Motorola HAF4015 User manual

Mobile Motorcycle Antenna
762-870 MHz
HAF4015
HAF4018
806-941 MHz
HAF4038
Installation Manual
© 2022 Motorola Solutions, Inc.
All rights reserved. *MN007792A01*
MN007792A01-AA
m

List of Figures..............................................................................................................3
List of Tables............................................................................................................... 4
Foreword......................................................................................................................5
Product Safety and RF Exposure Compliance.............................................................................. 5
Intellectual Property and Regulatory Notices.................................................................................5
Chapter 1: Antenna Overview.................................................................................. 7
1.1 FCC Requirements..................................................................................................................8
Chapter 2: Installation...............................................................................................9
2.1 Required Tools and Materials .................................................................................................9
2.2 Assembling the Coaxial Connector .........................................................................................9
2.3 Antenna Installation............................................................................................................... 12
MN007792A01-AA
Contents
Contents
2

List of Figures
Figure 1: Motorola Solutions Crimping Tool 66-80388A26 ....................................................................10
Figure 2: Assembling the Coaxial Connector ........................................................................................ 11
Figure 3: Coaxial Cable Stripping Dimensions ......................................................................................11
Figure 4: Coaxial Cable Stripping Dimensions ......................................................................................12
Figure 5: Bushing Assembly Parts ........................................................................................................ 13
Figure 6: Attaching the Antenna ............................................................................................................14
MN007792A01-AA
List of Figures
3

Table 1: Motorcycle Antennas .................................................................................................................7
Table 2: Bushing Assembly Parts Description .......................................................................................13
MN007792A01-AA
List of Tables
List of Tables
4

Foreword
This manual applies to digital mobile radios,unless otherwise specified. It includes instructions for
installing the motorcycle antenna on the motorcycle enclosure.
CAUTION: These servicing instructions are for the use of qualified personnel only. To reduce
the risk of electric shock, do not service parts other than those contained in the Operating
Instructions unless you are qualified to do so. Refer all servicing to qualified service personnel.
Product Safety and RF Exposure Compliance
CAUTION: This radio is restricted to occupational use only to satisfy FCC RF energy exposure
requirements. Before using this product, read the Product Safety and RF Exposure booklet
enclosed with your radio which contains important operating instructions for safe usage and RF
energy awareness and control for compliance with applicable standards and regulations.
For a list of Motorola Solutions-approved antennas, batteries, and other accessories, visit http://
www.motorolasolutions.com
Intellectual Property and Regulatory Notices
Copyrights
The Motorola Solutions products described in this document may include copyrighted Motorola
Solutions computer programs. Laws in the United States and other countries preserve for Motorola
Solutions certain exclusive rights for copyrighted computer programs. Accordingly, any copyrighted
Motorola Solutions computer programs contained in the Motorola Solutions products described in this
document may not be copied or reproduced in any manner without the express written permission of
Motorola Solutions.
No part of this document may be reproduced, transmitted, stored in a retrieval system, or translated
into any language or computer language, in any form or by any means, without the prior written
permission of Motorola Solutions, Inc.
Trademarks
MOTOROLA, MOTO, MOTOROLA SOLUTIONS, and the Stylized M Logo are trademarks or
registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other
trademarks are the property of their respective owners.
License Rights
The purchase of Motorola Solutions products shall not be deemed to grant either directly or by
implication, estoppel or otherwise, any license under the copyrights, patents or patent applications
of Motorola Solutions, except for the normal non-exclusive, royalty-free license to use that arises by
operation of law in the sale of a product.
Open Source Content
This product may contain Open Source software used under license. Refer to the product installation
media for full Open Source Legal Notices and Attribution content.
MN007792A01-AA
Foreword
5

The European Union's WEEE directive and the UK's WEEE regulation require that products sold
into EU countries and the UK must have the crossed-out wheelie bin label on the product (or the
package in some cases). As defined by the WEEE directive, this crossed-out wheelie bin label means
that customers and end-users in EU and UK countries should not dispose of electronic and electrical
equipment or accessories in household waste.
Customers or end-users in EU and UK countries should contact their local equipment supplier
representative or service centre for information about the waste collection system in their country.
Disclaimer
Please note that certain features, facilities, and capabilities described in this document may not be
applicable to or licensed for use on a specific system, or may be dependent upon the characteristics of
a specific mobile subscriber unit or configuration of certain parameters. Please refer to your Motorola
Solutions contact for further information.
© 2022 Motorola Solutions, Inc. All Rights Reserved
MN007792A01-AA
Foreword
European Union (EU) and United Kingdom (UK) Waste of Electrical and
Electronic Equipment (WEEE) Directive
6

Chapter 1
Antenna Overview
The motorcycle antenna is supplied with a coaxial lead-in cable and connector.
Motorcycle radio antennas are intended for mounting on the top cover of a weather-resistant enclosure
used with the mobile radio. The antenna has a base designed for mounting to a thick surface. The
following table lists the available motorcycle radio antenna.
Table 1: Motorcycle Antennas
HAF4015A
762–870 MHz
3 dB GAIN COLLINEAR
HAF4018A
762–870 MHz
3 dB GAIN LOW PROFILE
HAF4038
806–941 MHz
UNITY GAIN
MN007792A01-AA
Antenna Overview
7

CAUTION: To comply with FCC regulations when installing the antenna lead-in cable, DO NOT
shorten the cable.
NOTE: To comply with FCC requirements, do not exceed the maximum radio power level at the
antenna port of 18 W.
CAUTION: When unscrewing the antenna, advise the radio owner to unscrew the upper
antenna assembly at the knurled section (bottom). Be sure only the upper section, not the
locking nut is removed. If the locking nut should loosen, retighten it securely against the
mounting surface.
MN007792A01-AA
Chapter 1 : Antenna Overview
1.1
FCC Requirements
8

Chapter 2
Installation
The installation procedure in this chapter is for a typical motorcycle. The procedure may vary slightly
with the type of motorcycle on which the antenna is to be installed. Generally, however, the procedure
outlined below is universal in nature.
2.1
Required Tools and Materials
The following tools and materials are needed to properly install the motorcycle radio antennas:
• 10 in. adjustable wrench, or 1 in. open-end wrench
• 15/16 in. open-end wrench
• Antenna hole-cutting tool, Motorola Solutions RPX-4378A
• Center punch
• Crimping tool 66-80388A26
• Hammer
• Large hand drill
• Pliers
• Round file
• Side cutters
• Soldering station and solder
2.2
Assembling the Coaxial Connector
CAUTION: To comply with FCC regulations, do not trim or shorten the lead-in cable
Prerequisites: Assemble the antenna cable connector before installing the antenna lead-in cable in
the weather resistant enclosure.
Use the Motorola Solutions crimping tool (part number 66-80388A26) for the following procedure.
MN007792A01-AA
Installation
9

.256
.31
A
B
C
D
E
FIVE CRIMP AREAS
Procedure:
1Slip the ferrule and collar onto the cable.
MN007792A01-AA
Chapter 2 : Installation
Figure 1: Motorola Solutions Crimping Tool 66-80388A26
