Motorola MBP36S-2 User manual

MODELS:
MBP36S,
MBP36S-2,
MBP36S-3,
MBP36S-4
QUICK START GUIDE
For a full explanation of all features and instructions, please refer to the User’s Guide.
1. Setting up your Digital Video Baby Monitor
Connect the small plug of
the power adapter to the
Baby Unit and the other end
to the electrical outlet.
Only use the enclosed
adapter (5V DC/1000mA).
Ensure the ON/OFF switch
is at "ON" position.
A. Connecting power supply for the Baby Unit
Insert the wire tab of the
rechargeable battery pack
into the contact slot as
shown above and fit the
battery pack into the
compartment.
B. Installing the battery pack for the Parent Unit
Red
Black
Small cross head or
Flat end screw driver
C. Fastening the cover for the Parent Unit
Connect the small plug of
the power adapter to the
parent unit and the other
end to the electrical outlet.
Only use the enclosed
adapter (5V DC / 600mA).
Recommend charging at
least 12 hours before first
use.
D. Connecting power supply for the Parent Unit
WARNING:
STRANGULATION HAZARD - Keep the Unit and adapter cords more than 3 feet from the crib and out of baby's reach.
NEVER place camera or cords within the crib. Secure the cords more than 3 feet away from the baby's reach.
Never use extension cords with AC Adapters. Only use the AC Adapters provided.

2. Basic operation of the keys
Parent Unit
P ON/OFF button Press and hold to switch on/off the Unit.
+- UP/DOWN buttons Press to tilt the camera upward or downward. Press to adjust menu settings.
<> LEFT/RIGHT buttons Press to pan the camera left or right. Press to access different menu options.
MMENU button Press to open menu options or exit.
OOK button Press to confirm a selection.
VIDEO button Press to turn on/off the LCD display.
TTALK button Press and hold to talk to your baby.
Baby Unit
ON/OFF switch Push power switch to the right to switch on the Unit. Push power switch to the left to switch off the unit.
V
Manufactured, distributed or sold by Binatone Electronics International LTD., official licensee for this
product. MOTOROLA and the Stylized M Logo, are trademarks or registered trademarks of Motorola
Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their
respective owners.
© 2014 Motorola Mobility LLC. All rights reserved.
Printed in China
Version 7.0
