycle
Changes of operation mode
LED night light
Battery-power

10
5. Safety
5.1 Prohibition, Warnings, and Cautions
Prohibition: To prevent voiding of warranty
• Do not modify this equipment without authorization of the manufacturer.
• Do not disassemble or modify the product. The device has no user-
serviceable parts.
Warning: To avoid fire, electrocution, or serious burns
• Do not leave the product unattended when plugged into an electrical outlet.
• Close supervision is necessary when this product is used near children or
persons with disabilities.
• Place product out of reach of children.
• Use the product only for its intended use as described in this manual. Do not
use attachments not recommended by the manufacturer.
• Never operate this product if it has a damaged cord or plug if it is not working
properly, or if it has been dropped or damaged, or dropped into water.
• Keep cord away from heated surface.
• Never use while sleeping or when drowsy.
• Never drop or insert any object into any opening or tubing.
• Do not use outdoors, or operate where aerosol (spray) products are being
used where oxygen is being administered.
• Always inspect power adapter and battery pack wires prior to use for damage
or exposed wire. If damage is found, immediately discontinue use of power
adapter or battery pack and call Motif Medical® Customer Service.
• The Motif Medical Luna® should not be positioned so that it is difficult to
operate the adapter.

11MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL
Warning: To reduce the risk of electrocution
• Always unplug immediately after use.
• Do not use while bathing.
• Do not place or store product where it can fall or be pulled into a tub or sink.
• Do not place or drop into water or other liquid.
• Do not reach for a product if it has fallen into water. Immediately unplug from
electrical outlet.
Warning: To avoid health risk and reduce the risk of injury
• If you are a mother who is infected with Hepatitis B, Hepatitis C or Human
Immunodeficiency Virus (HIV) pumping breast milk will not reduce or remove
the risk of transmitting the virus to your baby through your breast milk.
• Before each use visually inspect the individual components for cracks, chips,
tears, discoloration or deterioration. In the event that damage to the device is
observed, please discontinue use until the parts have been replaced.
• This product is the intended for use by a single user only and should not be
shared between users.
• Do not drive while pumping.
• Never use while pregnant, as pumping can induce labor.
• Clean and sanitize all parts that come in contact with your breast and breast
milk prior to first use.
• Wash all parts that come in contact with your breast and breast milk after every
use.
• Do not continue pumping for more than 2 consecutive pumping session if no
results are achieved.
• Do not thaw frozen breast milk in a microwave or in a pan of boiling water.
• If tubing becomes moldy, discontinue use and replace with new tubing.
• If breast milk backup occurs you must clean tubing before your next pumping
session.

12
Caution: To avoid minor injury
• Do not wrap cord around adapter body.
• Use only the power adapter that comes with the powered breast pump.
• Pump only with the breast pump in an upright position.
• Do not shorten tubing.
• Make sure the voltage of the power adapter is compatible with the power
source.
• Plug the power adapter into the breast pump first and then into the wall
socket.
• Do not use antibacterial or abrasive cleaners/detergents when cleaning the
breast pump or breast pump parts.
• Never put the breast pump motor in water or sterilizer as you can cause
permanent damage to the breast pump.
• Do not attempt to remove the breast shield from your breast while pumping.
Turn the breast pump off and break the seal between your breast and breast
shield with your finger, then remove breast shield from your breast.
• If pumping is uncomfortable or causing pain, turn the unit off, break the seal
between the breast and breast shield with your finger, and remove the breast
shield from your breast.
• Plastic bottles and component parts become brittle when frozen and may
break when dropped.
• Bottles and component parts may become damaged if mishandled, e.g.
dropped, over- tightened or knocked over.
• Take appropriate care in handling bottles and components.
• Do not use the breast milk if bottles or components become damaged.
5. SAFETY

13MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL
6. Parts
6.1 What’s Included
While unpacking the box, make sure all of the following
components are enclosed.
1Powered Breast Pump,
Motif Medical® Luna
2Tubing (2)
3Diaphragm Top (2)
4Diaphragm (2)
5Diaphragm Bottom (2)
624mm & 28mm Breast Shields (2)
7Valve (2)
8Bottle (2)
9Bottle Cap (2)
10 Nipple (2)
11 Bottle Cover (2)
12 Bottle Disk (2)
13 Air Flow Port
14 Power Adapter - DC12V, 2A (2)
-Milk Collection Kits (2)
14
1
13
2
3
4
5
6
9
10
11
12
7
8

14
6. PARTS
Additional accessories and parts available for the Luna breast pump:
• Full resupply kit with replacement parts
• 21mm and 32mm Breast Shields
• Individual parts
• Luna pump cooler set
Find replacement parts and additional supplies for the Luna at:
motifmedical.com/replacement-supplies/

15MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL
6.2 Buttons and Features
LCD Screen
Massage Mode
(Symbol turns o when
using Expression Mode)
Expression Mode
Vacuum Level
Battery-power
(Indicates
remaining battery
power)
Battery-power
Fully charged
75% - 100%
50% - 75%
0% - 25%
0%
It is recommended to charge the battery as soon as battery
gets to 0% - 25%. If the battery dies, your Motif Luna® will
automatically shut down.

16
6. PARTS
Button Control
Mode Button
(Use to switch
between
Massage
Mode/
Expression
Mode)
Increase/
Decrease
Buttons
(Adjust Cycle
Level)
Power
Button
Increase/
Decrease
Buttons
(Adjust Vaccum
Level)
LED Night
Light
Night Light
• The LED light appears by pressing the button.
• Select between the three lighting levels by pressing the LED Night
Light button until desired light intensity is selected.
• To turn off the LED light completely, press this button until light is no
longer on.

17MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL
6.3 Settings and Modes
Using the Cycle and Suction Settings
The Motif Luna® will remember your settings automatically for your next
session. If you want to start pumping on different settings than those
you finished in your previous session, adjust the settings before you
start expressing.
The cycle level refers to the number of full pumping motions the device
will complete per minute; this is measure in Cycles Per Minute (CPM).
The cycle setting cannot be adjusted in Massage Mode and is set at 60
CPM. The cycle setting in Expression Mode can be adjusted from 46 to
30 CPM.
Suction Settings
The suction level on your breast pump refers to the suction strength;
this is measured in mm-Hg. When you are using your Motif Luna®, you
will usually find that expressing is most effective on the highest suction
level that you are comfortable with.
However, it’s important not to set section level so high that it makes
you uncomfortable, as the resulting pain will hinder your milk flow.
Expression Modes
Suction pattern with slower cycles and higher vacuum to express milk
gently and efficiently.
Massage Modes
Suction pattern with fast cycles and low vacuum to help with Letdown
and to start the flow of milk.

18
7. Sterilization and Cleaning
Before initial use sterilize each part of the:
• Diaphragms
• Valves
• Breast Shields
• Bottles
• Bottle Caps
• Nipples
*Do not sterilize or wash the tubing.
Repeat sterilization of other listed parts once daily after pump use.
Sterilization Instructions
1. If parts have been used previously, following cleaning
instructions first.
2. Place your breast pump parts in a pot and cover them with
water.
3. Bring water to a boil and let boil for five minutes.
4. Remove parts with clean tongs.
5. Place pump parts on a clean paper towel or dish towel and
allow to air dry completely.
Parts can also be sterilized in a steam sterilizer or microwave
sterilization bag to sterilize breast pump parts quickly and
efficiently.
Be sure not to place tubing into the Sterilizer Bags in attempt
to clean the tubing.

19MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL
Cleaning Instructions
1. Thoroughly wash your hands with warm soap and water.
2. Disassemble each breast pump part that came into
contact with breast milk. This includes the valves, bottles,
breast shields, and nipples. *Do not clean the tubing or
diaphragms. Diaphragms do not need to be cleaned
unless milk or moisture develops in them. If moisture or
milk becomes present in the tubing, replace it as soon as
possible. Do wash and hang it to dry if you need to use it
again before replacing. Assure the tubing is dry before use.
Moisture in the tubing could be pulled into the pump and
damage the motor.
3. Rinse each part with cool water to remove milk residue.
4. Options for washing pump parts:
• Separately wash each part in the sink with a soft brush and
soap. (Be sure to use a new brush or washcloth exclusively
for breast pump parts.)
• Soak each part in warm, soapy water for 5 minutes and
then thoroughly rinse them.
5. Dry each part with a clean towel or allow to fully air dry on a
sanitary surface, such as a clean paper towel or clean dish
towel. Do not pat dry.
6. Wipe the outside of your breast pump with a dry, clean towel.
*Do not wash the outside of your breast pump with water or
get your breast pump wet when cleaning it.
It is not recommended to wash and dry Motif Breast Pump
parts in the dishwasher. There is no standard temperature for
dishwashers and some may warp parts. Parts damaged in the
dishwasher are not covered under warranty.

20
7. STERILIZATION AND CLEANING
After Every Use
1. Thoroughly wash your hands before handling each breast
pump component.
2. Disassemble each part that comes into contact with breast
milk including the valve, bottle, bottle nipple, breast shield,
bottle disk, and bottle cover.
3. Rinse each part in cool water to remove milk residue.
4. Options for washing individual parts:
• Separately wash each part with a soft brush or a clean
dishcloth.
• Soak each part in warm soapy water for 5 minutes then
thoroughly rinse them.
5. Dry each part with a clean towel and/or allow them to
completely air dry on a sanitary surface.
6. Wipe the main body with a dry, clean towel after each use.
*Never use water to wash the outside of your breast pump.
7. Store parts after they completely dry in a clean bag or
container. *Do not store any damp parts.
