Motorola AM21
Digital Audio Baby Monitor
User Guide
For: AM21 and AM21-2

Welcome...
to your new Motorola Baby monitor!
Thank you for purchasing the Digital Audio Baby Monitor. Now you
hear your baby sleeping in another room.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola product, you will need to provide
a copy of your dated sales receipt as proof of warranty status.
Registration is not required for warranty coverage.
For product related questions, please contact us by visit:
This User Guide provides you with all the information you need to
get the most from your product. Please read the Safety Instructions
on page 6 before you install the units.
Got everything?
• 1 x Parent Unit
• 1 x Baby Unit
• 1 x Battery door for Parent Unit
• 1 x Power adapter for Parent unit
• 1 x Power adapter for Baby unit
In packs with dual parent units, you will find an additional parent unit
with power adapter.
motorolanursery.com/support

Overview of the Parent Unit
2
1
5
3
6
7
4
8
1. Power/Link indicator
On when the parent unit is
powered on and linked to
the baby unit.
Flashes when the parent
unit is searching the baby
unit.
2. Microphone
3. LEFT button <
Press to decrease the
speaker volume.
4. RIGHT button >
Press to increase the
speaker volume.
5. Power button
0
Press and hold to power on/
o the parent unit.
6. Battery cover
7. Speaker
8. Power jack

Overview of the Baby Unit
Important guidelines for installing your digital baby monitor
• To use your baby unit and parent unit together, you must be able to
establish a radio link between them. Note - The range may be aected
by environmental conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet,
a metallic door or reinforced concrete, between the baby unit and
parent unit may block the radio signal.
• The signal strength may also be reduced by other solid structures,
like walls, or by radio or electrical equipment, such as TVs, computers,
cordless or mobile phones, fluorescent lights or dimmer switches.
• If the signal is poor, try moving the parent unit and/or the baby unit to
a dierent position in the room.
4
1
2
3
5
6
1. Microphone
2. Power button
0
Press and hold to power on/
o the baby unit.
3. Speaker
4. Power indicator
On when the baby unit is
powered on.
5. Power jack
6. Temperature sensor

5
Table of contents
1. Safety Instructions..........................................................................6
2. Getting Started................................................................................8
2.1 Baby unit power supply........................................................................ 8
2.2 Parent unit power supply..................................................................... 9
2.3 Parent unit battery installation .........................................................10
3. Using Your Digital Audio Baby Monitor.................................... 11
3.1 Power on or o the Baby Unit ...........................................................11
3.2 Power on or o the Parent Unit.........................................................11
3.3 Speaker volume ...................................................................................... 11
4. Disposal of the Device (environment) .................................... 12
5. Cleaning........................................................................................... 13
6. Troubleshooting ............................................................................ 14
7. General Information...................................................................... 16
8. Technical Specifications .............................................................. 21
Table of contents

6Safety Instructions
1. Safety Instructions
WARNING:
Strangulaton Hazard. Chldren have
STRANGLED n cords. Keep ths cord out of
the reach of chldren (more than 1metre away).
Never use extenson cords wth AC Adapters.
Only use the AC Adapters provded.

7
Safety Instructions
BABY MONITOR SET UP & USE:
• Determine a location for the BABY UNIT that will allow you to
hear your baby in his/her cot.
• Place the BABY UNIT on a flat surface, such as a dresser, bureau,
or shelf or mount the Unit to a wall securely using the keyhole
slots under the stand.
• NEVER place the Baby Unit or cords within the cot.
WARNING
This Digital Audio Baby Monitor is compliant with all relevant
standards regarding electromagnetic fields and is, when handled as
described in the User Guide, safe to use. Therefore, always read the
instructions in this User Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children
when assembling.
• This product is not a toy. Do not allow children to play with it.
• This Digital Audio Baby Monitor is not a substitute for responsible
adult supervision.
• Keep this User Guide for future reference.
• Keep the cords out of reach of children.
• Do not cover the Digital Audio Baby Monitor with a towel or
blanket.
•Test this monitor and all its functions so that you are familiar with it
prior to actual use.
• Do not use the Digital Audio Baby Monitor in damp areas or close
to water.
• Do not install the Digital Audio Baby Monitor in extreme cold or
heat, direct sunlight, or close to a heat source.
• Do not touch the plug contacts with sharp or metal objects.
• Connect the power adapters to easily accessible mains power.
CAUTION
There is a risk of explosion if the battery is replaced by an incorrect
type. Dispose of used batteries according to the instructions.

8Getting Started
2. Getting Started
2.1 Baby unit power supply
• Insert the DC plug of the power adapter into the DC jack on the side
of the baby unit, as shown.
• Connect the other end of the power adapter to a suitable mains
power socket.
• The Power indicator will illuminate.
NOTE
Only use the power adapter provided (DC6/400mA).

9
Getting Started
2.2 Parent unit power supply
MBP21PU
• Insert the DC plug of the power adapter into the DC jack on the
side of the parent unit.
• Connect the other end of the power adapter to a suitable mains
power socket.
• The parent unit will turn on.
NOTE
Only use the power adapter provided (DC6/400mA).

10 Getting Started
2.3 Parent unit battery installation
As an option, the Parent Unit can be powered by alkaline batteries
(Size AAA x 2, NOT included), so that it continues to work if you
disconnect it from the mains power to carry it to another location.
Please follow the steps below to install alkaline batteries.
• Open and lift the battery door up as shown in the figure. (Fig.b1)
(Fig.b1)
(Fig.b2)
(Fig.b3)
• Insert the alkaline batteries follow the direction into battery
compartment.(Fig.b2)
(Fig.b1)
(Fig.b2)
(Fig.b3)
• Insert the catches at the top of the battery door then close the
door as shown in the picture. (Fig.b3)
(Fig.b1)
(Fig.b2)
(Fig.b3)

11
Using Your Digital Audio Baby Monitor
3. Using Your Digital Audio Baby Monitor
Please read these instructions carefully, and be aware that this
digital audio baby monitor is only intended as an aid. It is not a
substitute for responsible and proper adult supervision.
3.1 Power on or o the Baby Unit
• Press and hold 0to power on the baby unit. The Power indicator
will illuminate.
• Press and hold 0again to power o the baby unit. The Power
indicator will extinguish.
3.2 Power on or o the Parent Unit
• Press and hold 0to power on the parent unit. The Power/Link
indicator will illuminate.
• Press and hold 0again to power o the parent unit. The Power/
Link indicator will extinguish.
NOTE
If you place the parent and baby units too close together, you may
hear a high pitched noise. This is not a fault. The units are designed
to be operated at some distance apart, e.g. in separate rooms, so
move the units further apart.
If the Power/Link indicator flashes on the parent unit, they are not
linked to each other. Make sure that both units are powered on, and
reduce the distance between the units, but not closer than 1 metre.
3.3 Speaker volume
You can adjust the speaker volume of the parent unit from Volume 1
to Volume 5, or turn it off.
• Press <or >on the parent unit when it is not in use.

12 Disposal of the Device (environment)
4. Disposal of the Device (environment)
At the end of the product life cycle, you should not
dispose of this product with normal household waste.
Take this product to a collection point for the recycling of
electrical and electronic equipment. The symbol on the
product, user guide and/or box indicates this.
Some of the product materials can be re-used if you take them
to a recycling point. By reusing some parts or raw materials from
used products you make an important contribution to the protection
of the environment.
Please contact your local authorities in case you need more
information on the collection points in your area.
Dispose of the battery pack in an environmentally-friendly manner
according to your local regulations.

13
Cleaning
5. Cleaning
Clean your Digital Audio Baby Monitor with a slightly damp cloth
or with an anti-static cloth. Never use cleaning agents or abrasive
solvents.
Cleaning and care
• Do not clean any part of the Digital Audio Baby Monitor with
thinners or other solvents and chemicals - this may cause
permanent damage to the product which is not covered by the
warranty.
• Keep your Digital Audio Baby Monitor away from hot, humid areas
or strong sunlight, and do not let it get wet.
• Every eort has been made to ensure high standards of reliability
of your Digital Audio Baby Monitor. However, if something does go
wrong, please do not try to repair it yourself - contact Customer
Service for assistance.
IMPORTANT
Always switch o and disconnect the power adapter before cleaning
your Digital Audio Baby Monitor.

14 Troubleshooting
6.Troubleshooting
Power/Link Indicator on the parent unit does not come on
• Check whether the parent unit is powered on.
Power/link indicator on the parent unit flashes
• The parent unit and the baby unit may be out of range with each
other. Reduce the distance between the units, but not closer than 1
metre.
• The baby unit may be powered o. Press and hold 0to power on
the baby unit.
•Replace with new alkaline battery (size AAA x 2).
The parent unit beeps
• The parent unit may have lost connection with the baby unit.
Reduce the distance between the parent unit and the baby unit,
but not closer than 1 metre.
• The baby unit may be powered o. Press and hold 0to power on
the baby unit.
• Battery in the parent unit is running low. Replace with new alkaline
battery (size AAA x 2).
Cannot hear sound or baby cry from the parent unit
• The volume level in the parent unit may be set too low. Increase
the volume level of the parent unit. Refer to section 3.3 For volume
level settings.
• The parent unit and the baby unit may be out of range with each
other. Reduce the distance between the units, but not closer than 1
metre.

15
Troubleshooting
The Digital Audio Baby Monitor system produces a high-
pitched noise
•The parent unit and the baby unit are too close to each other. Make
sure that the parent unit and baby unit are at least 1 metre away
from each other.
• The speaker volume of the parent unit may be set too high.
Decrease the volume of the parent unit. Refer to section 3.3 for
volume level settings.
Battery in the parent unit is running low quickly
• The volume level of the parent unit may be set too high, which
consumes power. Decrease the volume level of the parent unit.
Refer to section 3.3 for volume level settings.

16 General Information
7. General Information
If your product is not working properly, read this Quick Start Guide
or the User’s Guide of one of the models listed on page 1.
Please contact us by visit: motorolanursery.com.suppoort
Consumer Products and Accessories Limited Warranty
(“Warranty”)
Thank you for purchasing this Motorola branded product
manufactured under license by Meizhou Guo Wei Electronics Co.
LTD ("MZGW").
What Does this Warranty Cover?
Subject to the exclusions contained below, MZGW warrants that
this Motorola branded product ("Product") or certified accessory
("Accessory") sold for use with this product that it manufactured to
be free from defects in materials and workmanship under normal
consumer usage for the period outlined below. This Warranty is
your exclusive warranty and is not transferable.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU
MAY HAVE OTHER RIGHTS THAT VARY BY STATE, PROVINCE OR
COUNTRY. FOR CONSUMERS WHO ARE COVERED BY
CONSUMER PROTECTION LAWS OR REGULATIONS IN THEIR
COUNTRY OF PURCHASE OR, IF DIFFERENT, THEIR COUNTRY OF
RESIDENCE, THE BENEFITS CONFERRED BY THIS LIMITED
WARRANTY ARE IN ADDITION TO ALL RIGHTS AND REMEDIES
CONVEYED BY SUCH CONSUMER PROTECTION LAWS AND
REGULATIONS. FOR A FULL UNDERSTANDING OF YOUR RIGHTS
YOU SHOULD CONSULT THE LAWS OF YOUR COUNTRY,
PROVINCE OR STATE.
Who is covered?
This Warranty extends only to the first consumer purchaser, and is
not transferable.

17
General Information
What will MZGW do?
MZGW or its authorised distributor at its option and within a
commercially reasonable time, will at no charge repair or replace
any Products or Accessories that do not conform to this Warranty.
We may use functionally equivalent reconditioned/ refurbished/
pre-owned or new Products, Accessories or parts.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY,OTHERWISE THE REPAIR
OR REPLACEMENT PROVIDED UNDER THIS EXPRESS LIMITED
WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND
IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED. IN NO EVENT SHALL MOTOROLA OR MZGW
BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE
PRICE OF THE PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY
KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS,
LOSS OF INFORMATION OR OTHER FINANCIAL LOSS ARISING
OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY
TO USE THE PRODUCTS OR ACCESSORIES TO THE FULL EXTENT
THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some jurisdictions do not allow the limitation or exclusion of
incidental or consequential damages, or limitation on the length of
an implied warranty, so the above limitations or exclusions may not
apply to you. This Warranty gives you specific legal rights, and you
may also have other rights that vary from one jurisdiction to another.

18 General Information
Products Covered Length of Coverage
Consumer Products One (1) year from the date of the
products original purchase by the first
consumer purchaser of the product.
Consumer
Accessories
Ninety (90) days from the date of the
accessories original purchase by the first
consumer purchaser of the product.
Consumer Products
and Accessories
that are Repaired or
Replaced
The balance of the original warranty or for
Ninety (90) days from the date returned to
the consumer, whichever is longer.
Exclusions
Normal Wear and Tear. Periodic maintenance, repair and
replacement of parts due to normal wear and tear are excluded from
coverage.
Batteries. Only batteries whose fully charged capacity falls below
80% of their rated capacity and batteries that leak are covered by this
Warranty.
Abuse & Misuse. Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such
as physical damage (cracks, scratches, etc.) to the surface of the
product resulting from misuse; (b) contact with liquid, water, rain,
extreme humidity or heavy perspiration, sand, dirt or the like,
extreme heat, or food; (c) use of the Products or Accessories for
commercial purposes or subjecting the Product or Accessory to
abnormal usage or conditions; or (d) other acts which are not the
fault of MOTOROLA or MZGW, are excluded from coverage.
Use of Non-Motorola branded Products and Accessories. Defects or
damage that result from the use of Non-Motorola branded or
certified Products or Accessories or other peripheral equipment are
excluded from coverage.

19
General Information
Unauthorised Service or Modification. Defects or damages resulting
from service, testing, adjustment, installation, maintenance,
alteration, or modification in any way by someone other than
MOTOROLA, MZGW or its authorised service centres, are excluded
from coverage.
Altered Products. Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken
seals or that show evidence of tampering; (c) mismatched board
serial numbers; or (d) nonconforming or non-Motorola branded
housings, or parts, are excluded from coverage.
Communication Services. Defects, damages, or the failure of
Products or Accessories due to any communication service or signal
you may subscribe to or use with the Products or Accessories is
excluded from coverage.
How to Obtain Warranty Service or Other Information?
To obtain service or information, please visit us at:
motorolanursery.com.support
You will receive instructions on how to ship the Products or Accessories
at your expense and risk, to a MZGW Authorised Repair Centre.
To obtain service, you must include: (a) the Product or Accessory;(b)
the original proof of purchase (receipt) which includes the date,
place and seller of the Product; (c) if a warranty card was included in
your box, a completed warranty card showing the serial number of
the Product; (d) a written description of the problem; and, most
importantly; (e) your address and telephone number.
These terms and conditions constitute the complete warranty
agreement between you and MZGW regarding the Products or
Accessories purchased by you, and supersede any prior agreement
or representations, including representations made in any literature
publications or promotional materials issued by MZGW or
representations made by any agent, employee or staff of MZGW,
that may have been made in connection with the said purchase.

20 General Information
Disposal of the Device (environment)
At the end of the product life cycle, you should not
dispose of this product with normal household waste.
Take this product to a collection point for the recycling of
electrical and electronic equipment. The symbol on the
product, user’s guide and/or box indicates this.
Some of the product materials can be re-used if you take them to a
recycling point. By reusing some parts or raw materials from used
products you make an important contribution to the protection of
the environment.
Please contact your local authorities in case you need more
information on the collection points in your area.
EU Declaration of Conformity (DoC)
Hereby, Meizhou Guo Wei Electronics Co. LTD declares that the
radio equipment type is in compliance with RE Directive
2014/53/EU. The full text of the EU declaration of conformity is
available on the website: www.motorolanursery.com
