Motorola solutions GMKN4067 User manual

PROGRAMMING CABLE
GMKN4067
6866537D07.fm Page 1 Friday, April 16, 2021 12:08 PM

GENERAL INFORMATION
The GMKN4067 Programming Cable provides
a 4-wire RS232 interfaces (For example, RxD,
TxD, CTS, RTS) between a computer and a
mobile radio when the radio is to be
programmed or flashed.
OPERATION
The radio Basic Service Manual includes
programming procedures. Refer to the relevant
procedures for the radio being programmed and
connect the radio to the computer as directed.
SERVICE
The GMKN4067 Programming Cable is not
repairable. Order a replacement cable as
necessary.
!
C a u t i o n
Do not disconnect the cable in the
middle of a procedure. This may
leave the radio incorrectly
configured and degrade the radio
performance.
6866537D07.fm Page 2 Friday, April 16, 2021 12:08 PM

CABLE CONNECTIVITY
CONNECTOR DETAIL
1 DCD
2 RxD
3 TxD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
To Radio Accessory Connector
20 pins
To Computer
9 pins (female)
EXTERNAL PTT
FLASH
GND
GND
SWB +
CTS
RTS
TxD
RxD
3
6
7
8
13
17
18
19
20
Radio Interface Box
(RIB)
RS232
Level Shifter
R a d i o I n t e r f a c e B o x ( R I B )
5
1
9
6
T o t h e c o m p u t e r
T o R a d i o A c c e s s o r y
C o n n e c t o r
1 9
2 0
1
1 7
2
1 8
