Motorola C257 User manual

APPLICANT: MOTOROLA, INC.FCCID: IHDT56FY1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:

C257
GSM

1
HELLOMOTO
Welcome to the world of Motorola digital wireless
communications! We are pleased that you have chosen the
Motorola C257 wireless phone.
Earpiece
Listen to your voice
calls & messages.
Left Soft Key
Perform functions
identified by left
display prompt.
Send/Answer Key
Make & answer
calls. Press in idle
screen to see
recently dialed calls.
Menu Key
O
pen a menu when it
a
ppears in the display.
Right Soft Key
Perform functions
identified by right
display prompt.
Power/End Key
Press & hold to turn the
phone on/off.
Press & release to end
phone calls, exit menu
system.
Power Connector
Insert the charger.
Navigation Key
Scroll up, down, left or
right.

2
check it out!
check it out!
Note: Your phone may not appear exactly as the phone
image above.
Headset Jack
Insert the headset
accessory for
handsfree use.
Battery
Lanyard Attachment
Speakers

3
check it out!
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. 200x All other product or service names are the property
of their respective owners. © Motorola, Inc. 2005.
Caution: Changes or modifications made in the radio phone, not expressly
approved by Motorola, will void the user's authority to operate the
equipment.
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain features
may not be activated by your service provider, and/or the provider's
network settings may limit the feature’s functionality. Always contact your
service provider about feature availability and functionality. All features,
functionality, and other product specifications, as well as the information
contained in this user's guide are based upon the latest available
information and are believed to be accurate at the time of printing.
Motorola reserves the right to change or modify any information or
specifications without notice or obligation.
Manual Number: 680XXXXAXX-O

4
feature locator
feature locator
main menu
n Phonebook
s Recent Calls
• Received calls
• Dialed Calls
• NotePad
•CallTimes
•CallCosts
e Message
•Create
•Inbox
•Draft
• Outbox
•QuickNotes
•Voicemail
•BrowserMsgs
• Info Services
• MMS Templates
É Office Tools
• Calculator
•MyMenu
•AlarmClock
• Stop Watch
•Chat
• Dialing Services
•IM
Q Games & Apps
á Web Access
•StartBrowser
• Web Shortcut
•GotoURL
•BrowserSetting
• Stored Pages
•History
• General Setting
h Multimedia
•Pictures
• Sounds
l Personalize
• Home Screen
•MainMenu
• Color Setting
• Greeting
• Wallpaper
• Screen Saver
•QuickDial
w Settings
• (see next page)

5
feature locator
settings menu
t Ring Style
•Style
•Detail
H Call Forward
•VoiceCalls
•FaxCalls
•DataCalls
•CancelAll
• Forward Status
U In Call Setup
• In-Call Timer
• Call Cost Setup
• My Caller ID
• Answer Options
• Call Waiting
Z Initial Setup
•TimeandDate
• 1-Touch Dial
• Display Settings
• Backlight
•Scroll
• Language
• Contrast
•DTMF
• Master Reset
• Master Clear
m Phone Status
• My Numbers
• Active Line
• Battery Meter
S Headset
• Auto Answer
j Network
•NewNetwork
•NetworkSetup
•Avail.Networks
• My Network List
•ServiceTone
• Call Drop Tone
• Band Selection
u Security
• Phone Lock
• Lock Keypad
• Auto Key Lock
•FixedDial
• Call Barring
•SIMPIN
•NewPasswords

6
contents
check it out!. . . . . . . . . . 2
feature locator . . . . . . . . 4
contents. . . . . . . . . . . . . 6
essentials. . . . . . . . . . . . 9
about this guide. . . . . . 9
SIM card . . . . . . . . . . . 9
battery . . . . . . . . . . . . . 10
turn it on & off . . . . . . 12
make a call . . . . . . . . 13
answer a call . . . . . . . 13
your phone number. . 13
main attractions . . . . . 14
multimedia messages 14
using instant messaging .
16
basics . . . . . . . . . . . . . . 20
display . . . . . . . . . . . . 20
menus . . . . . . . . . . . . 23
text entry. . . . . . . . . . 25
volume . . . . . . . . . . . 28
navigation key . . . . . . 29
handsfree speaker. . . 29
codes & passwords. . 29
lock & unlock phone . 30
customize . . . . . . . . . . 31
ring style . . . . . . . . . . 31
time & date . . . . . . . . 31
wallpaper. . . . . . . . . . 32
screen saver . . . . . . . 32
display appearance . . 33
answer options . . . . . 33
personal greetings . . 33
optional handsfree
operation . . . . . . . . . . 34
calls . . . . . . . . . . . . . . . 35
recent calls . . . . . . . . 35
redial . . . . . . . . . . . . . 36
return a call . . . . . . . . 36
notepad . . . . . . . . . . . 36
hold or mute a call. . . 37
call waiting . . . . . . . . 37
caller ID . . . . . . . . . . . 38
emergency calls . . . . 38
international calls . . . 39
1-Touch dial . . . . . . . . 39
voicemail . . . . . . . . . . 40
inserting special
characters into dialing
sequences. . . . . . . . . 40

7
other features . . . . . . . . 42
advanced calling . . . . . 42
phonebook . . . . . . . . . 44
messages . . . . . . . . . . 47
instant messaging. . . . 49
chat . . . . . . . . . . . . . . . 50
personalizing . . . . . . . . 50
call times & costs . . . . 52
handsfree operation . . 53
network. . . . . . . . . . . . 54
personal organizer. . . . 54
fun & games . . . . . . . . 56
service and repairs . . . . 57
check here first . . . . . . 57
service and repairs . . . 58

8
European Union Directives
Conformance Statement
Hereby, Motorola declares that this product is in compliance
with:
• The essential requirements and other relevant provisions of
Directive 1999/5/EC
• All other relevant EU Directives
The above gives an example of a typical Product Approval Number.
You can view your product's Declaration of Conformity (DoC) to Directive
1999/5/EC (to R&TTE Directive) at www.motorola.com/rtte. To find your
DoC, enter the product Approval Number from your product's label in the
"Search" bar on the Web site.
[France Only]
0168
Product
Approval
Number

9
essentials
essentials
about this guide
This guide shows how to locate a menu feature as follows:
Find it : Press M > Recent Calls > Dialed Calls
This example shows that, from the home screen, you press
M to open the menu, highlight and select Recent Calls , then
highlight and select
Dialed Calls .
Press
M to scroll to and highlight a menu feature. Press the
SELECT key to select the highlighted menu feature.
SIM card
Yo u r Subscriber Identity Module (SIM) card contains personal
information like your phone number and phonebook entries.
Caution: Do not bend or scratch your SIM card. Keep it away
from static electricity, water, and dirt.
symbols
This means a feature depends on the network or
subscription and may not be available in all areas.
Contact your service provider for more information.
This means a feature requires an optional accessory.

10
essentials
battery
battery installation
Note: If you remove the battery for a long time, the phone
will ask you to reset the time and date. If you choose to
cancel or ignore, the time and date will be suspended. You
can input the correct time and date by:
Find it: Press M > Setting > Other Settings > Intiial Setup > Time and Date
12
12
3

11
essentials
But, if you remove the battery just for a few seconds (e.g.,
quickly change SIM card), the system either won’t ask you to
reset the time and date or if prompted, you can choose
BACK
on the time and date screen, the clock will only be slightly
affected.
battery charging
Before you can use your phone you
need to completely charge the
battery. New batteries are not fully
charged. Plug the travel charger into
your phone and an electrical outlet.
Your phone displays
Charge Complete
when finished.
Tip: You cannot overcharge your battery. It will perform best
after you fully charge and discharge it a few times.
New batteries are shipped partially charged. Before you can
use your phone, install and charge the battery as described
below. Some batteries perform best after several full
charge/discharge cycles.
battery tips
Battery life depends on the network, signal strength,
temperature, features, and accessories you use.
• Always use Motorola Original™ batteries and
chargers. The warranty does not cover damage
caused by non-Motorola batteries and/or
chargers.
Power Connector
Insert the charger.

12
essentials
• New batteries or batteries stored for a long time may
take more time to charge.
• When charging your battery, keep it near room
temperature.
• When storing your battery, keep it uncharged in a cool,
dark, dry place, such as a refrigerator.
• Never expose batteries to temperatures below -10°C
(14°F) or above 45°C (113°F). Always take your phone
with you when you leave your vehicle.
• It is normal for batteries to gradually wear down and
require longer charging times. If you notice a change in
your battery life, it is probably time to purchase a new
battery.
Contact your local recycling center for proper battery
disposal.
Warning: Never dispose of batteries in a fire because they
may explode.
Before using your phone, read the battery safety information
in the “Safety and General Information”section included in
the gray-edged pages at the back of this guide.
turn it on & off
To turn on your phone, press and hold
P for 2 seconds. If prompted, enter
your 6-digit SIM card PIN code and/or
4-digit unlock code.

13
essentials
Caution: If you enter an incorrect PIN code 3 times in a row,
your SIM card is disabled and your phone displays
SIM Blocked .
Contact your service provider.
To turn off your phone, press and hold
P for 2 seconds.
make a call
Enter a phone number and press N to make a call.
To end the call, press
P ..
answer a call
When your phone rings and/or vibrates, press N to answer.
To end the call, press
P ..
When your phone rings and/or vibrates, press
N to answer.
To end the call, press
P .
your phone number
To see your number:
Press
M > Settings > Phone Status > My Numbers
To store or edit your name and number on your SIM
card, press the
VIEW key while displaying it. If you don't
know your phone number, contact your service provider.

14
main attractions
main attractions
multimedia messages
For more message features, see page 47.
send a multimedia message
A Multimedia Messaging Service (MMS) message
contains pages with text and media objects (including
photos, pictures, animations, or sounds). You can send the
multimedia message to other phones with MMS and to
email addresses.
Find it: Press M > Messages > Create > MMS or MMS Templates
Note: The MMS templates can’t be downloaded or
expanded. You can only use the default template.
1 Press keypad keys to enter text on the page (for details
about text entry, see page 25).
To insert a
picture, sound, or other object on the page,
press the
INSERT key or M > Insert . Select the file type and
the file.
To insert another slide in the message, enter text or
objects on the current page and press
M > Insert > Add
Slide
. You can enter more text and objects on the new
page.
2 When you finish the message, press the OK key.
3 Choose one or more people for Send To .

15
main attractions
To select a phonebook entry , highlight the entry and
press the
ADD key. Repeat to add other phonebook
entries.
To
enter a new number, highlight [One Time Entry] and press
the
SELECT key.
To
enter and store a new number, highlight [New Entry] and
press the
SELECT key.
4 When you finish entering numbers/addresses, press the
DONE key. Your phone displays the message fields.
To e n t e r a
subject for the message, highlight Subject and
press the
CHANGE key.
To request a
delivery receipt for the message, highlight
Receipt and press the CHANGE key. Then press the SELECT key.
5 To send the message, press SEND key.
To
cancel or save the message as a Draft , press M .
receive a multimedia message
When you receive a multimedia message or letter, your
phone plays an alert and displays
New Message with a
message indicator such as
r .
Press the
READ key to open the message.
If a multimedia message contains media objects:
• Photos, pictures, and animations display as you read
the message.
• A sound file plays when its slide bar displays.

16
main attractions
using instant messaging
Use instant messaging to exchange messages in real
time with other wireless phone users. The messages
you send display immediately on the other users' phones.
logging in to IM
Find it: Press M > Office Tools > IM > Log In
1 Press keypad keys to enter your IM ID
2 Press OK to submit your IM ID
3 Press keypad keys to enter your Password (case-sensitive)
4 Press OK to submit your Password
Tip: To log in automatically next time, scroll to Offline Settings
>
Auto Login after you submit your password.
5 Press S to scroll to your Contact List
6 Press SELECT to view the Contact List
Your Contact List is sorted by online status:
• Conversations display first. These are online IM users
having active conversations with you. Press
VIEW to
open your conversation with them.
• Online Contacts are logged in to IM. Press SEND IM to send
the person a message. A
_ (busy) indicator shows
that someone is busy and unable to respond.
• Offline Contacts are logged out of IM. You can press SEND IM
to send a message, in case the person has logged in
since you refreshed your list.

17
main attractions
Note: To refresh your Contact List , press M > Refresh List
while viewing the list.
Sending and Receiving Instant Messages
When you log in to IM, you can exchange messages with
other IM users.
1 Press S to scroll to a name on the Contact List
2 Press SEND IM to start a conversation with the person or
press
VIEW to open a conversation in progress
3 Press keypad keys to enter message text
4 Press SEND to send the message
Your phone displays the conversation history, where you can
see the text you sent and the person's replies as they arrive.
In the conversation display, you can:
• Press BACK to return to the Contact List , where you can
open more conversations
• Press P to return to the home screen, without
logging out of IM or closing the converstation
Note: Your phone displays d New IM if you receive a
message while on the home screen or in another
application.
• Press M > Contact Info to view the screen name and
online status of the person in this conversation
• Press M > Add Contact to add the screen name to your
Contact List
• Press M > End Conversation to end the conversation

18
main attractions
Note: If you log out of IM, you can still view the
conversation text by pressing
M > IM > Offline Convs.
from the home screen. Turning off your phone erases
the conversations.
setting your online status
When you log in to IM, your online status is visible to other
IM users. To set your online status:
1 Press S to scroll to My Status
2 Press SELECT to select the option
3 Press S to scroll to Available , Busy , or Invisible
4 Press SELECT to select the status setting
setting up IM
adding and removing contacts
To add a name, open your Contact List or a conversation and
press
M > Add Contact . If you are not in a conversation, enter
the new screen name and press
OK . IM returns an error if it
cannot verify the name on the server.
To remove a name from your
Contact List , highlight the name
and press
M > Delete Contact .
setting your busy message
If you are logged in to IM but not responding to new
messages, you can set the
_ (busy) indicator to display next
to your name in everyone else's
Contact List . From the IM Online
menu, select
My Status > Busy .
